地理学报 ›› 2016, Vol. 71 ›› Issue (5): 768-780.doi: 10.11821/dlxb201605006
张立伟1(), 傅伯杰2, 吕一河2, 董治宝1,3, 李英杰1, 曾源4, 吴炳方4
收稿日期:
2015-10-14
修回日期:
2015-12-30
出版日期:
2016-05-25
发布日期:
2016-05-25
作者简介:
作者简介:张立伟(1985-), 男, 陕西咸阳人, 博士后, 中国地理学会会员(S110010642M), 主要从事生态系统服务保护优先区评估研究。E-mail:
基金资助:
Liwei ZHANG1(), Bojie FU2, Yihe LÜ2, Zhibao DONG1,3, Yingjie LI1, Yuan ZENG4, Bingfang WU4
Received:
2015-10-14
Revised:
2015-12-30
Published:
2016-05-25
Online:
2016-05-25
Supported by:
摘要:
将生态系统服务保护纳入到传统的以保护区为基础的自然保护之中是生态保护研究的新领域。利用综合指标方法,分析了中国从2000-2010年的4种生态系统服务时空变化特征;并对中国的七大生态保护和恢复区域的服务空间保护成效进行评价,提出了国家尺度上的生态系统服务保护优先性分级。主要结论为:① 中国的生态系统服务自西北向东南逐渐增加,显著增加区主要分布在黄土高原地区,显著减少区主要分布在东北及华北地区。黄土高原的生态系统服务提高主要是农田向草地和林地、草地向林地的转换引的;华北地区的降低主要是耕地的减少以及人工用地的增加引起的;东北地区是由于林地向耕地草地、耕地向湿地与人工用地的转换引起的。② 七大生态保护和恢复区的生态系统服务均为增加趋势而且显著增加面积大于减少面积;显著增加面积最大的为三北防护林工程区、最小的为重点生态功能区;显著减少最大为重要生态功能区、最小的为三北防护林工程区。而且,对服务的保护成效在重要生态功能区最高,其次为天然林保护工程区,其余区域均小于全国平均水平。③ 提出的生态系统服务保护优先性等级中,极高级别占到了国土面积的26.18%,保护的生态系统服务量占到全国总量的64.19%,保护成效为全国平均水平的2.47倍。
张立伟, 傅伯杰, 吕一河, 董治宝, 李英杰, 曾源, 吴炳方. 基于综合指标法的中国生态系统服务保护有效性评价研究[J]. 地理学报, 2016, 71(5): 768-780.
Liwei ZHANG, Bojie FU, Yihe LÜ, Zhibao DONG, Yingjie LI, Yuan ZENG, Bingfang WU. The using of composite indicators to assess the conservational effectiveness of ecosystem services in China[J]. Acta Geographica Sinica, 2016, 71(5): 768-780.
表2
不同生态地区的总生态系统服务变化统计特征
生态区 | 多年平均总生态系统服务 | 2000-2010年的线性趋势 | |
---|---|---|---|
均值 | 总量 | 均值 | |
西北干旱生态地区 | 131.155 | 3713780000 | 0.321 |
青藏高原高寒生态地区 | 228.792 | 6468300000 | 0.255 |
内蒙古高原生态地区 | 244.272 | 3162330000 | 0.619 |
东北生态地区 | 444.568 | 8117970000 | -2.335 |
黄土高原生态地区 | 474.641 | 3802090000 | 3.310 |
华北生态地区 | 596.247 | 4820720000 | -3.287 |
长江中下游生态地区 | 795.032 | 5591970000 | 2.083 |
横断山区生态地区 | 690.687 | 6043490000 | 0.435 |
川渝生态地区 | 795.778 | 7432540000 | 4.049 |
华南生态地区 | 1064.16 | 15082600000 | 4.326 |
云贵高原生态地区 | 1052.16 | 8662450000 | 0.385 |
表3
中国各生态区域保护的总生态系统服务的显著性变化比例、占全国的保护总量比例以及保护效率特征
趋势变化显著性等级 | 国家级自然保护区 | 重要生态功能区 | 重点生态功能区 | 两屏三带区 | 天然林资源保护区 | 退耕还林工程区 | 三北防护林工程区 | 七大区域并集 |
---|---|---|---|---|---|---|---|---|
显著减少(%) | 3.11 | 4.16 | 3.63 | 4.05 | 3.06 | 3.55 | 3.04 | 3.69 |
不显著减少(%) | 33.87 | 40.42 | 40.63 | 40.13 | 41.07 | 37.85 | 33.53 | 38.70 |
无变化(%) | 0.01 | 0.00 | 0.00 | 0.00 | 0.00 | 0.00 | 0.00 | 0.00 |
不显著增加(%) | 53.29 | 46.80 | 48.12 | 46.98 | 47.39 | 50.36 | 51.70 | 49.64 |
显著增加(%) | 9.72 | 8.61 | 7.62 | 8.83 | 8.48 | 8.24 | 11.72 | 7.97 |
占全国总量比例(%) | 5.50 | 27.35 | 25.82 | 32.00 | 37.17 | 77.20 | 20.21 | 86.05 |
保护效率指数 | 0.61 | 1.10 | 0.91 | 0.85 | 1.08 | 0.99 | 0.49 | 0.95 |
[1] |
Costanza R, d'Arge R, de Groot R S, et al. The value of the world’s ecosystem services and natural capital. Nature, 1997, 387(6630): 253-260.
doi: 10.1038/387253a0 |
[2] | MEA (Millennium Ecosystem Assessment). Ecosystems and human well-being: Synthesis. Washington, DC: World Resources Institute, 2005. |
[3] |
Sutherland W J, Armstrong Brown S, Armsworth P R, et al.The identification of 100 ecological questions of high policy relevance in the UK. Journal of Applied Ecology, 2006, 43(4): 617-627.
doi: 10.1111/j.1365-2664.2006.01188.x |
[4] |
Palmer M A, Morse J, Bernhardt E, et al.Ecology for a crowded planet. Science, 2004, 304(5675): 1251-1252.
doi: 10.1126/science.1095780 pmid: 15166349 |
[5] |
Crossman N D, Nedkov B B S. Quantifying and mapping ecosystem services. International Journal of Biodiversity Science, 2012, 8(1): 1-4.
doi: 10.1080/21513732.2012.695229 |
[6] | Liu J G, Li S X, Ouyang Z Y, et al.Ecological and socioeconomic effects of China's policies for ecosystem services. Proceedings of the National academy of Sciences of the United States of America, 2008, 105(28): 9477-9482. |
[7] |
Cowling R M, Egoh B, Knight A T, et al.An operational model for mainstreaming ecosystem services for implementation. Proceedings of the National Academy of Sciences of the United States of America, 2008, 105(28): 9483-9488.
doi: 10.1073/pnas.0706559105 pmid: 18621695 |
[8] |
Daily G C, Polasky S, Goldstein J, et al.Ecosystem services in decision making: Time to deliver. Frontiers in Ecology and the Environment, 2009, 7(1): 21-28.
doi: 10.1890/080025 |
[9] |
Trabucchi M, Ntshotsho P, O’Farrell P, et al. Ecosystem service trends in basin-scale restoration initiatives: A review. Journal of Environmental Management, 2012, 111(6): 18-23.
doi: 10.1016/j.jenvman.2012.06.040 pmid: 22813855 |
[10] |
Bateman I J, Harwood A R, Mace G M, et al.Bringing ecosystem services into economic decision-making: Land use in the United Kingdom. Science, 2013, 341(6141): 45-50.
doi: 10.1126/science.1234379 pmid: 23828934 |
[11] | Maes J, Teller A, Erhard M, et al.Mapping and Assessment of Ecosystems and their Services. An analytical framework for ecosystem assessments under action 5 of the EU biodiversity strategy to 2020. Publications Office of the European Union, Luxembourg, 2013. |
[12] |
Speziale L, Geneletti D.Applying an ecosystem services approach to support land-use planning: A case study in Koboko district, Uganda. Ecological Processes, 2014, 3(1): 1-13.
doi: 10.1186/2192-1709-3-10 |
[13] |
Pimm S L, Jenkins C N, Abell R, et al.The biodiversity of species and their rates of extinction, distribution, and protection. Science, 2014, 344(6187): 1246752.
doi: 10.1126/science.1246752 pmid: 24876501 |
[14] | Brooks T M, Mittermeier R A, da Fonseca G A, et al. Global biodiversity conservation priorities. Science, 2006, 313(5783): 58-61. |
[15] | Jax K, Barton D N,Chan K M A, et al. Ecosystem services and ethics. Ecological Economics, 2013, 93(3): 260-268. |
Rodrigues A S L. Are global conservation efforts successful? Science, 2006, 313(5790): 1051-1052. | |
[16] |
Paviolo A, Blanco Y E D, Angelo C D, et al. Protection affects the abundance and activity patterns of pumas in the Atlantic Forest. Journal of Mammalogy, 2009, 90(4): 926-934.
doi: 10.1644/08-MAMM-A-128.1 |
[17] | Wilcove D S, Rothstein D, Dubow J, et al.Quantifying threats to imperiled species in the United States. BioScience, 1998, 48(8): 607-615. |
[18] |
Butchart S H M, Walpole1 M, Collen B, et al. Global biodiversity: Indicators of recent declines. Science, 2010, 328(5982): 1164-1168.
doi: 10.1126/science.1187512 pmid: 20430971 |
[19] |
Balvanera P, Daily G C, Ehrlich P R, et al.Conserving biodiversity and ecosystem services. Science, 2001, 291(5511): 2047.
doi: 10.1126/science.291.5511.2047 pmid: 11256386 |
[20] |
Egoh B, Rouget M, Reyers B, et al.Integrating ecosystem services into conservation assessments: A review. Ecological Economics, 2007, 63(4): 714-721.
doi: 10.1016/j.ecolecon.2007.04.007 |
[21] |
Goldman R L, Tallis H.A critical analysis of ecosystem services as a tool in conservation projects. Annals of the New York Academy of Sciences, 2009, 1162: 63-78.
doi: 10.1016/0735-1097(88)91548-3 pmid: 19432645 |
[22] |
Tallis H, Goldman R, Uhl M, et al.Integrating conservation and development in the field: Implementing ecosystem service projects. Frontiers in Ecology and the Environment, 2009, 7(1): 12-20.
doi: 10.1890/080012 |
[23] |
Polasky S, Johnson K, Keeler B, et al.Are investments to promote biodiversity conservation and ecosystem services aligned? Oxford Review of Economic Policy, 2012, 28(1): 139-163.
doi: 10.1093/oxrep/grs011 |
[24] | Lü Yihe, Zhang Liwei, Wang Jianglei.Assessment of ecosystem and its services conservation: Indicators and methods. Chinese Journal of Applied Ecology, 2013, 24(5): 1237-1243. |
[吕一河, 张立伟, 王江磊. 生态系统及其服务保护评估: 指标与方法. 应用生态学报, 2013, 24(5): 1237-1243.] | |
[25] |
Turner W R, Brandon K, Brooks T M, et al.Global conservation of biodiversity and ecosystem services. Bioscience, 2007, 57(10): 868-873.
doi: 10.1641/B571009 |
[26] |
Maes J, Paracchini M L, Zulian G, et al.Synergies and trade-offs between ecosystem service supply, biodiversity, and habitat conservation status in Europe. Biological Conservation, 2012, 155(4): 1-12.
doi: 10.1016/j.biocon.2012.06.016 |
[27] |
Chan K M, Hoshizaki L, Klinkenberg B.Ecosystem services in conservation planning: Targeted benefits vs. co-benefits or costs? PloS one, 2011, 6(9): e24378.
doi: 10.1371/journal.pone.0024378 pmid: 3167855 |
[28] |
Daily G C, Matson P A.Ecosystem services: From theory to implementation. Proceedings of the National Academy of Sciences of the United States of America, 2008, 105(28): 9455-9456.
doi: 10.1073/pnas.0804960105 pmid: 18621697 |
[29] |
Zhang Liwei, Fu Bojie.The progress in ecosystem services mapping: A review. Acta Ecologica Sinica, 2014, 34(2): 316-325.
doi: 10.5846/stxb201303110391 |
[张立伟, 傅伯杰. 生态系统服务制图研究进展. 生态学报, 2014, 34(2): 316-325.]
doi: 10.5846/stxb201303110391 |
|
[30] |
Burkhard B, Crossman N, Nedkov S, et al.Mapping and modelling ecosystem services for science, policy and practice. Ecosystem Services, 2013, 4: 1-3.
doi: 10.1016/j.ecoser.2013.04.005 |
[31] | Martínez-Harms, M J, Balvanera P. Methods for mapping ecosystem service supply: A review. International Journal of Biodiversity Science, Ecosystem Services & Management, 2012, 8(1-2), 17-25. |
[32] |
Egoh B, Drakou E G, Dunbar M B, et al.Indicators for mapping ecosystem services: A review. Luxembourg: Publications Office of the European Union, 2012.
doi: 10.13140/2.1.3420.2565 |
[33] | Eigenbrod F, Armsworth P R, Anderson B J, et al.The impact of proxy-based methods on mapping the distribution of ecosystem services. Journal of Applied Ecology, 2010, 47(2): 377-385. |
[34] | Hauck J, Görg C, Varjopuro R, et al."Maps have an air of authority": Potential benefits and challenges of ecosystem service maps at different levels of decision making. Ecosystem Services, 2013, 4(1): 25-32. |
[35] | Burkhard B, Kroll F, Nedkov S, et al.Mapping supply, demand and budgets of ecosystem services. Ecological Indicators, 2012, 21(3): 17-20. |
[36] |
Crossman N D, Burkhard B, Nedkov S, et al.A blueprint for mapping and modelling ecosystem services. Ecosystem Services, 2013, 4: 4-14.
doi: 10.1016/j.ecoser.2013.02.001 |
[37] |
Malmstrom C M, Butterfield H S, Barber C, et al.Using remote sensing to evaluate the influence of grassland restoration activities on ecosystem forage provisioning services. Restoration Ecology, 2008, 17(4): 526-538.
doi: 10.2514/1.17327 |
[38] |
Friedl M A, Sulla-Menashe D, Tan B, et al.MODIS Collection 5 global land cover: Algorithm refinements and characterization of new datasets. Remote Sensing of Environment, 2010, 114(1): 168-182.
doi: 10.1016/j.rse.2009.08.016 |
[39] |
Lautenbach S, Kugel C, Lausch A, et al.Analysis of historic changes in regional ecosystem service provisioning using land use data. Ecological Indicators, 2011, 11(2): 676-687.
doi: 10.1016/j.ecolind.2010.09.007 |
[40] |
Homolová L, Schaepman M E, Lamarque P, et al.Comparison of remote sensing and plant trait-based modelling to predict ecosystem services in subalpine grasslands. Ecosphere, 2014, 5(8): 100.
doi: 10.1890/ES13-00393.1 |
[41] |
Feng X, Fu B,YangX, et al. Remote sensing of ecosystem services: An opportunity for spatially explicit assessment. Chinese Geographical Science, 2010, 20(6): 522-535.
doi: 10.1007/s11769-010-0428-y |
[42] |
Ayanu Y Z, Conrad C, Nauss T, et al.Quantifying and mapping ecosystem services supplies and demands: A review of remote sensing applications. Environmental Science & Technology, 2012, 46(16): 8529-8541.
doi: 10.1021/es300157u pmid: 22816512 |
[43] |
Andrew M E, Nelson T A, Wulder M A.Potential contributions of remote sensing to ecosystem service assessments. Progress in Physical Geography, 2014, 38(3): 328-352.
doi: 10.1177/0309133314528942 |
[44] |
Roces-Díaz J V, Díaz-Varela R A, Álvarez-Álvarez P, et al. A multiscale analysis of ecosystem services supply in the NW Iberian Peninsula from a functional perspective. Ecological Indicators, 2015, 50: 24-34.
doi: 10.1016/j.ecolind.2014.10.027 |
[45] |
Feng Zhiming.Land use zoning scheme of China based on detailed land surveys. Journal of Natural Resources, 2001, 16(4): 325-333.
doi: 10.3321/j.issn:1000-3037.2001.04.005 |
[封志明. 一个基于土地利用详查的中国土地资源利用区划新方案. 自然资源学报, 2001, 16(4): 325-333.]
doi: 10.3321/j.issn:1000-3037.2001.04.005 |
|
[46] |
Wu Shaohong, Yang Qinye, Zheng Du.Delineation of eco-geographic regional system of China. Journal of Geographical Sciences, 2003, 13(3): 309-315.
doi: 10.1007/BF02837505 |
[47] |
Fu Bojie, Liu Guohua, Lü Yihe, et al.Ecoregions and ecosystem management in China. The International Journal of Sustainable Development & World Ecology, 2004, 11(4): 397-409.
doi: 10.1080/13504500409469842 |
[48] | Zheng Jingyun, Yin Yunhe, Li Bingyuan.A new scheme for climate regionalization in China. Acta Geographica Sinica, 2010, 65(1): 3-12. |
[郑景云, 尹云鹤, 李柄元. 中国气候区划新方案. 地理学报, 2010, 65(1): 3-12.] | |
[49] |
Lü Y H, Ma Z, Zhang L W, et al.Redlines for the greening of China. Environmental Science & Policy, 2013, 33(11): 346-353.
doi: 10.1016/j.envsci.2013.05.007 |
[50] |
Potter C S, Rerson J T, Field C B, et al.Terrestrial ecosystem production: A process model based on global satellite and surface data. Global Biogeochemical Cycles, 1993, 7(4): 811-841.
doi: 10.1029/93GB02725 |
[51] | Wischmeier W H, Smith D D.Predicting Rainfall-erosion Losses from Cropland East of the Rocky Mountains: Guide for Selection of Practices for Soil and Water Conservation. US Department of Agriculture, Washington, DC, 1965. |
[52] | Budyko M I.Climate and Life. San Diego, California: Academic Press, 1974. |
[53] |
Zhang L W, Dawes W R, Walker G R.Response of mean annual ET to vegetation changes at catchment scale. Water Resources Research, 2001, 37(3): 701-708.
doi: 10.1029/2000WR900325 |
[54] |
Zhang L W, Fu B J, Lü Y H, et al.Balancing multiple ecosystem services in conservation priority setting. Landscape Ecology, 2014, 30(3): 535-546.
doi: 10.1007/s10980-014-0106-z |
[55] |
Carreño L, Frank F C, Viglizzo E F.Tradeoffs between economic and ecosystem services in Argentina during 50 years of land-use change. Agriculture Ecosystems & Environment, 2012, 154(5): 68-77.
doi: 10.1016/j.agee.2011.05.019 |
[56] | Lü Y H, Zhang L W, Feng X, et al.Recent ecological transitions in China: Ereening, browning, and influential factors. Scientific Reports, 2015, 5. |
[57] |
Zurlini G, Petrosillo I, Aretano R, et al.Key fundamental aspects for mapping and assessing ecosystem services: Predictability of ecosystem service providers at scales from local to global. Annali Di Botanica, 2014, 4: 53-63.
doi: 10.4462/annbotrm-11754 |
[58] | Gaston K J.Global patterns in biodiversity. Nature, 2000, 405(6783): 220-227. |
[59] |
Costanza R.Ecosystem services: Multiple classification systems are needed. Biological Conservation, 2008, 141(2): 350-352.
doi: 10.1016/j.biocon.2007.12.020 |
[60] |
Costanza R, Fisher B, Mulder K, et al.Biodiversity and ecosystem services: A multi-scale empirical study of the relationship between species richness and net primary production. Ecological Economics, 2007, 61(S2-3): 478-491.
doi: 10.1016/j.ecolecon.2006.03.021 |
[61] |
Richmond A, Kaufmann R K, Myneni R B.Valuing ecosystem services: A shadow price for net primary production. Ecological Economics, 2007, 64(2): 454-462.
doi: 10.1016/j.ecolecon.2007.03.009 |
[62] | Petrosillo I, Semeraro T, Zaccarelli N, et al.The possible combined effects of land-use changes and climate conditions on the spatial-temporal patterns of primary production in a natural protected area. Ecological Indicators, 2013, 29(6):367-375. |
[63] |
Barral M P, Oscar M N.Land-use planning based on ecosystem service assessment: A case study in the Southeast Pampas of Argentina. Agriculture, Ecosystems & Environment, 2012, 154(7): 34-43.
doi: 10.1016/j.agee.2011.07.010 |
[64] |
Liu Y, Zhang H, Yang X, et al.Identifying priority areas for the conservation of ecosystem services using GIS-based multicriteria evaluation. Polish Journal of Ecology, 2013, 61(1): 415-430.
doi: 10.3402/polar.v32i0.19888 |
[65] | Liu Xinping, Liu Cunxia.Educational Statistics and Evolutional Introductions. Beijing: Science Press, 2003. |
[刘新平, 刘存侠. 教育统计与测评导论. 北京: 科学出版社, 2003.] | |
[66] | Fu Bojie, Liu Guohua, Chen Liding, et al.Scheme of ecological regionalization in China. Acta Ecologica Sinica, 2001, 21(1): 1-6. |
[傅伯杰, 刘国华, 陈利顶, 等. 中国生态区划方案.生态学报, 2001, 21(1): 1-6.] | |
[67] |
Xie Gaodi, Zhang Changshun, Zhang Linbo, et al.China's county-scale ecological regionalization. Journal of Natural Resources, 2012, 27(1): 154-162.
doi: 10.11849/zrzyxb.2012.01.016 |
[谢高地, 张昌顺, 张林波, 等. 保持县域边界完整性的中国生态区划方案. 自然资源学报, 2012, 27(1): 154-162.]
doi: 10.11849/zrzyxb.2012.01.016 |
