中国降水非均匀性综合评价

doi:10.11821/dlxb201503004

摘要/Abstract

摘要：

本研究经过对比各种降水非均匀性研究方法后,选择降水集中度作为降水非均匀性研究方法,结合正态分布函数、累积频率和百分位法,确定降水非均匀性等级评价指标,分析了1960-2013年中国降水非均匀性等级时空变化特征,并进行综合评价。研究结果表明：① 结合正态分布函数、累积频率和百分位法,确定降水非均匀性等级评价指标,划分为7个等级：高度集中、中度集中、轻度集中、正常、轻度分散、中度分散和高度分散。② 近54年来,中国降水年内分配趋于正常或分散的区域有所增加。

关键词: 非均匀性, 降水集中度, 评价指标, 综合评价, 中国

Abstract:

Through comparisons of various methods, the method of precipitation concentration degree (PCD) was used to study precipitation heterogeneity. In addition to PCD, normal distribution functions, cumulative frequencies, and percentiles were used to establish a graded evaluation index of precipitation heterogeneity. A comprehensive evaluation of precipitation heterogeneity and its spatiotemporal variation in China in 1960-2013 were analyzed. Results indicated that: (1) seven categories of precipitation heterogeneity could be identified: high centralization, moderate centralization, mild centralization, normal, mild dispersion, moderate dispersion, and high dispersion; (2) during the study period, the precipitation in more parts of China tended to be normal or dispersed, which is beneficial to human activities.

Key words: heterogeneity, precipitation concentration degree, evaluation index, comprehensive evaluation, China

刘永林, 延军平, 岑敏仪. 中国降水非均匀性综合评价[J]. 地理学报, 2015, 70(3): 392-406.

Yonglin LIU, Junping YAN, Minyi CEN. Comprehensive evaluation of precipitation heterogeneity in China[J]. Acta Geographica Sinica, 2015, 70(3): 392-406.

图/表 19

图1

表1

表2

图2

图3

表3

表4

表5

表6

表7

图4

表8

图5

图6

图7

图8

图9

图10

图11

参考文献 37

[1]	Tang Qicheng.Calculation and discussion of the non-uniform coefficient of annual runoff distribution. Resources Science, 1982, 4(3): 59-65.
	[汤奇成. 径流年内分配不均匀系数的计算和讨论. 资源科学, 1982, 4(3): 59-65.]
[2]	Feng Guozhang, Li Ying, Li Peicheng.Quantification of nonuniformity in annual distribution of stream flows. Journal of Northwest Agricultural University, 2000, 28(2): 50-53.
	[冯国章, 李瑛, 李佩成. 河川径流年内分配不均匀性的量化研究. 西北农业大学学报, 2000, 28(2): 50-53.]
[3]	Zhen Hongxing, Liu Changming.Changes of annual runoff distribution in the headwater of the Yellow River Basin. Progress in Geography, 2003, 22(6): 585-590.
	[郑红星, 刘昌明. 黄河源区径流年内分配变化规律分析. 地理科学进展, 2003, 22(6): 585-590.]
[4]	Gu Wanlong, Wang Jijun, Zhu Yeyu et al. Annual distribution of precipitation over the Huaihe River basin. Resources and Environment in the Yangtze Basin, 2010, 19(4): 426-431.
	[顾万龙, 王纪军, 朱业玉等. 淮河流域降水量年内分配变化规律分析. 长江流域资源与环境, 2010, 19(4): 426-431.]
[5]	Tang Qicheng, Cheng Tianwen, Li Xiuyun.Preliminary study on the degree and time of concentration of monthly runoff of Chinese streams. Acta Geographica Sinica, 1982, 37(4): 383-393.
	[汤奇成, 程天文, 李秀云. 中国河川月径流的集中度和集中期的初步研究. 地理学报, 1982, 37(4): 383-393.]
[6]	Yang Yuandong.Calculation method of the annual runoff distribution. Acta Geographica Sinica, 1984, 39(2): 218-227.
	[杨远东. 河川径流年内分配的计算方法. 地理学报, 1984, 39(2): 218-227.]
[7]	Wang Jijun, Pei Tiefan.Non-uniformity index of annual precipitation distribution. Chinese Journal of Ecology, 2007, 26(9): 1364-1368.
	[王纪军, 裴铁璠. 降水年内分配不均匀性指标. 生态学杂志, 2007, 26(9): 1364-1368.]
[8]	Zhang Lujun, Qian Yongfu.Annual distribution features of precipitation in China and their interannual variations. Acta Meteorologica Sinica, 2003, 17(2): 146-163.
[9]	Zhang Lujun, Qian Yongfu.A study on the feature of precipitation concentration and its relation to flood-producing in the Yangtze River valley of China. Chinese Journal of Geophysics, 2004, 47(4): 622-630.
	[张录军, 钱永甫. 长江流域汛期降水集中程度和洪涝关系研究. 地球物理学报, 2004, 47(4): 622-630.]
[10]	Qin Weijian, Wang Yongqing.Study on variation characteristics of precipitation concentration degree in Guangxi under the background of global climate becoming warm. Meteorological and Environmental Research, 2010, 1(5):17-21.
[11]	Li Xuemei, Jiang Fengqing, Li Lanhai.Spatial and temporal variability of precipitation concentration index, concentration degree and concentration period in Xinjiang, China. International Journal of Climatology, 2011, 31(11): 1679-1693.
[12]	Lu Zhihua, Xia Ziqiang, Yu Lanlan et al. Temporal and spatial variation of characteristics of precipitation in Songhua River basin during 1958-2009. Journal of Natural Resources, 2012, 27(6): 990-1000.
	[陆志华, 夏自强, 于岚岚等. 1958-2009年松花江流域降水时空演变特征. 自然资源学报, 2012, 27(6): 990-1000.]
[13]	Wang Nan, Li Dongliang, Zhang Jie.The intra-seasonal heterogeneity of the strong precipitation events and the corresponding atmosphere circulation characteristics in the middle and upper Yellow River Basin in flood season. Journal of Desert Research, 2013, 33(1): 239-248.
	[王楠, 李栋梁, 张杰. 黄河中上游季节内强降水的时间非均匀性特征及其对大气环流的响应. 中国沙漠, 2013, 33(1): 239-248.]
[14]	Zou Liyao, Ding Yihui, Wang Ji.Spatial and temporal characteristics of heavy precipitation long-term changes in Northeast China and causation analysis. Journal of Natural Resources, 2013, 28(1): 137-147.
	[邹立尧, 丁一汇, 王冀. 东北强降水时空变化的特征和原因分析. 自然资源学报, 2013, 28(1): 137-147.]
[15]	Liu Wenli, Zhang Mingjun, Wang Shengjie et al. Intra-annual inhomogeneity of precipitation and its prediction in Shaanxi Province of Northwest China in 1960-2011. Chinese Journal of Ecology, 2013, 32(7): 1877-1887.
	[刘文莉, 张明军, 王圣杰等. 1960-2011年陕西省年内降水分配非均匀性特征及预测. 生态学杂志, 2013, 32(7): 1877-1887.]
[16]	Cao Yongqiang, Lulu, Zhang Tingting et al. Spatio-temporal variation in precipitation in Zhejiang province based on PCD and PCP. Resources Science, 2013, 35(5): 1001-1006.
	[曹永强, 路璐, 张亭亭等. 基于降水集中度和集中期的浙江省降水时空变化特征分析. 资源科学, 2013, 35(5): 1001-1006.]
[17]	Feng Guangyang.Discussion on intra-annual differential coefficient. Resources Science, 1994, 16(5): 67-72.
	[冯光扬. 年内不均匀系数探讨. 资源科学, 1994, 16(5): 67-72.]
[18]	Shi Wanli, Yu Xuezhong, Liao Wengen et al. Spatial and temporal variability of daily precipitation concentration in the Lancang River basin, China. Journal of Hydrology, 2013, 495: 197-207.
[19]	Liu Xinyou, Shi Zhengtao, Peng Haiying et al. Study on precipitation temporal distribution homogeneous degree based on the Gini coefficient. Journal of Meteorological Research and Application, 2007, 28(2): 46-48.
	[刘新有, 史正涛, 彭海英等. 基于“基尼系数”的降水时间分布均匀度变化研究. 气象研究与应用, 2007, 28(2): 46-48.]
[20]	Shi Wanli, Yang Qinke, Li Xiaofang et al. Study on temporal inequality of precipitation in the Loess Plateau based on Lorenz curve. Agricultural Research in the Arid Areas, 2012, 30(4): 172-177.
	[史婉丽, 杨勤科, 李小芳等. 基于洛伦茨曲线的陕北黄土高原降雨分布不均匀性分析. 干旱地区农业研究, 2012, 30(4): 172-177.]
[21]	Singh V P.The use of entropy in hydrology and water resources. Hydrological Processes, 1997, 11(6): 587-626.
[22]	Wang Dong.Principle of maximum entropy and its application in hydrology and water resources. Advances in Water Science, 2001, 12(3): 424-430.
	[王栋. 最大熵原理在水文水资源科学中的应用. 水科学进展, 2001, 12(3): 424-430.]
[23]	Mishra A K, Özger M, Singh V P.An entropy-based investigation into the variability of precipitation. Journal of Hydrology, 2009, 370(1): 139-154.
[24]	Deng Pengxin, Hu Qingfang.Heterogeneity study of rainfall in the Taihu Lake basin. Hydro-Science and Engineering, 2014(5): 34-40.
	[邓鹏鑫, 胡庆芳. 太湖流域降水不均匀性研究. 水利水运工程学报, 2014(5): 34-40.]
[25]	Xiong Jun.A comparative analysis of appraisal method of Gini coefficient. Research on Financial and Economic Issues, 2003, (1): 79-82.
	[熊俊. 基尼系数估算方法的比较研究. 财经问题研究, 2003, (1): 79-82.]
[26]	Wang Xiurong, Guo Jinxiu.China Meteorological Geographical Regionalization (Consultation Draft). Beijing: National Climate Center, 2009.
	[王秀荣, 郭进修. 中国气象地理区划 (征求意见稿). 北京: 国家气候中心, 2009]
[27]	Ju Xiaosheng, Yang Xianwei, Chen Lijuan et al. Research on determination of station indexes and division of regional flood/ drought grades in China. Quarterly Journal of Applied Meteorology, 1997, 8(1): 26-33.
	[鞠笑生, 杨贤为, 陈丽娟等. 我国单站旱涝指标确定和区域旱涝级别划分的研究. 应用气象学报, 1997, 8(1): 26-33.]
[28]	Li Qingxiang.Study on threshold values with an extreme event of precipitation in Beijing. Advances in Water Science, 2010, 21(5): 660-665.
	[李庆祥. 北京地区强降水极端气候事件阈值. 水科学进展, 2010, 21(5): 660-665.]
[29]	Zhang Qiang, Zou Xukai, Xiao Fengjing.Classification of Meteorological Drought, GB/T 20481-2006. Beijing: Standards Press of China, 2006.
	[张强, 邹旭恺, 肖风劲. 气象干旱等级GB/T20481-2006. 北京: 中国标准出版社, 2006.]
[30]	Huang Jiayou.Meteorological Statistical Analysis and Prediction Method. Beijing: China Meteorological Press, 2007: 24-26.
	[黄嘉佑. 气象统计分析与预报方法. 北京: 气象出版社, 2007: 24-26.]
[31]	Zhang Xuebin, Wang Jiafeng, Zwiers F W et al. The influence of large-scale climate variability on winter maximum daily precipitation over North America. Journal of Climate, 2010, 23(11): 2902-2915.
[32]	Dong Quan, Chen Xing, Chen Tiexi.Characteristics and changes of extreme precipitation in the Yellow-Huaihe and Yangtze-Huaihe rivers basins, China. Journal of Climate, 2011, 24(14): 3781-3795.
[33]	Li Jian, Yu Rucong, Sun Wei.Calculation and analysis of the thresholds of hourly extreme precipitation in mainland China. Torrential Rain and Disasters, 2013, 32(1): 11-16.
	[李建, 宇如聪, 孙溦. 中国大陆地区小时极端降水阈值的计算与分析. 暴雨灾害, 2013, 32(1): 11-16.]
[34]	Zhai Panmao, Pan Xiaohua.Change in extreme temperature and precipitation over northern China during the second half of the20th century. Acta Geographica Sinica, 2003, 58(S1): 1-10.
	[翟盘茂, 潘晓华. 中国北方近50年温度和降水极端事件变化. 地理学报, 2003, 58(S1): 1-10.]
[35]	Gong Daoyi, Han Hui.Extreme climate events in northern China over the last 50 years. Acta Geographica Sinica, 2004, 59(2): 230-238.
	[龚道溢, 韩晖. 华北农牧交错带夏季极端气候的趋势分析. 地理学报, 2004, 59(2): 230-238.]
[36]	Zhang Xuebin, Hegerl G, Zwiers F W et al. Avoiding inhomogeneity in percentile-based indices of temperature extremes. Journal of Climate, 2005, 18(11): 1641-1651.
[37]	Alexander L V, Zhang Xuebin,Peterson T C et al. Global observed changes in daily climate extremes of temperature and precipitation. Journal of Geophysical Research, 2006, 111(D5).

大区名称	省级行政区
西北地区	陕西省、甘肃省、宁夏回族自治区、青海省、新疆维吾尔自治区
华北地区	山西省、河北省、北京市、天津市
内蒙古地区	内蒙古自治区
东北地区	辽宁省、吉林省、黑龙江省
华东地区	山东省、河南省、湖北省、安徽省、江苏省、上海市
江南地区	湖南省、山西省、福建省、浙江省
华南地区	广西壮族自治区、广东省、海南省、香港特别行政区、澳门特别行政区、台湾省
西南地区	四川省、重庆市、云南省、贵州省
西藏地区	西藏自治区

等级	类型	Z指数	发生频率	累积频率(%)
1	极涝	Z>1.645	5	100
2	大涝	1.037<Z≤1.645	10	95
3	偏涝	0.842<Z≤1.037	15	80
4	正常	-0.842≤Z≤0.842	40	70
5	偏旱	-1.037≤Z<-0.842	15	30
6	大旱	-1.645≤Z<-1.037	10	15
7	极旱	Z<-1.645	5	5

气候阶段	偏度系数	峰度系数	气候阶段	偏度系数	峰度系数
1960-1989	-0.426	-0.282	1973-2002	-0.419	-0.284
1961-1990	-0.419	-0.301	1974-2003	-0.416	-0.281
1962-1991	-0.424	-0.264	1975-2004	-0.424	-0.246
1963-1992	-0.414	-0.267	1976-2005	-0.446	-0.218
1964-1993	-0.398	-0.294	1977-2006	-0.453	-0.222
1965-1994	-0.396	-0.318	1978-2007	-0.450	-0.206
1966-1995	-0.410	-0.292	1979-2008	-0.447	-0.196
1967-1996	-0.405	-0.268	1980-2009	-0.439	-0.224
1968-1997	-0.405	-0.285	1981-2010	-0.441	-0.228
1969-1998	-0.420	-0.292	1982-2011	-0.443	-0.204
1970-1999	-0.424	-0.259	1983-2012	-0.450	-0.193
1971-2000	-0.428	-0.253	1984-2013	-0.446	-0.213
1972-2001	-0.439	-0.254

转换方法	平方	立方	平方根	立方根	倒数	对数	反正弦	平方根反正弦	Z指数
偏度系数	0.24	0.81	-0.92	-1.15	87.16	-1.91	-0.07	-0.39	-0.10
峰度系数	-0.47	0.60	0.98	1.97	9640.34	8.03	-0.18	0.16	-0.40

气候阶段	5%	15%	30%	70%	85%	95%
1960-1989	0.275	0.390	0.482	0.654	0.729	0.806
1961-1990	0.269	0.385	0.477	0.651	0.725	0.804
1962-1991	0.272	0.388	0.479	0.652	0.726	0.804
1963-1992	0.272	0.386	0.478	0.650	0.724	0.802
1964-1993	0.271	0.385	0.477	0.648	0.723	0.800
1965-1994	0.268	0.383	0.475	0.648	0.723	0.802
1966-1995	0.273	0.387	0.479	0.651	0.725	0.803
1967-1996	0.273	0.387	0.479	0.651	0.725	0.803
1968-1997	0.270	0.385	0.478	0.651	0.725	0.804
1969-1998	0.270	0.385	0.477	0.650	0.725	0.803
1970-1999	0.271	0.386	0.478	0.650	0.724	0.803
1971-2000	0.268	0.383	0.476	0.649	0.723	0.802
1972-2001	0.266	0.382	0.474	0.648	0.723	0.802
1973-2002	0.269	0.385	0.477	0.649	0.723	0.801
1974-2003	0.269	0.383	0.475	0.648	0.722	0.800
1975-2004	0.271	0.384	0.475	0.647	0.720	0.798
1976-2005	0.272	0.386	0.477	0.647	0.720	0.799
1977-2006	0.271	0.384	0.475	0.646	0.719	0.798
1978-2007	0.271	0.384	0.475	0.646	0.719	0.797
1979-2008	0.271	0.383	0.474	0.645	0.718	0.796
1980-2009	0.269	0.382	0.472	0.643	0.717	0.795
1981-2010	0.267	0.381	0.471	0.642	0.716	0.794
1982-2011	0.269	0.382	0.471	0.642	0.715	0.793
1983-2012	0.268	0.381	0.471	0.641	0.714	0.793
1984-2013	0.267	0.381	0.472	0.643	0.717	0.795
均值	0.270	0.384	0.476	0.647	0.721	0.800
标准差	0.002	0.002	0.003	0.003	0.004	0.004
