高速铁路对中国城市空间相互作用强度的影响

doi:10.11821/dlxb201412009

摘要/Abstract

摘要：

高速铁路作为一种新型的交通方式,其快速发展将会带来交通运输史上一次重大的飞跃,且其对区域空间结构、人口流动、经济联系和土地利用等的影响也越来越成为人们关注的焦点。在中国区域经济一体化进程不断加快的背景下,研究高速铁路对城市空间相互作用强度的影响,对加强区域间经济联系、促进区域经济发展和地域空间组织模式的重构具有重要意义。本文基于GIS网络分析工具,构建时间成本矩阵,研究中国333个地级行政单元和4个直辖市对外经济联系总量和城市对间经济联系强度的空间分布特征,构建无高铁、高铁现状和规划高铁三种情景,并对三种情景进行模拟与探讨。结果显示：① 城市空间相互作用呈现出明显的地带性和“廊道效应”,反映了高速交通在重塑区域空间结构中的作用;② 高速铁路建设提升了城市对外经济联系强度总量,且逐渐从追求“效率”转向“公平性”;③ 高速铁路建设缩小了全国城市对外经济联系总量的差异,但却扩大了城市对间经济联系强度的差异;④ 三大城市群成为城市对外经济总量绝对获益量最大的地区,而其毗邻的中小城市成为提升速率最大的城市。

关键词: 高速铁路, 网络分析, 经济联系强度, 空间差异, 中国

Abstract:

As a new mode of transportation, the rapid development of high-speed rail (HSR) will bring a leap in the history of transportation and have a comprehensive impact on the regional structure, population mobility, geographical division of labors, regional linkages, land use, and so on. Therefore, it is significantly important to study the impacts of HSR on regional spatial interactions, especially under the background of regional economic integration. The paper researches the impact of high speed rail on the reconstruction of spatial economic linkages. Based on the GIS network analysis tools, this paper first calculates the time cost matrix of 333 prefecture-level administrative units and four municipalities, and then uses the gravity model to calculate the interurban economic linkages, and lastly analyzes the distribution of the total economic linkage and the economic linkages between any two cities. In order to analyze the impact of HSR on regional spatial interaction, this paper resumes three scenarios: the current transport network in 2012 without the HSR network (scenario 1), the current transport network in 2012 (scenario 3), and the planning HSR network in 2020 (scenario 3) based on the current transport network, to calculate the time cost matrix of 337 cities. Results indicate that: (1) Cities in the east have the highest economic linkages, and cities with the highest increase of economic linkages are located along the HSR lines, which will lead to regional restructuring; (2) The development of HSR lines will improve the economic linkages between cities, and the increasing rate during the first period (comparing scenario 2 with scenario 1) is much higher than that during the second period (comparing scenario 3 with scenario 2); (3) From different perspectives and regional scales, the development of HSR has different impacts on spatial difference; (4) It is possible for cities in a long distance to have high economic linkages with the construction of HSR lines, which could also change the linkage directions.

Key words: high-speed rail, network analysis, economic linkage, spatial disparity, China

王姣娥, 焦敬娟, 金凤君. 高速铁路对中国城市空间相互作用强度的影响[J]. 地理学报, 2014, 69(12): 1833-1846.

Jiao'e WANG, Jingjuan JIAO, Fengjun JIN. Spatial effects of high-speed rails on interurban economic linkages in China[J]. Acta Geographica Sinica, 2014, 69(12): 1833-1846.

图/表 12

表1

表2

图1

表3

图2

图3

图4

图5

图6

图7

图8

图9

参考文献 33

[1]	Li Xiaojian, Li Guoping, Zeng Gang et al. Economic Geography. Beijing: Higher Education Press, 1999.
	[李小建, 李国平, 曾刚等. 经济地理学. 北京: 高等教育出版社, 1999.]
[2]	Yang Wuyang, Liang Jinshe. Advanced Economic Geography.Perking University Press, 1997.
	[杨吾扬, 梁进社. 高等经济地理学. 北京: 北京大学出版社, 1997.]
[3]	Jin Fengjun, Wang Jiao'e. Raiway network expansion and spatial accessibility analysis in China: 1906-2000. Acta Geographica Sinica, 2004, 52(2): 293-302.
	[金凤君, 王姣娥. 20世纪中国铁路网扩展及其空间通达性. 地理学报, 2004, 52(2): 293-302.]
[4]	Wang Jiaoe, Jin Fengjun.Railway network organization and spatial service system optimization in China. Acta Geographica Sinica, 2005, 60(3): 371-380.
	[王姣娥, 金凤君. 中国铁路客运网络组织与空间服务系统优化. 地理学报, 2005, 60(3): 371-380.]
[5]	Wang Jiao'e, Mo Huihui, Jin Fengjun. Spatial structural characteristics of Chinese aviation network based on complex network theory. Acta Geographica Sinica, 2009, 64(8): 900-910.
	[王姣娥, 莫辉辉, 金凤君. 中国航空网络空间结构的复杂性. 地理学报, 2009, 64(8): 900-910.]
[6]	Zhou Yixing, Hu Zhiyong.Looking into the network structure of Chinese urban system from the perspective of air transportation. Geographical Research, 2002, 21(3): 276-286.
	[周一星, 胡智勇. 从航空运输看中国城市体系的空间网络结构. 地理研究, 2002, 21(3): 276-286.]
[7]	Wang Chengjin.Regional impaction and evolution of express way networks in China. Progress in Geography, 2006, 25(6): 126-137.
	[王成金. 中国高速公路网的发展演化及区域效应研究. 地理科学进展, 2006, 25(6): 126-137.]
[8]	Vickerman R W.The regional impacts of trans-European networks. The Annals of Regional Science, 1995, 29: 237-254.
[9]	Vickerman R W.Accessibility and economic development in Europe. Regional Studies, 1999, 33(1): 1-15.
[10]	Vikerman R W.Accessibility, attention, and potential: A review of some concepts and their use in determining mobility. Environment and Planning A, 1974, 6: 675-691.
[11]	Gutiérrez J, Condeço-Melhorado A, Martín J C.Using accessibility indicators and GIS to assess spatial spillovers of transport infrastructure investment. Journal of transport Geography, 2010, 18: 141-152.
[12]	Gutiérrez J, González R, Gómez, G.The European high-speed train network: predicted effects on accessibility patterns. Journal of Transport Geography, 1996, 4(4): 227-238.
[13]	Gutiérrez J, Monzón A, Piero J M.Accessibility, network efficiency, and transport infrastructure planning. Environment and Planning A, 1998, 30: 1337-1350.
[14]	Gutiérrez J.Location, economic potential and daily accessibility: An analysis of the accessibility of the accessibility impact of the high-speed line Madrid-Barcelona-French border. Journal of Transport Geography, 2001, 9: 229-242.
[15]	Wang Jiaoe, Ding Jinxue.High-speed Rail and its impacts on the urban spatial structure of China. Urban Planning International, 2011, 26(6): 47-52.
	[王姣娥, 丁金学. 高速铁路对中国城市空间结构的影响研究. 国际城市规划, 2011, 26(6): 47-52.]
[16]	Jiang Haibing, Xu Jiangang, Qi Yi.The influence of Beijing-Shanghai high-speed railways on land accessibility of regional center cities. Acta Geographica Sinica, 2010, 65(10): 1287-1298.
	[蒋海兵, 徐建刚, 祁毅. 京沪高铁对区域中心城市陆路可达性影响. 地理学报, 2010, 65(10): 1287-1298.]
[17]	Givoni M, Banister D.Airline and railway integration. Transport Policy, 2006, 13(5): 386-397.
[18]	Bonnafous A.The regional impact of the TGV. Transportation, 14: 127-137.
[19]	Park Y, Ha H K.Analysis of the impact of high-speed railroad service on air transport demand. Transportation Research Part E, 2006, 42(2): 96-140.
[20]	Vickerman R.W. High-speed rail in Europe: Experience and issues for future development. The Annals of Regional Science, 1997, 31: 21-38.
[21]	Hou Xue, Liu Su, Zhang Wenxin et al. Characteristics of commuting behaviors between Beijing and Tianjing influenced by high speed train. Economic Geography, 2011, 31(9): 1573-1579.
	[候雪, 刘苏, 张文新等. 高铁影响下的京津城际出行行为研究. 经济地理, 2011, 31(9): 1573-1579.]
[22]	Wu Kang, Fang Chuanglin, Zhao Miaoxi et al. The intercity space of flow influenced by high-speed rail: A case study for the rail transit passenger behavior between Beijing and Tianjin. Acta Geographica Sinica, 2013, 68(2): 159-174.
	[吴康, 方创琳, 赵渺希等. 京津城际高速铁路影响下的跨城流动空间特征. 地理学报, 2013, 68(2): 159-174.]
[23]	Wang Jiao'e, Hu Hao. Competition and cooperation of high-speed railway and air transport in China: A perspective from spatial service market view. Acta Geographica Sinica, 2013, 68(2): 175-185.
	[王姣娥, 胡浩. 高铁与民航的空间服务市场竞合分析. 地理学报, 2013, 68(2): 175-185.]
[24]	Ureñaa J M, Meneraultb P, Garmendia M.The high-speed rail challenge for big intermediate cities: A national, regional, and local perspective. Cities, 2009, 26: 266-279.
[25]	Bonnafous A.The regional impact of the TGV. Transportation, 1987, 14: 127-137.
[26]	Zhang Wenxin, Ding Nan, Lv Guowei et al. Study on the influence of high speed railway on the consumption space of Yangtze River Delta cities. Economic Geography, 2012, 32(6): 1-6.
	[张文新, 丁楠, 吕国玮等. 高速铁路对长三角地区消费空间的影响. 经济地理, 2012, 32(6): 1-6.]
[27]	Wang Degen, Chen Tian, Li Li et al. Enlightenment and research of tourism impacts on high-speed rail. Scientia Geographica Sinica, 2012, 32(3): 322-328.
	[汪德根, 陈田, 李立等. 国外高速铁路对旅游影响研究及启示. 地理科学, 2012, 32(3): 322-328.]
[28]	Zhang Nannan, Xu Yilun.Research on the impacts of high speed rail on regional development. Areal Research and Development, 2005, 24(3): 32-36.
	[张楠楠, 徐逸伦. 高速铁路对沿线区域发展的影响研究. 地域研究与开发, 2005, 24(3): 32-36.]
[29]	Hu Tianjun, Shen Jinsheng.Effect analysis of Jing-Hu high-speed railway on regional economic development. Economic Geography, 1999, 19(5): 101-104.
	[胡天军, 申金升. 京沪高速铁路对沿线经济发展的影响分析. 经济地理, 1999, 19(5): 101-104.]
[30]	Miao Changhong, Wang Haijiang.On the direction and intensity of urban economic contacts in Henan Province. Geographical Research, 2006, 25(2): 222-232.
	[苗长虹, 王海江. 河南省城市的经济联系方向与强度: 兼论中原城市群的形成与对外联系. 地理研究, 2006, 25(2): 222-232.]
[31]	Xu Xueqiang. UrbanGeography.Beijing: Higher Education Press, 1997.
	[许学强. 城市地理学. 北京: 高等教育出版社, 1997.]
[32]	Wu Wei, Cao Youhui, Cao Weidong et al. Spatial pattern of regional comprehensive transportation cost. Scientia Geographica Sinica, 2009, 29(4): 485-492.
	[吴威, 曹有挥, 曹卫东等. 区域综合运输成本的空间格局研究. 地理科学, 2009, 29(4): 485-492.]
[33]	Lu Feng, Chen Jie.Location superiority and accessibility analysis on Wuhan metropolitan region. Progress in Geography, 2008, 27(4): 68-74.
	[陆峰, 陈洁. 武汉城市圈城市区位与可达性分析. 地理科学进展, 2008, 27(4): 68-74.]

指标		均值	变异系数	指标		均值	变异系数
全国	无高铁	247.61	3.97	中部地区	无高铁	99.06	1.36
	2012年	764.30	3.24		2012年	289.82	1.51
	2020年	912.99	3.43		2020年	329.23	1.42
东部地区	无高铁	665.33	2.58	西部地区	无高铁	39.14	2.46
	2012年	2097.21	1.99		2012年	99.52	3.80
	2020年	2513.27	2.13		2020年	128.73	3.23

位序	经济联系强度			变化量			变化率
位序	无高铁	2012年	2020年	2012年 /无高铁	2020年 /2012年	2020年 /无高铁	2012年 /无高铁	2020年 /2012年	2020年 /无高铁
1	广州	广州	广州	上海	佛山	广州	清远	定西	清远
2	佛山	上海	佛山	苏州	广州	上海	廊坊	肇庆	廊坊
3	上海	苏州	上海	广州	南通	佛山	咸宁	茂名	泉州
4	东莞	佛山	苏州	北京	上海	苏州	辽阳	南通	莆田
5	苏州	北京	北京	无锡	南京	北京	苏州	毕节地区	铁岭
6	深圳	东莞	东莞	东莞	天津	无锡	锦州	泸州	咸宁
7	北京	无锡	无锡	天津	北京	天津	秦皇岛	恩施州	厦门
8	无锡	天津	天津	深圳	杭州	东莞	无锡	贺州	辽阳
9	天津	深圳	深圳	常州	泰州	深圳	莆田	湛江	锦州
10	中山	常州	南京	中山	重庆	南京	葫芦岛	泰州	苏州

地区	无高铁		2012年		2020年
地区	平均值	变异系数	平均值	变异系数	平均值	变异系数
全国	0.74	53.23	2.27	33.06	2.72	39.33
东部-东部	6.21	21.05	19.59	12.68	23.47	15.13
中部-中部	0.56	15.51	1.54	10.15	1.69	9.35
西部-西部	0.25	22.00	0.66	40.49	0.80	33.73
东部-西部	0.06	4.71	0.12	4.95	0.20	4.95
东部-中部	0.31	5.79	1.03	6.26	1.20	6.35
中部-西部	0.04	5.01	0.08	6.79	0.12	6.81
