基于最优供需分配的公共设施空间可达性分析

doi:10.11821/dlxb202204017

地理学报 ›› 2022, Vol. 77 ›› Issue (4): 1028-1038.doi: 10.11821/dlxb202204017

• 区域发展 • 上一篇

基于最优供需分配的公共设施空间可达性分析

翟石艳¹(), 何新新², 孔云峰¹(), 罗静静², 宋根鑫²

1. 河南大学黄河中下游数字地理技术教育部重点实验室,开封 475000
2. 河南大学地理与环境学院,开封 475004

收稿日期:2020-12-18 修回日期:2021-08-18 出版日期:2022-04-25 发布日期:2022-06-20
通讯作者: 孔云峰(1967-), 男, 教授, 博士生导师, 主要从事空间分析、空间优化等研究。E-mail: yfkong@henu.edu.cn
作者简介:翟石艳(1983-), 女, 副教授, 博士生导师, 主要从事空间分析、空间优化和空间行为决策等研究。E-mail: zsycenu@hotmail.com
基金资助:
国家自然科学基金项目(41871307);河南省高等学校重点科研项目(21A170007)

Measuring the spatial accessibility of public services by optimal supply-demand allocation

ZHAI Shiyan¹(), HE Xinxin², KONG Yunfeng¹(), LUO Jingjing², SONG Genxin²

1. Key Laboratory of Geospatial Technology for the Middle and Lower Yellow River Regions, Ministry of Education, Henan University, Kaifeng 475000, Henan, China
2. College of Geography and Environmental Science, Henan University, Kaifeng 475004, Henan, China

Received:2020-12-18 Revised:2021-08-18 Published:2022-04-25 Online:2022-06-20
Supported by:
National Natural Science Foundation of China, No(41871307);Key Scientific Research Project of Henan Institution of Higher Education, No(21A170007)

摘要/Abstract

摘要：

空间可达性是衡量公共服务设施公平性的重要指标,在医疗、教育、休闲等公共服务的布局规划中得到广泛应用。然而已有设施服务可达性模型难以充分反映服务供需关系,计算指标也缺乏物理意义。本文提出新的最优供需分配的公共设施空间可达性计算方法（OSD）取代现有方法。该方法基于最优供需分配模型,将设施服务分配给需求者,根据分配结果计算空间可达性指标。给定服务设施与需求的空间分布,以最小化旅行成本为目标,顾及设施服务能力,采用经典的运输问题模型确定最优的服务供需分配方案,进而度量服务的空间可达性。以郑州市金水区社区卫生服务为例,求解25个中心与1333个居住小区的最优服务配置。使用最优配置结果确定每个设施的服务范围、每个居住小区使用服务的旅行时间,以及特定时间阈值的服务覆盖比率。与流行的两步移动搜索法相比,新方法的计算指标具有明确的物理意义。本文提出的可达性评价方法无需参数,计算高效,结果易于解释,在公共服务评价及设施布局规划方面具有应用潜力。

关键词: 公共服务, 空间可达性, 最优供需分配, 案例研究

Abstract:

Spatial accessibility is an important index for measuring fairness in public services such as health care, education, and outdoor leisure. It has also been widely used in the layout planning of public facilities. However, the existing accessibility models cannot fully illustrate the direct relationship between service supply and demand, and thus, the accessibility indicators cannot be explained with explicit meanings. This article introduces a new method for measuring accessibility based on optimal supply and demand allocation, which is different from the supply-demand relationships in existing methods. Given the supply locations, the demand locations, their attributes, and the travel costs between them, the transportation problem model is used to allocate services to demands. The classical model can be easily solved with optimal total travel cost. Based on the model results, the spatial accessibility of services can be measured. The proposed method was tested on healthcare services in a district in Zhengzhou, Henan, China. There were 25 healthcare centres and 1333 residential communities in the study area. The instance model was effectively built by an open-source MIP solver in 2.2 seconds. The service area of each healthcare centre and the travel time from each community were obtained according to the modelling results. In addition, the coverage percentages with predefined service thresholds were calculated. The proposed method was also compared with popular methods, such as the two-step floating catchment area method (2SFCA), Gaussian 2SFCA, and gravity 2SFCA. Areas with poor healthcare services were identified by using the results from the three 2SFCA methods. However, the spatial variation in service accessibility might be very different when selecting different search thresholds and/or distance decay coefficients. The optimal supply-demand accessibility method (OSD) proposed in this study has advantages such as being parameter-free, easy to calculate, and easy to explain. The authors believe that the method has application potential to replace the existing methods in evaluating public services and facility planning.

Key words: public service, spatial accessibility, optimal service allocation, case study

翟石艳, 何新新, 孔云峰, 罗静静, 宋根鑫. 基于最优供需分配的公共设施空间可达性分析[J]. 地理学报, 2022, 77(4): 1028-1038.

ZHAI Shiyan, HE Xinxin, KONG Yunfeng, LUO Jingjing, SONG Genxin. Measuring the spatial accessibility of public services by optimal supply-demand allocation[J]. Acta Geographica Sinica, 2022, 77(4): 1028-1038.

图/表 7

图1

图2

图3

表1

图4

图5

表2

参考文献 46

[1]	Xie Lijian, Zhou Suhong. The characteristics of inter-city commuting in Guangzhou under the context of regional integration. Urban Insight, 2010(4):85-93.
	[ 解利剑, 周素红. 区域一体化下的广州市居民城际通勤特征分析. 城市观察, 2010(4):85-93.]
[2]	Hansen, W G. How accessibility shapes land use. Journal of the American Institute of Planners, 1959, 25(2):73-76. doi: 10.1080/01944365908978307
[3]	Dalvi M Q, Martin K M. The measurement of accessibility: Some preliminary results. Transportation, 1976, 5(1):17-42. doi: 10.1007/BF00165245
[4]	Järv O, Tenkanen H, Salonen M, et al. Dynamic cities: Location-based accessibility modelling as a function of time. Applied Geography, 2018, 95:101-110. doi: 10.1016/j.apgeog.2018.04.009
[5]	Kwan M P, Weber J. Individual accessibility revisited: Implications for geographical analysis in the twenty-first century. Geographical Analysis, 2003, 35(4):341-353. doi: 10.1111/j.1538-4632.2003.tb01119.x
[6]	Zhang Q Y, Northridge M E, Jin Z, et al. Modeling accessibility of screening and treatment facilities for older adults using transportation networks. Applied Geography, 2018, 93:64-75. doi: 10.1016/j.apgeog.2018.02.013
[7]	Luo W, Wang F H. Measures of spatial accessibility to healthcare in a GIS environment: Synthesis and a case study in Chicago region. Environment and Planning B, Planning & Design, 2003, 30(6):865-884.
[8]	Mcgrail M R, Humphreys J S. Measuring spatial accessibility to primary care in rural areas: Improving the effectiveness of the two-step floating catchment area method. Applied Geography, 2009, 29(4):533-541. doi: 10.1016/j.apgeog.2008.12.003
[9]	Liao Xinzhi, Wang Hua, Zhao Wanmin. Evaluation method of medical facilities service coverage in mountainous cities based on map data. Journal of Geo-Information Science, 2021, 23(4):604-616.
	[ 廖心治, 王华, 赵万民. 融合地图数据的山地城市医疗设施服务覆盖评估方法研究. 地球信息科学学报, 2021, 23(4):604-616.]
[10]	Guo S H, Song C, Pei T, et al. Accessibility to urban parks for elderly residents: Perspectives from mobile phone data. Landscape and Urban Planning, 2019, 191:103642. DOI: 10.1016/j.landurbplan.2019.103642. doi: 10.1016/j.landurbplan.2019.103642
[11]	Wu J Y, Chen H T, Wang H Y, et al. Will the opening community policy improve the equity of green accessibility and in what ways? Response based on a 2-step floating catchment area method and genetic algorithm. Journal of Cleaner Production, 2020, 263:121454. DOI: 10.1016/j.jclepro.2020.121454 doi: 10.1016/j.jclepro.2020.121454
[12]	Xiao Y, Wang D, Fang J. Exploring the disparities in park access through mobile phone data: Evidence from Shanghai, China. Landscape and Urban Planning, 2019, 181:80-91. doi: 10.1016/j.landurbplan.2018.09.013
[13]	Chen Y, Yue W Z, Rosa D L. Which communities have better accessibility to green space? An investigation into environmental inequality using big data. Landscape and Urban Planning, 2020, 204:103919. DOI: 10.1016/j.landurbplan.2020.103919 doi: 10.1016/j.landurbplan.2020.103919
[14]	Yang Wenyue, Li Xin, Chen Huiling, et al. Multi-scale accessibility of green spaces and its equity in Guangzhou based on multi-mode two-step floating catchment area method (M2SFCA). Acta Ecologica Sinica, 2021, 41(15):6064-6074.
	[ 杨文越, 李昕, 陈慧灵, 等. 基于多出行模式两步移动搜索法的广州多尺度绿地可达性与公平性研究. 生态学报, 2021, 41(15):6064-6074.]
[15]	Han Zenglin, Dong Mengru, Liu Tianbao, et al. Spatial accessibility evaluation and layout optimization of basic education facilities in community life circle: A case study of Shahekou in Dalian. Scientia Geographica Sinica, 2020, 40(11):1774-1783. doi: 10.13249/j.cnki.sgs.2020.11.002
	[ 韩增林, 董梦如, 刘天宝, 等. 社区生活圈基础教育设施空间可达性评价与布局优化研究: 以大连市沙河口区为例. 地理科学, 2020, 40(11):1774-1783.]
[16]	Andersson F, Haltiwanger J C, Kutzbach M J, et al. Job displacement and the duration of joblessness: The role of spatial mismatch. The Review of Economics and Statistics, 2018, 100(2):203-218. doi: 10.1162/REST_a_00707
[17]	El-Geneidy A, Levinson D. Place rank: Valuing spatial interactions. Networks and Spatial Economics, 2011, 11(4):643-659. doi: 10.1007/s11067-011-9153-z
[18]	Korsu E, Wenglenski S. Job accessibility, residential segregation and risk of long-term unemployment in the Paris region. Urban Studies, 2010, 47(11):2279-2324. pmid: 20845591
[19]	Wan N, Zou B, Sternberg T. A three-step floating catchment area method for analyzing spatial access to health services. International Journal of Geographical Information Science, 2012, 26(6):1073-1089. doi: 10.1080/13658816.2011.624987
[20]	Yiannakoulias N, Bland W, Svenson L W. Estimating the effect of turn penalties and traffic congestion on measuring spatial accessibility to primary health care. Applied Geography, 2013, 39:172-182. doi: 10.1016/j.apgeog.2012.12.003
[21]	Lucas K, Wee B, Maat K. A method to evaluate equitable accessibility: Combining ethical theories and accessibility-based approaches. Transportation, 2016, 43(3):473-490. doi: 10.1007/s11116-015-9585-2
[22]	Talen E, Anselin L. Assessing spatial equity: An evaluation of measures of accessibility to public playgrounds. Environment and Planning A: Economy and Space, 1998, 30(4):595-613. doi: 10.1068/a300595
[23]	Zhao Pengjun, Luo Jia, Hu Haoyu. Spatial match between residents' daily life circle and public service facilities using big data analytics: A case of Beijing. Progress in Geography, 2021, 40(4):541-553. doi: 10.18306/dlkxjz.2021.04.001
	[ 赵鹏军, 罗佳, 胡昊宇. 基于大数据的生活圈范围与服务设施空间匹配研究: 以北京为例. 地理科学进展, 2021, 40(4):541-553.]
[24]	Xia N, Cheng L, Chen S, et al. Accessibility based on Gravity-Radiation model and Google Maps API: A case study in Australia. Journal of Transport Geography, 2018, 72:178-190. doi: 10.1016/j.jtrangeo.2018.09.009
[25]	Lakhani A, Parekh S, Gudes O, et al. Disability support services in Queensland, Australia: Identifying service gaps through spatial analysis. Applied Geography, 2019, 110:102045. DOI: 10.1016/j.apgeog.2019.102045. doi: 10.1016/j.apgeog.2019.102045
[26]	Shi Xun, Wang Fahui. Application of Geospatial Information Technologies in the Public Health. Beijing: Higher Education Press, 2016: 183-186.
	[ 施迅, 王法辉. 地理信息技术在公共卫生与健康领域的应用. 北京: 高等教育出版社, 2016: 183-186.]
[27]	Joseph A E, Bantock P R. Measuring potential physical accessibility to general practitioners in rural areas: A method and case study. Social Science & Medicine, 1982, 16(1):85-90. doi: 10.1016/0277-9536(82)90428-2
[28]	Onega T, Duell E J, Shi X, et al. Geographic access to cancer care in the US. Cancer, 2008, 112(4):909-918. doi: 10.1002/cncr.23229
[29]	Shen Q. Location characteristics of inner-city neighborhoods and employment accessibility of low-wage workers. Environment and Planning B, 1998, 25(3):345-365. doi: 10.1068/b250345
[30]	Cheng Min, Lian Yuejiao. Spatial accessibility of urban medical facilities based on improved potential model: A case study of Yangpu district in Shanghai. Progress in Geography, 2018, 37(2):266-275.
	[ 程敏, 连月娇. 基于改进潜能模型的城市医疗设施空间可达性: 以上海市杨浦区为例. 地理科学进展, 2018, 37(2):266-275.]
[31]	Luo W, Qi Y. An enhanced two-step floating catchment area (E2SFCA) method for measuring spatial accessibility to primary care physicians. Health & Place, 2009, 15(4):1100-1107.
[32]	Mcgrail M R, Humphreys J S. Measuring spatial accessibility to primary care in rural areas: Improving the effectiveness of the two-step floating catchment area method. Applied Geography, 2009, 29(4):533-541. doi: 10.1016/j.apgeog.2008.12.003
[33]	Luo W, Whippo T. Variable catchment sizes for the two-step floating catchment area (2SFCA) method. Health & Place, 2012, 18(4):789-795.
[34]	Yang D H, Goerge R, Mullner R. Comparing GIS-based methods of measuring spatial accessibility to health services. Journal of Medical Systems, 2006, 30(1):23-32. doi: 10.1007/s10916-006-7400-5
[35]	Guagliardo M F. Spatial accessibility of primary care: Concepts, methods and challenges. International Journal of Health Geographics, 2004, 3(1):3-16. pmid: 14987337
[36]	Dai D J. Black residential segregation, disparities in spatial access to health care facilities, and late-stage breast cancer diagnosis in metropolitan Detroit. Health & Place, 2010, 16(5):1038-1052.
[37]	Wang Chengjin. Function simulation and regularity of distance decay of inter-urban traffic flow in China. Progress in Geography, 2009, 28(5):690-696.
	[ 王成金. 中国交通流的衰减函数模拟及特征. 地理科学进展, 2009, 28(5):690-696.]
[38]	Liu Yu, Gong Li, Tong Qingxi. Quantifying the distance effect in spatial interactions. Acta Scientiarum Naturalium Universitatis Pekinensis, 2014, 50(3):526-534.
	[ 刘瑜, 龚俐, 童庆禧. 空间交互作用中的距离影响及定量分析. 北京大学学报(自然科学版), 2014, 50(3):526-534.]
[39]	Rong P J, Zheng Z C, Kwan M P, et al. Evaluation of the spatial equity of medical facilities based on improved potential model and map service API: A case study in Zhengzhou, China. Applied Geography, 2020, 119:102192. DOI: 10.1016/j.apgeog.2020.102192. doi: 10.1016/j.apgeog.2020.102192
[40]	Wang Qi. Accessibility analysis of medical services in Shanghai based on improved 2SFCA[D]. Wuhan: Wuhan University, 2019.
	[ 王奇. 基于改进两步移动搜索法的上海市医疗服务可达性分析[D]. 武汉: 武汉大学, 2019.]
[41]	Jiang Daoqi. Practical Linear Programming Method and Its Supporting System. Beijing: Tsinghua University Press, 2006: 193-197.
	[ 江道琪. 实用线性规划方法及其支持系统. 北京: 清华大学出版社, 2006: 193-197.]
[42]	Fu Jialiang. Operations Research Methods and Models. Shanghai: Fudan University Press, 2014: 118-121.
	[ 傅家良. 运筹学方法与模型. 上海: 复旦大学出版社, 2014: 118-121.]
[43]	National Health Commission of the People's Republic of China. Standard of service capacity of community health service centers (2018 edition). http://www.nhc.gov.cn/jws/s7882/201809/d77cd05877b84909b0bd0e8b92a3e5f8.shtml, 2018-08-22.
	[中华人民共和国国家卫生健康委员会. 社区卫生服务中心服务能力标准(2018年版). http://www.nhc.gov.cn/jws/s7882/201809/d77cd05877b84909b0bd0e8b92a3e5f8.shtml, 2018-08-22.]
[44]	National Health and Family Planning Commission of the People's Republic of China. More than 80% of residents can reach the nearest medical point within 15 minutes. http://www.nhc.gov.cn/libin/mtbd/201710/d25a52d908b64ba492dcd 212b5a91b86.shtml, 2017-10-22.
	[中华人民共和国国家卫生何计划生育委员会. 80%以上居民15分钟内就能到达最近的医疗点. http://www.nhc.gov.cn/libin/mtbd/201710/d25a52d908b64ba492dcd212b5a91b86.shtml, 2017-10-22.]
[45]	Tao Haiyan, Chen Xiaoxiang, Li Xia. Research on spatial accessibility to health service-A case study in the Haizhu district of Guangzhou. Geomatics & Spatial Information Technology, 2007(1):7-11.
	[ 陶海燕, 陈晓翔, 黎夏. 公共医疗卫生服务的空间可达性研究: 以广州市海珠区为例. 测绘与空间地理信息, 2007(1):7-11.]
[46]	Wang Yuanfei. GIS and Voronoi polygon based public health care accessibility analysis. Geomatics & Spatial Information Technology, 2006, 29(3):77-80.
	[ 王远飞. GIS与Voronoi多边形在医疗服务设施地理可达性分析中的应用. 测绘与空间地理信息, 2006, 29(3):77-80.]

分类(min)	实际服务能力最优分配		最大服务能力最优分配		服务现状
分类(min)	人数(人)	占比(%)	人数(人)	占比(%)	人数(人)	占比(%)
≤ 5	134038	8.29	141442	8.75	120419	7.45
5~10	368009	22.76	385789	23.86	321689	19.89
10~15	358494	22.17	359843	22.25	310973	19.23
> 15	756538	46.78	730005	45.14	863998	53.43

可达性计算方法	差(≤ 0.4)	较差(0.4~0.8)	一般(0.8~1.2)	较好(1.2~1.4)	好(> 1.4)
简单2SFCA	42.82	4.12	22.16	7.94	22.95
高斯2SFCA	51.51	6.63	9.57	7.97	24.32
重力2SFCA(β=1)	43.43	17.26	10.75	6.95	21.62
重力2SFCA(β=1.2)	46.01	19.13	8.60	7.44	18.82
重力2SFCA(β=1.5)	52.93	15.63	9.06	7.34	15.03
重力2SFCA(β=1.8)	59.97	13.54	8.93	3.93	13.63
重力2SFCA(β=2)	63.60	14.09	6.56	3.10	12.65
