高铁网络化下中国城市旅游场强空间格局及演化

doi:10.11821/dlxb201610010

摘要/Abstract

摘要：

交通是旅游系统不可或缺的先决条件。“四纵四横”高铁网络是中国“交通革命”的重要里程碑,高铁网络化对中国城市旅游可达性空间格局产生重要影响,进而极大地改变城市的旅游吸引力和辐射力。本文运用GIS空间分析方法测度高铁对全国338个城市可达性影响,进而分析高铁网络化全国城市旅游吸引力空间特征及演变。结果表明：① 高铁网络化下中国城市可达性整体得到优化,可达性空间格局呈现明显交通指向性,形成“高铁廊道”效应;② 高铁网络化下中国城市旅游场强空间格局呈现出“多中心”环状发散和“枝状”扩散的双重特征,尤其是沿高铁线“枝状”扩散更为明显;城市旅游场强变化率在高铁线形成高值走廊,并呈现以高铁轴线为中心向外围递减的空间格局;③ 高铁对高旅游场强区和较高旅游场强区影响最为显著,分布城市数量大幅增加,面积拓展超过100%;且高铁提升了区域中心城市旅游场强值,旅游吸引力辐射范围沿高铁线扩张。

关键词: 高铁网络化, 旅游场强, 空间格局, 演化, 中国

Abstract:

Traffic is an indispensable prerequisite for tourism system. The high speed rail network of "four vertical and four horizontal" is an important milestone of "traffic revolution" in China, which will produce important effect on the spatial pattern of tourism accessibility in Chinese cities, and then change the tourism attraction force and radiation force of cities greatly. The paper analyzes the evolution and spatial characteristics of tourism attraction force of cities under high speed rail network in China, based on the measurements of the influence of accessibility of 338 cities under HSR with the help of GIS. The results show that: (1) the accessibilities of Chinese cities are optimized under high speed rail network. The spatial pattern of accessibilities presents obvious traffic direction and forms the “high speed rail corridor” effect. (2) The spatial pattern of tourism field strength in Chinese cities presents the dual characteristics of the "multi-center" annular divergence and "dendritic" diffusion, especially "dendritic" diffusion is more obvious along high speed rails; The change rate of urban tourism field strength forms the high value corridor along high speed rails and presents the spatial pattern of decreasing from the center to the outer circumference along high speed rails. (3) The influence of the highest tourism field strength area and higher tourism field strength area under high speed rails is most significant, and the number of cities distributed in two types of tourism field strength increases significantly, the area of the two types of tourism field strength expands more than 100%; high speed rails enhance the tourism field strength value of regional central cities, and radiation range of tourism attraction extends along high speed rails.

Key words: high speed rail network, tourism field strength, spatial pattern, evolution, China

汪德根, 钱佳, 牛玉. 高铁网络化下中国城市旅游场强空间格局及演化[J]. 地理学报, 2016, 71(10): 1784-1800.

WANG Degen,QIAN Jia,NIU Yu. Evolution and spatial characteristics of tourism field strength of cities under high speed rail network in China[J]. Acta Geographica Sinica, 2016, 71(10): 1784-1800.

图/表 14

图1

表1

图2

表2

图3

图4

表3

图5

表4

表5

图6

图7

表6

表7

参考文献 28

[1]	Li Xiaojian. Economic Geography.Beijing: Higher Education Press, 1999: 200-214.
	[李小建. 经济地理学. 北京: 高等教育出版社, 1999: 200-214.]
[2]	Prideaux B.The role of the transport system in destination development. Tourism Management, 2000, 21(3): 53-63. doi: 10.1016/S0261-5177(99)00079-5
[3]	Kaul R N.Dynamics of Tourism: A Trilogy Transportation and Marketing. New Delhi: Sterling Publishers, 1985.
[4]	Leiper N.Tourist attraction systems. Annals of Tourism Research, 1990, 17(4): 33-45.
[5]	Gilbert E W.The growth of inland and seaside health resorts in England. The Scottish Geographical Magazine, 1939, 55(1): 16-35. doi: 10.1080/00369223908735100
[6]	Nelson R, Wall G.Transport and accommodation changing interrelation ships on Vancouver Island. Annals of Tourism Research, 1986, 13(2): 239-260.
[7]	Prideaux B.Possible elects of new transport technologies on the tourism industry in the 21st century. Papers of the Australasian Transport Research Forum, Graduate School of Management. The University of Queensland, 1993, 18: 245-258.
[8]	Chew J.Transport and tourism in the year 2000. Tourism Management, 1987, 8(2): 83-85. doi: 10.1016/0261-5177(87)90003-3
[9]	Abeyratne R I R. Air transport tax and its consequences on tourism. Annals of Tourism Research, 1993, 20(2): 450-460. doi: 10.1016/0160-7383(93)90002-K
[10]	Wang Degen, Niu Yu, Wang Li.Influence of high-speed rail on choices of tourist destination based on the gravity model: Case study of Beijing-Shanghai high-speed rail in China. Geographical Research, 2015, 34(9): 1770-1780. doi: 10.11821/d1yj201509014
	[汪德根, 牛玉, 王莉. 高铁对旅游者目的地选择的影响: 以京沪高铁为例. 地理研究, 2015, 34(9): 1770-1780.] doi: 10.11821/d1yj201509014
[11]	Sophie Masson, Romain Petiot.Can the high speed rail reinforce tourism attractiveness? The case of the high speed rail between Perpignan (France) and Barcelona (Spain). Technovation, 2009, 29:611-617. doi: 10.1016/j.technovation.2009.05.013
[12]	Chen Cai. The effect of SHINKANSEN to tourism in Japan. Journal of Chinese Tourism, 2011-03-04.
	[陈才. 新干线对日本旅游业的影响. 中国旅游报, 2011-03-04.]
[13]	Wang Degen.Spatial structure impacts of HSR on domestic tourism market in China. Scientia Geographica Sinica, 2013, 33(7): 797-805
	. [汪德根. 旅游地国内客源市场空间结构的高铁效应. 地理科学, 2013, 33(7): 797-805.]
[14]	Yin Ping.HSR and establishment of new pattern of regional tourism: Case study of the HSR between Zhengzhou and Xi'an. Tourism Tribune, 2012, 27(12): 47-53. doi: 10.3969/j.issn.1002-5006.2012.12.006
	[殷平. 高速铁路与区域旅游新格局构建: 以郑西高铁为例. 旅游学刊, 2012, 27(12): 47-53.] doi: 10.3969/j.issn.1002-5006.2012.12.006
[15]	Wang Degen, Qian Jia, Chen Tian, et al.Influence of the high-speed rail on the regional tourism spatial pattern. Asia Pacific Journal of Tourism Research, 2014, 19(8): 890-912. doi: 10.1080/10941665.2013.818049
[16]	Wang Xin, Zou Tongqian.Impact of the high speed network on the development and distribution of Chinese area's tourism industry. Economic Geography, 2010, 30(7): 1189-1194.
	[王欣, 邹统钎. 高速铁路网对我国区域旅游产业发展与布局的影响. 经济地理, 2010, 30(7): 1189-1194.]
[17]	Wang Degen.The impact of Wuguang HSR on regional tourism spatial pattern in Hubei province. Geographical Research, 2013, 32(8): 1555-1564. doi: 10.3969/j.issn.1673-8918.2014.18.043
	[汪德根. 武广高速铁路对湖北省区域旅游空间格局的影响. 地理研究, 2013, 32(8): 1555-1564. ] doi: 10.3969/j.issn.1673-8918.2014.18.043
[18]	Wang Degen, Chen Tian, Lu Lin, et al.Mechanism and HSR effect of spatial structure of regional tourist flow: Case study of Beijing-Shanghai HSR in China. Acta Geographica Sinica, 2015, 70(2): 213-232. doi: 10.11821/dlxb201502004
	[汪德根, 陈田, 陆林, 等. 区域旅游流空间结构的高铁效应及机理: 以中国京沪高铁为例. 地理学报, 2015, 70(2): 213-232.] doi: 10.11821/dlxb201502004
[19]	Wang Degen.Optimizing of tourist space and effect on accessibility of along metropolitan circles under Wuhan-Guangzhou HSR. Urban Development Studies, 2014, 21(9): 110-117. doi: 10.3969/j.issn.1006-3862.2014.09.016
	[汪德根. 武广高铁对沿线都市圈可达性影响及旅游空间优化. 城市发展研究, 2014, 21(9): 110-117.] doi: 10.3969/j.issn.1006-3862.2014.09.016
[20]	Liang Xuesong.Discussion on the development opportunity of tourism industry in Hunan province based on the dual location space. Economic Geography, 2010, 30(5): 859-864.
	[梁雪松. 基于双重区位空间的湖南旅游业发展机遇探讨. 经济地理, 2010, 30(5): 859-864.]
[21]	Wang Degen, Zhang Yun.The influence of high-speed railways on accessibility of Yangtze River Delta region's metropolitans. Economic Geography, 2015, 35(2): 54-61. doi: 10.15957/j.cnki.jjdl.2015.02.008
	[汪德根, 章鋆. 高速铁路对长三角地区都市圈可达性影响. 经济地理, 2015, 35(2): 54-61.] doi: 10.15957/j.cnki.jjdl.2015.02.008
[22]	Wu Kang, Fang Chuanglin.The intercity space of flow influenced by high-speed rail: A case study for the rail transit passenger behavior between Beijing and Tianjin. Acta Geographica Sinica, 2013, 68(2): 159-174. doi: 10.11821/xb201302002
	[吴康, 方创琳. 京津城际高速铁路影响下的跨城流动空间特征. 地理学报, 2013, 68(2): 159-174.] doi: 10.11821/xb201302002
[23]	Dodgson J S.Motorway investment and sub-regional growth: The case of the M62. Regional Studies, 1974, 8: 75-91.
[24]	Javier Gutiérrez.Location, economic potential and daily accessibility: An analysis of the accessibility impact of the high-speed line Madrid-Barcelona-French border. Journal of Transport Geography, 2001, 9(4): 229-242. doi: 10.1016/S0966-6923(01)00017-5
[25]	Zhang Chao, Yang Binggeng. Quantitative Geography Foundation.Beijing: Higher Education Press, 1991
	[张超, 杨秉赓. 计量地理学基础. 北京: 高等教育出版社, 1991.]
[26]	Pan Jinghu, Liu Weisheng, Yin Jun.Evolution and urban hinterland area of cities at prefecture level or above in China. Urban Problems, 2014(6): 37-45.
	[潘竟虎, 刘伟圣, 尹君. 地级及以上城市影响腹地及其演变. 城市问题, 2014(6): 37-45.]
[27]	Yang Ben.Study on the influence to regional development under HSR [D]. Shanghai: East China Normal University, 2011.
	[杨犇. 高速铁路对区域发展的影响研究[D]. 上海: 华东师范大学, 2011.]
[28]	Wang Li, Deng Yu, Liu Shenghe, et al.The study of urban spheres of influence based on improved field model and its applications: Case study of Central China. Acta Geographca Sinica, 2011, 66(2): 189-198. doi: 10.11821/xb201102005
	[王丽, 邓羽, 刘盛和, 等. 基于改进场模型的城市影响范围动态演变: 以中国中部地区为例. 地理学报, 2011, 66(2): 189-198.] doi: 10.11821/xb201102005

空间对象	高速公路	国道	省道	水域	铁路	高铁			陆地
速度(km/h)	120	80	60	1	160	200	250	300	5
时间成本(Min)	0.5	0.75	1	60	0.375	0.3	024	0.2	12

前20位					后20位
城市		Z_i	城市	Z_i	城市	Z_i	城市	Z_i
北京	161.06	武汉	25.15		果洛	0.07	阿里	0.52
上海	76.62	南京	23.72		黄南	0.20	山南	0.65
广州	56.23	青岛	19.84		玉树	0.21	怒江	0.65
深圳	53.58	大连	19.32		克孜	0.24	阿拉善	0.68
重庆	50.20	沈阳	18.44		海北	0.33	吴忠	0.69
天津	35.26	宁波	18.42		金昌	0.37	和田	0.71
苏州	32.90	西安	18.06		七台河	0.47	中卫	0.74
杭州	32.79	长沙	18.03		大兴安岭	0.47	固原	0.74
珠海	29.28	无锡	18.01		海南(州)	0.49	嘉峪关	0.75
成都	26.41	郑州	16.35		昌都	0.50	博尔塔拉	0.76

等时圈(h)	非高铁(km²)	高铁(km²)	变化率(%)	等时圈(h)	非高铁(km²)	高铁(km²)	变化率(%)
0~0.5	345868	470327	35.98	6~10	1278643	1260835	-1.39
0.5~1	884396	950462	7.47	10~15	582401	577868	-0.78
1~1.5	1003070	998255	-0.48	15~20	265217	263301	-0.72
1.5~2	929261	904988	-2.61	20~25	135743	135100	-0.47
2~2.5	824206	794014	-3.66	25~30	51301	50975	-0. 64
2.5~3	723282	697495	-3.57	>30	8692	8692	0.00
3~6	2748062	2667989	-2.91

地带	地带			省域				城市
地带	非高铁		高铁	变化率(%)	非高铁	高铁	变化率(%)	非高铁	高铁	变化率(%)
东部	37.37	51.82	38.67	59.06	77.67	31.51		33.35	46.93	40.72
中部	15.33	22.07	43.97	18.19	28.36	55.91		19.11	30.40	59.08
西部	7.25	10.18	40.41	11.27	16.09	42.77		11.79	16.84	42.83

前10名	非高铁			高铁		后10名	非高铁			高铁
前10名	城市		场强值		城市	后10名	场强值	城市	场强值	城市	场强值
1	北京	276.69		北京	346.31	1	巴音	4.55		阿克苏	5.93
2	深圳	191.91		深圳	290.03	2	那曲	4.38		巴音郭楞	5.93
3	廊坊	128.84		天津	176.30	3	山南	4.36		那曲	5.21
4	上海	125.14		廊坊	171.56	4	阿克苏	4.34		山南	5.21
5	天津	120.69		上海	136.36	5	日喀则	4.22		克孜	5.05
6	广州	108.18		保定	118.83	6	克孜	3.87		日喀则	4.95
7	保定	86.44		广州	115.35	7	喀什	3.69		喀什	4.75
8	唐山	79.05		东莞	114.33	8	阿里	3.48		和田	4.17
9	东莞	75.30		唐山	105.97	9	和田	3.44		阿里	3.99
10	佛山	67.11		苏州	93.11	10	琼直辖	2.50		琼直辖	3.29
