基于收入群体差异的北京典型郊区低收入居民的行为空间困境

doi:10.11821/dlxb201710004

摘要/Abstract

摘要：

既有低收入居民空间困境的研究以居住空间研究为主,关注低收入者受到的住房与社区隔离,难以刻画低收入者在整日尺度面临的时空制约。行为空间作为行为地理学与时间地理学的重要概念,为描述低收入居民在日常生活中面临的移动性与可达性相关的问题提供了有力的工具。本文提出利用潜在活动空间和实际活动空间共同描述居民行为空间,分析低收入居民在时空可达性和实际利用城市空间能力上的劣势。基于2012年北京市上地—清河居民活动与出行日志,利用路网分析、最小多边形分析等方法刻画居民每日的潜在活动空间和实际活动空间。通过对不同收入群体的比较,发现低收入居民比其他居民的潜在活动空间和实际活动空间都要小。进一步构建模型分析潜在活动空间和实际活动空间的影响因素,发现包括收入在内的个体社会经济属性、空间属性和行为属性对潜在活动空间和实际活动空间存在影响,但是二者的影响因素存在差异。对行为空间的测量有利于增进对于不同群体社会分异与空间隔离的认知,对未来的研究具有重要的意义。

关键词: 时间地理学, 潜在活动空间, 实际活动空间, 群体差异, 北京

Abstract:

How low-income residents suffer from spatial inequality has attracted significant attention in urban geography and urban planning. Although most research related to this question has addressed spatial segregation and spatial dilemmas in the context of residential neighborhoods, an increasing number of studies have focused on inequality in daily activity and travel behaviors. Particularly in a modern society with high mobility, behavior space is believed to be a good index for measuring spatial inequality among different social groups. In this paper, we use a behavior space approach to study spatial inequality among income groups. The study area is Shangdi-Qinghe, which is an inner suburban region with mixed social groups and neighborhoods. Using a GPS-facilitated activity diary completed in Beijing in 2012, we calculate individuals' daily potential path areas and activity spaces by using network analysis tools and minimum polygon tools in ArcGIS 10.2. We compare the sizes of daily potential path areas and activity spaces among income groups and find that compared with other social groups, low-income residents have smaller daily potential path areas and smaller activity spaces. This result indicates that such residents suffer from both an accessibility dilemma and disadvantages in mobility. By constructing a regression model, we find that socio-economy, urban form and activity factors have significant impact on behavior spaces. Middle- and low-income single residents have relatively small daily potential path areas and activity spaces. Women, older residents, and those who do not live in danwei neighborhoods and residents who work in local areas have relatively small activity spaces. Activity space and daily potential path area are both positively related to facility density around one's home, while activity space is negatively related to facility density around one's workplace. Residents who live far from railway stations and work near railway stations have relatively small activity spaces. Working hours have a significant negative impact on both daily potential path area and activity space. Space-time constraints significantly affect daily potential path area. Certain planning applications of these findings are discussed.

Key words: time geography, daily potential path area, activity space, group differentiation, Beijing

塔娜, 柴彦威. 基于收入群体差异的北京典型郊区低收入居民的行为空间困境[J]. 地理学报, 2017, 72(10): 1776-1786.

Na TA, Yanwei CHAI. Spatial dilemma of suburban low-income residents: An analysis of behavior space among different income groups[J]. Acta Geographica Sinica, 2017, 72(10): 1776-1786.

图/表 9

图1

表1

图2

图3

图4

图5

图6

图7

表2

参考文献 42

[1]	Liu Lin, Yang Gangbin, He Shenjing.Housing differentiation in low-income neighbourhoods in large Chinese cities under market transition. Scientia Geographica Sinica, 2014, 34(8): 897-906.
	[柳林, 杨刚斌, 何深静. 市场转型期中国大城市低收入社区住房分异研究. 地理科学, 2014, 34(8): 897-906.]
[2]	Huang Youqin.Low-income housing in Chinese cities: Policies and practices. The China Quarterly, 2012, 212: 941-964 doi: 10.1017/S0305741012001270
[3]	He Shenjing, Liu Yuting, Wu Fulong, et al.Poverty concentration and determinants in low-income neighbourhoods and social groups in Chinese large cities. Acta Geographica Sinica, 2010, 65(12): 1464-1475. doi: 10.1111/j.1468-2427.2010.00907.x
	[何深静, 刘玉亭, 吴缚龙, 等. 中国大城市低收入邻里及其居民的贫困集聚度和贫困决定因素. 地理学报, 2011, 65(12): 1464-1475.] doi: 10.1111/j.1468-2427.2010.00907.x
[4]	Chen Li, Zhang Wenzhong, Dang Yunxiao, et al.The spatial distribution, transition and residential pattern of low-income residents in Beijing. Geographical Research, 2012, 31(4): 720-732. doi: 10.11821/yj2012040014
	[谌丽, 张文忠, 党云晓, 等. 北京市低收入人群的居住空间分布、演变与聚居类型. 地理研究, 2012, 31(4): 720-732.] doi: 10.11821/yj2012040014
[5]	Wang Yaping.Low-income communities and urban poverty in China. Urban Geography, 2013, 26(3): 222-242. doi: 10.2747/0272-3638.26.3.222
[6]	Liu Zhilin, Liao Lu, Niu Chenlin.Residential satisfaction of community social capital: An empirical study of middle and low income residents in urban Beijing. Human Geography, 2015, 30(3): 21-27.
	[刘志林, 廖露, 钮晨琳. 社区社会资本对居住满意度的影响: 基于北京市中低收入社区调查的实证分析. 人文地理, 2015, 30(3): 21-27.]
[7]	Li Xinyi, Li Zhigang.A study on residents' neighborhood interaction in affordable housing community of Guangzhou, China. Journal of South China Normal University (Natural Science Edition), 2015, 47(2): 108-114.
	[李欣怡, 李志刚. 中国大城市保障性住房社区的“邻里互动”研究: 以广州为例.华南师范大学学报(自然科学版), 2015, 47(2): 108-114.]
[8]	Saegert S, Winkel G, Swartz C.Social capital and crime in New York City's low-income housing. Housing Policy Debate, 2002, 13(1): 189-226. doi: 10.1080/10511482.2002.9521439
[9]	Farber S, O' Kelly M, Miller HJ, et al. Measuring segregation using patterns of daily travel behavior: A social interaction based model of exposure. Journal of Transport Geography, 2015, 49: 26-38. doi: 10.1016/j.jtrangeo.2015.10.009
[10]	Li Fei, Wang Donggen. Measuring urban segregation based on individuals’ daily activity patterns: A multidimensional approach. Environment and Planning A.2016. doi: 0308518X16673213. doi: 10.1177/0308518X16673213
[11]	Ta Na, Chai Yanwei, Kwan Mei-Po.Suburbanization, daily lifestyle and space-behavior interaction in Beijing. Acta Geographica Sinica, 2015, 70(8): 1271-1280. doi: 10.11821/dlxb201508007
	[塔娜, 柴彦威, 关美宝. 北京郊区居民日常生活方式的行为测度与空间—行为互动. 地理学报, 2015, 70(8): 1271-1280.] doi: 10.11821/dlxb201508007
[12]	Wang Donggen, Li Fei, Chai Yanwei.Activity spaces and sociospatial segregation in Beijing. Urban Geography, 2012, 33(2): 256-277. doi: 10.2747/0272-3638.33.2.256
[13]	Schönfelder S, Axhausen KW.Activity spaces: measures of social exclusion? Transport policy, 2003, 10(4): 273-286. doi: 10.1016/j.tranpol.2003.07.002
[14]	Wong D W S, Shaw Shih-Lung. Measuring segregation: An activity space approach. Journal of Geographical Systems, 2011, 13(2): 127-145. doi: 10.1007/s10109-010-0112-x pmid: 3106997
[15]	Kwan Mei-Po.Gender and individual access to urban opportunities: A study using space-time measures. The Professional Geographer, 2000, 51(2): 210-227. doi: 10.1111/0033-0124.00158
[16]	Miller HJ.Measuring space-time accessibility benefits within transportation networks: Basic theory and computational procedures. Geographical Analysis, 1999, 31(1): 1-26. doi: 10.1111/j.1538-4632.1999.tb00408.x
[17]	Kim H-M, Kwan Mei-Po.Space-time accessibility measures: A geocomputational algorithm with a focus on the feasible opportunity set and possible activity duration. Journal of Geographical Systems, 2003, 5(1): 71-91. doi: 10.1007/s101090300104
[18]	Weber J, Kwan Mei-Po.Evaluating the effects of geographic contexts on individual accessibility: A multilevel approach. Urban Geography, 2003, 24(8): 647-671. doi: 10.2747/0272-3638.24.8.647
[19]	Hawthorne T L, Kwan Mei-Po.Using GIS and perceived distance to understand the unequal geographies of healthcare in lower-income urban neighbourhoods. The Geographical Journal, 2012, 178(1): 18-30. doi: 10.1111/j.1475-4959.2011.00411.x pmid: 22400154
[20]	Golledge R G, Stimson R J.Spatial Behaviour: A Geographic Perspective. New York, 1997.
[21]	Dharmowijoyo D B E, Susilo Y O, Karlström A. Day-to-day interpersonal and intrapersonal variability of individuals' activity spaces in a developing country. Environment and Planning B: Planning and Design, 2014, 41(6): 1063-1076. doi: 10.1068/b130067p
[22]	Buliung R N, Kanaroglou P S.Urban form and household activity-travel behavior. Growth and Change, 2006, 37(2): 172-199. doi: 10.1111/j.1468-2257.2006.00314.x
[23]	Fan Yingling, Khattak A.Urban form, individual spatial footprints, and travel: Examination of space-use behavior. Transportation research record: Journal of the Transportation Research Board, 2008, (2082): 98-106. doi: 10.3141/2082-12
[24]	Zenk S N, Schulz A J, Matthews S A, et al.Activity space environment and dietary and physical activity behaviors: A pilot study. Health & Place, 2011, 17(5): 1150-1161. doi: 10.1016/j.healthplace.2011.05.001 pmid: 21696995
[25]	Patterson Z, Farber S.Potential path areas and activity spaces in application: A review. Transport Reviews, 2015, 35(6): 679-700. doi: 10.1080/01441647.2015.1042944
[26]	Liu Zhilin, Wang Maojun.Job accessibility and its impacts on commuting time of urban residents in Beijing: From a spatial mismatch perspective. Acta Geographica Sinica, 2011, 66(4): 457-467. doi: 10.11821/xb201104003
	[刘志林, 王茂军. 北京市职住空间错位对居民通勤行为的影响分析: 基于就业可达性与通勤时间的讨论. 地理学报, 2011, 66(4): 457-467.] doi: 10.11821/xb201104003
[27]	Song Jinping, Wang Enru, Zhang Wenxin, et al.Housing suburbanization and employment spatial mismatch in Beijing. Acta Geographica Sinica, 2007, 62(4): 387-396. doi: 10.3321/j.issn:0375-5444.2007.04.005
	[宋金平, 王恩儒, 张文新, 等. 北京住宅郊区化与就业空间错位. 地理学报, 2007, 62(4): 387-396.] doi: 10.3321/j.issn:0375-5444.2007.04.005
[28]	Zhou Suhong, Chen Luping, Wu Zhidong.The jobs-housing relocation and spatial matching of residents in alleviatory housing neighborhoods in Guangzhou. Geographical Research, 2010, 29(10): 1735-1745. doi: 10.11821/yj2010100002
	[周素红, 程璐萍, 吴志东. 广州市保障性住房社区居民的居住—就业选择与空间匹配性. 地理研究, 2010, 29(10): 1735-1745.] doi: 10.11821/yj2010100002
[29]	Li Xiaoguang, Qiu Daochi, Li Feng, et al.Matching analysis of the job and residence space of residents in the public rental housing community in Chongqing. Geographical Research, 2013, 32(8): 1457-1466.
	[李小广, 邱道持, 李凤, 等. 重庆市公共租赁住房社区居民的职住空间匹配. 地理研究, 2013, 32(8): 1457-1466.]
[30]	Zhou Suhong, Wu Zhidong, Cheng Luping.The impact of spatial mismatch on residents in low-income housing neighbourhoods: A study of the Guangzhou metropolis, China. Urban Studies, 2013, 50(9): 1817-1835. doi: 10.1177/0042098012465906
[31]	Gan Di, Wang De, Zhu Wei.Research on the residents' commuting feature of large-scale residential district in suburban Shanghai: A case study of Gucun, Baoshan District. Geographical Research, 2015, 34(8): 1481-1491. doi: 10.11821/dlyj201508007
	[干迪, 王德, 朱玮. 上海市近郊大型社区居民的通勤特征: 以宝山区顾村为例. 地理研究, 2015, 34(8): 1481-1491.] doi: 10.11821/dlyj201508007
[32]	Zhang Yan, Chai Yanwei.The spatio-temporal activity pattern of the middle and the low-income residents in Beijing, China. Scientia Geographica Sinica, 2011, 31(9): 1056-1064.
	[张艳, 柴彦威. 北京城市中低收入者日常活动时空间特征分析. 地理科学, 2011, 31(9): 1056-1064.]
[33]	Meng Qingjie, Qiao Guanmin.A research on floating populaiton's life quality in the view of leisure in metropolis. Urban Studies, 2010, 17(5): 4-7.
	[孟庆洁, 乔观民. 闲暇视角的大城市流动人口生活质量研究. 城市发展研究, 2010, 17(5): 4-7.]
[34]	Zhou Pei, Zhu Xigang, Ma Guoqiang.Policies and travel issues of low-income urban residents: A case study in Nanjing. Urban Problems, 2013(3): 68-72.
	[周配, 朱喜钢, 马国强. 城市低收入群体的出行问题及其解决对策: 以南京市为例. 城市问题, 2013(3): 68-72.]
[35]	Lv Bin, Zhang Chun, Chen Tianming.Study on changes in job accessibility for the urban low-income: A case study of Beijing. Urban Planning Review, 2013, 37(1): 56-63.
	[吕斌, 张纯, 陈天鸣. 城市低收入群体的就业可达性变化研究: 以北京为例. 城市规划, 2013, 37(1): 56-63.]
[36]	Hägerstrand T.What about people in regional science? Papers in Regional Science, 1970, 24(1): 7-24. doi: 10.1007/BF01936872
[37]	Fang Zhixiang, Tu Wei, Li Qingquan, et al.A multi-objective approach to scheduling joint participation with variable space and time preferences and opportunities. Journal of Transport Geography, 2011, 19(4): 623-634. doi: 10.1016/j.jtrangeo.2010.06.019
[38]	Chen Biyu, Li Qingquan, Wang Donggen, et al.Reliable space-time prisms under travel time uncertainty. Annals of the Association of American Geographers, 2013, 103(6): 1502-1521. doi: 10.1080/00045608.2013.834236
[39]	Kwan Mei-Po, Kotsev A.Gender differences in commute time and accessibility in Sofia, Bulgaria: A study using 3D geovisualisation. The Geographical Journal, 2015, 181(1): 83-96. doi: 10.1111/geoj.12080
[40]	Tana, Kwan Mei-Po, Chai Yanwei. Urban form, car ownership and activity space in inner suburbs: A comparison between Beijing (China) and Chicago (United States). Urban Studies, 2016, 53(9): 1784-1802. doi: 10.1177/0042098015581123
[41]	Buliung R N, Remmel T K.Open source, spatial analysis, and activity-travel behaviour research: Capabilities of the aspace package. Journal of Geographical Systems, 2008, 10(2): 191-216. doi: 10.1007/s10109-008-0063-7
[42]	Feng Jianxi, Dijst M, Wissink B, et al.The impacts of household structure on the travel behaviour of seniors and young parents in China. Journal of Transport Geography, 2013, 30: 117-126. doi: 10.1016/j.jtrangeo.2013.03.008

变量		样本数	频率(%)
性别	男性	111	45.83
	女性	132	54.17
年龄		36.24
户口	非北京户口	32	13.22
	北京户口	211	86.78
个人月收入(元)	≤ 2000	30	12.50
	2001~4000	91	37.50
	4001~6000	55	22.50
	6001~10000	44	17.92
	10001~15000	9	3.75
	>15000	14	5.83
教育程度	高中及以下	30	14.33
	大专或大学	146	68.75
	研究生及以上	67	17.92
住房产权	自有住房	31	87.08
	租住住房	212	12.92
汽车所有权	有小汽车	148	60.83
	无小汽车	95	39.17

	模型1：潜在活动空间			模型2：实际活动空间
	系数		显著性	系数	显著性
个人月收入(参考变量：高收入)
低收入	-341.09	0.023		-83.42	0.005
中收入	-195.40	0.041		-111.56	0.000
女性(参考变量：男性)	-73.13	0.369		-14.30	0.009
年龄	-0.92	0.880		-0.97	0.020
家庭结构(参考变量：单身)
已婚无小孩	270.85	0.071		20.82	0.040
已婚有小孩核心家庭	253.78	0.090		13.68	0.174
已婚有小孩扩展家庭	248.25	0.130		18.48	0.096
住在单位社区	-18.52	0.845		12.37	0.053
家周边设施密度	3.60	0.013		0.21	0.031
工作地周边设施密度	-2.85	0.042		-0.14	0.140
家到地铁站的距离	24.70	0.656		-9.63	0.010
工作地到地铁站的距离	-41.31	0.177		3.51	0.089
本地就业	127.13	0.165		-24.27	0.000
工作时间	-0.56	0.090		-0.26	0.000
收入×工作时间				0.13	0.060
收入×工作时间				0.21	0.000
空间固定性	56.93	0.002
时间固定性	-154.77	0.000
截距	1504.15	0.000		202.01	0.000
R²	0.1557			0.1897
