近50年来祁连山冰川变化——基于中国第一、二次冰川编目数据

doi:10.11821/dlxb201509004

地理学报 ›› 2015, Vol. 70 ›› Issue (9): 1402-1414.doi: 10.11821/dlxb201509004

近50年来祁连山冰川变化——基于中国第一、二次冰川编目数据

孙美平^1,²(), 刘时银²(), 姚晓军¹, 郭万钦², 许君利²

1. 西北师范大学地理与环境科学学院,兰州 730070
2. 中国科学院寒区旱区环境与工程研究所冰冻圈科学国家重点实验室,兰州 730000

收稿日期:2015-04-26 修回日期:2015-06-19 出版日期:2015-09-20 发布日期:2015-09-20
作者简介:
作者简介：孙美平(1981-), 女, 辽宁沈阳人, 博士, 副教授, 主要从事寒区水文过程与气候变化影响评估研究。E-mail: sunmeiping1982@163.com
基金资助:
科技部科技基础性工作专项(2013FY111400);国家重大科学研究计划项目(2010CB951401);国家科技支撑计划项目(2012BAC19B07);国家自然科学基金(41261016);甘肃省高等学校科研项目(2014A-001, 2013A-018)

Glacier changes in the Qilian Mountains in the past half century: Based on the revised First and Second Chinese Glacier Inventory

Meiping SUN^1,²(), Shiyin LIU²(), Xiaojun YAO¹, Wanqin GUO², Junli XU²

Received:2015-04-26 Revised:2015-06-19 Published:2015-09-20 Online:2015-09-20
Supported by:
National Basic Work Program of MST, No.2013FY111400;National Major Sciences Research, No.2010CB951401;National Science-technology Support Plan Project, No.2012BAC19B07;National Natural Science Foundation of China, No.41261016;Scientific Research Project of Higher Learning Institution in Gansu Province, No.2014A-001, No.2013A-018

摘要/Abstract

摘要：

基于修订后的祁连山区第一次冰川编目（1956-1983年）和最新发布的第二次冰川编目数据（2005-2010年）,对祁连山区冰川变化进行分析。结果表明：① 祁连山区现有冰川2684条,面积1597.81±70.30βkm²,冰储量约84.48βkm³。其中,甘肃省和青海省各有冰川1492条和1192条,面积分别为760.96βkm²和836.85βkm²。② 祁连山区冰川数量和面积分别以面积< 1.0βkm²的冰川和面积介于1~5βkm²的冰川为主;冰川平均中值面积海拔为4972.7βm,并自东向西由4483.8βm逐渐上升为5234.1βm。③ 疏勒河流域冰川面积和冰储量最大,占祁连山冰川总量的31.91%和35.11%;其次是哈尔腾河流域,巴音郭勒河流域冰川面积最小,为2.20βkm²;黑河流域是祁连山区冰川平均面积最小的四级流域,冰川平均面积仅0.21βkm²。④ 近50年间祁连山冰川面积和冰储量分别减少420.81βkm²（-20.88%）和21.63βkm³（-20.26%）。面积< 1.0βkm²的冰川急剧萎缩是该区冰川面积减少的主要原因,海拔4000βm以下山区冰川已完全消失,海拔4350~5100βm区间冰川面积减少量占冰川面积总损失的84.24%。冰川数量和面积在各个朝向均呈减少态势,其中朝北冰川面积减少最多,朝东冰川面积减少最快,而西北朝向冰川变化最为缓慢。⑤ 祁连山冰川变化呈现明显的经度地带性分异,东段冰川退缩较快,中西段冰川面积减少较慢。

关键词: 冰川, 编目, 冰储量, 气候变化, 祁连山

Abstract:

According to the Second Chinese Glacier Inventory (SCGI) that were mostly compiled based on Landsat TM/ETM+images, the Qilian Mountains contained 2684 glaciers covering an area of 1597.81±70.30βkm² and ice volume of ~84.48βkm³ from 2005 to 2010. While most glaciers are small (85.66% are smaller than 1.0βkm²), some larger ones (12.74%, with each having 1.0 and 5.0βkm²) cover 42.44% of the total glacier area. The Laohugou No.12 Glacier (20.42βkm²) located on the north slope of the Daxue Range is the only one larger than 20 km² in the Qilian Mountains. The average median altitude of glacier was 4972.7βm a.s.l. and gradually rose from east to west. Glaciers in the Qilian Mountains are mostly distributed in Gansu and Qinghai provinces, which have 1492 glaciers (760.96βkm²) and 1192 glaciers (836.85βkm²), respectively. In 11 watersheds, the Shule River contains most of the glaciers in either area or volume. However, the Heihe River, the second longest interior river in China, has the minimum average area of glacier. Comparison of glaciers from the SCGI and the revised glacier inventory based on topographic maps and aerial photos taken from 1956 to 1983 indicated that all the glaciers in the Qilian Mountains were receding, which is consistent with other mountains and plateaus in western China. In the past half century, the area and volume of glaciers decreased by 420.81βkm² (-20.88%) and 21.63βkm³ (-20.26%), respectively. The glaciers which are smaller than 1.0βkm² constituted the main body of glacier number depression and area recession. Due to shrinkage, the glaciers below 4000βm a.s.l. completely disappeared.

Key words: glacier, glacier inventory, glacier volume, climate change, Qilian Mountains

孙美平, 刘时银, 姚晓军, 郭万钦, 许君利. 近50年来祁连山冰川变化——基于中国第一、二次冰川编目数据[J]. 地理学报, 2015, 70(9): 1402-1414.

Meiping SUN, Shiyin LIU, Xiaojun YAO, Wanqin GUO, Junli XU. Glacier changes in the Qilian Mountains in the past half century: Based on the revised First and Second Chinese Glacier Inventory[J]. Acta Geographica Sinica, 2015, 70(9): 1402-1414.

图/表 11

图1

图2

图4

图3

表1

表2

图5

图6

图7

图8

表3

参考文献 39

[1]	Kargel J S, Leonard G J, Bishop M P, et al.Global Land Ice Measurements from Space. Heidelberg: Springer, 2014.
[2]	Orelemans J.Modelling the response of glaciers to climate warming. Climate Dynamics, 1998, 14(4): 267-274.
[3]	Shi Yafeng, Liu Shiyin.Pre-estimation for the response of China glaciers to global warming in the 21st century. Chinese Science Bulletin, 2000, 45(4): 434-438.
	[施雅风, 刘时银. 中国冰川对21世纪全球变暖响应的预估. 科学通报, 2000, 45(4): 434-438.]
[4]	Xie Zichu, Feng Qinghua, Wang Xin, et al.Modeling the response of glacier system to climate warming: Taking glaciers in China as an example. Research of Soil and Water Conservation, 2005, 12(5): 77-82.
	[谢自楚, 冯清华, 王欣, 等. 中国冰川系统变化趋势预测研究. 水土保持研究, 2005, 12(5): 77-82.]
[5]	Liu Shiyin, Yao Xiaojun, Guo Wanqin, et al.The contemporary glaciers in China base on the Second Chinese Glacier Inventory. Acta Geographica Sinica, 2015, 70(1): 3-16.
	[刘时银, 姚晓军, 郭万钦, 等. 基于第二次冰川编目的中国冰川现状. 地理学报, 2015, 70(1): 3-16.]
[6]	Liu Chaohai, Kang Ersi, Liu Shiyin, et al.Study on the glacier variation and its runoff responses in the arid region of northwest China. Science in China Series D, 1999, 29(S1): 55-62.
	[刘潮海, 康尔泗, 刘时银, 等. 西北干旱区冰川变化及其径流效应研究. 中国科学(D辑: 地球科学), 1999, 29(增刊1): 55-62.]
[7]	Zhang Jiutian, He Xiaojia, Shangguan Donghui, et al.Impact of intensive glacier ablation on arid regions of northwest China and its countermeasure. Journal of Glaciology and Geocryology, 2012, 34(4): 848-854.
	[张九天, 何霄嘉, 上官冬辉, 等. 冰川加剧消融对我国西北干旱区的影响及其适应对策. 冰川冻土, 2012, 34(4): 848-854.]
[8]	Wang Yuzhe, Ren Jiawen, Qin Dahe, et al.Regional glacier volume changes derived from satellite data: A case study in the Qilian Mountains. Journal of Glaciology and Geocryology, 2013, 35(3): 583-592.
	[王玉哲, 任贾文, 秦大河, 等. 利用卫星资料反演区域冰川冰量变化的尝试: 以祁连山为例. 冰川冻土, 2013, 35(3): 583-592.]
[9]	Zhang Mingjun, Wang Shengjie, Li Zhongqin, et al.Variation of glacier area in China against the warming in the past 50 years. Acta Geographica Sinica, 2011, 66(9): 1155-1165.
	[张明军, 王圣杰, 李忠勤, 等. 近50年气候变化背景下中国冰川面积状况分析. 地理学报, 2011, 66(9): 1155-1165.]
[10]	Liu Shiyin, Shen Yongping, Sun Wenxin, et al.Glacier variation since the Maximum of the Little Ice Age in the western Qilian Mountains, northwest China. Journal of Glaciology and Geocryology, 2002, 24(3): 227-233.
	[刘时银, 沈永平, 孙文新, 等. 祁连山西段小冰期以来的冰川变化研究. 冰川冻土, 2002, 24(3): 227-233.]
[11]	Liu Shiyin, Ding Yongjian, Li Jing, et al.Glaciers in response to recent climate warming in western China. Quaternary Sciences, 2006, 26(5): 762-771.
	[刘时银, 丁永建, 李晶, 等. 中国西部冰川对近期气候变暖的响应. 第四纪研究, 2006, 26(5): 762-771.]
[12]	Chen Hui, Li Zhongqin, Wang Puyu, et al.Change of glaciers in the central Qilian Mountain. Arid Zone Research, 2013, 30(4): 588-593.
	[陈辉, 李忠勤, 王璞玉, 等. 近年来祁连山中段冰川变化. 干旱区研究, 2013, 30(4): 588-593.]
[13]	Bie Qiang, Qiang Wenli, Wang Chao, et al.Monitoring the glacier variation in the upper reaches of the Heihe River based on remote sensing in 1961-2010. Journal of Glaciology and Geocryology, 2013, 35(3): 574-582.
	[别强, 强文丽, 王超, 等. 1960-2010年黑河流域冰川变化的遥感监测. 冰川冻土, 2013, 35(3): 574-582.]
[14]	Cao Bo, Pan Baotian, Gao Hongshan, et al.Glacier variation in the Lenglongling Range of eastern Qilian Mountains from 1972 to 2007. Journal of Glaciology and Geocryology, 2010, 32(2): 242-248.
	[曹泊, 潘保田, 高红山, 等. 1972-2007年祁连山东段冷龙岭现代冰川变化研究. 冰川冻土, 2010, 32(2): 242-248.]
[15]	Zhang Huawei, Lu Anxin, Wang Lihong, et al.Glacier change in the Lenglongling Mountain monitored by remote sensing. Remote Sensing Technology and Application, 2010, 25(5): 682-686.
	[张华伟, 鲁安新, 王丽红, 等. 基于遥感的祁连山东部冷龙岭冰川变化研究. 遥感技术与应用, 2010, 25(5): 682-686.]
[16]	Tian H, Yang T, Liu Q.Climate change and glacier area shrinkage in the Qilian Mountains, China, from 1956 to 2010. Annals of Glaciology, 2014, 55(66): 187-197.
[17]	Yao Xiaojun, Liu Shiyin, Guo Wanqin, et al.Glacier change of Altay Mountain in China from 1960 to 2009: Based on the Second Glacier Inventory of China. Journal of Natural Resources, 2012, 27(10): 1734-1745.
	[姚晓军, 刘时银, 郭万钦, 等. 近50a来中国阿尔泰山冰川变化: 基于中国第二次冰川编目成果. 自然资源学报, 2012, 27(10): 1734-1745.]
[18]	Paul F, Barry R G, Cogley J G, et al.Recommendations for the compilation of glacier inventory data from digital sources. Annals of Glaciology, 2010, 50(53): 119-126.
[19]	You Lianyuan, Yang Jingchun.Geomorphology in China. Beijing: Science Press, 2013.
	[尤联元, 杨景春. 中国地貌. 北京:科学出版社, 2013.]
[20]	Wang Zongtai, Liu Chaohai, You Genxiang, et al.Glacier Inventory of China I Qilian Mountains. Lanzhou: Lanzhou Institute of Glaciology and Cryopedology, CAS, 1981.
	[王宗太, 刘潮海, 尤根祥, 等. 中国冰川目录I祁连山区. 兰州: 中国科学院兰州冰川冻土研究所, 1981.]
[21]	Shi Yafeng.A Concise China Glacier Inventory. Shanghai: Shanghai Science Popular Press, 2005.
	[施雅风. 简明中国冰川目录. 上海: 上海科学普及出版社, 2005.]
[22]	Guo W, Liu S, Xu J, et al.The second Chinese glacier inventory. Journal of Glaciology, 2015, 61(226): 357-372.
[23]	Yan Lili, Wang Jian.Study of extracting glacier information from remote sensing. Journal of Glaciology and Geocryology, 2013, 35(1): 110-118.
	[彦立利, 王建. 基于遥感的冰川信息提取方法研究进展. 冰川冻土, 2013, 35(1): 110-118.]
[24]	Racoviteanu A E, Paul F, Raup B, et al.Challenges and recommendations in mapping of glacier parameters from space, Boulder, Colorado, USA. Annals of Glaciology, 2009, 50(53): 53-69.
[25]	Shi Yafeng.Glaciers and their Environments in China: The Present, Past and Future. Beijing: Science Press, 2000.
	[施雅风. 中国冰川与环境: 现在、过去和未来. 北京: 科学出版社, 2000.]
[26]	Su Zhen, Zhao Jingdong, Zheng Benxing.Distribution and features of the glaciers' ELAs and the decrease of ELAs during the Last Glaciation in China. Journal of Glaciology and Geocryology, 2014, 36(1): 9-19.
	[苏珍, 赵井东, 郑本兴. 中国现代冰川平衡线分布特征与末次冰川平衡线下降值研究. 冰川冻土, 2014, 36(1): 9-19.]
[27]	Radić V, Hock R.Regional and global volumes of glaciers derived from statistical upscaling of glacier inventory data. Journal of Geophysical Research, 2010, 115, F01010. doi: 10.1029/2009JF001373.
[28]	Ding Yihui.Assessment of Environmental Evolution in Western China (Volume II): Science Press, 2002.
	[丁一汇. 中国西部环境演变评估(第二卷). 北京: 科学出版社, 2002.]
[29]	Zhang Huawei, Lu Anxin, Wang Lihong, et al.Glacier change in the Shulenan Mountain monitored by remote sensing. Journal of Glaciology and Geocryology, 2011, 33(1): 8-13.
	[张华伟, 鲁安新, 王丽红, 等. 祁连山疏勒南山地区冰川变化的遥感研究. 冰川冻土, 2011, 33(1): 8-13.]
[30]	Gärtner-Roer I, Naegeli K, Huss M, et al.A database of worldwide glacier thickness observations. Global and Planetary Change, 2014, 122: 330-344.
[31]	Grinsted A.An estimate of global glacier volume. The Cryosphere, 2013, 7: 141-151.
[32]	Liu S, Sun W, Shen Y, et al.Glacier changes since the Little Ice Age maximum in the western Qilian Shan, northwest China, and consequences of glacier runoff for water supply. Journal of Glaciology, 2003, 49(164): 117-124.
[33]	Duan Jianping, Wang Lili, Ren Jiawen, et al.Progress in glacier variations in China and its sensitivity to climatic change during the past century. Progress in Geography, 2009, 28(2): 231-237.
	[段建平, 王丽丽, 任贾文, 等. 近百年来中国冰川变化及其对气候变化的敏感性研究进展. 地理科学进展, 2009, 28(2): 231-237.]
[34]	Wang Shengjie, Zhang Mingjun, Li Zhongqin, et al.Reponse of glacier area variation to climate change in Chinese Tianshan Mountains in the past 50 years. Acta Geographica Sinica, 2011, 66(1): 38-46.
	[王圣杰, 张明军, 李忠勤, 等. 近50年来中国天山冰川面积变化对气候的响应. 地理学报, 2011, 66(1): 38-46.]
[35]	Xie Zichu, Liu Chaohai.Introduction to Glaciology. Shanghai: Shanghai Science Popular Press, 2010.
	[谢自楚, 刘潮海. 冰川学导论. 上海: 上海科学普及出版社, 2010.]
[36]	Gao Xiaoqing.Discussion on the relationship between glacial fluctuation and climate change. Plateau Meteorology, 2000, 19(1): 9-16.
	[高晓清. 冰川变化与气候变化关系的若干探讨. 高原气象, 2000, 19(1): 9-16.]
[37]	Wang Haijun, Zhang Bo, Jin Xiaohua, et al.Spatio-temporal variations analysis of air temperature and precipitation in Qilian mountainous region based on GIS. Journal of Desert Research, 2009, 29(6): 1196-1202.
	[王海军, 张勃, 靳晓华, 等. 基于GIS的祁连山区气温和降水的时空变化分析. 中国沙漠, 2009, 29(6): 1196-1202.]
[38]	Zhang Liang, Zhang Qiang, Feng Jianying, et al.A study of atmospheric water cycle over the Qilian Mountains (I): Variation of annual water vapor transport. Journal of Glaciology and Geocryology, 2014, 36(5): 1079-1091.
	[张良, 张强, 冯建英, 等. 祁连山地区大气水循环语句(I): 空中水汽输送年际变化分析. 冰川冻土, 2014, 36(5): 1079-1091.]
[39]	Lin Shu, Li Hongying, Dang Bing, et al.The latest evidences of a warm-wet climatic shift in Hexi Corridor, Gansu. Journal of Glaciology and Geocryology, 2014, 36(5): 1111-1121.
	[林纾, 李红英, 党冰, 等. 甘肃河西走廊地区气候暖湿转型后的最新事实. 冰川冻土, 2014, 36(5): 1111-1121.]

三级流域(编码)	四级流域(编码)	冰川数量			冰川面积			冰储量*
三级流域(编码)	四级流域(编码)	(条)		(%)		(km²)	(%)	(km³)	(%)
大通河(5J4)	大通河(5J42)	68	2.53		20.83	1.30		0.73	0.86
河西内流水系 (5Y4)	石羊河(5Y41)	97	3.61		39.94	2.50		1.55	1.83
	黑河(5Y42)	375	13.97		78.33			4.90	2.39	2.83
	北大河(5Y43)	577	21.50	215.27		13.47	8.75		10.36
	疏勒河(5Y44)	660	24.59	509.87		31.91	29.66		35.11
	党河(5Y45)	318	11.85	203.77		12.75	10.08		11.93
	合计	2027	75.52	1047.18		65.54	52.43		62.07
柴达木内流水系 (5Y5)	布哈河—青海湖(5Y51)	24	0.89	10.27	0.64	0.42	0.50
	哈尔腾河(5Y56)	268	9.99	283.52		17.74	17.58		20.81
	哈拉湖(5Y57)	108	4.02	78.73		4.93	4.56		5.40
	鱼卡河—塔塔棱河(5Y58)	179	6.67	155.08		9.71	8.69		10.29
	巴音郭勒河(5Y59)	10	0.37	2.20		0.14	0.06		0.07
	合计	589	21.94	529.8		33.16	31.31		37.07

省	市(自治州)	冰川数量			冰川面积			冰储量
省	市(自治州)	(条)		(%)		(km²)	(%)	(km²)	(%)
甘肃	酒泉	718	26.75		508.99	31.86		28.17	33.35
	张掖	739	27.53		245.65	15.37		9.60	11.36
	武威	35	1.31		6.32	0.40		0.17	0.20
	合计	1492	55.59		760.96	47.63		37.94	44.91
青海	海西	825	30.74		729.79	45.67		42.79	50.65
	海北	367	13.67	107.06		6.70	3.75		4.44
	合计	1192	44.41	836.85		52.37	46.54		55.09

第一次冰川编目冰储量(km³)	第二次冰川编目冰储量(km³)	冰川储量变化			冰川冰储量估算经验公式	公式出处
第一次冰川编目冰储量(km³)	第二次冰川编目冰储量(km³)	km³			km³/10 a	%/10 a
101.90	81.30	-20.60	-5.12	-5.65	V=0.0365A^1.375	Radić和Hock^[27]
109.86	87.52	-22.34	-5.56	-5.69	V=0.0433A^1.29	Grinsted^[31]
108.44	86.49	-21.95	-5.46	-5.66	V=0.04A^1.35	Liu等^[32]
