亚热带山地丘陵区植被NPP时空变化及其与气候因子的关系----以湖南省为例

doi:10.11821/dlxb201601003

地理学报 ›› 2016, Vol. 71 ›› Issue (1): 35-48.doi: 10.11821/dlxb201601003

亚热带山地丘陵区植被NPP时空变化及其与气候因子的关系----以湖南省为例

陈晓玲^1,²(), 曾永年^1,²

1. 中南大学地球科学与信息物理学院,长沙 410083
2. 中南大学空间信息技术与可持续发展研究中心,长沙 410083

收稿日期:2015-10-09 修回日期:2015-12-15 出版日期:2016-01-31 发布日期:2016-01-15
作者简介:
作者简介:陈晓玲(1991-), 女, 福建漳州人, 硕士, 主要从事遥感与地理信息系统及其环境变化研究.E-mail: cxlgis@126.com
基金资助:
国家自然科学基金项目(41171326, 41201386);中南大学中央高校基本科研业务费专项资金(2015zzts254)

Spatial and temporal variability of the net primary production (NPP) and its relationship with climate factors in subtropical mountainous and hilly regions of China: A case study in Hunan province

CHEN Xiaoling^1,²(), ZENG Yongnian^1,²

1. School of Geosciences and Info-physics, Central South University, Changsha 410083, China
2. Center for Geomatics and Regional Sustainable Development Research, Central South University, Changsha 410083, China

Received:2015-10-09 Revised:2015-12-15 Published:2016-01-31 Online:2016-01-15
Supported by:
National Natural Science Foundation of China, No.41171326, No.41201386;The Fundamental ResearchFunds for the Central Universities of Central South University, No.2015zzts254

摘要/Abstract

摘要：

以湖南省为研究区,采用250 m×250 m空间分辨率的MODIS-NDVI数据,结合相应时间段的气象数据,使用改进的CASA模型,模拟并分析该区域2000-2013年间的植被NPP的时空变化特征,并借助统计分析方法对不同土地覆盖类型中植被NPP的变化趋势及其显著性,NPP与气候因子的相关性进行量化分析.结果表明:① 该区域的净初级生产量年际变化特征明显,年净初级生产量分布在41.62~125.40 Tg C/yr之间,平均值为86.34 Tg C/yr,总体来看,14年间湖南省植被净初级生产量呈波动减少趋势,年际减少趋势为2.70 Tg C/yr;② NPP空间分布差异较大,基本特点是西高东低,南高北低,从西南向东北呈逐渐递减趋势,其中,各植被分区的NPP有明显差异;③ 2000-2013年,湖南省植被NPP呈极显著增加(slope >0,p < 0.01),显著增加(slope > 0,0.01 ≤ p < 0.05),无明显变化(p ≥ 0.05),极显著减少(slope < 0,p < 0.01)和显著减少(slope < 0,0.01 ≤ p < 0.05)的区域分别占总面积的比例为5.40%,2.02%,61.64%,16.79%和14.15%.植被NPP变化趋势总体上显示为减少的趋势,而不同土地覆盖类型的植被NPP变化趋势及显著性存在较大差异,其中草地的NPP变化趋势最为显著,接着依次是森林,其他土地,建设用地和农田;④ 分析不同土地覆盖类型的植被NPP对气候因子的响应,发现NPP与降水量之间的相关关系强于其与温度的相关关系.

关键词: NPP, 气候, 亚热带山地丘陵, 湖南省

Abstract:

In this study, we selected Hunan province as the study area. The vegetation NPP and its changes from 2000 to 2013 were calculated using improved Carnegie-Ames-Stanford Approach (CASA) model with MODIS-NDVI data at a 250 m×250 m spatial resolution and meteorological data. Furthermore, we quantitatively analyzed the correlation between NPP and climate for various land-cover types so as to provide reliable information for local environment and sustainable development. The results indicate that: (1) The annual amount of NPP decreased from 41.62 Tg C/yr in 2000 to 125.40 Tg/yr in 2013, with an average being about 86.34 Tg C/yr. In general, the total amount of NPP has decreased obviously since 2000, with an annual rate of about 2.70 Tg C/yr. (2) The annual NPP from 2000 to 2013 had significant spatial differences throughout the study area, decreasing from the southwest to the northeast. There were obvious differences over various vegetation divisions. (3) According to the changes rate of NPP from 2000 to 2013, the study area could be divided into five regions, namely, extremely remarkable increase rate (slope > 0, p < 0.01), remarkable increase rate (slope > 0, 0.01 ≤ p < 0.05), unnoticeable rate (p ≥ 0.05), extremely remarkable decrease rate (slope < 0, p < 0.01) and remarkable decrease rate (slope < 0, 0.01 ≤ p < 0.05), which accounted for 5.40%, 2.02%, 61.64%, 16.79% and 14.15%, respectively. In general, NPP decreased from 2000 to 2013 over different land-cover types, among which, the most significant change took place in grassland and forestland, followed by other types of land, construction land and farmland. (4) The spatial distribution of NPP had higher correlation with precipitation than with temperature.

Key words: NPP, climate, mountainous and hilly regions of subtropical China, Hunan province

陈晓玲, 曾永年. 亚热带山地丘陵区植被NPP时空变化及其与气候因子的关系----以湖南省为例[J]. 地理学报, 2016, 71(1): 35-48.

CHEN Xiaoling,ZENG Yongnian. Spatial and temporal variability of the net primary production (NPP) and its relationship with climate factors in subtropical mountainous and hilly regions of China: A case study in Hunan province[J]. Acta Geographica Sinica, 2016, 71(1): 35-48.

图/表 11

图1

表1

图2

图3

图4

图5

图6

图7

图8

图9

表2

参考文献 35

[1]	Field C B, Randerson J T, Malmstrom C M.Global netprimary production-combining ecology and remote sensing. Remote Sensing of Environment, 1995, 51(1): 74-88.
[2]	Li Jia, Cui Yaoping, Liu Jiyuan, et al.Estimation and analysis of net primary productivity by integrating MODIS remote sensing data with a light use efficiency model. Ecological Modelling, 2013, 252: 3-10.
[3]	Xie Baoni, Qin Zhanfei, Wang Yang, et al.Spatial and temporal variation in terrestrial net primary productivity on Chinese Loess Plateau and its influential factors. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2014, 30(11): 244-253.
	[谢宝妮, 秦占飞, 王洋, 等. 黄土高原植被净初级生产力时空变化及其影响因素. 农业工程学报, 2014, 30(11): 244-253.]
[4]	Fang Jingyun. Global Ecology.Beijing: Higher Education Press, 2000.
	[方精云. 全球生态学. 北京: 高等教育出版社, 2000.]
[5]	Zhu Wenquan.Estimation of net primary productivity of Chinese terrestrial vegetation based on remote sensing and its relationship with global climate change [D]. Beijing: Beijing Normal University, 2005.
	[朱文泉. 中国陆地生态系统植被净初级生产力遥感估算及其与气候变化关系的研究[D]. 北京: 北京师范大学, 2005.]
[6]	Wang Zongming, Liang Yinli.Progress in vegetation net primary productivity model research. Journal of Northwest Forestry University, 2002, 17(2): 22-25.
	[王宗明, 梁银丽. 植被净第一性生产力模型研究进展. 西北林学院学报, 2002, 17(2): 22-25.]
[7]	McGuire A D, Melillo J M, Kicklighter D W, et al. Equilibrium responses of soil carbon to climate change: Empirical and process-based estimates. J. Biogeogr., 1995, 22(4/5): 785-796.
[8]	Potter C S, Randerson J T, Field C B, et al.Terrestrial ecosystem production: A process model based on global satellite and surface data. Global Biogeochemical Cycles, 1993, 7(4): 811-841.
[9]	Los S O.Linkages between global vegetation and climate: An analysis based on NOAA Advanced Very High Resolution Radiometer Data. National Aeronautics and Space Administration (NASA), 1998.
[10]	Los S O, Justice C O, Tucker C J.A global 1° by 1° NDVI dataset for climate studies derived from the GIMMS continental NDVI data. International Journal of Remote Sensing. 1994, 15(17): 3493-3518.
[11]	Zhu Wenquan, Pan Yaozhong, Long Zhonghua, et al.Estimate net primary productivity of terrestrial vegetation based on GIS and RS. Journal of Remote Sensing, 2005, 9(3): 300-307.
	[朱文泉, 潘耀忠, 龙中华, 等. 基于GIS和RS的区域陆地植被NPP估算. 遥感学报, 2005, 9(3): 300-307.]
[12]	Zhang Yushun, Jia Wenxiong.Spatial- temporal variations of net primary productivity of Qilian Mountains vegetation based on CASA model. Acta Boanica Boreali-Occidentalia Sinica, 2014, 34(10): 2085-2091.
	[张禹舜, 贾文雄. 基于CASA模型研究祁连山地区植被净初级生产力的时空变化. 西北植物学报, 2014, 34(10): 2085-2091.]
[13]	Zhang Fuping, Feng Qi, Li Xupu, et al.Remotely-sensed estimation of NPP and its spatial-temporal characteristics in the Heihe River Basin. Journal of Desert Research, 2014, 34(6): 1657-1664.
	[张福平, 冯起, 李旭谱, 等. 黑河流域NPP遥感估算及其时空变化特征. 中国沙漠, 2014, 34(6): 1657-1664.]
[14]	Liu Chunyu, Dong Xiaofeng, Liu Yingying.Changes of NPP and their relationship to climate factors based on the transformation of different scales in Gansu, China. Catena, 2015, 125: 19-199.
[15]	Mao Dehua, Wang Zongming, Han Jixing, et al.Spatio temporal pattern of net primary productivity and its driven factors in Northeast China in 1982-2010. Scientia Geographica Sinica, 2012, 32(9): 1106-1111.
	[毛德华, 王宗明, 韩佶兴, 等. 1982-2010年中国东北地区植被NPP时空格局及驱动因子分析. 地理科学, 2012, 32(9): 1106-1111.]
[16]	Zhang Yili, Qi Wei, Zhou Caiping, et al.Spatial and temporal variability in the net primary production (NPP) of alpine grassland on Tibetan Plateau from 1982 to 2009. Acta Geographica Sinica, 2013, 68(9): 1197-1210.
	[张镱锂, 祁威, 周才平, 等. 青藏高原高寒草地净初级生产力(NPP)时空分异. 地理学报, 2013, 68(9): 1197-1210.]
[17]	Sun Li.Drought monitoring and early warning in mountain and hilly area [D]. Beijing: China Agricultural University. [孙丽. 山地丘陵区的旱灾监测预警技术研究[D]. 北京: 中国农业大学, 2014.]
[18]	Zhou Binggen, Yao Min.Characteristics and problems in course of development of the mountains and hills in the subtropic zone in China. Bulletin of Soil and Water Conservation, 1994, 14(6): 5-9.
	[周秉根, 姚敏. 我国亚热带山地丘陵区特征及开发中的有关问题. 水土保持通报, 1994, 14(6): 5-9.]
[19]	Dai Erfu, Li Shuangyuan, Wu Zhuo.Spatial pattern of net primary productivity and its relationship with climatic factors in hilly red soil region of southern China. Geographical Research, 2015, 34(7): 1222-1234.
	[戴尔阜, 李双元, 吴卓. 中国南方红壤丘陵区植被净初级生产力空间分布及其与气候因子的关系. 地理研究, 2015, 34(7): 1222-1234.]
[20]	Zhang Jun.NPP and carbon storage in subtropical forest, eastern China [D]. Hangzhou: Zhejiang University, 2008.
	[张骏. 中国中亚热带东部森林生态系统生产力和碳储量研究[D]. 杭州: 浙江大学, 2008.]
[21]	Peng Shaolin, Zhang Zhuping.Studies on the biomass, primary productivity and energy use efficiency of the mixed forest community in Mt. Dinghushan, Guangdong. Acta Ecologica Sinica, 1994, 14(3): 300-305.
	[彭少麟, 张祝平. 鼎湖山针阔叶混交林的第一性生产力研究. 生态学报, 1994, 14(3): 300-305.]
[22]	Chen Zhanghe, Wang Bosun, Zhang Hongda.Growth of the trees and saplings in the lower subtropical evergreen broad-leaved forest in Heishiding, Guangdong province. Acta Phytoecologica Sinica, 1999, 23(5): 441-460.
	[陈章和, 王伯荪, 张宏达. 广东黑石顶南亚热带常绿阔叶林树木生长研究. 植物生态学报, 1999, 23(5): 441-460.]
[23]	Tang Xuli, Zhou Guoyi, Wen Dazhi.Distribution of carbon storage in a lower subtropical monsoon evergreen broad-leaved forest in Dinghushan Nature Reserve. Acta Ecologica Sinica, 2003, 23(1): 90-97.
	[唐旭利, 周国逸, 温达致, 等. 鼎湖山南亚热带季风常绿阔叶林C贮量分布. 生态学报, 2003, 23(1): 90-97.]
[24]	Zhang Shengli, Xiang Wenhua, Deng Xiangwen, et al.Carbon storage in 2009 and potential carbon sequestration in future of Cunninghamia lanceolata forests in Hunan province, China. Journal of Central South University of Forestry & Technology, 2014, 36(6): 94-111.
	[张胜利, 项文化, 邓湘雯, 等. 湖南省2009年杉木林碳贮存量及未来固碳潜力分析. 中南林业科技大学学报, 2014, 36(6): 94-111.]
[25]	Huang Xiangnan, Tong Jie.Dynamics of carbon storage of Chinese fir in Hunan Province. Journal of Central South University of Forestry & Technology, 2011, 31(12): 80-85.
	[黄湘南, 童洁. 湖南省杉木林植被C贮量动态特征. 中南林业科技大学学报, 2011, 31(12): 80-85.]
[26]	Li Bin, Fang Xi, Xiang Wenhua, et al.Carbon storage, carbon density, and carbon sequestration potential of Cunninghamia lanceolata plantations in Hunan Province. Scientia Silvae Sinica, 2013, 49(3): 25-32.
	[李斌, 方晰, 项文化, 等. 湖南省杉木林植被碳贮量,碳密度及碳吸存潜力. 林业科学, 2013, 49(3): 25-32.]
[27]	Jiao Xiumei, Xiang Wenhua, Tian Dalun.Carbon storage of forest vegetation and its geographical distribution in Hunan Province. Journal of Central South Forestry University, 2005, 25(1): 4-8.
	[焦秀梅, 项文化, 田大伦. 湖南省森林植被碳贮量及地理分布规律. 中南林学院学报, 2005, 25(1): 4-8.]
[28]	Liu Qiongfeng, Li Mingde, Duan Jiannan, et al.The spatio-temporal variation of benefit of cultivated land use based on GIS technology in Hunan province. Economic Geography, 2013, 33(9): 142-147.
	[刘琼峰, 李明德, 段建南, 等. 基于GIS的湖南省耕地利用效益时空变异研究. 经济地理, 2013, 33(9): 142-14.]
[29]	Zhu Lei, Huang Jingfeng.Comparison of spatial interpolation method for precipitation of mountain areas in county scale. Transactions of the CSA E, 2007, 23(7): 80-85.
	[朱蕾, 黄敬峰. 山区县域尺度降水量空间插值方法比较. 农业工程学报, 2007, 23(7): 80-85.]
[30]
[31]	Fang Jingyun, Liu Guohua.Biomass and net production of forest vegetation in China. Acta Prataculturae Sinica, 1996, 16(5): 497-508.
	[方精云, 刘国华. 我国森林植被的生物量和净生产量. 生态学报, 1996, 16(5): 497-508.]
[32]	Johnson W C, Sharpe D M.The ratio of total to merchantable forest biomass and its application to the global carbon budget. Canadian Journal of Forest Research, 1983, 13: 372-383.
[33]	Agricultural Regionalization in Hunan Province. Changsha: Hunan Science & Technology Press, 1986.
	[湖南省农业区划委员会. 湖南省农业区划. 长沙: 湖南省科学技术出版社, 1986.]
[34]	Yi Min.Investigation and assessment of ecological environment in Hunan Province [D]. Xiangtan: Xiangtan University, 2014.
	[易敏. 湖南省生态环境遥感调查与评估[D]. 湘潭: 湘潭大学, 2014.]
[35]	Gao Y H, Zhou X, Wang Q, et al.Vegetation net primary productivity and its response to climate change during 2001-2008 in the Tibetan Plateau. Sci. Total Environ., 2013, 444(1): 356-362.

一级类型	类型代码	二级类型	NDVI_max	NDVI_min	ε_max
森林	11	常绿针叶林	0.737	0.575	0.39
	12	常绿阔叶林	0.732	0.530	0.99
	13	落叶针叶林	0.739	0.579	0.49
	14	落叶阔叶林	0.730	0.558	0.69
	15	针阔混交林	0.740	0.594	0.48
	16	灌丛	0.749	0.622	0.43
草地	21	草甸草地	0.561	0.299	0.54
	22	典型草地	0.715	0.509	0.54
	26	灌丛草地	0.739	0.612	0.54
农田	31	水田	0.650	0.499	0.54
	32	水浇地	0.615	0.473	0.54
	33	旱地	0.675	0.497	0.54
建设用地	41	城镇建设用地	0.550	0.273	0.54
建设用地	42	农村建设用地	0.630	0.431	0.54
其他土地	51	沼泽	0.633	0.420	0.54
	53	内陆水体	--	--	--
	54	河湖滩地	0.601	0.291	0.54
	61	裸岩	--	--	--
	62	裸地	--	--	--

面积百分比(%)
一级类型	气候因子	平均相关系数	显著正相关	不显著正相关	显著负相关	不显著负相关
森林	降水	0.056	5.27	63.10	3.67	27.96
	*降水	0.044	6.09	57.60	5.09	31.23
	气温	-0.015	7.22	38.77	7.35	46.67
	*气温	0.005	7.36	42.26	7.59	42.79
草地	降水	0.041	7.60	61.05	5.00	26.34
	*降水	0.033	6.77	55.52	5.65	32.07
	气温	0.004	7.56	42.84	7.23	42.37
	*气温	0.013	7.23	44.72	7.17	40.88
农田	降水	0.074	4.88	64.78	3.70	26.70
	*降水	0.052	7.36	58.02	5.61	29.01
	气温	-0.057	6.73	31.91	7.07	54.28
	*气温	-0.028	7.11	35.66	7.58	49.66
建设用地	降水	0.052	4.25	58.13	4.05	33.57
	*降水	0.041	5.73	59.18	4.98	30.11
	气温	-0.028	7.22	40.31	7.22	45.25
	*气温	-0.008	7.93	48.97	7.74	35.36
其他土地	降水	0.106	4.40	65.65	4.20	25.75
	*降水	0.137	4.37	71.75	4.02	19.87
	气温	0.031	6.92	46.17	6.70	40.21
	*气温	0.090	7.54	57.79	6.85	27.82
