城市企业社区用地更新潜力分析框架与应用

doi:10.11821/dlxb202110005

摘要/Abstract

摘要：

用地更新潜力分析是践行集约利用空间与城市更新、可持续性城市建设的重要基础,对认识城市土地利用、居住空间转型与治理意义重大,包括面积更新潜力与集约利用潜力。从社区土地面积、空间集约利用和两者关联性3个维度出发,采用企业社区兴趣点、兴趣面数据与建筑基底数据,以及景观格局指数、区位熵、重要性—绩效分析等方法,构建城市企业社区用地更新潜力分析框架,探究用地更新潜力特征,以西安市为案例进行验证。结果表明：① 企业社区总更新潜力933.56 hm²,平均面积1.63 hm²。小型企业社区（0.07~1.18 hm²）居多（62.87%）,面积更新潜力较小（19.42%）,相对集聚于内部市区,桃园路、土门、长乐中路等街道。面积大的数量少,分散在外围市区,洪庆、纺织城、鱼化寨等街道;② 绝大多数企业社区（93.01%）在立体空间上有集约利用潜力,整体呈东西两头稍高、内城中间低的略“U”型分异,以及南部向中北部地区近线性增加趋势;③ 集约利用潜力大的企业社区（A型）占20.63%,平均楼层高度3.31层,以土门、桃园路、纺织城、韩森寨等街道为主。集约利用潜力较大的企业社区（B型）占55.94%,平均5.24层,小集聚、大分散,长乐中路、纺织城、电子城、桃园路等街道分布多;④ 面积更新潜力与集约利用潜力大的高—高型企业社区占13.46%（77个）,主要在中心城区外围,纺织城、电子城、枣园、韩森寨等街道;面积更新潜力小集约利用潜力大的低—高型企业社区占30.07%（172个）,土门、纺织城、桃园路、电子城等街道为主;需要重点关注高—高型和低—高型企业社区更新改造与未来发展建设。应用过程与分析框架匹配,结果与现实较吻合,体现方法架构的逻辑性。研究有助于深化内城居住空间演替理论、新城市主义与城市更新理论。

关键词: 企业社区, 用地更新潜力, 集约利用潜力, 景观格局指数, 西安市

Abstract:

It is significant to analyze the renewal potential of urban land use in China. Enterprise communities (ECs) are a major type of gated and walled-off residential space. They were mostly built and managed by the state or collectively-owned enterprises to meet the housing and livelihood needs of workers during the planned economy period from the 1950s to the 1970s, and many are still occupied in urban China. As a result, ECs exist in most cities need renewal. In this paper, an analysis framework of ECs' renewal potential in the city is constructed to probe into the renewal potential and its spatial distribution characteristics. The framework consists of three dimensions: renewal potential of land area, potential for spatial intensive utilization and their relevance. Point of interest (POI) data, area of interest (AOI) data and data of floor area and methods such as index of landscape pattern, location quotient and importance-performance analysis are adopted. Further, Xi'an is chosen as a case city to verify applicability of the analytical framework. The results are shown as follows: (1) Total renewal potentials of the ECs in Xi'an are 933.56 hm², with an average area of 1.63 hm². Small-sized ECs (0.07-1.18 hm²) are the majority (62.87%), mainly concentrated in Taoyuanlu, Tumen and Changlezhonglu sub-districts near the downtown, but the potentials for area renewal are relatively minor (19.42%). ECs with large land area are scattered, distributed in Hongqing, Fangzhicheng, Yuhuazhai and other sub-districts away from the downtown. (2) The vast majority of ECs (93.01%) have the potentials of intensive use in three-dimensional space, showing a pattern of slightly U-shaped spatial differentiation with higher at both ends of the east and west and lower in the middle of the inner city, as well as a near-linear increasing trend from the south to the north-central region. (3) ECs of type B with great potentials for intensive use account for 55.94%, with an average of 5.24 floors and spatial characteristics of small aggregation and large dispersion, mainly distributed in the sub-districts of Changlezhonglu, Fangzhicheng, Dianzicheng and Taoyuanlu. The ECs of type A with the highest potentials cover 20.63%, with an average of 3.31 floors, mostly in Tumen, Taoyuanlu, Fangzhicheng, Hansenzhai and other sub-districts. (4) ECs of high-high type with great potentials for area renewal and intensive use come up to 13.46% (77), primarily distributed in Fangzhicheng, Dianzicheng, Zaoyuan, Hansenzhai and other sub-districts outside the central city. ECs of low-high type with small potentials for area renewal and high potentials for intensive use reach 30.07% (172), principally in Tumen, Fangzhicheng, Taoyuanlu, Dianzicheng and other sub-districts. Renewal and development construction of ECs including the high-high and low-high types need be more focused in the future.

Key words: enterprise community, renewal potential of land use, potential of intensive use, index of landscape pattern, Xi'an city

吴文恒, 史海金, 杨毕红, 许玉婷, 李研. 城市企业社区用地更新潜力分析框架与应用[J]. 地理学报, 2021, 76(10): 2391-2406.

WU Wenheng, SHI Haijin, YANG Bihong, XU Yuting, LI Yan. An analysis framework on enterprise communities' renewal potential of land use in the city and its application[J]. Acta Geographica Sinica, 2021, 76(10): 2391-2406.

图/表 13

图1

表1

景观格局指数

指数	指数含义	计算公式
斑块类型数量(NP)	某斑块类型中所有斑块数量(个)	$NP = n i$
斑块密度(PD)	单位面积上的斑块数量(块/km²)	$PD = n i A$
斑块类型面积(CA)	某一斑块类型面积总和(hm²)	$CA = ∑ j = 1 n a ij 110000$
斑块面积百分比(PLAND)	某一斑块类型面积与景观总面积之比(%)	$PLAND = P i = ∑ j = 1 n a ij A 100$
斑块平均面积(MPS)	某一斑块类型的平均斑块面积(hm²)	$MPS = ∑ j = 1 n x ij n i$
斑块大小标准偏差(AREA_SD)	反映数据集的离散程度	$AREA_SD = ∑ j = 1 n x ij - ∑ j = 1 n x ij n i 2 n i$
平均最小斑块距离(ENN_MN)	反映某斑块类型聚集程度(m)	$ENN_MN = h ij n$

表1

图2

图3

表2

图4

表3

图5

表4

图6

图7

图8

图9

参考文献 54

[1]	Han Gang, Yuan Jiadong, Wang Zhaobo. Spatial temporal evolution and correlation of urban compactness and urban efficiency in Jilin province. China Population, Resources and Environment, 2017, 27(1):20-27.
	[ 韩刚, 袁家冬, 王兆博. 吉林省城市紧凑度与城市效率的时空演变及相关性. 中国人口·资源与环境, 2017, 27(1):20-27.]
[2]	Artmann M, Kohler M, Meinel G, et al. How smart growth and green infrastructure can mutually support each other: A conceptual framework for compact and green cities. Ecological Indicators, 2019, 96(2):10-22. doi: 10.1016/j.ecolind.2017.07.001
[3]	Xiu Chunliang, Wei Ye, Wang Qi. Evaluation of urban resilience of Dalian city based on the perspective of 'Size-Density-Morphology'. Acta Geographica Sinica, 2018, 73(12):2315-2328. doi: 10.11821/dlxb201812004
	[ 修春亮, 魏冶, 王绮. 基于“规模—密度—形态”的大连市城市韧性评估. 地理学报, 2018, 73(12):2315-2328.]
[4]	Li X, Kleinhans R, van Ham M. Ambivalence in place attachment: The lived experiences of residents in Danwei communities facing demolition in Shenyang, China. Housing Studies, 2019, 34(6):997-1020. doi: 10.1080/02673037.2018.1509948
[5]	Zhang Jingxiang, Zhao Dan, Chen Hao. Termination of growth supremacism and transformation of China's urban planning. City Planning Review, 2013, 37(1):45-50, 55.
	[ 张京祥, 赵丹, 陈浩. 增长主义的终结与中国城市规划的转型. 城市规划, 2013, 37(1):45-50, 55.]
[6]	Shi Weiliang. Planning should realize the transformation from increment to stock and reduction planning. City Planning Review, 2014, 38(11):21-22.
	[ 施卫良. 规划编制要实现从增量到存量与减量规划的转型. 城市规划, 2014, 38(11):21-22.]
[7]	Zou Bing. The transformation from greenfield-based planning to redevelopment planning: Theoretical analysis and practical strategies. Urban Planning Forum, 2015(5):12-19.
	[ 邹兵. 增量规划向存量规划转型: 理论解析与实践应对. 城市规划学刊, 2015(5):12-19.]
[8]	Ou Xiong, Feng Changchun, Li Fang. Urban land-use capacity assessment: A case study of Tianhe district, Guangzhou city. Areal Research and Development, 2007, 26(5):100-104.
	[ 欧雄, 冯长春, 李方. 城镇土地利用潜力评价: 以广州市天河区为例. 地域研究与开发, 2007, 26(5):100-104.]
[9]	Feng Changchun, Cheng long. Research on evaluating land intensive use of the stock land in ancient city: Dongcheng district of Peking as an example. Urban Studies, 2010, 17(7):86-92. doi: 10.1080/00420988020080121
	[ 冯长春, 程龙. 老城区存量土地集约利用潜力评价: 以北京市东城区为例. 城市发展研究, 2010, 17(7):86-92.]
[10]	Wang Haiyun, Wang Hongmei, Zheng Minhui, et al. Potential analysis of three-old renovation based on the planning. Modern Urban Research, 2015, 30(3):78-85, 103.
	[ 王海云, 王红梅, 郑敏辉, 等. 基于规划的“三旧”改造潜力分析. 现代城市研究, 2015, 30(3):78-85, 103.]
[11]	Zhang Yuqing, Zhen Feng, Chang Enyu. Research on intensive utilization of urban land based on the evaluation of enterprises' comprehensive benefits: A case study of Zhangjiagang city. Human Geography, 2016, 31(6):95-101.
	[ 章雨晴, 甄峰, 常恩予. 基于企业综合效益评价的城市土地集约利用研究: 以张家港市为例. 人文地理, 2016, 31(6):95-101.]
[12]	Deng Yuanyuan, Chang Jiang, Yang Fan. Land potential evaluation in old industrial areas from the perspective of self-organization: A case study of Gulou district of Xuzhou City. Modern Urban Research, 2017, 32(4):59-67.
	[ 邓元媛, 常江, 杨帆. 自组织视角下老工业区土地利用潜力评价研究: 以徐州市鼓楼区为例. 现代城市研究, 2017, 32(4):59-67.]
[13]	Wang Yuqing, Song Ge. The benefits evaluation method and application of urban land use. Scientia Geographica Sinica, 2006, 26(6):743-748.
	[ 王雨晴, 宋戈. 城市土地利用综合效益评价与案例研究. 地理科学, 2006, 26(6):743-748.]
[14]	Wang Xiangdong, Liu Xiaoqian, Pei Tao, et al. Potential evaluation of urban land intensive use in Beijing-Tianjin-Hebei region based on measurement of technical efficiency. Acta Geographica Sinica, 2019, 74(9):1853-1865. doi: 10.11821/dlxb201909011
	[ 王向东, 刘小茜, 裴韬, 等. 基于技术效率测算的京津冀城市土地集约利用潜力评价. 地理学报, 2019, 74(9):1853-1865.]
[15]	Yang Donglang, An Xiaoli. Colligation evaluation of Xi'an urban-land intensive use. Economic Geography, 2007, 27(3):470-475.
	[ 杨东朗, 安晓丽. 西安市城市土地集约利用综合评价. 经济地理, 2007, 27(3):470-475.]
[16]	Yue Dapeng, Shi Jinsong, Jiao Yang. Analyzing and developing the connotation of the potentiality of intensive land use in development districts: An example of Xi'an city. Chinese Land Science, 2011, 25(11):37-42.
	[ 岳大鹏, 石劲松, 焦洋. 开发区土地集约利用潜力的内涵分析与拓展: 以西安市为例. 中国土地科学, 2011, 25(11):37-42.]
[17]	Mao Zidan, Chai Yanwei. The evolution and direction of community governance in China's Danwei community: A case study of Maofangnan community, Beijing. Urban Studies, 2013, 20(3):17-22.
	[ 毛子丹, 柴彦威. 中国城市单位社区治理模式转型路径及其未来趋势: 以北京市毛纺南社区为例. 城市发展研究, 2013, 20(3):17-22.]
[18]	Zhang C, Chai Y W. Un-gated and integrated Work Unit communities in post-socialist urban China: A case study from Beijing. Habitat International, 2014, 43:79-89. doi: 10.1016/j.habitatint.2014.01.011
[19]	Wu W H, Ding Z H, Huang K, et al. Spatial distribution of enterprise communities and its implications based on POI data: Case of Xi'an, China. Journal of Urban Planning and Development, 2021, 147(3):05021028. DOI: 10.1061/(ASCE)UP.1943-5444.0000707. doi: 10.1061/(ASCE)UP.1943-5444.0000707
[20]	Yang Q R, Ley D. Residential relocation and the remaking of socialist workers through state-facilitated urban redevelopment in Chengdu, China. Urban Studies, 2019, 56(12):2480-2498. doi: 10.1177/0042098018790724
[21]	Zhou M, Huang L, Shen Z. Community renewal strategy from the perspective of cultural planning: A case study on Caohuajie community in Chongqing. International Review for Spatial Planning and Sustainable Development, 2018, 6A(1):1-16. doi: 10.14246/irspsd.6A.1_1
[22]	Ren Shaobin. Decomposing of the Danwei and integrationof Danwei compound urban land space. Planners, 2002, 18(11):60-63.
	[ 任绍斌. 单位大院与城市用地空间整合的探讨. 规划师, 2002, 18(11):60-63.]
[23]	Chai Yanwei, Ta Na, Mao Zidan. Urban spatial reconstruction in cities in China: From the perspective of Danwei. Modern Urban Research, 2011, 26(3):5-9.
	[ 柴彦威, 塔娜, 毛子丹. 单位视角下的中国城市空间重构. 现代城市研究, 2011, 26(3):5-9.]
[24]	Zhang Yan, Chai Yanwei, Zhou Qianjun. The spatiality and spatial changes of Danwei compound in Chinese cities: Case study of Beijing No.2 Textile Factory. Urban Planning International, 2009, 24(5):20-27.
	[ 张艳, 柴彦威, 周千钧. 中国城市单位大院的空间性及其变化: 北京京棉二厂的案例. 国际城市规划, 2009, 24(5):20-27.]
[25]	Zhang Chun, Chai Yanwei, Chen Lingji. The evolution from Danwei community to citizen community: Case study of Tongrentang in Beijing. Urban Planning International, 2009, 24(5):33-36.
	[ 张纯, 柴彦威, 陈零极. 从单位社区到城市社区的演替: 北京同仁堂的案例. 国际城市规划, 2009, 24(5):33-36.]
[26]	Zhang Chun, Chai Yanwei. The spatial dynamic of Danwei community in transitional urban China: Spatial response and land use renewal. Urban Planning International, 2009, 24(5):28-32.
	[ 张纯, 柴彦威. 中国城市单位社区的空间演化: 空间形态与土地利用. 国际城市规划, 2009, 24(5):28-32.]
[27]	Xiao Zuopeng, Chai Yanwei. The property practice and physical space evolution in Danwei compound: A case in Beijing. Urban Development Studies, 2014, 21(4):105-112.
	[ 肖作鹏, 柴彦威. 产权实践视角下单位大院的物质空间演变: 以北京化工大院为例. 城市发展研究, 2014, 21(4):105-112.]
[28]	Chai Yanwei, Chen Lingji, Zhang Chun. Transformation of Danwei system: A angle of view on city changes in China. World Regional Studies, 2007, 16(4):60-69.
	[ 柴彦威, 陈零极, 张纯. 单位制度变迁: 透视中国城市转型的重要视角. 世界地理研究, 2007, 16(4):60-69.]
[29]	Wang Chenghui. Community micro-renewal mechanism directed by good governance. Planners, 2018, 34(2):5-10.
	[ 王承慧. 走向善治的社区微更新机制. 规划师, 2018, 34(2):5-10.]
[30]	Huang Yi, Wu Changfu. Exploration on China's community planning based on urban regeneration and urban governance: Practice of Jinyang new village community in Pudong new area of Shanghai. Urban Development Studies, 2020, 27(4):110-118.
	[ 黄怡, 吴长福. 基于城市更新与治理的我国社区规划探析: 以上海浦东新区金杨新村街道社区规划为例. 城市发展研究, 2020, 27(4):110-118.]
[31]	Wu Wenheng, et al. Study on Space Reproduction of Enterprise Community. Beijing: Science Press, 2020.
	[ 吴文恒, 等. 企业社区空间再生产研究. 北京: 科学出版社, 2020.]
[32]	Cheng Changxiu, Shi Peijun, Song Changqing, et al. Geographic big data: A new opportunity for geography complexity study. Acta Geographica Sinica, 2018, 73(8):1397-1406. doi: 10.11821/dlxb201808001
	[ 程昌秀, 史培军, 宋长青, 等. 地理大数据为地理复杂性研究提供新机遇. 地理学报, 2018, 73(8):1397-1406.]
[33]	Xu Wanting, Zhang Xiyu, Long Ying. A preliminary study on housing choice behavior in urban residential space based on mobile phone data and multi-source data: Taking communities within fifth ring road of Beijing as an example. Urban Development Studies, 2019, 26(10):48-56.
	[ 徐婉庭, 张希煜, 龙瀛. 基于手机信令等多源数据的城市居住空间选择行为初探: 以北京五环内小区为例. 城市发展研究, 2019, 26(10):48-56.]
[34]	Wu Qingxi. Urban community governance from the perspective of social media and big data. Journal of East China Normal University (Humanities and Social Sciences), 2017, 49(6):43-50, 170.
	[ 吴青熹. 社会化媒体与大数据视野下的城市社区治理. 华东师范大学学报(哲学社会科学版), 2017, 49(6):43-50, 170.]
[35]	Zhang Su, Chang Fang, Li Jiuquan, et al. Preliminary study of geo-informatic Tupu method for urban community quality of life space based on big data: A case study of Xi'an. Human Geography, 2016, 31(3):52-59.
	[ 张苏, 常芳, 李九全, 等. 大数据支持下城市社区生活空间质量的可获性图谱法初探: 以西安为例. 人文地理, 2016, 31(3):52-59.]
[36]	Wu Wenheng, Huang Kun, Ding Zhuhui, et al. Distribution pattern and formation mechanism of enterprise community in Xi'an, China. Geographical Research, 2019, 38(12):3038-3054. doi: 10.11821/dlyj020180962
	[ 吴文恒, 黄坤, 丁竹慧, 等. 西安市企业社区分布格局与形成机制. 地理研究, 2019, 38(12):3038-3054.]
[37]	Fu Bojie, Chen Liding, Ma Keming, et al. Principle and Application of Landscape Ecology. Beijing: Science Press, 2011.
	[ 傅伯杰, 陈利顶, 马克明, 等. 景观生态学原理及应用. 北京: 科学出版社, 2011.]
[38]	Chen Liding, Li Xiuzhen, Fu Bojie, et al. Development history and future research priorities of landscape ecology in China. Acta Ecologica Sinica, 2014, 34(12):3129-3141.
	[ 陈利顶, 李秀珍, 傅伯杰, 等. 中国景观生态学发展历程与未来研究重点. 生态学报, 2014, 34(12):3129-3141.]
[39]	Li Guangdong, Qi Wei. Impacts of construction land expansion on landscape pattern evolution in China. Acta Geographica Sinica, 2019, 74(12):2572-2591. doi: 10.11821/dlxb201912011
	[ 李广东, 戚伟. 中国建设用地扩张对景观格局演化的影响. 地理学报, 2019, 74(12):2572-2591.]
[40]	Turner M G. Spatial and temporal analysis of landscape patterns. Landscape Ecology, 1990, 4(1):21-30. doi: 10.1007/BF02573948
[41]	Zhao Ruifeng, Chen Yaning, Li Weihong, et al. Land cover change and landscape pattern in the mainstream of the Tarim River. Acta Geographica Sinica, 2009, 64(1):95-106.
	[ 赵锐锋, 陈亚宁, 李卫红, 等. 塔里木河干流区土地覆被变化与景观格局分析. 地理学报, 2009, 64(1):95-106.]
[42]	Zang Yuzhu, Liu Yansui, Yang Yuanyuan. Land use pattern change and its topographic gradient effect in the mountainous areas: A case study of Jinggangshan city. Journal of Natural Resources, 2019, 34(7):1391-1404. doi: 10.31497/zrzyxb.20190704
	[ 臧玉珠, 刘彦随, 杨园园. 山区县域土地利用格局变化及其地形梯度效应: 以井冈山市为例. 自然资源学报, 2019, 34(7):1391-1404.]
[43]	Jiang Yiyi, Wang Yanglin, Cheng Shengkui. Preliminary research on patterns of the tourism landscape ecosystem: Concept and spatial units system. Acta Ecologica Sinica, 2009, 29(2):910-915.
	[ 蒋依依, 王仰麟, 成升魁. 旅游景观生态系统格局: 概念与空间单元. 生态学报, 2009, 29(2):910-915.]
[44]	Wang Zheng, Li Gangqiang, Xie Shuling, et al. Industrial specialization of new economic industry in China. Acta Geographica Sinica, 2007, 62(8):831-839.
	[ 王铮, 李刚强, 谢书玲, 等. 中国新经济产业区域专业化水平分析. 地理学报, 2007, 62(8):831-839.]
[45]	Yuan Yuan, Ding Kaili, Cao Xinyu, et al. A review of neighborhood satisfaction. Urban Development Studies, 2018, 25(10):105-111.
	[ 袁媛, 丁凯丽, 曹新宇, 等. 社区满意度及影响因素研究方法综述. 城市发展研究, 2018, 25(10):105-111.]
[46]	Wei Yan, Yang Haozhong. A historical study of urban industrial patterns in modern Xi'an. Urban Planning Forum, 2015(1):106-112.
	[ 魏琰, 杨豪中. 近现代西安城市工业格局演变的历史研究(1869—1978). 城市规划学刊, 2015(1):106-112.]
[47]	Shen Weijun, Wu Jianguo, Lin Yongbiao, et al. Effects of changing grain size on landscape pattern analysis. Acta Ecologica Sinica, 2003, 23(12):2506-2519.
	[ 申卫军, 邬建国, 林永标, 等. 空间粒度变化对景观格局分析的影响. 生态学报, 2003, 23(12):2506-2519.]
[48]	Bjorklund E M. The danwei: Socio-spatial characteristics of work units in China's urban society. Economic Geography, 1986, 62(1):19-29. doi: 10.2307/143493
[49]	Bray D. Social space and governance in urban China: The Danwei system from origins to reform. Stanford: Stanford University Press, 2005.
[50]	Long Ying, Han Haoying, Mao Qizhi. Establishing urban growth boundaries using constrained CA. Acta Geographica Sinica, 2009, 64(8):999-1008.
	[ 龙瀛, 韩昊英, 毛其智. 利用约束性CA制定城市增长边界. 地理学报, 2009, 64(8):999-1008.]
[51]	Xu Zening, Gao Xiaolu. A novel method for identifying the boundary of urban built-up areas with POI data. Acta Geographica Sinica. 2016, 71(6):928-939. doi: 10.11821/dlxb201606003
	[ 许泽宁, 高晓路. 基于电子地图兴趣点的城市建成区边界识别方法. 地理学报, 2016, 71(6):928-939.]
[52]	Ma L J C. Urban transformation in China, 1949-2000: A review and research agenda. Environment and Planning A: Economy and Space, 2002, 34(9):1545-1569. doi: 10.1068/a34192
[53]	Liu Xiao, Liu Zhiguo, Wang Lidan, et al. Shenyang old city stock land planning in the context of supply-side structural reform. Planners, 2017, 33(6):19-25.
	[ 刘笑, 刘治国, 王丽丹, 等. 供给侧结构性改革背景下沈阳旧城存量土地规划实践. 规划师, 2017, 33(6):19-25.]
[54]	La Rosa D, Privitera R, Barbarossa L, et al. Assessing spatial benefits of urban regeneration programs in a highly vulnerable urban context: A case study in Catania, Italy. Landscape and Urban Planning, 2017, 157:180-192. doi: 10.1016/j.landurbplan.2016.05.031

类型/面积范围(hm²)	0.07~1.18	1.18~2.77	2.77~5.17	5.17~8.38	8.38~15.37
CA (hm²)	181.32	214.00	231.14	184.55	122.55
PLAND (%)	19.42	22.92	24.76	19.77	13.13
NP (个)	359	113	61	27	11
PD (个/km²)	0.43	0.14	0.07	0.03	0.01
MPS (hm²)	0.50	1.89	3.78	6.83	11.14
AREA_SD	0.30	0.45	0.68	0.88	1.88
ENN_MN (m)	207.56	471.12	531.53	690.43	2919.13

行政区	街道	0.07~1.18			1.18~2.77			2.77~5.17		5.17~8.38		8.38~15.37
行政区	街道	数量(个)	面积(hm²)		数量(个)	面积(hm²)		数量(个)	面积(hm²)	数量(个)	面积(hm²)	数量(个)	面积(hm²)
莲湖区	桃园路	25	10.41		10	20.58		6	23.12	1	6.91	0	0
	土门	19	9.52		10	18.17		1	2.98	1	5.96	0	0
	红庙坡	14	8.38		7	12.11		1	3.47	0	0	0	0
	枣园	4	2.44		5	9.47		4	18.73	3	19.12	0	0
新城区	胡家庙	17	10.81		4	7.46		1	3.20	0	0	0	0
	长乐中路	20	8.26		9	17.9		11	41.27	3	20.58	0	0
	韩森寨	11	6.74		4	6.92		7	29.38	3	19.63	0	0
	太华路	8	4.35		6	12.16		1	3.47	0	0	0	0
碑林区	太乙路	18	12.30		2	3.02		2	7.20	0	0	1	9.56
碑林区	张家村	18	7.25	4		10.19		3	11.06	0	0	0	0
灞桥区	纺织城	16	7.02	8		16.02		1	4.93	6	43	2	21.02
	灞桥	1	0.82	1		1.77		0	0	1	8.30	0	0
	洪庆	1	0.21	0		0		0	0	1	8.01	3	35.39
雁塔区	电子城	14	7.42	7		13.85		6	21.85	3	20.12	0	0
	等驾坡	5	2.60	2		3.28	0		0	0	0	1	10.66
	鱼化寨	4	2.25	2		2.95	2		7.11	0	0	1	15.37
未央区	张家堡	7	3.42	1		1.42	0		0	0	0	1	9.91
	三桥	5	2.96	6		14.13	2		7.78	0	0	0	0
	辛家庙	2	1.17	0		0	0		0	2	13.77	1	10.12
	徐家湾	1	0.36	2		3.17	0		0	0	0	1	10.48
