基于公路客流的中国城市网络结构与空间组织模式

doi:10.11821/dlxb201702004

地理学报 ›› 2017, Vol. 72 ›› Issue (2): 224-241.doi: 10.11821/dlxb201702004

基于公路客流的中国城市网络结构与空间组织模式

陈伟^1,²(), 刘卫东¹(), 柯文前³, 王女英⁴

1. 中国科学院地理科学与资源研究所中国科学院区域可持续发展分析与模拟重点实验室,北京 100101
2. 中国科学院大学,北京 100049
3. 福建师范大学地理研究所,福州 350007
4. 北京大学城市与环境学院,北京 100871

收稿日期:2016-05-28 修回日期:2016-09-26 出版日期:2017-02-15 发布日期:2017-02-15
作者简介:
作者简介：陈伟(1989-), 男, 安徽淮南人, 博士生, 主要研究方向为经济地理与区域发展。E-mail: geochw@163.com
基金资助:
国家自然科学基金项目(41530751, 41471113);福建省自然科学基金项目(2016J05093)

The spatial structures and organization patterns of China's city networks based on the highway passenger flows

Wei CHEN^1,²(), Weidong LIU¹(), Wenqian KE³, Nvying WANG⁴

1. Institute of Geographic Sciences and Natural Resources Research, Key Laboratory of Regional Sustainable Development Modeling, CAS, Beijing 100101, China
2. University of Chinese Academy of Sciences, Beijing 100049, China
3. Institute of Geography, Fujian Normal University, Fuzhou 350007, China
4. College of Urban and Environmental Sciences, Peking University, Beijing 100871, China

Received:2016-05-28 Revised:2016-09-26 Published:2017-02-15 Online:2017-02-15
Supported by:
National Natural Science Foundation of China, No.41530751, No.41471113;Natural Science Foundation of Fujian Province, No.2016J05093

摘要/Abstract

摘要：

多视角和多尺度城市网络逐渐成为认识空间关系的主要途径。公路流数据具有显著的空间依赖性和距离衰减特性,对于刻画区域尺度空间关系具有重要意义。基于全国地级行政单元间的公路客运流,论文尝试刻画中国城市网络功能结构和区域效应,并对其空间组织模式进行特征提取和规律挖掘,以期能够为城市网络研究提供新的方法支撑和认知视角。研究结果表明：① 基于公路流的城市网络空间形态表现出强烈的空间依赖性和层级特征,与中国主要城市群分布存在较大程度的空间耦合,更多体现的是区域尺度的空间关系及核心—外围组合关系;② 通过社区发现算法识别出19个城市经济区,其空间内涵主要包括行政区经济、巨型区域溢出效应和核心—边缘结构等;③ 不同地域系统内城市网络自成体系,表现出显著的空间依赖性和多元的空间组织模式,多层次、流动性和网络化的地域系统格局凸显;④ 从空间形态上看,区域城市网络空间结构大致可划分为单中心结构、双核心结构、多中心结构和低水平均势结构等区域关联形态,并以单中心发育模式为主。

关键词: 城市网络, 城市经济区, 城市体系, 区域划分, 单中心结构, 多中心结构, 社区发现, 中国

Abstract:

The multi-level perspective and multi-scalar city network have gradually become the critical pathways to understand spatial interactions and linkages. The road linkages represent distinguished characteristics of spatial dependence and distance decay, which is of great significance in depicting spatial relationships at regional scale. Based on the data of highway passenger flows between prefecture-level administrative units, this paper tries to identify the functional structures and regional impacts of China's city network, and further explores the spatial organization patterns of the existing functional regions, aiming to deepen the understanding of city network structure and provide new cognitive perspectives for the extant research. The empirical results are shown as follows: (1) It is immediately visible that the highway flows are extremely concentrated on the mega-regions of eastern coastal China and major economic zones in central and western China. And city networks based on highway flows demonstrate strong spatial dependence and hierarchical characteristics, which to a large extent has spatial coupling with the distributions of major mega-regions in China. It is a reflection of spatial relationships at regional scale and core-periphery structure. (2) A total of 19 communities that belong to important spatial configurations are identified through community detection algorithm, and we believe that they are urban economic regions within urban China. Their spatial metaphors can be concluded in three aspects. Firstly, many communities have the same boundaries with provincial level administrative units, which reveals that significant administrative region economy still exists in contemporary China. Secondly, trans-provincial linkages can be formed through spatial spillover effects of mega-regions within specific communities. Thirdly, cities located in the marginal areas of provinces and attracted by powerful center cities in neighboring provinces may become increasingly disconnected with their own provinces and be enrolled into communities of neighboring provinces, which make contribution to the formation of the trans-provincial core-periphery structures. (3) Each community, with its distinguished city network system, demonstrates strong spatial dependence and various spatial organization patterns. Regional patterns have emerged with the features of a multi-level, dynamic and networked system. (4) From the morphology perspective, the spatial pattern of regional city networks can be basically divided into monocentric structure, dual-nuclei structure, polycentric structure and low-level equilibration structure, with the monocentric structure as the major type.

Key words: city network, urban economic region, urban system, regional division, monocentric structure, polycentric structure, community detection, China

陈伟, 刘卫东, 柯文前, 王女英. 基于公路客流的中国城市网络结构与空间组织模式[J]. 地理学报, 2017, 72(2): 224-241.

Wei CHEN, Weidong LIU, Wenqian KE, Nvying WANG. The spatial structures and organization patterns of China's city networks based on the highway passenger flows[J]. Acta Geographica Sinica, 2017, 72(2): 224-241.

图/表 8

图1

图2

图3

图4

图5

图6

图7

图8

参考文献 32

[1]	Taylor P J, Hoyler M, Verbruggen R.External urban relational process: Introducing central flow theory to complement central place theory. Urban Studies, 2010, 47(13): 2803-2818. doi: 10.1177/0042098010377367
[2]	Castells M.Globalisation, networking, urbanisation: Reflections on the spatial dynamics of the information age. Urban Studies, 2010, 47(13): 2737-2745. doi: 10.1177/0042098010377365
[3]	Liu Weidong, Zhen Feng.Spatial implications of new information and communication technologies. Acta Geographica Sinica, 2004, 59(Suppl.): 67-76. doi: 10.3321/j.issn:0375-5444.2004.z1.010
	[刘卫东, 甄峰. 信息化对社会经济空间组织的影响研究. 地理学报, 2004, 59(增刊): 67-76.] doi: 10.3321/j.issn:0375-5444.2004.z1.010
[4]	Gao Xin, Xiu Chunliang, Wei Ye.Study on the sinicization of "Space of Flows" basing on the visual angle of urban geography. Human Geography, 2012, 27(4): 32-36.
	[高鑫, 修春亮, 魏冶. 城市地理学的“流空间”视角及其中国化研究. 人文地理, 2012, 27(4): 32-36.]
[5]	Camagni R, Capello R.The city network paradigm: Theory and empirical evidence//Capello R, Nijkamp P. Urban Dynamics and Growth: Advances in Urban Economics. Amsterdam: Elsevier, 2004: 495-529.
[6]	Lu Minghua.The development of urban networks in Randstad Holland. Urban Planning International, 2010, 25(6): 53-58. doi: 10.3969/j.issn.1673-9493.2010.06.009
	[卢明华. 荷兰兰斯塔德地区城市网络的形成与发展. 国际城市规划, 2010, 25(6): 53-58.] doi: 10.3969/j.issn.1673-9493.2010.06.009
[7]	Taylor P J, Catalano G, Walker D R F. Measurement of the world city network. Urban Studies, 2002, 39(13): 2367-2376. doi: 10.1080/00420980220080011
[8]	Taylor P J, Evans D M, Hoyler M, et al.The UK space economy as practised by advanced producer service firms: Identifying two distinctive polycentric city-regional processes in contemporary Britain. International Journal of Urban and Regional Research, 2009, 33(3): 700-718. doi: 10.1111/j.1468-2427.2009.00857.x
[9]	Hoyler M, Kloosterman R C, Sokol M.Polycentric puzzles-emerging mega-city regions seen through the lens of advanced producer services. Regional Studies, 2008, 42(8): 1055-1064. doi: 10.1080/00343400802389377
[10]	Malecki E J.The economic geography of the Internet's infrastructure. Economic Geography, 2002, 78(4): 399-424. doi: 10.1111/j.1944-8287.2002.tb00193.x
[11]	Derudder B, Witlox F.Mapping world city networks through airline flows: Context, relevance, and problems. Journal of Transport Geography, 2008, 16(5): 305-312. doi: 10.1016/j.jtrangeo.2007.12.005
[12]	Alderson A S, Beckfield J.Power and position in the world city system. American Journal of sociology, 2004, 109(4): 811-851. doi: 10.1086/378930
[13]	Beaverstock J V, Smith J.Lending jobs to global cities: Skilled international labour migration, investment banking and the city of London. Urban Studies, 1996, 33(8): 1377-1394.
[14]	Taylor P J.The new geography of global civil society: NGOs in the world city network. Globalizations, 2004, 1(2): 265-277. doi: 10.1080/1474773042000308604
[15]	Ma Xueguang, Li Guicai.Research methods for world city network and relevant inspirations. Progress in Geography, 2012, 31(2): 255-263. doi: 10.11820/dlkxjz.2012.02.015
	[马学广, 李贵才. 世界城市网络研究方法论. 地理科学进展, 2012, 31(2): 255-263.] doi: 10.11820/dlkxjz.2012.02.015
[16]	Yu Taofang, Gu Chaolin, Li Zhigang.China's urban systems in terms of air passenger and cargo flows since 1995. Geographical Research, 2008, 27(6): 1407-1418. doi: 10.1016/S1872-5791(08)60058-5
	[于涛方, 顾朝林, 李志刚. 1995年以来中国城市体系格局与演变: 基于航空流视角. 地理研究, 2008, 27(6): 1407-1418.] doi: 10.1016/S1872-5791(08)60058-5
[17]	Zhong Yexi, Lu Yuqi.Hierarchical structure and distribution pattern of Chinese urban system based on railway network. Geographical Research, 2011, 30(5): 785-794. doi: 10.11821/yj2011050002
	[钟业喜, 陆玉麒. 基于铁路网络的中国城市等级体系与分布格局. 地理研究, 2011, 30(5): 785-794.] doi: 10.11821/yj2011050002
[18]	Zhao Miaoxi, Liu Zheng.Research on China's city network based on production service industry. City Planing Review, 2012, 36(9): 23-28, 38.
	[赵渺希, 刘铮. 基于生产性服务业的中国城市网络研究. 城市规划, 2012, 36(9): 23-28, 38.]
[19]	Wang Cheng, Wang Maojun, Chai Qing.The relationship between centrality and power in the city network. Acta Geographica Sinica, 2015, 70(12): 1953-1972.
	[王成, 王茂军, 柴箐. 城市网络地位与网络权力的关系: 以中国汽车零部件交易链接网络为例. 地理学报, 2016, 70(12): 1953-1972.]
[20]	Zhen Feng, Wang Bo, Chen Yingxue.China's city network characteristics based on social network space: An empirical of sina micro-blog. Acta Geographica Sinica, 2012, 67(8): 1031-1043. doi: 10.1007/s11783-011-0280-z
	[甄峰, 王波, 陈映雪. 基于网络社会空间的中国城市网络特征: 以新浪微博为例. 地理学报, 2012, 67(8): 1031-1043.] doi: 10.1007/s11783-011-0280-z
[21]	Dong Chao, Xiu Chunliang, Wei Ye.Network structure of 'space of flows' in Jilin Province based on telecommunication flows. Acta Geographica Sinica, 2014, 69(4): 510-519. doi: 10.11821/dlxb201404007
	[董超, 修春亮, 魏冶. 基于通信流的吉林省流空间网络格局. 地理学报, 2014, 69(4): 510-519.] doi: 10.11821/dlxb201404007
[22]	Chen Wei, Xiu Chunliang, Ke Wenqian, et al.Hierarchical structures of China's city network from the perspective of multiple traffic flows. Geographical Research, 2015, 34(11): 2073-2083. doi: 10.11821/dlyj201511006
	[陈伟, 修春亮, 柯文前, 等. 多元交通流视角下的中国城市网络层级特征. 地理研究, 2015, 34(11): 2073-2083.] doi: 10.11821/dlyj201511006
[23]	Girvan M, Newman M E J. Community structure in social and biological networks. Proceedings of the National Academy of Sciences, 2002, 99(12): 7821-7826. doi: 10.1073/pnas.122653799 pmid: 12060727
[24]	Pons P, Latapy M.Computing communities in large networks using random walks. Journal of Graph Algorithms and Applications, 2006, 10(2): 191-218.
[25]	Clauset A, Newman M E J, Moore C. Finding community structure in very large networks. Physical Review E, 2004, 70(6): 066111.
[26]	Blondel V D, Guillaume J L, Lambiotte R, et al.Fast unfolding of communities in large networks. Journal of Statistical Mechanics: Theory and Experiment, 2008, 2008(10): P10008.
[27]	Raghavan U N, Albert R, Kumara S.Near linear time algorithm to detect community structures in large-scale networks. Physical Review E, 2007, 76(3): 036106. doi: 10.1103/PhysRevE.76.036106 pmid: 17930305
[28]	Rosvall M, Bergstrom C T.Maps of random walks on complex networks reveal community structure. Proceedings of the National Academy of Sciences, 2008, 105(4): 1118-1123.
[29]	Lancichinetti A, Fortunato S.Community detection algorithms: A comparative analysis. Physical Review E, 2009, 80(5): 056117.
[30]	Zhong C, Arisona S M, Huang X, et al.Detecting the dynamics of urban structure through spatial network analysis. International Journal of Geographical Information Science, 2014, 28(11): 2178-2199. doi: 10.1080/13658816.2014.914521
[31]	Gu Chaolin.A preliminary study on the division of urban economic regions in China. Acta Geographica Sinica, 1991, 46(2): 129-141. doi: 10.11821/xb199102001
	[顾朝林. 中国城市经济区划分的初步研究. 地理学报, 1991, 46(2): 129-141.] doi: 10.11821/xb199102001
[32]	Zhou Yixing, Zhang Li.China's urban economic region in the open context. Acta Geographica Sinica, 2003, 58(2): 271-284. doi: 10.3321/j.issn:0375-5444.2003.02.015
	[周一星, 张莉. 改革开放条件下的中国城市经济区. 地理学报, 2003, 58(2): 271-284.] doi: 10.3321/j.issn:0375-5444.2003.02.015
