近10年来可可西里地区主要湖泊冰情时空变化

doi:10.11821/dlxb201507008

Abstract

Abstract:

Based on the boundary data of lakes, some moderate-high resolution remote sensing datasets including MODIS and Landsat TM/ETM+ images and the meteorological data, the spatial-temporal variations of lake ice in the Hoh Xil region during the period 2000-2011 are analyzed by using RS and GIS technology. And the factors affecting the lake ice phenology are also discussed. Some conclusions can be drawn as follows. (1) The freeze-up start (FUS) and freeze-up end (FUE) of lake ice appears in late October - early November, and mid-November - early December, respectively. The duration of lake ice freeze-up is about half a month. The time of break-up start (BUS) and break-up end (BUE) of lake ice is relatively dispersed, and appears in late April - early June, and early May - early June, respectively. The ice duration (ID) and the complete ice duration (CID) of lakes are 196 days and 181 days, respectively. (2) The phenology of lake ice in the Hoh Xil region changed dramatically in the last 10 years. Specifically, the FUS and FUE time of lake ice showed an increasingly delaying trend. In contrast, the BUS and BUE time of lake ice presented an advance. This led to the reduction of the ID and CID of lake ice. The average rates of ID and CID were -2.21 d/a and -1.91 d/a, respectively. (3) The variations of phenology and evolution of lake ice are the results of local and climatic factors. The temperature, lake area, salinity and shape of the shoreline are the main factors affecting the phenology of lake ice. (4) The spatial process of lake ice freeze-up is contrary to its break-up process. The type of lake ice extending from one side of lakeshore to the opposite side is dominant in the Hoh Xil region.

Key words: lake ice, lake, phenology, climate change, Hoh Xil region, MODIS

Xiaojun YAO, Long LI, Jun ZHAO, Meiping SUN, Jing LI, Peng GONG, Lina AN. Spatial-temporal variations of lake ice in the Hoh Xil region from 2000 to 2011[J].Acta Geographica Sinica, 2015, 70(7): 1114-1124.

Figures/Tables 10

Fig. 1

Fig. 2

Tab. 1

Fig. 3

Fig. 4

Fig. 5

Tab. 2

Fig. 6

Fig. 7

Fig. 8

References 32

[1]	Qin Dahe.Climate and Environment Change in China: 2012 Comprehensive Volume. Beijing: China Meteorological Press, 2012.
	[秦大河. 中国气候与环境演变: 2012 综合卷. 北京: 气象出版社, 2012.]
[2]	Vaughan D G, Comiso J C, Allison I, et al.Observations: Cryosphere//Stocker T F, Qin D, Plattner G K et al. Climate Change 2013: The Physical Science Basis. Contribution of Working Group I to the Fifth Assessment Report of the Intergovernmental Panel on Climate Change. Cambridge: Cambridge University Press, 2013.
[3]	Deguay C R, Prowse T D.Recent trends in Canadian lake ice cover. Hydrology Process, 2006, 20: 781-801.
[4]	Palecki M A, Barry R G.Freeze-up and break-up of lakes as an index of temperature changes during the transition seasons: A case study for Finland. Journal of Applied Meteorology and Climatology, 1986, 25: 893-902.
[5]	Hodgkins A G, James I C, Huntington T G.Historical changes in lake ice-out dates as indicators of climate change in New England, 1850-2000. International Journal of Climate, 2002, 22: 1819-1827.
[6]	Gould M.Temperature variations in lake ice in central Alaska, USA. Annals of Glaciology, 2005, 40(1): 89-94.
[7]	Johnson S L, Stefan H G.Indicators of climate warming in Minnesota: Lake ice covers and snowmelt runoff. Climate Change, 2006, 75(4): 421-453.
[8]	Marszelewski W, Skowron R.Ice cover as an indicator of winter air temperature changes: Case study of the Polish Lowland lakes. Hydrological Sciences Journal, 2006, 51(2): 336-349.
[9]	Lenormand F, Duguay C R, Gauthier R.Development of a historical ice database for the study of climate change in Canada. Hydrological Processes, 2002, 16(18): 3707-3722.
[10]	Hall D K, Riggs G A.MODIS snow-cover products. Remote Sensing of Environment, 2002, 83: 181-194.
[11]	Latifovic R, Pouliot D.Analysis of climate change impacts on lake ice phenology in Canada using the historical satellite data record. Remote Sensing of Environment, 2007, 106: 492-507.
[12]	Wang J, Bai X, Hu H, et al.Temporal and spatial variability of Great Lakes ice cover, 1973-2010. Journal of Climate. 2012, 25: 1318-1329.
[13]	Benson B J, Magnuson J J, Jensen O P, et al.Extreme events, trends, and variability in Northern Hemisphere lake-ice phenology (1855-2005). Climatic Change, 2012, 112: 299-323.
[14]	Chen Xianzhang, Wang Guangyu, Li Wenjun, et al.Lake ice and its remote sensing monitoring in the Tibetan Plateau. Journal of Glaciology and Geocryology, 1995, 17(3): 241-246.
	[陈贤章, 王光宇, 李文君, 等. 青藏高原湖冰及其遥感监测. 冰川冻土, 1995, 17(3): 241-246.]
[15]	Che Tao, Li Xin, Jin Rui.Monitoring the frozen duration of Qinghai Lake using satellite passive microwave remote sensing low frequency data. Chinese Science Bulletin, 2009, 54: 2294-2299.
	[车涛, 李新, 晋锐. 利用被动微波遥感低频亮温数据监测青海湖封冻与解冻期. 科学通报, 2009, 54(6): 787-791]
[16]	Qu Bin, Kang Shichang, Chen Feng, et al.Lake ice and its effect factors in the Nam Co basin, Tibetan Plateau. Progressus Inquisitiones De Mutatione Climatis, 2012, 8(5): 327-333.
	[曲斌, 康世昌, 陈锋, 等. 2006-2011年西藏纳木错湖冰状况及其影响因素分析. 气候变化研究进展, 2012, 8(5): 327-333.]
[17]	Wei Qiufang, Ye Qinghua.Review of lake ice monitoring by remote sensing. Progress in Geography, 2010, 29(7): 803-810.
	[魏秋方, 叶庆华. 湖冰遥感监测方法综述. 地理科学进展, 2010, 29(7): 803-810.]
[18]	Wu Shaohong, Yin Yunhe, Zheng Du, et al.Climate change in the Tibetan Plateau during the last three decades. Acta Geographica Sinica, 2005, 60(1): 3-11.
	[吴绍洪, 尹云鹤, 郑度, 等. 青藏高原近30年气候变化趋势. 地理学报, 2005, 60(1): 3-11.]
[19]	Hu Dongsheng.Investigation and study on lake resources in Kekexili region. Arid Land Geography, 1992, 15(3): 50-58.
	[胡东生. 可可西里地区湖泊资源调查研究. 干旱区地理, 1992, 15(3): 50-58.]
[20]	Wang Sumin, Dou Hongshen.Records of Chinese Lakes. Beijing: Science Press, 1998.
	[王苏民, 窦鸿身. 中国湖泊志. 北京: 科学出版社, 1998.]
[21]	Yao Xiaojun, Liu Shiyi, Sun Meiping, et al.Changes of Kusai Lake in Hoh Xil region and causes of its water overflowing. Acta Geographica Sinica, 2012, 67(5): 689-698.
	[姚晓军, 刘时银, 孙美平, 等. 可可西里地区库赛湖变化及湖水外溢成因. 地理学报, 2012, 67(5): 689-698.]
[22]	Yao X, Liu S, Li L, et al.Spatial-temporal characteristics of lake area variations in Hoh Xil region from 1970 to 2011. Journal of Geographical Sciences, 2014, 24(4): 689-702.
[23]	Kropáček J, Maussion F, Chen F, et al.Analysis of ice phenology of lakes on the Tibetan Plateau from MODIS data. The Cryosphere, 2013, 7: 287-301.
[24]	Reed B, Budde M, Spencer P, et al.Integration of MODIS-derived metrics to assess interannual variability in snowpack, lake ice, and NDVI in southwest Alaska. Remote Sensing of Environment, 2009, 113: 1443-1452.
[25]	Choinski A, Kolendowicz L, Pociask K J, et al.Changes in lake ice cover on the Morskie Oko Lake in Poland (1971-2007). Advances in Climate Change Research, 2010, 1(2): 71-75.
[26]	Luo Chongguang.Study on sublacustrine morphology of main lakes in Hoh Xil region. Journal of Salt lake Research, 2010, 18(1): 1-8.
	[罗重光. 青海可可西里主要湖泊湖底地貌研究. 盐湖研究, 2010, 18(1): 1-8.]
[27]	Ménard P, Duguay C R, Flato G M, et al.Simulation of ice phenology on Great Slave Lake, Northwest Territories, Canada. Hydrology Process, 2002, 16: 3691-3706.
[28]	Todd M C.Large-scale climate controls on Lake Baikal ice cover. Journal of Climate, 2003, 16(19): 3186-3199.
[29]	Ghanbari R N, Bravo H R, Magnuson J J, et al.Coherence between lake ice cover, local climate and teleconnections. Journal of Hydrology, 2009, 374(3/4): 282-293.
[30]	Barrie R B, Terry D P, Claude R D, et al.Impacts of large-scale teleconnections on freshwater-ice break/freeze-up dates over Canada. Journal of Hydrology, 2006, 330: 340-353.
[31]	Livingstone D M.Break-up dates of alpine lakes as proxy data for local and regional mean surface air temperatures. Climatic Change, 1997, 37: 407-439.
[32]	Zheng Mianping, Xiang Jun, Wei Xinjun, et al.Saline Lakes on the Qinghai-Xizang (Tibet) Plateau. Beijing: Science Press, 1989.
	[郑绵平, 向军, 魏新俊, 等. 青藏高原盐湖. 北京: 科学出版社, 1989.]

序号	湖泊名称	面积(km²)	海拔(m)	开始冻结(FUS)	完全冻结(FUE)	开始消融(BUS)	完全消融(BUE)	完全封冻期(CID)	封冻期(ID)
1	乌兰乌拉湖	563.79	4854	297±2	321±4	116±23	164±8	160±23	208±11
2	多格错仁	459.62	4921	308±16	353±8	61±8	112±15	72±11	124±20
3	西金乌兰湖	395.95	4769	301±8	350±18	34±23	127±15	49±33	142±19
4	可可西里湖	319.43	4878	300±3	318±3	161±4	174±6	208±4	221±7
5	多格错仁强错	313.08	4787	310±13	327±17	107±31	124±24	146±49	163±42
6	库赛湖	268.01	4475	318±2	337±3	129±5	141±8	157±6	169±9
7	卓乃湖	261.32	4751	312±5	326±2	146±6	160±7	185±7	198±9
8	勒斜武担湖	246.27	4867	319±6	334±6	109±17	126±12	140±22	158±18
9	加德仁错	205.33	4688	300±7	310±8	116±13	147±9	171±16	202±14
10	美马错	147.77	4920	304±5	322±5	145±6	167±8	188±10	210±11
11	玛尔盖茶卡	144.19	4785	300±6	310±5	137±7	153±8	192±10	208±12
12	若拉错	142.63	4807	293±6	311±3	128±8	150±9	182±9	204±11
13	错尼	137.73	4902	296±3	315±6	121±16	160±6	171±20	210±11
14	拜惹布错	136.25	4958	302±7	319±5	152±8	167±8	197±11	212±11
15	碱水湖	129.65	4884	291±4	307±4	146±8	161±9	204±11	219±12
16	玉液湖	120.16	4850	283±2	304±7	153±15	166±12	214±18	227±16
17	羊湖	118.12	4778	296±3	315±6	148±5	161±4	198±10	210±9
18	饮马湖	107.41	4918	289±2	311±2	135±19	166±8	189±20	220±10
19	阿鲁错	105.16	4940	313±5	331±6	81±17	134±12	115±15	168±13
20	太阳湖	101.91	4882	316±4	329±3	145±11	164±9	181±13	201±10
21	向阳湖	100.58	4870	300±4	310±3	150±7	162±2	205±9	217±5
22	黑石北湖	100.55	5048	301±6	317±5	159±3	169±4	207±4	217±6

湖冰物候特征	湖泊面积	湖泊形态因子	湖面海拔	湖水矿化度	年均气温
开始冻结	0.22	-0.72^**	-0.24	0.03	0.26
完全冻结	0.59^**	-0.28	-0.15	0.55^**	0.49^*
开始消融	-0.53^**	-0.03	0.12	-0.65^**	-0.69^**
完全消融	-0.43^*	0.18	0.28	-0.62^**	-0.61^**
完全封冻期	-0.58^**	-0.25	0.26	-0.04	-0.75^**
封冻期	-0.53^**	0.24	0.24	-0.63^**	-0.60^**

Spatial-temporal variations of lake ice in the Hoh Xil region from 2000 to 2011
