地理学报 ›› 2021, Vol. 76 ›› Issue (11): 2841-2852.doi: 10.11821/dlxb202111017
汤国安1,2,3(), 李吉龙1,2,3,4(
), 熊礼阳1,2,3, 那嘉明1,2,3
收稿日期:
2021-06-11
修回日期:
2021-10-14
出版日期:
2021-11-25
发布日期:
2022-01-25
通讯作者:
李吉龙(1988-), 男, 博士, 主要从事GIS数字地形分析研究。E-mail: leejeelong@126.com作者简介:
汤国安(1961-), 男, 博士, 教授, 博导, 主要从事地理信息科学方面的研究。E-mail: tangguoan@njnu.edu.cn
基金资助:
TANG Guoan1,2,3(), LI Jilong1,2,3,4(
), XIONG Liyang1,2,3, NA Jiaming1,2,3
Received:
2021-06-11
Revised:
2021-10-14
Published:
2021-11-25
Online:
2022-01-25
Supported by:
摘要:
地理边界的科学界定体现着对地理对象空间分异规律科学抽象与系统分析的认知水平,是地理学的基础科学问题。本文从地球系统科学的视角,首先阐述了地理边界的基本概念、科学内涵与基本属性等核心概念问题,基于科学性、系统性的基本原则,以内在机理、外在表现以及科学属性等视角为核心依据,对地理边界进行了系统分类。论文分析了地理边界的数学内涵与表达方法,比较了传统地理边界划分法和现代地理边界定量划分方法的特点与差异性,提出了集定性、定量、定位为一体的“地理边界模型”的研究架构。该研究盼在地理边界这个地理学基础理论问题上进行概念辨析与方法分析,丰富地理信息科学的理论与方法。
汤国安, 李吉龙, 熊礼阳, 那嘉明. 论地理边界的科学属性与表达[J]. 地理学报, 2021, 76(11): 2841-2852.
TANG Guoan, LI Jilong, XIONG Liyang, NA Jiaming. Scientific attributes and expression methods of geographical boundary[J]. Acta Geographica Sinica, 2021, 76(11): 2841-2852.
表1
常见的地理边界数学模型表达与对比
过渡属性 | 数学模型 | 表达原理 | 示意图 | 模型特点与划分方法 |
---|---|---|---|---|
显性突变 | 势函数 | 根据突变理论,势函数 式中: (1) 当 (2) 使势函数( 对于显性突变属性的地理边界,由势函数衍生出的平衡曲面与分叉集共同确定。 | ![]() | 模型特点:适用有明显地理阻隔环境下的显性突变地理边界表达。 划分方法:采用突变理论与突变级数法进行地物显著差异分析并定位。 |
模糊渐变 | 模糊集 | 模糊集通过构建模糊隶属函数计算隶属度的大小来确定划界单元的归属。已知论域 式中:称映射 在地理边界的表达中, | ![]() | 模型特点:更加自然表示地理现象,适用于模糊地理边界模糊划分。划分方法:通过构建模糊隶属度函数(根据专家知识、数据集特征给出)提取地物类型边界,建立模糊边界划分模型。 |
复杂交替 | 粗糙集 | 针对复杂交替特征的地理现象采用粗糙集进行边界表达: 式中:论域 | ![]() | 模型特点:完全由数据驱动,不涉及隶属函数的构造,在表达地理边界的特征上更加客观。划分方法:根据地物相关数据集,确定上下近似集,计算得到的边界域即为最终划定的地理边界(过渡带)。 |
表2
定量地理边界划分方法对比
方法 | 优点 | 缺点 |
---|---|---|
直接法 | 由数据驱动,划分思路简便,适用于具有显性突变或明显地理阻隔的地理边界划分研究中 | 使用局限,面对复杂的地理现象或过程,划分捉襟见肘 |
模糊数学法 | 符合地理认知,能够更加自然表示地理现象、对象或过程,适用于具有模糊过渡特征的边界划分 | 模糊隶属函数可以根据专家知识或实验数据给出,或根据数据集属性特征的聚类得到,划分结果存在差异 |
空间统计建模法 | 充分顾及划界指标的重要性,同时兼顾划分过程中的尺度依赖性,适用于多种过渡属性的边界划分 | 需要有领域知识和统计知识,且通常需要假设空间分布数据具有统计上不存在空间自相关和平稳性,然而对于地理边界划分过程而言,其空间属性关联不可避免 |
新型划分法 | 通常采用启发式学习方式来进行边界划分,并从数据本身入手,在符合地理认知的基础上,具有稳定的划分效率与准确性 | 需要大量的初始参数,如网络拓扑结构、权值和阈值,划分过程黑盒等 |
[1] | Dictionary Editorial Office, Institute of Linguistics of the Chinese Academy of Social Sciences. The Contemporary Chinese Dictionary. 7th ed. Beijing: The Commercial Press, 2016. |
[中国社会科学院语言研究所词典编辑室. 现代汉语词典. 7版. 北京: 商务印书馆, 2016.] | |
[2] | Staff M W. Merriam-Webster's Collegiate Dictionary. 11th ed. Springfield: Merriam-Webster, 2003. |
[3] | Mendelson B. Introduction to Topology. 2nd ed. New York: Dover, 1990. |
[4] | Perrot P. A to Z of Thermodynamics. Oxford: Oxford University Press, 1998. |
[5] | Zuo Dakang. A Modern Dictionary of Geography. Beijing: The Commercial Press, 1990. |
[左大康. 现代地理学辞典. 北京: 商务印书馆, 1990.] | |
[6] | Zhou Juqian. On geographic boundary. Yunnan Geographic Environment Research, 1992, 4(1):51-59. |
[周钜乾. 论地理边界. 云南地理环境研究, 1992, 4(1):51-60.] | |
[7] | Zheng Du, Ge Quansheng, Zhang Xueqin, et al. Regionalization in China: Retrospect and prospect. Geographical Research, 2005, 24(3):330-344. |
[郑度, 葛全胜, 张雪芹, 等. 中国区划工作的回顾与展望. 地理研究, 2005, 24(3):330-344.] | |
[8] | Zheng Du, Ou Yang, Zhou Chenghu. Understanding of and thinking over geographical regionalization methodology. Acta Geographica Sinica, 2008, 63(6):563-573. |
[郑度, 欧阳, 周成虎. 对自然地理区划方法的认识与思考. 地理学报, 2008, 63(6):563-573.] | |
[9] | Haining R. Spatial Data Analysis in the Social and Environmental Sciences. Cambridge: Cambridge University Press, 1993. |
[10] | Burt J, Barber G, Rigby D L. Elementary Statistics for Geographers. 3rd ed. New York: Guilford Press, 2009. |
[11] | Chen Shupeng. Geographic information system exploration and experiments. Scientia Geographica Sinica, 1983, 3(4):287-302. |
[陈述彭. 地理信息系统的探索与试验. 地理科学, 1983, 3(4):287-302.] | |
[12] |
Jacquez G M, Maruca S, Fortin M J. From fields to objects: A review of geographic boundary analysis. Journal of Geographical Systems. 2000, 2(3):221-241.
doi: 10.1007/PL00011456 |
[13] | Hu Zui, Tang Guoan, Lv Guonian. The concept and characteristics of GIS language. Acta Geographica Sinica, 2012, 67(7):867-877. |
[胡最, 汤国安, 闾国年. GIS作为新一代地理学语言的特征. 地理学报, 2012, 67(7):867-877.] | |
[14] | Xiao Ping, Li Deren. The geographic boundary sharpness and a method to calculate the membership in fuzzy GIS. Journal of the PLA Institute of Surveying and Mapping, 1998, 15(3):204-206. |
[肖平, 李德仁. GIS模糊栅格数据结构隶属度的解算和地理多边形边界锐度. 解放军测绘学院学报, 1998, 15(3):204-206.] | |
[15] | Cao Han, Chen Jun, Du Daosheng. Geographic phenomena data model with fuzzy boundaries. Journal of Northwest University (Natural Science Edition), 2001, 31(2):108-110, 114. |
[曹菡, 陈军, 杜道生. 模糊边界地理现象的建模方法. 西北大学学报(自然科学版), 2001, 31(2):108-110, 114.] | |
[16] |
Fu Bojie. Geography: From knowledge, science to decision making support. Acta Geographica Sinica, 2017, 72(11):1923-1932.
doi: 10.11821/dlxb201711001 |
[傅伯杰. 地理学:从知识、科学到决策. 地理学报, 2017, 72(11):1923-1932.] | |
[17] |
Xiong L Y, Tang G A, Yang X, et al. Geomorphology-oriented digital terrain analysis: Progress and perspectives. Journal of Geographical Sciences, 2021, 31(3):456-476.
doi: 10.1007/s11442-021-1853-9 |
[18] |
Tobler W R. A computer movie simulating urban growth in the Detroit region. Economic Geography, 1970, 46(Suppl.):234-240.
doi: 10.2307/143141 |
[19] |
Goodchild M F. The validity and usefulness of laws in geographic information science and geography. Annals of the Association of American Geographers, 2004, 94:300-303.
doi: 10.1111/j.1467-8306.2004.09402008.x |
[20] | Qiu Yang, Zhang Jintun, Zheng Fengying. The kernel of landscape ecology: Spatial and temporal heterogeneity in ecological systems. Chinese Journal of Ecology, 2000, 19(2):42-49. |
[邱扬, 张金屯, 郑凤英. 景观生态学的核心: 生态学系统的时空异质性. 生态学杂志, 2000, 19(2):42-49.] | |
[21] | Risser P G. Landscape ecology: State of the art//Turner M G. Landscape Heterogeneity and Disturbance: Ecological Studies. New York: Springer, 1987. |
[22] | Zhu Axing, Lv Guonian, Zhou Chenghu, et al. Geographic similarity: Third law of geography? Journal of Geo-Information Science, 2020, 22(4):673-679. |
[朱阿兴, 闾国年, 周成虎, 等. 地理相似性: 地理学的第三定律? 地球信息科学学报, 2020, 22(4):673-679.] | |
[23] |
Zhu A X, Lv G N, Liu J, et al. Spatial prediction based on Third Law of Geography. Annals of GIS, 2018, 24(4):225-240.
doi: 10.1080/19475683.2018.1534890 |
[24] | Ma Ainai. Geographical complexity system and geographical nonlinearity model. Journal of Systemic Dialectics, 2001, 9(4):19-23. |
[马蔼乃. 地理复杂系统与地理非线性复杂模型. 系统辩证学学报, 2001, 9(4):19-23.] | |
[25] |
Phillips J D. Sources of nonlinearity and complexity in geomorphic systems. Progress in Physical Geography: Earth and Environment, 2003, 27(1):1-23.
doi: 10.1191/0309133303pp340ra |
[26] |
Swain J B, Sahoo M M, Patra K C. Homogeneous region determination using linear and nonlinear techniques. Physical Geography. 2016, 37(5):361-384.
doi: 10.1080/02723646.2016.1211460 |
[27] | Wei Shengmin. Theoretical explanation of the time-space sequence in geographic environment. Journal of Northwest University (Natural Science Edition), 1986, 16(4):84-91. |
[韦省民. 地理环境时空有序性的理论解释. 西北大学学报(自然科学版), 1986, 16(4):84-91.] | |
[28] | Tang Wenya. The muddy and variable charctors of physi-geographic regional boundary and its clustered judgment. Journal of Central China Normal University (Natural Sciences), 1987, 21(1):110-116. |
[唐文雅. 自然地理区界的模糊性、可变性及其聚类判定. 华中师范大学学报(自然科学版), 1987, 21(1):110-116.] | |
[29] | Schonewald C M. Introduction to boundary space. Complexity, 2000, 6(2):41-57. |
[30] | Li Z, Khoshelham K, Zheng D, et al. Empirical Mode Decomposition (EMD) transform for spatial analysis//Li Z, Zhou Q, Kainz W. Advances in Spatial Analysis and Decision Making. Boca Raton: CRC Press, 2003. |
[31] |
Li J L, Na J M, Yang X, et al. Application of the Hilbert-Huang transform for recognition of active gully erosion sites in the Loess Plateau of China. Transactions in GIS, 2019, 23(1):137-157.
doi: 10.1111/tgis.v23.1 |
[32] | Fang Chuanglin. Dissipative structure theory and geography system. Arid Land Geography, 1989, 12(3):51-56. |
[方创琳. 耗散结构理论与地理系统论. 干旱区地理, 1989, 12(3):51-56.] | |
[33] | Zhang G, Jacob E K. Understanding boundaries: Physical, epistemological and virtual dimensions. Information Research, 2013, 18(3): paper C21. http://InformationR.net/ir/18-3/colis/paperC21.html. |
[34] |
Gao Jiangbo, Huang Jiao, Li Shuangcheng, et al. The new progresses and development trends in the research of physio-geographical regionalization in China. Progress in Geography, 2010, 29(11):1400-1407.
doi: 10.11820/dlkxjz.2010.11.032 |
[高江波, 黄姣, 李双成, 等. 中国自然地理区划研究的新进展与发展趋势. 地理科学进展, 2010, 29(11):1400-1407.] | |
[35] | Long Yongjun. The geographical gray boundary and its research value. Journal of Guizhou Normal College, 2013, 29(9):53-58. |
[龙拥军. 地理灰边界内涵及其研究应用价值. 贵州师范学院学报, 2013, 29(9):53-58.] | |
[36] |
Thom R. Structural stability, catastrophe theory, and applied mathematics. SIAM Review, 1977, 19(2):189-201.
doi: 10.1137/1019036 |
[37] |
Fagan W F, Fortin M J, Soykan C. Integrating edge detection and dynamic modeling in quantitative analyses of ecological boundaries. BioScience, 2003, 53(8):730-738.
doi: 10.1641/0006-3568(2003)053[0730:IEDADM]2.0.CO;2 |
[38] |
Fang Chuanglin. Theoretical foundation and patterns of coordinated development of the Beijing-Tianjin-Hebei Urban Agglomeration. Progress in Geography, 2017, 36(1):15-24.
doi: 10.18306/dlkxjz.2017.01.002 |
[方创琳. 京津冀城市群协同发展的理论基础与规律性分析. 地理科学进展, 2017, 36(1):15-24.] | |
[39] | Zheng Du, Yang Qinye, et al. (eds.). Researches on Regional Physio-geographical System. Beijing: China Environmental Science Press, 1997. |
[郑度, 杨勤业, 等编. 自然地域系统研究. 北京: 中国环境科学出版社, 1997.] | |
[40] | Zheng Du, Fu Xiaofeng. A preliminary study on issues of integrated geographical regionalization. Scientia Geographica Sinica, 1999, 19(3):193-197. |
[郑度, 傅小锋. 关于综合地理区划若干问题的探讨. 地理科学, 1999, 19(3):193-197.] | |
[41] | Huang Bingwei. On the comprehensive physical regionalization of China. New Construction, 1965(3):65-74. |
[黄秉维. 论中国综合自然区划. 新建设, 1965(3):65-74.] | |
[42] | Chen Yanguang. Mathematical Methods for Geography. Beijing: Science Press, 2011. |
[陈彦光. 地理数学方法: 基础和应用. 北京: 科学出版社, 2011.] | |
[43] | Lin Chao. Outline of physical geography regionalization in China: An abstract. Acta Geographica Sinica, 1954, 20(4):395-418. |
[林超. 中国自然地理区划大纲 (摘要). 地理学报, 1954, 20(4):395-418.] | |
[44] | Ding Sibao. Province-regions in China: Positivity of their geographical boundary and development. Human Geography, 2001, 16(2):12-16. |
[丁四保. 我国的省区: 它的地理边界和它的必然发展. 人文地理, 2001, 16(2):12-16.] | |
[45] |
Fan Jie. Draft of major function oriented zoning of China. Acta Geographica Sinica, 2015, 70(2):186-201.
doi: 10.11821/dlxb201502002 |
[樊杰. 中国主体功能区划方案. 地理学报, 2015, 70(2):186-201.] | |
[46] | Li Weizheng, Ai Chang, Peng Shikui. A method to extract the subcompartment boundary from contour of the relief map supported using GIS technology. Journal of Nanjing Forestry University (Natural Sciences Edition), 2009, 33(2):69-72. |
[李卫正, 艾畅, 彭世揆. 一种利用地形图和遥感影像提取小班界线的方法. 南京林业大学学报 (自然科学版), 2009, 33(2):69-72.] | |
[47] |
Wagner M P, Oppelt N. Extracting agricultural fields from remote sensing imagery using graph-based growing contours. Remote Sensing, 2020, 12(7):1205. DOI: 0.3390/rs12071205.
doi: 0.3390/rs12071205 |
[48] |
Mark D M, Csillag F. The nature of boundaries on "area-class" maps. Cartographica: The International Journal for Geographic Information and Geovisualization. 1989, 26(1):65-78.
doi: 10.3138/D235-3262-062X-4472 |
[49] | Burrough P A, Frank A (eds.). Geographic Objects with Indeterminate Boundaries. London: Taylor & Francis, 1996. |
[50] |
Wang F J, Hall G B. Fuzzy representation of geographical boundaries in GIS. International Journal of Geographical Information Systems, 1996, 10(5):573-590.
doi: 10.1080/02693799608902098 |
[51] | Jiang B. Visualisation of fuzzy boundaries of geographic objects. Cartography, 1998, 27(2):41-46. |
[52] |
Lu H L, Carlin B P. Bayesian areal wombling for geographical boundary analysis. Geographical Analysis. 2005, 37(3):265-285.
doi: 10.1111/gean.2005.37.issue-3 |
[53] |
Yan Luming. Application of extension engineering method to division of physical geography boundary. Geographical Research, 1999, 18(1):53-58.
doi: 10.11821/yj1999010008 |
[晏路明. 可拓工程方法在自然地理界线划分中的应用. 地理研究, 1999, 18(1):53-58.] | |
[54] | Yan Luming. A matter-element model to division of physical geography boundary. Systems Engineering Theory and Practice, 1999, 19(12):85-89. |
[晏路明. 自然地理界线划分的物元模型. 系统工程理论与实践, 1999, 19(12):85-89.] | |
[55] | Yan Luming. The discriminant analysis on physical geography boundary based on GIS. Journal of Applied Statistics and Management, 2003(Suppl.1):286-291. |
[晏路明. 基于GIS的自然地理界线的判别分析. 数理统计与管理, 2003(Suppl.1):286-291.] | |
[56] | Li Shuangcheng, Zheng Du, Zhang Yili. Application of SOFM neural network to ecological assets regionalization in Qinghai-Tibet Plateau. Journal of Natural Resources, 2002, 17(6):750-756. |
[李双成, 郑度, 张镱锂. 青藏高原生态资产地域划分中的SOFM网络技术. 自然资源学报, 2002, 17(6):750-756.] | |
[57] | Li Shuangcheng, Zhao Zhiqiang, Gao Jiangbo. Identifying eco-geographical boundary using spatial wavelet transform. Acta Ecologica Sinica, 2008, 28(9):4313-4322. |
[李双成, 赵志强, 高江波. 基于空间小波变换的生态地理界线识别与定位. 生态学报, 2008, 28(9):4313-4322.] | |
[58] | Hong Tao, Guo Yan, Wu Chengzhen, et al. The research of the projection pursuit method for the physical geography boundary. Journal of Mountain Science, 2008, 26(6):665-671. |
[洪滔, 郭妍, 吴承祯, 等. 自然地理界线判别的投影寻踪技术. 山地学报, 2008, 26(6):665-671.] | |
[59] | Gómez Álvarez L, Bennett B. Classification, Individuation and Demarcation of Forests: Formalising the multi-faceted semantics of geographic terms. 13th International Conference on Spatial Information Theory 2017, 2017. |
[60] |
Wang Jinfeng, Xu Chengdong. Geodetector: Principle and prospective. Acta Geographica Sinica, 2017, 72(1):116-134.
doi: 10.11821/dlxb201701010 |
[王劲峰, 徐成东. 地理探测器: 原理与展望. 地理学报, 2017, 72(1):116-134.] | |
[61] |
Dong Yuxiang, Xu Qian, Yang Ren, et al. Delineation of the northern border of the tropical zone of China's mainland using Geodetector. Acta Geographica Sinica, 2017, 72(1):135-147.
doi: 10.11821/dlxb201701011 |
[董玉祥, 徐茜, 杨忍, 等. 基于地理探测器的中国陆地热带北界探讨. 地理学报, 2017, 72(1):135-147.] | |
[62] | Li Shuangcheng. On Paradigms of Physical Geography. Beijing: Science Press, 2013. |
[李双成. 自然地理学研究范式. 北京: 科学出版社, 2013.] |
