水文地理研究发展若干问题商榷

doi:10.11821/dlxb202201001

摘要/Abstract

摘要：

水问题研究一直是我们国家最重要的课题之一,关系到社会稳定、民生福祉、经济发展等一系列国家重大需求。水文地理是水文学与地理学交叉学科,主要采用地理学原理、观点和方法。陆地表层系统的提出对水文地理的系统性研究具有重要的启发作用。首先,对水文地理学的交叉关联、研究内容、全球水系统和生态水文研究的兴起进行阐述;其次,在总结陆地表层系统论思想的主要倡导者及其观点后,讨论了地理研究综合性和区域性的关系,提出综合性、区域性和时空动态过程机理等“三性”应是水文地理系统的研究思想;再次,基于学科基础理论的扩展,给出深化水文地理时空动态过程机理的系统科学技术的几个案例;最后,讨论了中国水文地理研究的几个重点发展方向,主要包括气候变化与人类活动对水循环过程的影响、生态水文四大平衡动态演变过程机理、水资源可再生性维护、“蓝绿水”的认知意义、水文地理区划与制图技术及智能技术等。

关键词: 水文地理, 水循环, 系统论, 生态水文, 时空动态过程机理

Abstract:

Water-related issues have long been one of the most important topics in China, and these issues are related to a series of major national requirements, including social stability, people's livelihood and welfare, and economic development. Hydro-geography is an interdisciplinary subject of hydrology and geography that adopts the principles, perspective and methodologies of geography. The theory of the terrestrial surface system has an important enlightening effect on the systematic research of hydro-geography. First, this study discusses the cross-relationship and research content in hydro-geography, as well as the rise of research on global water systems and the ecohydrology. After summarizing the main advocates of terrestrial surface system theory and their viewpoints, this study explores the relationship between the comprehensive and regional aspects of geographic research, while proposing that the "three characteristics" (i.e., comprehensive, regional and orderly characteristics of processes) should be the research thought for hydro-geographical system. Furthermore, based on the expansion of the basic theories of the subject, this study presents several cases of systems science and technology that can deepen the spatiotemporal dynamic process mechanism (orderliness) of hydro-geography. Finally, several key development and research directions of hydro-geographic research in China are discussed, mainly including: research on the impact of climate change and impacts of human activities on the water cycle process; research on the dynamic evolution mechanism of the four major balances in ecohydrology; research on renewability of water resources; the process of evapotranspiration of plants (crops) and water-saving control; hydro-geographic zoning, mapping technology and intelligence technology applications.

Key words: hydro-geography, water cycle, system theory, ecohydrology, orderliness

刘昌明, 刘璇, 杨亚锋, 王红瑞. 水文地理研究发展若干问题商榷[J]. 地理学报, 2022, 77(1): 3-15.

LIU Changming, LIU Xuan, YANG Yafeng, WANG Hongrui. A discussion on some issues of hydro-geographical research[J]. Acta Geographica Sinica, 2022, 77(1): 3-15.

图/表 9

图1

表1

图2

图3

图4

图5

图6

表2

表3

参考文献 42

[1]	Liu Changming, Zhou Chenghu, Yu Jingjie, et al. Hydrogeology of China. Beijing: Science Press, 2014.
	[ 刘昌明, 周成虎, 于静洁, 等. 中国水文地理. 北京: 科学出版社, 2014.]
[2]	Liu Changming. Research progress in geographical hydrology and its prospect in 21st century. Acta Geographica Sinica, 1994, 49(Suppl.1): 601-608.
	[ 刘昌明. 地理水文学的研究进展与21世纪展望. 地理学报, 1994, 49(Suppl.1): 601-608.]
[3]	Liu Changming. Hydrogeography and the geographical study of hydrology. Yellow River, 1984, 6(2): 57-60.
	[ 刘昌明. 水文地理学与水文学的地理研究. 人民黄河, 1984, 6(2): 57-60.]
[4]	Guo Jinghui, Liu Changming. The direction and development trend of geographical study of hydrology. Acta Geographica Sinica, 1984, 39(2): 206-212.
	[ 郭敬辉, 刘昌明. 水文学的地理研究方向与发展趋势. 地理学报, 1984, 39(2): 206-212.]
[5]	Huang Weilun. Hydrology of ancient China. Journal of China Hydrology, 1984, 4(4): 35-40.
	[ 黄伟纶. 我国古代的水文科学. 水文, 1984, 4(4): 35-40.]
[6]	Chorley R J. Introduction to Geographical Hydrology: Spatial Aspects of the Interactions between Water Occurrence and Human Activity. London: Routledge, 1979.
[7]	Leemans R, Asrar G, Busalacchi A, et al. Developing a common strategy for integrative global environmental change research and outreach: The earth system science partnership (ESSP). Current Opinion in Environmental Sustainability, 2009, 1(1): 4-13. doi: 10.1016/j.cosust.2009.07.013
[8]	Alcamo J, Grassl H, Hoff H, et al. The global water system project: Science framework and implementation activities. GWSP Report No.1, 2005.
[9]	Vörösmarty C J, Pahl-wostl C, Bhaduri A. Water in the Anthropocene: New perspectives for global sustainability. Current Opinion in Environmental Sustainability, 2013, 5(6): 535-538. doi: 10.1016/j.cosust.2013.11.011
[10]	Gleeson T, Wang-erlandsson L, Porkka M, et al. Illuminating water cycle modifications and earth system resilience in the Anthropocene. Water Resources Research, 2020, 56(4): e2019WR024957. DOI: 10.1029/2019WR024957. doi: 10.1029/2019WR024957
[11]	Blöschl G, Bierkens M F, Chambel A, et al. Twenty-three Unsolved Problems in Hydrology: A community perspective. Hydrological Sciences Journal, 2019, 64(10): 1141-1158. doi: 10.1080/02626667.2019.1620507
[12]	Gao Yang, Yu Guirui. Biogeochemical cycle and its hydrological coupling processes and associative controlling mechanism in a watershed. Acta Geographica Sinica, 2018, 73(7): 1381-1393. doi: 10.11821/dlxb201807015
	[ 高扬, 于贵瑞. 流域生物地球化学循环与水文耦合过程及其调控机制. 地理学报, 2018, 73(7): 1381-1393.]
[13]	Kroeze C, Hofstra N, Ivens W, et al. the links between global carbon, water and nutrient cycles in an urbanizing world: The case of coastal eutrophication. Current Opinion in Environmental Sustainability, 2013, 5(6): 566-572. doi: 10.1016/j.cosust.2013.11.004
[14]	Leemans R, Eickhout B. Another reason for concern: Regional and global impacts on ecosystems for different levels of climate change. Global Environmental Change, 2004, 14(3): 219-228. doi: 10.1016/j.gloenvcha.2004.04.009
[15]	Heisler J, Glibert P, Burkholder J, et al. Eutrophication and harmful algal blooms: A scientific consensus. Harmful Algae, 2008, 8(1): 3-13. doi: 10.1016/j.hal.2008.08.006 pmid: 28781587
[16]	Yan Denghua, He Yan, Deng Wei, et al. Advances in the ecohydrology research. Scientia Geographica Sinica, 2001, 21(5): 467-473.
	[ 严登华, 何岩, 邓伟, 等. 生态水文学研究进展. 地理科学, 2001, 21(5): 467-473.]
[17]	Xia J, Zuo Qiting, Han Chunhui, et al. Disciplinary system and development strategy for eco-hydrology. Advances in Earth Science. 2018, 33(7): 665-674.
	[ 夏军, 左其亭, 韩春辉, 等. 生态水文学学科体系及学科发展战略. 地球科学进展, 2018, 33(7): 665-674.]
[18]	Liu Changming, Men Baohui, Zhao Changsen. Ecohydrology: Environmental flow and its driving factors. Advances in Water Science, 2020, 31(5): 765-774.
	[ 刘昌明, 门宝辉, 赵长森. 生态水文学: 生态需水及其与流速因素的相互作用水科学进展, 2020, 31(5): 765-774.]
[19]	Ingram H. Ecohydrology of Scottish peatlands. Transactions of the Royal Society of Edinburgh Earth Sciences, 1987, 78(4): 287-296. doi: 10.1017/S0263593300011226
[20]	Rodriguez-Iturbe I. Ecohydrology: A hydrologic perspective of climate-soil-vegetation dynamies. Water Resources Research, 2000, 36(1): 3-9. doi: 10.1029/1999WR900210
[21]	Burgess S S O, Adams M A, Turner N C, et al. The redistribution of soil water by tree root systems. Oecologia, 1998, 115(3): 306-311. doi: 10.1007/s004420050521
[22]	Le P V V, Kumar P. Interaction between ecohydrologic dynamics and Microtopographic Variability Under Climate Change. Water Resources Research, 2017, 53(10): 8383-8403. doi: 10.1002/wrcr.v53.10
[23]	Wang L, Wei X, Bishop K, et al. Vegetation Changes and water cycle in a changing environment. Hydrology and Earth System Sciences, 2018, 22(3): 1731-1734. doi: 10.5194/hess-22-1731-2018
[24]	Poff N L, Zimmerman J K H. Ecological responses to altered flow regimes: A literature review to inform the science and management of environmental flows. Freshwater Biology, 2010, 55: 194-205. doi: 10.1111/fwb.2009.55.issue-1
[25]	Prince George's County of Maryland, Department of Environmental Resources, Programs and Planning Division. Low-impact development design strategies: An integrated design approach. 1999. https://cfpub.epa.gov/watertrain/pdf/LID_National_Manual.pdf.
[26]	Liu Changming. Improve the cognition of the relationship between water ecology and ecological water. China Water Resources, 2020(2): 20.
	[ 刘昌明. 提高水生态与生态水关系的认知. 中国水利, 2020(2): 20.]
[27]	Wei Hongseng, Zeng Guoping. Systematicism. Beijing: Tsinghua University Press, 1995.
	[ 魏宏森, 曾国屏. 系统论北京: 清华大学出版社, 1995]
[28]	Qian Xuesen, Yu Jingyuan, Dai Ruwei. A new discipline of science: The study of open complex giant system and itsmethodology. Chinese Journal of Nature, 1990, 13(1): 3-10, 64.
	[ 钱学森, 于景元, 戴汝为. 一个科学新领域: 开放的复杂巨系统及其方法论. 自然杂志, 1990(1): 3-10, 64.]
[29]	Qian Xuesen. Discussion on the contents and research methods of Geographical Science (Speech at the "Geographical Science" symposium of the Geographical Society of China on 6 April 1991. Acta Geographica Sinica, 1991, 46(3): 257-265.
	[ 钱学森. 谈地理科学的内容及研究方法(在1991年4月6日中国地理学会“地理科学”讨论会上的发言). 地理学报, 1991, 46(3): 257-265.]
[30]	Chen Yongshen, Liang Shan. Some Thinking on developing modern geography from Prof. Zhu Kezhen. Acta Geographica Sinica, 1986, 41(2): 177-183. doi: 10.11821/xb198602008
	[ 陈永申, 梁珊. 竺可桢同志关于发展地理学的思想. 地理学报, 1986, 41(2): 177-183.]
[31]	Ge Quansheng, Zhao Mingcha, Zheng Jingyun, et al. Division of the terrestrial system in China: A case study from Huang's theory on terrestrial system science. Scientia Geographica Sinica, 2003, 23(1): 1-6.
	[ 葛全胜, 赵名茶, 郑景云, 等. 中国陆地表层系统分区: 对黄秉维先生陆地表层系统理论的学习与实践. 地理科学, 2003, 23(1): 1-6.]
[32]	Huang Bingwei. On earth system science and sustainable development strategy (Ⅰ). Acta Geographica Sinica, 1996, 51(4): 350-354. doi: 10.11821/xb199604008
	[ 黄秉维. 论地球系统科学与可持续发展战略科学基础(Ⅰ). 地理学报, 1996, 51(4): 350-354.]
[33]	Xie Jiaze. Some questions about the view of the earth surface system. Advances in Earth Science, 1995, 10(5): 432-435.
	[ 谢家泽. 关于地球表层系统观的几个问题. 地球科学进展, 1995, 10(5): 432-435.]
[34]	Wei Hongsen, Zeng Guoping. The fundamental law of systematicism. Studies in Dialectics of Nature, 1995, 11(4): 22-27.
	[ 魏宏森, 曾国屏. 系统论的基本规律. 自然辩证法研究, 1995, 11(4): 22-27.]
[35]	Song Changqing, Cheng Changxiu, Shi Peijun. Geography complexity: New connotations of geography in the new era. Acta Geographica Sinica, 2018, 73(7): 1204-1213. doi: 10.11821/dlxb201807002
	[ 宋长青, 程昌秀, 史培军. 新时代地理复杂性的内涵. 地理学报, 2018, 73(7): 1204-1213.]
[36]	Sivapalan M, Savenije H H G, Blöschl G. Socio-hydrology: A new science of people and water. Hydrological Processes, 2012, 26(8): 1270-1276. doi: 10.1002/hyp.8426
[37]	Liu Changming, Li Yuncheng. "Green water" and water saving: Discussion on issue for connotation of water resources in China. Impact of Science on Society, 2006(1): 16-20.
	[ 刘昌明, 李云成. “绿水”与节水: 中国水资源内涵问题讨论. 科学对社会的影响, 2006(1): 16-20.]
[38]	Zheng Du, Liu Changming, Chen Fazu, et al. Physical geographical processes and hydrological interface analysis//Institute of Geography, CAS. Comprehensive Study of Physical Geography: A Study of Prof. Huang's Academic Thoughts. Beijing: China Meteorological Press, 1993.
	[ 郑度, 刘昌明, 陈发祖, 等. 自然地理界面过程与水文界面分析//中国科学院地理研究所. 自然地理综合研究: 黄秉维学术思想探讨. 北京: 气象出版社, 1993.]
[39]	Liu Changming, Yu Jingjie, Liu Suxia, et al. Advances in Innovative Research in Hydrology. Beijing: Science Press, 2014.
	[ 刘昌明, 于静洁, 刘苏峡, 等. 水文科学创新研究进展. 北京: 科学出版社, 2014.]
[40]	Liu C M. The quantitative features of China's water resources: An overview. Tucson: Technical Report No.38, University of Arizona, 1983.
[41]	Zhang S F, Jia S F, Liu C M, et al. Study on the changes of water cycle and its impacts in the source region of the Yellow River. Science in China Series E: Technological Sciences, 2004, 47(1): 142-151. doi: 10.1360/04ez0012
[42]	Liu Changming, Wang Hongrui. An analysis of the relationship between water resources and population-economy-society-environment. Journal of Natural Resources, 2003, 18(5): 635-644.
	[ 刘昌明, 王红瑞. 浅析水资源与人口、经济和社会环境的关系. 自然资源学报, 2003, 18(5): 635-644.]

研究问题	研究内容
水资源/资源水	地表、地下各种水体的科学分析、检测、评价、计算预报、设计规划
水环境/环境水	保护、水质监测、评价、污染防治与修复
水生态/生态水	维护、生态需水检测、评价、退化防治与修复
水灾害/灾害水	防治、洪涝与干旱监测、预报与预警、设计规划
水管控/工程水	合理配置、优化调度、一体化管理(IWRM)与流域综合管理(IRBM)

	人口(P)	经济($)	社会(S)	水资源(R)	生态(B)	环境(E)
人口(P)	1	P/$	P/S	P/R	P/B	P/E
经济($)	$/P	1	$/S	$/R	$/B	$/E
社会(S)	S/P	S/$	1	S/R	S/B	S/E
水资源(R)	R/P	R/$	R/S	1	R/B	R/E
生态(B)	B/P	B/$	B/S	B/R	1	B/E
环境(E)	E/P	E/$	E/S	E/R	E/B	1

系统方法应用	系统输入	作用机制	系统输出
分析—鉴别	已知	?	已知
预测—预报	已知	已知	?
反馈—控制	?	已知	已知
