区域“水—土—能—碳”耦合作用机制分析

doi:10.11821/dlxb201609012

地理学报 ›› 2016, Vol. 71 ›› Issue (9): 1613-1628.doi: 10.11821/dlxb201609012

区域“水—土—能—碳”耦合作用机制分析

赵荣钦¹(), 李志萍¹, 韩宇平², 张战平¹, 丁明磊¹

1. 华北水利水电大学资源与环境学院,郑州 450045
2. 华北水利水电大学黄河科学研究院,郑州 450045
3. 不列颠哥伦比亚大学资源环境与可持续发展研究所,加拿大 V6T 1Z4

收稿日期:2016-02-04 修回日期:2016-05-05 出版日期:2016-11-25 发布日期:2016-11-25
作者简介:
作者简介：赵荣钦(1978-), 男, 河南孟津人, 博士后, 副教授, 中国地理学会会员(S110008988M), 从事土地利用与碳排放研究。E-mail: zhaorq234@163.com
基金资助:
国家自然科学基金项目(41301633, 51679089)

The coupling interaction mechanism of regional water-land-energy-carbon system

Rongqin ZHAO¹(), Zhiping LI¹, Yuping HAN², KANDLIKAR Milind³, Zhanping ZHANG¹, Minglei DING¹

1. School of Resources and Environment, North China University of Water Resources and Electric Power, Zhengzhou 450045, China
2. The Yellow River Institute of Science, North China University of Water Resources and Electric Power, Zhengzhou 450045, China
3. Institute for Resources, Environment and Sustainability, University of British Columbia, Vancouver, V6T 1Z4, Canada

Received:2016-02-04 Revised:2016-05-05 Published:2016-11-25 Online:2016-11-25
Supported by:
National Natural Science Fundation of China, No.41301633, No.51679089

摘要/Abstract

摘要：

在相关研究的基础上,对区域“水—土—能—碳”耦合系统及其要素关系进行解析;分析其耦合作用机制、主要研究视角和影响因素;并提出了未来的研究趋向。① 区域“水—土—能—碳”耦合作用系统不仅体现了地表系统四大圈层的作用,更以水循环、土地利用、能量流通、碳循环的形式构成了区域“自然—经济—社会”的核心内容,该系统不仅反映了区域不同资源类型的匹配关系和开发利用效率,也体现了人类社会对环境的影响程度;② 该系统可以分为三个相互联系、相互作用的子系统：水系统、土地系统和能源系统。它们之间通过不同途径相互联系、互为资源,共同构成了区域社会经济发展的资源基础,而区域碳排放强度则主要取决于水、土、能等要素之间相互需求的类型、产业活动方式和能源类型与结构等;③ 区域“水—土—能—碳”耦合作用机制可以从微观角度、产业活动、土地利用等不同视角来分析;④ 区域“水—土—能—碳”耦合作用系统主要受自然、经济、社会和压力等因素的影响。其中经济因素,特别是经济发展水平、生产效率和技术水平是系统结构、功能和效率的决定性要素;⑤ 未来应重点从区域“水—土—能—碳”耦合系统模拟、其与气候变化和粮食安全的关系、资源耦合开发的碳排放效率及其综合评估与调控研究等方面开展研究。

关键词: 区域, 水—, 土—, 能—, 碳, 耦合, 机制

Abstract:

Water, land, energy and carbon are key elements of earth's surface system. Researches on regional water-land-energy-carbon system (WLEC system) will not only help to reveal the impact mechanism of resource coupling exploitation on carbon emissions, but also has great significance to explore low-carbon development mode based on water, land and energy saving. Based on the literature review, this paper analyzed the element relationship of regional WLEC system, discussed the coupling interaction mechanism, research perspectives and impact factors of regional WLEC system, and put forward the future research points in this field. The main conclusions are as follows: (1) Regional WLEC system reflects the interactions among different spheres of earth's surface system. Through water cycle, land use, energy flow and carbon cycle, WLEC system becomes the core of regional natural-economic-social system. It not only reflects the matching relationship and exploitation efficiency of regional resources, but also embodies the impact extent of human activities on environment. (2) Regional WLEC system can be divided into three subsystems: water system, land system and energy system. They interacted with each other and together formed the resource base for the regional socio-economic development. Regional carbon emission intensity is mainly determined by the need relationship among three subsystems, industrial activities and energy structure. (3) Regional WLEC system can be studied from different perspectives such as microscopic view, industrial activities and land use. (4) Regional WLEC system is influenced by natural, economic, social and pressure factors, in which economic factor, especially economic development level, production efficiency and technology, is the determinant factor of the function and efficiency of regional WLEC system. (5) In the future, modeling of regional WLEC system, relationship between WLEC system and climate change and food security, carbon emission efficiency of resource coupling exploitation and the integrated evaluation and regulation of WLEC system should be strengthened.

Key words: region, water-land-energy-carbon system, coupling, mechanism

赵荣钦, 李志萍, 韩宇平, 张战平, 丁明磊. 区域“水—土—能—碳”耦合作用机制分析[J]. 地理学报, 2016, 71(9): 1613-1628.

Rongqin ZHAO, Zhiping LI, Yuping HAN, KANDLIKAR Milind, Zhanping ZHANG, Minglei DING. The coupling interaction mechanism of regional water-land-energy-carbon system[J]. Acta Geographica Sinica, 2016, 71(9): 1613-1628.

图/表 8

图1

表1

图2

表2

图3

图4

图5

图6

参考文献 83

[1]	Venkatesh D, Chan A, Brattebo H.Understanding the water-energy-carbon nexus in urban water utilities: Comparison of four city case studies and the relevant influencing factors. Energy, 2014,75: 153-166. doi: 10.1016/j.energy.2014.06.111
[2]	Kennedy C, Steinberger J, Gasson B, et al.Methodology for inventorying greenhouse gas emissions from global cities. Energy Policy, 2010, 38: 4828-4837. doi: 10.1016/j.enpol.2009.08.050
[3]	Ali G, Nitivattananon V.Exercising multidisciplinary approach to assess interrelationship between energy use, carbon emission and land use change in a metropolitan city of Pakistan. Renewable and Sustainable Energy Reviews, 2012, 16(1): 775-786. doi: 10.1016/j.rser.2011.09.003
[4]	Skaggs R, Janetos T C.Climate and Energy-Water-Land System Interactions. US Department of Energy, 2012. doi: 10.2172/1040680
[5]	Watanabe M D B, Ortega E. Dynamic emergy accounting of water and carbon ecosystem services: A model to simulate the impacts of land-use change. Ecological Modelling, 2014, 271: 113-131. doi: 10.1016/j.ecolmodel.2013.03.006
[6]	Ringler C, Bhaduri A, Lawford R.The nexus across water, energy, land and food (WELF): Potential for improved resource use efficiency? Current Opinion in Environmental Sustainability 2013, 5: 617-624. doi: 10.1016/j.cosust.2013.11.002
[7]	Fais B, Mourao Z S, Konadu D, et al..
[8]	Sus O, Heuer M W, Meyers T P W, et al. A data assimilation framework for constraining upscaled cropland carbon flux seasonality and biometry with MODIS. Biogeosciences, 2013, 10(4): 2451-2466. doi: 10.5194/bg-10-2451-2013
[9]	Baldocchi D D, Falge E.FLUXNET: A new tool to study the temporal and spatial variability of ecosystem-scale carbon dioxide, water vapor, and energy flux densities. Bulletin of the American Meteorological Society, 2001, 82: 2415-2434.
[10]	Yu Guirui, Gao Yang, Wang Qiufeng, et al.Discussion on the key processes of carbon-nitrogen-water coupling cycles and biological regulation mechanisms in terrestrial ecosystem. Chinese Journal of Eco-Agriculture, 2013, 21(1): 1-13. doi: 10.3724/SP.J.1011.2013.00001
	[于贵瑞, 高扬, 王秋凤, 等. 陆地生态系统碳—氮—水循环的关键耦合过程及其生物调控机制探讨. 中国生态农业学报, 2013, 21(1): 1-13.] doi: 10.3724/SP.J.1011.2013.00001
[11]	Shi Tingting, Gao Yufang, Yuan Fenghui, et al.Simulation of CO2 and H2O fluxes over temperate mixed forest and sensitivity analysis of layered methods: stomatal conductance-photosynthesis-energy balance coupled model. Acta Ecologica Sinica, 2012, 32(15): 4630-4640. doi: 10.5846/stxb201107281106
	[施婷婷, 高玉芳, 袁凤辉, 等. 温带混交林碳水通量模拟及其对冠层分层方式的响应—耦合的气孔导度—光合作用—能量平衡模型. 生态学报, 2012, 32(15): 4630-4640.] doi: 10.5846/stxb201107281106
[12]	Song Chunlin, Sun Xiangyang, Wang Genxu.A review on carbon and water interactions of forest ecosystem and its impact factors. Chinese Journal of Applied Ecology,2015, 26(9): 2891-2902.
	[宋春林, 孙向阳, 王根绪. 森林生态系统碳水关系及其影响因子研究进展. 应用生态学报, 2015, 26(9): 2891-2902.]
[13]	Gervois S, Ciais P, Noblet-Ducoudré N, et al. Carbon and water balance of European croplands throughout the 20th century. Global Biogeochemical Cycles, 2008, 22, GB2022.doi: 10.1029/2007GB003018. doi: 10.1029/2007gb003018
[14]	Yu Guirui, Song Xia, Wang Qiufeng, et al.Water-use efficiency of forest ecosystems in eastern China and its relations to climatic variables. New Phytologist, 2008, 177(4): 927-937. doi: 10.1111/j.1469-8137.2007.02316.x pmid: 18069958
[15]	Ren Xiaoli, He Honglin, Liu Min, et al.Modeling of carbon and water fluxes of Qianyanzhou subtropical coniferous plantation using model-data fusion approach. Acta Ecologica Sinica, 2012, 32(23): 7313-7326. doi: 10.5846/stxb201203230397
	[任小丽, 何洪林, 刘敏,等. 基于模型数据融合的千烟洲亚热带人工林碳水通量模拟. 生态学报, 2012, 32(23): 7313-7326.] doi: 10.5846/stxb201203230397
[16]	Raymond P A, Hartmann J, Lauerwald R, et al.Global carbon dioxide emissions from inland waters. Nature, 2013, 503: 355-359. doi: 10.1038/nature12760
[17]	Abril G, Guerin F, Richard S, et al. Carbon dioxide and methane emissions and the carbon budget of a 10-year old tropical reservoir((PetitSaut,French Guiana) . Global Biogeochemical Cycles, 2005, 19, GB4007.doi: 10.1029/2005GB002457. doi: 10.1029/2005GB002457
[18]	Barros N, Cole J J, Tranvik L J, et al.Carbon emission from hydroelectric reservoirs linked to reservoir age and latitude.Nature Geoscience, 2011, 4: 593-596. doi: 10.1038/ngeo1211
[19]	Jiang Tao, Guo Jinsong, Li Zhe, et al.Air-water surface greenhouse gas flux in Pengxi River at different operational stages of the Three Gorges Reservoir. Chinese Journal of Environmental Science, 2012, 33(5): 1463-1470.
	[蒋滔, 郭劲松, 李哲, 等. 三峡水库不同运行状态下支流澎溪河水: 气界面温室气体通量特征初探. 环境科学, 2012, 33(5): 1463-1470.]
[20]	Zhao Dengzhong, Tan Debao, Wang Chaohui, et al.Measurement and analysis of greenhouse gas fluxes from Shuibuya Reservoir in Qingjiang River Basin. Journal of Yangtze River Scientific Research Institute, 2011, 28(10): 197-204.
	[赵登忠, 谭德宝, 汪朝辉, 等. 清江流域水布垭水库温室气体交换通量监测与分析研究. 长江科学院院报, 2011, 28(10):197-204.]
[21]	Han Yang, Zheng Youfei, Wu Rongjun, et al.Greenhouse gases emission characteristics of Nanjing typical waters in Spring. China Environmental Science, 2013, 33(8): 1360-1371.
	[韩洋, 郑有飞, 吴荣军, 等. 南京典型水体春季温室气体排放特征研究. 中国环境科学, 2013, 33(8): 1360-1371.]
[22]	PMSEIC. Challenges at Energy-Water-Carbon Intersections. Prime Minister's Science, Engineering and Innovation Council, Canberra, Australia, 2010.
[23]	Rothausen S G S A, Conway D. Greenhouse-gas emissions from energy use in the water sector. Nature Climate Change. 2013, 503: 355-359.
[24]	Qin Huapeng, Yuan Huizhou.Urban Water System and Carbon Emission. Beijing: Science Press, 2014.
	[秦华鹏, 袁辉洲. 城市水系统与碳排放 . 北京: 科学出版社, 2014.]
[25]	Yan Denghua, Qin Tianling, Zhang Ping.Study on water resources rational deployment framework based on the low-carbon development mode. Journal of Hydraulic Engineering, 2010, 41(8): 970-976.
	[严登华, 秦天玲, 张萍. 基于低碳发展模式的水资源合理配置框架研究. 水利学报, 2010, 41(8): 970-976.]
[26]	Rodriguez N, Armenteras D, Retana J.National ecosystems services priorities for planning carbon and water resource management in Colombia. Land Use Policy, 2015, 42: 609-618. doi: 10.1016/j.landusepol.2014.09.013
[27]	Wang J X,Rothausen S G S A, Conway D, et al. China's water-energy nexus: Greenhouse-gas emissions from groundwater use for agriculture. Environmental Research Letters, 2012, 7: 268-272.
[28]	Li C, Wang Y, Qiu G Y.Water and energy consumption by agriculture in the Minqin oasis region. Journal of Integrative Agriculture, 2013, 12(8): 1330-1340.
[29]	Egilmez G, Park Y S.Transportation related carbon, energy and water footprint analysis of U.S. manufacturing: An eco-efficiency assessment. Transportation Research Part D: Transport and Environment, 2014, 32: 143-159. doi: 10.1016/j.trd.2014.07.001
[30]	Schneider A G, Townsend-Small A.Impact of direct greenhouse gas emissions on the carbon footprint of water reclamation processes employing nitrification-denitrification. Science of the Total Environment, 2015, 505(1): 1166-1173. doi: 10.1016/j.scitotenv.2014.10.060 pmid: 25461114
[31]	Kothavala Z, Arain M A, Black T A.The simulation of energy, water vapor and carbon dioxide fluxes over common crops by the Canadian Land Surface Scheme (CLASS). Agriculture and Forest Meteorology, 2005, 133(1-4): 89-108. doi: 10.1016/j.agrformet.2005.08.007
[32]	Zhang Y C, Shen Y J, Xu X L, et al.Characteristics of the water-energy-carbon fluxes of irrigated pear (Pyrus bretschneideri Rehd) orchards in the North China Plain. Agriculture Water Management, 2013, 128: 140-148. doi: 10.1016/j.agwat.2013.07.007
[33]	Flechard C R, Neftel A, Jocher M, et al.Bi-directional soil/atmosphere N2O exchange over two mown grassland systems with contrasting management practices. Global Change Biology, 2005, 11: 2114-2127. doi: 10.1111/j.1365-2486.2005.01056.x
[34]	Wang Yuesi, Ji Baoming, Huang Yao, et al.Effects of grazing and cultivating on emission of nitrous oxide, carbon dioxide and uptake of methane from grasslands. Environmental Science, 2001, 22(6): 7-13. doi: 10.3321/j.issn:0250-3301.2001.06.002
	[王跃思, 纪宝明, 黄耀, 等. 农垦与放牧对内蒙古草原N2O、CO2排放和CH4吸收的影响. 环境科学, 2001, 22(6): 7-13.] doi: 10.3321/j.issn:0250-3301.2001.06.002
[35]	Chen Guangsheng, Tian Hanqin.Land use/cover change effects on carbon cycling in terrestrial ecosystems. Journal of Plant Ecology (Chinese version), 2007, 31(2): 189-204.
	[陈广生, 田汉勤. 土地利用/覆盖变化对陆地生态系统碳循环的影响. 植物生态学报, 2007, 31(2): 189-204.]
[36]	Grūnzweig J M, Sparrow S D, Chapin F S, et al.Impact of forest conversion to agriculture on carbon and nitrogen mineralization in subarctic Alaska. Biogeochemistry, 2003, 64: 271-296. doi: 10.1023/A:1024976713243
[37]	Carlisle E A, Steenwerth K L, Smart D R.Effects of land use on soil respiration: Conversion of oak woodlands to vineyards. Journal of Environmental Quality, 2006, 35: 1396-1404. doi: 10.2134/jeq2005.0155 pmid: 16825460
[38]	Liu Huifeng, Wu Xing, Li Ya, et al.Effects of land use change on greenhouse gas fluxes from soils: A review. Chinese Journal of Ecology, 2014, 33(7): 1960-1968.
	[刘慧峰, 伍星, 李雅, 等. 土地利用变化对土壤温室气体排放通量影响研究进展. 生态学杂志, 2014, 33(7): 1960-1968.]
[39]	Ostle N J, Levy P E, Evans C D, et al.UK land use and soil carbon sequestration. Land Use Policy, 2009, 26: S274-S283 doi: 10.1016/j.landusepol.2009.08.006
[40]	Houghton R A, Hackler J L, Lawrence K T. The U.S.carbon budget: contributions from land-use change. Science, 1999, 285(5427): 574-578.
[41]	Wang Yuangang, Luo Geping, Zhao Shubin, et al.Effects of arable land change on regional carbon balance in Xinjiang. Acta Geographica Sinica, 2014, 69(1): 110-120. doi: 10.11821/dlxb201401011
	[王渊刚, 罗格平, 赵树斌, 等. 新疆耕地变化对区域碳平衡的影响. 地理学报, 2014, 69(1): 110-120.] doi: 10.11821/dlxb201401011
[42]	Houghton R A, House JI, Pongratz J, et al.Carbon emissions from land use and land-cover change. Biogeosciences, 2012, 9: 5125-5142. doi: 10.5194/bg-9-5125-2012
[43]	Kalnay E, Cai M.Impact of urbanization and land-use change on climate. Nature, 2003, 423: 528-531.
[44]	Zhang C, Tian H Q, Chen G S, et al.Impacts of urbanization on carbon balance in terrestrial ecosystems of the southern United States. Environmental Pollution, 2012, 164(5): 89-101. doi: 10.1016/j.envpol.2012.01.020 pmid: 22343525
[45]	Houghton R A, Hackler J L.Sources and sinks of carbon from land-use change in China. Global Biogeochemical Cycles, 2003, 17(2): 1034-1047.
[46]	Ge Quansheng, Dai Junhu, He Fanneng, et al.Research on land use and land cover change and carbon cycle during the past three hundred years in China. Science in China (Series D), 2008, 38(2): 197-210. doi: 10.3724/SP.J.1005.2008.01083
	[葛全胜, 戴君虎, 何凡能, 等. 过去300年中国土地利用、土地覆被变化与碳循环研究. 中国科学(D辑), 2008, 38(2): 197-210.] doi: 10.3724/SP.J.1005.2008.01083
[47]	Fang J Y, Chen A P, Peng C H, et al.Changes in forest biomass carbon storage in China between 1949 and 1998. Science, 2001, 292(5525): 2320-2322. doi: 10.1126/science.1058629 pmid: 11423660
[48]	Zhao Rongqin, Huang Xianjin.Carbon emission and carbon footprint of different land use types based on energy consumption of Jiangsu province. Geographical Research, 2010, 29(9): 1639-1649.
	[赵荣钦, 黄贤金. 基于能源消费的江苏省土地利用碳排放与碳足迹. 地理研究, 2010, 29(9): 1639-1649.]
[49]	Lai Li, Huang Xianjin.Carbon Emission Effect of Land Use in China. Nanjing: Nanjing University Press, 2011.
	[赖力,黄贤金. 中国土地利用的碳排放效应研究. 南京: 南京大学出版社, 2011.]
[50]	Koemer B, Klopatek J.Anthropogenic and natural CO2 emission sources in an arid urban environment. Environmental Pollution, 2002, 116(Suppl.1): S45-S51. doi: 10.1016/S0269-7491(01)00246-9 pmid: 11833917
[51]	Araujo M S M, Silva C, Campos C P. Land use change sector contribution to the carbon historical emissions and the sustainability. Renewable and Sustainable Energy Reviews, 2009, 13(3): 696-702. doi: 10.1016/j.rser.2007.10.008
[52]	Zhao Rongqin, Huang Xianjin, Liu Ying, et al.Carbon emission of regional land use and its decomposition analysis: Case study of Nanjing city, China. Chinese Geographical Science, 2015, 25(2): 198-212. doi: 10.1007/s11769-014-0714-1
[53]	Zhao Rongqin, Chen Zhigang, Huang Xianjin, et al.Research progresses of land use carbon emission in Nanjing University. Scientia Geographica Sinica, 2012, 32(12): 1473-1480.
	[赵荣钦, 陈志刚, 黄贤金, 等. 南京大学土地利用碳排放研究进展. 地理科学, 2012, 32(12): 1473-1480.]
[54]	Zhao Rongqin, Huang Xianjin, Liu Ying, et al.Mechanism and policy framework for land regulation of carbon cycle of regional system. China Population, Resources and Environment, 2014, 24(5): 51-56. doi: 10.3969/j.issn.1002-2104.2014.05.009
	[赵荣钦, 黄贤金, 刘英, 等. 区域系统碳循环的土地调控机理及政策框架研究. 中国人口·资源与环境, 2014, 24(5): 51-56.] doi: 10.3969/j.issn.1002-2104.2014.05.009
[55]	Chuai Xiaowei, Huang Xianjin, Lai Li, et al.Land use structure optimization based on carbon storage in several regional terrestrial ecosystems across China. Environmental Science and Policy, 2013, 25: 50-61. doi: 10.1016/j.envsci.2012.05.005
[56]	Chuai Xiaowei, Huang Xianjin, Wang Wanjing, et al.Land use, total carbon emission change and low carbon land management in coastal Jiangsu, China. Journal of Cleaner Production, 2015, 103: 77-86.
[57]	You Heyuan, Wu Cifang.Carbon emission efficiency and low carbon optimization of land use: Based on the perspective of energy consumption. Journal of Natural Resources, 2010, 25(11): 1875-1886. doi: 10.11849/zrzyxb.2010.11.007
	[游和远, 吴次芳. 土地利用的碳排放效率及其低碳优化: 基于能源消费的视角. 自然资源学报, 2010, 25(11): 1875-1886.] doi: 10.11849/zrzyxb.2010.11.007
[58]	Zhao Rongqin, Huang Xianjin, Zhong Taiyang, et al.Carbon effect evaluation and low-carbon optimization of land use in Nanjing. Transactions of the Chinese Society of Agricultural Engineering, 2013, 29(17): 220-229.
	[赵荣钦, 黄贤金, 钟太洋, 等. 区域土地利用结构的碳效应评估及低碳优化. 农业工程学报, 2013, 29(17): 220-229.]
[59]	Yu Degui, Wu Qun.Application of the model of land used structure optimization based on low-carbon limited. Resources and Environment in the Yangtza Basin, 2011, 20(8): 911-917.
	[余德贵, 吴群. 基于碳排放约束的土地利用的结构优化模型研究及其应用. 长江流域资源与环境, 2011, 20(8): 911-917.
[60]	Tang Jie, Mao Zilong, Wang Chenye, et al.Regional land use structure optimization based on carbon balance: A case study in Tongyu county, Jilin province. Resources Science, 2009, 31(1): 130-135.
	[汤洁, 毛子龙, 王晨野, 等. 基于碳平衡的区域土地利用结构优化: 以吉林省通榆县为例. 资源科学, 2009, 31(1): 130-135.]
[61]	Zhong Xuebin, Yu Guangming, He Guosong, et al.Carbon storage loss during land readjustment and optimization of ecological compensation. Chinese Journal of Ecology, 2006, 25(3): 303-308.
	[钟学斌, 喻光明, 何国松, 等. 土地整理过程中碳量损失与生态补偿优化设计. 生态学杂志, 2006, 25(3): 303-308.]
[62]	IPCC. 2006 IPCC Guidelines for National Greenhouse Gas Inventories . 2006. doi: 10.1016/S1462-9011(99)00023-4
[63]	Dhakal S.Urban energy use and greenhouse gas emissions in Asian mega-cities. Kitakyushu: Institute for Global Environmental Strategies, 2004: 43-61.
[64]	Zhao Rongqin, Huang Xianjin, Zhong Taiyang, et al.Carbon footprint of different industrial spaces based on energy consumption in China. Journal of Geographical Sciences, 2011, 21(2): 285-300. doi: 10.1007/s11442-011-0845-6
[65]	Shi Peihua, Wu Pu.A rough estimation of energy consumption and CO2 emission in tourism sector of China. Acta Geographica Sinica, 2011, 66(2): 235-243.
	[石培华, 吴普. 中国旅游业能源消耗与CO2排放量的初步估算. 地理学报, 2011, 66(2): 235-243.
[66]	Qu Jiansheng, Zhang Zhiqiang, Zeng Jingjing, et al.Household carbon emission differences and their driving factors in northwestern China. Chinese Science Bulletin, 2013, 58(3): 260-266. doi: 10.1360/972012-1141
	[曲建升, 张志强, 曾静静, 等. 西北地区居民生活碳排放结构及其影响因素. 科学通报, 2013, 58(3): 260-266.] doi: 10.1360/972012-1141
[67]	Howitt O J A, Revol V G N, Smith I J, et al. Carbon emissions from international cruise ship passengers' travel to and from New Zealand. Energ Policy, 2010, 38(5): 2552-2560. doi: 10.1016/j.enpol.2009.12.050
[68]	Ma Jing, Chai Yanwei, Liu Zhilin.The mechanism of CO2 emissions from urban transport based on individuals' travel behavior in Beijing. Acta Geographica Sinica, 2011, 66(8): 1023-1032.
	[马静, 柴彦威, 刘志林. 基于居民出行行为的北京市交通碳排放影响机理. 地理学报, 2011, 66(8): 1023-1032.]
[69]	Dong Huijuan, Geng Yong, Xue Bing, et al.Differences of energy consumption and carbon emission scenarios between central city and suburban areas. Research of Environmental Sciences, 2011, 24(3): 354-362.
	[董会娟, 耿涌, 薛冰, 等. 沈阳市中心城区和市郊区能耗碳排放格局差异. 环境科学研究, 2011, 24(3): 354-362.]
[70]	Hammond G P, Norman J B.Decomposition analysis of energy-related carbon emissions from UK manufacturing. Energy, 2012, 41(1): 220-227. doi: 10.1016/j.energy.2011.06.035
[71]	Lu Zhiming, Peng Xizhe, Wu Kaiya, et al.Factors decomposition and empirical analysis of variations in energy carbon emission in China. Resources Science, 2009, 31(12): 2072-2079.
	[陆志明, 彭希哲, 吴开亚, 等. 中国能源消费碳排放变化的因素分解及实证分析. 资源科学, 2009, 31(12): 2072-2079.]
[72]	Zhu Yongbin, Wang Zheng, Pang Li, et al.Simulation on China's economy and prediction on energy consumption and carbon emission under optimal growth path. Acta Geographica Sinica, 2009, 64(8): 935-944. doi: 10.3321/j.issn:0375-5444.2009.08.004
	[朱永彬, 王铮, 庞丽, 等. 基于经济模拟的中国能源消费与碳排放高峰预测. 地理学报, 2009, 64(8): 935-944.] doi: 10.3321/j.issn:0375-5444.2009.08.004
[73]	Nie Rui, Zhang Tao, Wang Di.The scenario analysis on energy consumption and carbon emissions based on environmental loads model. Journal of Natural Resources, 2010, 25(9): 1557-1564. doi: 10.11849/zrzyxb.2010.09.015
	[聂锐, 张涛, 王迪. 基于IPAT模型的江苏省能源消费与碳排放情景研究. 自然资源学报, 2010, 25(9): 1557-1564.] doi: 10.11849/zrzyxb.2010.09.015
[74]	Shi Minjun, Wang Yan, Zhang Zhuoying, et al.Regional carbon footprint and interregional transfer of carbon emissions in China. Acta Geographica Sinica, 2012, 67(10): 1327-1338.
	[石敏俊, 王妍, 张卓颖, 等. 中国各省区碳足迹与碳排放空间转移. 地理学报, 2012, 67(10): 1327-1338.]
[75]	Yao Liang, Liu Jingru.Transfer of carbon emissions between China's eight major regions. China Population, Resources and Environment, 2010, 20(12): 16-19. doi: 10.3969/j.issn.1002-2104.2010.12.004
	[姚亮, 刘晶茹. 中国八大区域间碳排放转移研究. 中国人口·资源与环境, 2010, 20(12): 16-19.] doi: 10.3969/j.issn.1002-2104.2010.12.004
[76]	Xie Shichen, Chen Changhong, Li Li, et al.The energy related carbon dioxide emission inventory and carbon flow chart in Shanghai city. China Environmental Science, 2009, 29(11): 1215-1220.
	[谢士晨, 陈长虹, 李莉, 等. 上海市能源消费 CO2排放清单与碳流通图. 中国环境科学, 2009, 29(11): 1215-1220.]
[77]	Chen S, Chen B.Network environ perspective for urban metabolism and carbon emissions: A case study of Vienna, Austria. Environmental Science and Technology, 2012, 46(8): 4498-4506.
[78]	Zhao R, Huang X, Zhong T, et al.Carbon flow of urban system and its policy implications: The case of Nanjing. Renewable and Sustainable Energy Reviews, 2014, 33(5): 589-601. doi: 10.1016/j.rser.2014.02.020
[79]	Fang K, Heijungs R, Snoo G R.Theoretical exploration for the combination of the ecological, energy, carbon, and water footprints: Overview of a footprint family. Ecological Indicators, 2014, 36: 508-518. doi: 10.1016/j.ecolind.2013.08.017
[80]	Felzer BS.Carbon, nitrogen, and water response to climate and land use changes in Pennsylvania during the 20th and 21st centuries. Ecological Modelling, 2012, 240: 49-63. doi: 10.1016/j.ecolmodel.2012.05.003
[81]	Ababaei B, Sohrabi T, Mirzaei F.Development and application of a planning support system to assess strategies related to land and water resources for adaptation to climate change. Climate Risk Management, 2014, 6: 39-50. doi: 10.1016/j.crm.2014.11.001
[82]	Rajan N, Maas S J, Ale S, et al.Impact of biofuel induced land use change on energy, water, carbon and greenhouse balances of the Southeast U.S.Cotton Belt region.
[83]	National Renewable Energy Laboratory.

研究类别	研究核心内容	方法	区域	年份	作者
“水—碳”耦合	陆地生态系统的碳水耦合	通量观测和模拟	江西千烟洲	2012	任小丽等^[15]
“水—碳”耦合	水体的碳释放	样点监测与模拟	全球	2013	Raymond等^[16]
“水—能—碳”耦合	区域水系统与碳排放	物质流和生命周期分析	多伦多等4个城市	2014	Venkatesh等^[1]
	农业水资源开发利用的碳排放	样点调查和估算方法	中国	2012	Wang等^[27]
	农作物“水—碳—能”通量	涡度相关法	加拿大	2005	Kothavala等^[31]
“土—碳”耦合	土地利用与土壤碳通量	碳通量观测	美国加利福尼亚	2006	Carlisle等^[37]
“土—碳”耦合	土地利用与生态系统碳收支	参数估算法	美国	1999	Houghton等^[40]
“土—能—碳”耦合	土地利用、能源消费与碳排放	温室气体清单	巴基斯坦	2012	Ali等^[3]
“土—能—碳”耦合	面向低碳的土地利用调控	线性规划	中国	2011	赖力等^[49]
“能—碳”耦合	能源消费碳排放的核算	温室气体清单	全球	2010	Kennedy等^[2]
“能—碳”耦合	能源流通与隐含碳转移	隐含碳分析	南京市	2014	Zhao等^[78]
“水—土—能—碳”耦合	“水—土—能—碳”系统与生态系统服务	能值分析方法	巴西	2014	Watanabe等^[5]
“水—土—能—碳”耦合	“水—土—能—碳”和气候变化关系	系统分析方法	美国	2012	Skaggs等^[4]

耦合关系	需求种类	主要环节^[4]	碳排放
水土关系	水资源开发对土地的需求	流域集水/蓄水工程、地表覆被工程、生态系统保护与建设。	水利工程及生态保护工程的直接和间接的碳排放。
水土关系	土地开发对水的需求	生态系统保护、农作物生产、畜牧业、采矿业、工业、市政、商业及生活用水。	不同土地利用方式下的水资源开发的碳排放;土地开发导致的直接碳排放。
土能关系	土地开发对能源的需求	土地开发、交通建设、经济生活、资源开发与利用。	土地开发过程中能源消费的碳排放;土地开发导致的直接碳排放;资源开发过程中能源消费的碳排放;各项经济活动能源消费的碳排放。
土能关系	能源开发对土地的需求	能源基础设施建设、水利工程、矿山开采、电厂、太阳能和风能工厂、输电线路建设、输油管道、铁路、精炼厂/炼油厂、生物能源及生物燃料生产、碳捕获与封存、能源矿床开发。	能源基地及能源基础设施建设活动中的碳排放;能源开采和运输过程中的碳泄露;土地利用方式变化的直接碳排放。
水能关系	水资源开发对能源的需求	抽水、输水、水资源调节及污水处理。	水资源开发过程中能源消费的碳排放;污水处理过程的碳排放。
水能关系	能源开发对水的需求	能源开发与提取、冷却、加工、碳捕获与封存等过程。	能源开发用水过程中能源消耗的碳排放。

区域“水—土—能—碳”耦合作用机制分析

The coupling interaction mechanism of regional water-land-energy-carbon system

RichHTML

PDF (PC)

赞

可视化

被引次数

摘要/Abstract

引用本文

使用本文

图/表 8

参考文献 83

相关文章 15

Metrics

本文评价

[1]	徐藜丹, 邓祥征, 姜群鸥, 马丰魁. 中国县域多维贫困与相对贫困识别及扶贫路径研究[J]. 地理学报, 2021, 76(6): 1455-1470.
[2]	刘诗奇, 王平, 王田野, 黄其威, 于静洁. 西伯利亚北极河流有机碳输出特征及影响要素[J]. 地理学报, 2021, 76(5): 1065-1077.
[3]	王利, 吴良, 李言鹏, 张丹, 杨林生. 北极能源开发的地缘要素驱动机制[J]. 地理学报, 2021, 76(5): 1078-1089.
[4]	郭向阳, 穆学青, 丁正山, 秦东丽. 长三角多维城市化对PM_2.5浓度的非线性影响及驱动机制[J]. 地理学报, 2021, 76(5): 1274-1293.
[5]	张可云, 朱春筱. 中国工业结对集聚和空间关联性分析[J]. 地理学报, 2021, 76(4): 1019-1033.
[6]	吴锋, 刘桂君, 郭纳良, 李志慧, 邓祥征. COVID-19疫情对中国区域经济及产业的影响[J]. 地理学报, 2021, 76(4): 1034-1048.
[7]	田深圳, 李雪铭, 杨俊, 张威, 郭建科. 东北三省城市拟态与现实人居环境时空耦合协调特征与机制[J]. 地理学报, 2021, 76(4): 781-798.
[8]	盛科荣, 张杰, 张红霞. 上市公司500强企业网络嵌入对中国城市经济增长的影响[J]. 地理学报, 2021, 76(4): 818-834.
[9]	王淑佳, 孙九霞. 中国传统村落可持续发展评价体系构建与实证[J]. 地理学报, 2021, 76(4): 921-938.
[10]	李智, 刘劲松. 冀南平原典型农业村落转型特征及成长机制[J]. 地理学报, 2021, 76(4): 939-954.
[11]	袁丽华, 陈小强, 宋长青, 程昌秀, 沈石. 环印度洋区域国家地缘经济格局分析[J]. 地理学报, 2021, 76(4): 955-972.
[12]	王少剑, 崔子恬, 林靖杰, 谢金燕, 苏坤. 珠三角地区城镇化与生态韧性的耦合协调研究[J]. 地理学报, 2021, 76(4): 973-991.
[13]	马佐澎, 李诚固, 张平宇. 东北三省城镇收缩的特征及机制与响应[J]. 地理学报, 2021, 76(4): 767-780.
[14]	陈妤凡, 徐勇. 区域环境功能管控区划方法及应用[J]. 地理学报, 2021, 76(3): 663-679.
[15]	袁丹, 朱传耿, 陈寒昱. 中国按比例安排残疾人就业的动力机制与空间分布[J]. 地理学报, 2021, 76(2): 341-351.
