地理学报 ›› 2016, Vol. 71 ›› Issue (9): 1640-1652.doi: 10.11821/dlxb201609014
李中轩1(), 吴国玺1, 朱诚2, 郑敬刚1, 李开封3, 焦士兴4
收稿日期:
2016-02-25
修回日期:
2016-04-28
出版日期:
2016-11-25
发布日期:
2016-11-25
作者简介:
作者简介:李中轩(1971-), 博士, 副教授, 中国地理学会会员(S110007772M), 主要研究方向为自然地理学。E-mail:
基金资助:
Zhongxuan LI1(), Guoxi WU1, Cheng ZHU2, Jinggang ZHENG1, Kaifeng LI3, Shixing JIAO4
Received:
2016-02-25
Revised:
2016-04-28
Published:
2016-11-25
Online:
2016-11-25
Supported by:
摘要:
用GIS方法和既有的考古资料研究了嵩山南麓颖河上游和双洎河上游龙山晚期和夏商期聚落的时空特征。受距今4000年前降温事件影响,嵩山南麓地区的史前聚落在夏商期对地貌的选择与龙山晚期有显著差异,而且两个时期聚落的R-S分布也从多要素竞争型向单因素支配型转变;对聚落在龙山晚期和夏商期的域面进行的泰森分析表明,环境变迁对聚落域变化幅度的影响在颍河上游大于双洎河上游。根据影响聚落分布的自然和文化因子,文章认为龙山晚期的聚落空间结构演化表现为文化选择型模式,反映了人本主义的规划法则,而夏代早期的聚落结构则表现出环境选择型的某些特征。基于此演化序列,文章最后归纳了气候转折期史前聚落演化的两种模式。
李中轩, 吴国玺, 朱诚, 郑敬刚, 李开封, 焦士兴. 4.2~3.5kaBP嵩山南麓聚落的时空特征及其演化模式[J]. 地理学报, 2016, 71(9): 1640-1652.
Zhongxuan LI, Guoxi WU, Cheng ZHU, Jinggang ZHENG, Kaifeng LI, Shixing JIAO. Spatial and temporal pattern of the 4.2-3.5 kaBP settlements and its succession models in the south of the Songshan Mountain[J]. Acta Geographica Sinica, 2016, 71(9): 1640-1652.
表1
嵩山南麓新石器晚期聚落的地貌参数比较(%)
地貌要素 | 高程(m) | 坡度(°) | 坡向(°) | 缓冲区(m) | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
要素范围 | 100~200 | 200~300 | >300 | 0~1.5 | 1.5~3 | >3 | 0~90 | 90~180 | 180~270 | 270~360 | 500 | 1000 | ||||
龙山期 | 颖河谷地 | 53.0 | 13.1 | 33.9 | 47.4 | 34.2 | 18.4 | 26.2 | 21.2 | 31.6 | 21.0 | 70.8 | 83.8 | |||
双洎河谷地 | 71.9 | 26.3 | 1.8 | 40.4 | 36.8 | 22.8 | 33.3 | 31.6 | 22.8 | 12.3 | 68.4 | 85.2 | ||||
夏商期 | 颖河谷地 | 47.6 | 14.3 | 38.1 | 47.6 | 19.0 | 33.4 | 47.6 | 14.3 | 14.3 | 23.8 | 52.5 | 76.3 | |||
双洎河谷地 | 55.4 | 42.0 | 2.6 | 28.9 | 28.9 | 42.2 | 26.3 | 21.1 | 23.7 | 28.9 | 49.8 | 74.6 |
[1] |
Perkins D J, Daly P.A hunters' village in Neolithic Turkey. Scientific American, 1968, 219(5): 96-106.
doi: 10.1038/scientificamerican1168-96 pmid: 5680233 |
[2] | Shaw J.Kommos: A major prehistoric town in Crete. Archaeology, 1978, 31(2): 50-52. |
[3] | Roberts Richard G.Luminescence dating in archaeology: From origins to optical. Radiation Measurements, 1997, 27(5):819-892. |
[4] |
Cabanes D, Gadot Y, Cabanes M, et al.Human impact around settlement sites: A phytolith and mineralogical study for assessing site boundaries, phytolith preservation, and implications for spatial reconstructions using plant remains. Journal of Archaeological Sciences, 2012, 39(8): 2697-2705.
doi: 10.1016/j.jas.2012.04.008 |
[5] | Pompeani D P, Abbott M B, Bain D J, et al.Copper mining on Isle Royale 6500-5400 years ago identified using sediment geochemistry from McCargoe Cove, Lake Superior. Holocene, 2014, 25(2): 253-262. |
[6] |
Hritz C.Contributions of GIS and satellite-based remote sensing to landscape archaeology in the Middle East. Journal of Archaeological Research, 2014, 22(3):229-276.
doi: 10.1007/s10814-013-9072-2 |
[7] |
Smith Michael E.Empirical urban theory for archaeologists. Journal of Archaeological Method & Theory, 2011, 18(3):167-192.
doi: 10.1007/s10816-010-9097-5 |
[8] |
Crema Enrico R.A simulation model of fission-fusion dynamics and long-term settlement change. Journal of Archaeological Method & Theory, 2014, 21(3): 385-404.
doi: 10.1007/s10816-013-9185-4 |
[9] |
Paul R.Duffy. Site size hierarchy in middle-range societies. Journal of Anthropological Archaeology, 2015, 37: 85-99.
doi: 10.1016/j.jaa.2014.12.001 |
[10] | Yan Wenming. Settlement archaeology and research on prehistoric society. Cultural Relics, 1997(6): 27-35. |
[严文明. 聚落考古与史前社会研究. 文物, 1997(6): 27-35.] | |
[11] | Chen Chun.Comparison of settlement-houses and wall-cities. Cultural Relics, 1997(8): 43-47. |
[陈淳. 聚落-居址与围墙-城址. 文物, 1997(8): 43-47.] | |
[12] | Sun Guangqing.Prehistoric city sites and ancient civilization in China. Cultural Relics of Central China, 1999(2): 69-73. |
[孙广清. 中国史前城址与古代文明. 中原文物, 1999(2): 69-73.] | |
[13] | Zhang Zhongpei.Preliminary study on settlement archaeology. Cultural Relics of Central China, 1999(3): 31-38. |
[张忠培. 聚落考古初论. 中原文物, 1999(3): 31-38.] | |
[14] |
Guo Weimin.Application of spatial analysis in settlement archaeology. Huaxia Archaeology, 2008(4): 142-150.
doi: 10.3969/j.issn.1001-9928.2008.04.017 |
[郭伟民.论聚落考古中的空间分析方法. 华夏考古, 2008(4): 142-150.]
doi: 10.3969/j.issn.1001-9928.2008.04.017 |
|
[15] | Wang Miaofa.Archaeological Geography of Prehistoric Settlement Sites in China. Wakayama: Wakayama University Press, 2012. |
[王妙发. 中国先史集落の考古地理学研究. 和歌山: 和歌山大学出版会, 2012.] | |
[16] |
Lu Peng, Tian Yan, Chen Panpan, et al.The relationship between settlements distribution and regional tectonics around the Songshan Mountain during 9000-3000 a BP. Acta Geographica Sinica, 2014, 69(6): 738-746.
doi: 10.11821/dlxb201406002 |
[鲁鹏, 田燕, 陈盼盼, 等. 环嵩山地区9000-3000 a BP聚落分布与区域构造的关系. 地理学报, 2014, 69(6): 738-746.]
doi: 10.11821/dlxb201406002 |
|
[17] | Zhang Li, Chen Zhongyuan, Liu Yan, et al.Rise of grand aquatic project in the Liangzhu Ancient City of Yangtze Delta and its environmental significance. Sientia Sinica (Terrae), 2014, 44(5): 957-966. |
[张立, 陈中原, 刘演, 等. 长江三角洲良渚古城、大型水利工程的兴起和环境地学的意义. 中国科学: 地球科学, 2014, 44(5): 957-966.] | |
[18] | Li Lina.A study of city sites of Longshan and Erlitou Ages [D]. Zhengzhou: Zhengzhou University, 2010. |
[李丽娜. 龙山至二里头时代城邑研究[D]. 郑州: 郑州大学, 2010.] | |
[19] | Pauline Sebillard.Settlement spatial organization in Central China Plains during the period of transition from late Neolithic to early Bronze Age (c. 2500-1050 B.C.) [D]. Changchun: Jilin University, 2014. |
[史宝琳. 中原地区公元前三千纪下半叶和公元前两千纪的聚落分布研究[D]. 长春: 吉林大学, 2014.] | |
[20] | Zheng Hao.A study on prehistoric city sites in Yangtze River Basin [D]. Shanghai: Fudan University, 2014. |
[郑好. 长江流域史前城址研究[D]. 上海: 复旦大学, 2014.] | |
[21] | Hunan Provincial Institute of Archaeology. Excavation Report of the Chengtoushan City Site,Lixian(1997-1998). Cultural Relics, 1999(6): 4-17. |
[湖南省考古研究所. 澧县城头山古城址1997-1998年度发掘简报. 文物, 1999(6): 4-17.] | |
[22] | Zhao Chunqing.Prehistoric city site research in China: Its past, present and future. Communication of Ancient Civilization Research Center of CASS, 2011(21): 35-45. |
[赵春青. 中国史前城址研究的过去、现在与未来. 中国社会科学院古代文明研究中心通讯, 2011(21): 35-45.] | |
[23] | Qian Yaopeng.Research on Prehistoric City Sites and Civilization Origins of China. Xi'an: Northwest University Press, 2001: 23. |
[钱耀鹏. 中国史前城址与文明起源研究. 西安: 西北大学出版社, 2001: 23.] | |
[24] | Chen Xingcan, Liu Li, Lee Y K, et al.Development of social complexity in the Central China. Journal of Archaeology, 2003(2): 161-218. |
[陈星灿, 刘莉, 李润权, 等.中国文明腹地的社会复杂化进程. 考古学报, 2003(2): 161-218.] | |
[25] |
Wei Xingtao.Ages, development and decline of city sites in Central Plain in the late Longshan Period. Huaxia Archaelogy, 2010, 1: 49-60.
doi: 10.3969/j.issn.1001-9928.2010.01.005 |
[魏兴涛. 中原龙山城址的年代与兴废原因探讨. 华夏考古, 2010, 1: 49-60.]
doi: 10.3969/j.issn.1001-9928.2010.01.005 |
|
[26] | Expert Team for Chronological Research on Xia-Shang-Zhou Dynasties.Report of Project of Chronology on Xia-Shang-Zhou Dynasties (1996-2000). Beijing: World Book Publishing House, 2000: 7-79. |
[夏商周断代工程专家组.夏商周断代工程1996-2000年阶段成果报告. 北京: 世界图书出版公司, 2000: 7-79.] | |
[27] |
Xia Zhengkai, Wang Zanhong, Zhao Chunqing.Climate background of flood events in China Central Plain about 3500a BP.Science in China (Series D), 2003, 33(9): 881-888.
doi: 10.3969/j.issn.1674-7240.2003.09.007 |
[夏正楷, 王赞红, 赵春青. 我国中原地区3500 a BP前后的异常洪水事件及其气候背景. 中国科学(D辑), 2003, 33(9): 881-888.]
doi: 10.3969/j.issn.1674-7240.2003.09.007 |
|
[28] | School of Archaeology and Museology of Peking University, Henan Provincial Institute of Archaeology. Excavation Report of Wangchenggang Site, Dengfeng City(2002,2004 ).Archaeology, 2006(9): 3-16. |
[北京大学考古文博学院, 河南省文物考古研究所. 河南登封市王城岗遗址2002、2004年发掘简报 . 考古, 2006(9): 3-16.] | |
[29] | Center for Research of Ancient Civilization of Beijing University, Zhengzhou Institute of Archaeology.Excavation of the Xinzhai site at Xinmi, Henan. Culture Relics, 2004(3): 4-20. |
[北京大学古代文明研究中心, 郑州市文物考古研究所. 河南省新密市新砦遗址2000年发掘简报 . 文物, 2004(3): 4-20.] | |
[30] | Zhang Junna, Xia Zhengkai.Deposition evidences of the 4 ka BP flood events in Central China Plains. Acta Geographica Sinica, 2011, 66(5): 685-697. |
[张俊娜, 夏正楷. 中原地区4 ka BP前后异常洪水事件的沉积证据. 地理学报, 2011, 66(5): 685-697.] | |
[31] |
Xu Junjie, Mo Duowen, Wang Hui, et al.Preliminary research of environment archaeology in Zhenshui River, Xinmi City, Henan. Quaternary Sciences, 2013, 33(5): 954-964.
doi: 10.3969/j.issn.1001-7410.2013.05.13 |
[许俊杰, 莫多闻, 王辉, 等. 河南新密溱水流域全新世人类文化演化的环境背景研究. 第四纪研究, 2013, 33(5): 954-964.]
doi: 10.3969/j.issn.1001-7410.2013.05.13 |
|
[32] | State Administration of Cultural Heritage. An Atlas of Chinese Cultural Relics in Henan Province. Beijing: Cultural Relics Press, 2009. |
[国家文物局. 中国文物地图集·河南分册. 北京: 文物出版社, 2009.] | |
[33] | Geo-Information Cloud Platform. |
[地理信息云平台.] | |
[34] |
Lu Peng, Tian Yan, Yang Ruixia.Study of size-grade of settlements around the Songshan Mountain in 9000-3000 a BP based on SOFM networks. Acta Geographica Sinica, 2012, 67(10): 1375-1382.
doi: 10.11821/xb201210008 |
[鲁鹏, 田燕, 杨瑞霞. 环嵩山地区9000 a B.P.-3000 a B.P.聚落规模等级. 地理学报, 2012, 67(10): 1375-1382.]
doi: 10.11821/xb201210008 |
|
[35] |
Christian E P, Robert D D.Communities, settlements, sites and surveys: Regional-scale analysis of prehistoric human interaction. American Antiquity, 2005, 70(1): 5-30.
doi: 10.2307/40035266 |
[36] | Teng Mingyu.A spatial research on the distribution of the sites in the middle reaches of Banzhijian River during Ante-Qin Dynasty. Jinlin University Journal of Social Sciences Edition, 2009, 49(4): 73-80. |
[滕铭予. 半支箭河中游先秦时期遗址分布的空间考察. 吉林大学社会科学学报, 2009, 49(4): 73-80.] | |
[37] | Christian E P, Robert D D.Patterned variation in regional trajectories of community growth//Smith M. The Comparative Archaeology of Complex Societies. New York: Cambridge University Press, 2012: 88-137. |
[38] | Duan Tianjing.Discussion of the application of rank-size law in regional analysis of archaeology. Archaeology, 2015(4): 108-120. |
[段天璟. 等级—规模法则在考古区域分析研究中的相关问题. 考古, 2015(4): 108-120.] | |
[39] | George K Zipf.Human Behavior and Principle of Least Effort. Cambridge: Harvard University Press, 1949: 349-351. |
[40] | Higgs E S, Bita-Finzi C.Prehistoric economies: A territorial approach//Higgs E S. Papers in Economic Prehistory. Cambridge: Cambridge University Press, 1972: 27-36. |
[41] |
Wang Xinsheng, Liu Jiyuan, Zhuang Dafang, et al.The application of Voronoi diagram on spatial organizing of urban influence regions. Journal of Central China Normal University (Natural Sciences), 2003, 37(2): 256-260.
doi: 10.3321/j.issn:1000-1190.2003.02.031 |
[王新生, 刘纪远, 庄大方, 等. Voronoi图用于确定城市经济影响区域的空间组织. 华中师范大学学报(自然科学版), 2003, 37(2): 256-260.]
doi: 10.3321/j.issn:1000-1190.2003.02.031 |
|
[42] | Zhang Jingxiang.Spatial Organization of Urban Agglomeration. Nanjing: Southeast University Press, 2000: 28. |
[张京祥.城镇群体空间组合. 南京: 东南大学出版社, 2000: 28.] | |
[43] | Jin Guiyun, Liu Tungsheng.Mid-Holocene cooling events and culture evolution in North China. Chinese Science Bulletin, 2001, 46(20): 1725-1729. |
[靳桂云, 刘东生. 华北北部中全新世降温事件与古文化变迁. 科学通报, 2001, 46(20): 1725-1729.] | |
[44] | Wu Wenxiang, Liu Tungsheng.Variations in East Asia Monsoon around 4000 aBP and the collapse of Neolithic cultures around Central Plain. Quaternary Sciences, 2004, 24(3): 278-285. |
[吴文祥, 刘东生. 4000 a B.P.前后东亚季风变迁与中原周围地区新石器文化的衰落. 第四纪研究, 2004, 24(3): 278-285.] | |
[45] | Zhang Zhenyu, Zhou Kunshu, Yang Ruixia, et al.Environmental archaeology in the Shuangji River Basin. Quaternary Sciences, 2007, 27(3): 453-460. |
[张震宇, 周昆叔, 杨瑞霞, 等. 双洎河流域环境考古. 第四纪研究, 2007, 27(3): 453-460.] | |
[46] | Xia Zhengkai, Yang Xiaoyan.Preliminary study on the flood events about 4 ka B.P. in North China. Quaternary Sciences, 2003, 23(6): 667-674. |
[夏正楷, 杨晓燕. 我国北方4 ka B.P.前后异常洪水事件的初步研究. 第四纪研究, 2003, 23(6): 667-674.] | |
[47] |
Xia Zhengkai, Wang Zanhong, Zhao Chunqing.3500 aBP extraordinary floods and its climatic background in Central Plain of China. Science in China (Series D), 2003, 33(9): 881-888.
doi: 10.3969/j.issn.1674-7240.2003.09.007 |
[夏正楷, 王赞红, 赵春青. 我国中原地区3500aBP前后的异常洪水事件及其气候背景. 中国科学(D辑), 2003, 33(9): 881-888.]
doi: 10.3969/j.issn.1674-7240.2003.09.007 |
|
[48] |
Marcott S A, Shakun J D, Clark P U, et al.A reconstruction of regional and global temperature for the past 11,300 years. Science, 2013, 339: 1198-1201.
doi: 10.1126/science.1228026 pmid: 23471405 |
[49] |
Shao Xiaohua, Wang Yongjin, Cheng Hai, et al.Monsoon evolution and drought events in Holocene recorded by stalagmite in Shennongjia, Hubei. Chinese Science Bulletin, 2006, 51(1): 80-86.
doi: 10.1360/972005-882 |
[邵晓华, 汪永进, 程海, 等. 全新世季风气候演化与干旱事件的湖北神农架石笋记录. 科学通报, 2006, 51(1): 80-86.]
doi: 10.1360/972005-882 |
|
[50] |
Zhao Zhijun, Fang Yanming.Grain-floating results and analysis of the Wangchenggang deposits, Dengfeng. Huaxia Archaeology, 2007(2): 78-91.
doi: 10.3969/j.issn.1001-9928.2007.02.008 |
[赵志军, 方燕明. 登封王城岗遗址浮选结果及分析. 华夏考古, 2007(2): 78-91.]
doi: 10.3969/j.issn.1001-9928.2007.02.008 |
|
[51] |
Yang Liwen.On the growth rule of 4 rain-fed grain crops. Chinese Journal of Agriculture Science, 2011, 44(11): 2244-2251.
doi: 10.3864/j.issn.0578-1752.2011.11.005 |
[杨丽雯. 4种旱作谷类作物根系发育规律的研究. 中国农业科学, 2011, 44(11): 2244-2251.]
doi: 10.3864/j.issn.0578-1752.2011.11.005 |
|
[52] | Liu Li.A study of tomb formation in the Longshan Period. Journal of Culture Relics, 1999(2): 32-49. |
[刘莉. 龙山文化墓葬形态研究. 文物季刊, 1999(2): 32-49.] | |
[53] |
Wang Zhenzhong.Shun Culture and Chinese ancient civilization. Cultural Relics in Southern China, 2011(1): 131-134.
doi: 10.3969/j.issn.1004-6275.2011.01.016 |
[王震中. 大舜文化与中国早期文明. 南方文物, 2011(1): 131-134.]
doi: 10.3969/j.issn.1004-6275.2011.01.016 |
|
[54] | Zheng Jiexiang.Analysis of the Longshan Culture in Henan. Journal of Henan University (Social Sciences), 1979(4): 35-45. |
[郑杰祥. 河南龙山文化分析. 河南大学学报(社会科学版), 1979(4): 35-45.] | |
[55] | Shen Changyun. The social formation of early Chinese states: Viewing from the different Paths of civilization creation. Journal of Chinese Humanities, 2014(5): 89-94. |
[沈长云. 从不同文明产生的路径看中国早期的国家形态. 文史哲, 2014(5): 89-94.] | |
[56] | Zhang Guoshuo, Wang Qiong.On the ancient city sites and city walls in the Xia and Shang dynasties. Cultural Relics of Central China, 2014(6): 12-16. |
[张国硕, 王琼. 史前夏商城址城郭之制分析. 中原文物, 2014(6): 12-16.] | |
[57] | Xu Hong.2000BC: Archaeological observation of historic transition of the Central Plains//Oriental Archaeology Research Center of Shandong University. Oriental Archaeology Episode 9. Beijing: Science Press, 2012: 186-203. |
[许宏.公元前2000年: 中原大变局的考古学观察//山东大学东方考古研究中心. 东方考古. 9集. 北京: 科学出版社, 2012: 186-203.] |
