上海城市热岛与热浪协同作用及其影响因子

doi:10.11821/dlxb201909007

Abstract

Abstract:

Under the background of global warming, heat waves are expected to be more frequent and long lasting. Cities endure greater risk under heat wave events because of the pre-existing urban heat island. However, research on the interaction between heat wave and urban heat island is still lacking. Based on hourly data of air temperature, wind speed, relatively humidity, and eddy covariance energy flux data from Shanghai urban (XJH) and rural site (FX) during two summers (June-August) in 2016-2017, the difference of urban heat island (UHI) between heat wave (HW) and non-heat wave (NHW) conditions is analysed. In addition, an advection-diffusion analytical model has been used to unravel the mechanism of the interaction between UHI and HW. Results show that the UHI intensity is obviously enhanced during HWs, and the enhancement is stronger during daytime than that of nighttime, which indicates the synergistic effect between UHI and HW. The relative humidity ratio of urban and suburban areas during HWs significantly decreases compared with NHW conditions, indicating the urban surface becomes even drier than suburban areas during HWs that suppresses evaporation and intensifies UHI intensity. The mean wind speed also has an obvious decrease, leading to weaker advection cooling effect, which has a positive effect on UHI intensity. The increase of net radiation at the urban site is larger than that of the suburban site during HWs so that urban area receives more radiation input. Due to low vegetation cover and more impervious surfaces, the latent heat flux at the urban site has a slight decrease while it has an obvious increase at the suburban site. The increase of the urban sensible heat flux is larger than that of the suburban site. This change of the partition between sensible and latent heat flux also exacerbates the UHI intensity. This study has important implications for cities to cope with intensified thermal risks.

Key words: urban heat island, heat wave, analytical model, radiation flux, sensible heat flux, latent heat flux

AO Xiangyu, TAN Jianguo, ZHI Xing, GUO Jibing, LU Yiwen, LIU Dongwei. Synergistic interaction between urban heat island and heat waves and its impact factors in Shanghai[J].Acta Geographica Sinica, 2019, 74(9): 1789-1802.

Figures/Tables 13

Fig. 1

Fig. 2

Tab. 1

Tab. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Fig. 8

Fig. 9

Fig. 10

Fig. 11

References 40

[1]	Russo S, Dosio A, Graversen R G , et al. Magnitude of extreme heat waves in present climate and their projection in a warming world. Journal of Geophysical Research Atmospheres, 2015,119(22):12500-12512.
[2]	Mora C, Dousset B, Caldwell I R , et al. Global risk of deadly heat. Nature Climate Change, 2017,7:501-506.
[3]	Tan Jianguo, Huang Jiaxin . The impacts of heat waves on human health and its research methods. Climatic and Environmental Research, 2004,9(4):680-686.
	[ 谈建国, 黄家鑫 . 热浪对人体健康的影响及其研究方法. 气候与环境研究, 2004,9(4):680-686.]
[4]	Chen Qian, Ding Mingjun, Yang Xuchao , et al. Spatially explicit assessment of heat health risks using multi-source data: A case study of the Yangtze River Delta region, China. Journal of Geo-information Science, 2017,19(11):1475-1484.
	[ 陈倩, 丁明军, 杨续超 , 等. 长江三角洲地区高温热浪人群健康风险评价. 地球信息科学学报, 2017,19(11):1475-1484.]
[5]	Zaitchik B F, Macalady A K, Bonneau L R , et al. Europe's 2003 heat wave: A satellite view of impacts and land-atmosphere feedbacks. International Journal of Climatology, 2010,26(6):743-769.
[6]	Knutson T R, Zeng F R, Wittenberg A T . The extreme March-May 2012 warm anomaly over the eastern United States: global context and multimodel trend analysis. Bulletin of the American Meteorological Society, 2013,94(9):S13-S17.
[7]	Xia J, Tu K, Yan Z , et al. The super-heat wave in eastern China during July-August 2013: A perspective of climate change. International Journal of Climatology, 2016,36(3):1291-1298.
[8]	Ma S, Zhou T, Stone D , et al. Attribution of the July-August 2013 heat event in central and eastern China to anthropogenic greenhouse gas emissions. Environmental Research Letters, 2017,12:054020.
[9]	Chen Min, Geng Fuhai, Ma Leiming , et al. Analyses on the heat wave events in Shanghai in recent 138 years. Plateau Meteorology, 2013,32(2):597-607.
	[ 陈敏, 耿福海, 马雷鸣 , 等. 近138年上海地区高温热浪事件分析. 高原气象, 2013,32(2):597-607.]
[10]	Cao Chang, Li Xuhui, Zhang Mi , et al. Correlation analysis of the urban heat island effect and its impact factors in China. Environmental Science, 2017,38(10):3987-3997.
	[ 曹畅, 李旭辉, 张弥 , 等. 中国城市热岛时空特征及其影响因子的分析. 环境科学, 2017,38(10):3987-3997.]
[11]	Meehl G A, Tebaldi C . More intense, more frequent, and longer lasting heat waves in the 21st century. Science, 2004,305:994-997.
[12]	Robinson P J . On the definition of a heat wave. Journal of Applied Meteorology, 2001,40:762-775.
[13]	Matsumura S, Sugimoto S, Sato T . Recent intensification of the Western Pacific subtropical high associated with the East Asian summer monsoon. Journal of Climate, 2015,28(4):2873-2883.
[14]	He C, Zhou T, Lin A , et al. Enhanced or weakened western north pacific subtropical high under global warming? Scientific Reports, 2015,5:16771.
[15]	Peng Baofa, Shi Yishao, Wang Hefeng , et al. The impacting mechanism and laws of function of urban heat islands effect: A case study of Shanghai. Acta Geographica Sinica, 2013,68(11):1461-1471.
	[ 彭保发, 石忆邵, 王贺封 , 等. 城市热岛效应的影响机理及其作用规律: 以上海市为例. 地理学报, 2013,68(11):1461-1471.]
[16]	Oke T R . The energetic basis of the urban heat-Island. Quarterly Journal of the Royal Meteorological Society, 1982,108:1-24.
[17]	Grimmond S . Urbanization and global environmental change: Local effects of urban warming. Geographical Journal, 2007,173:83-88.
[18]	Liu Yue, Shintaro Goto, Zhuang Dafang , et al. Urban surface heat flux inversion based on infrared remote sensing and the relationship with land cover. Acta Geographica Sinica, 2012,67(1):101-112.
	[ 刘越, Shintaro G, 庄大方 , 等. 城市地表热通量遥感反演及与下垫面关系分析. 地理学报, 2012,67(1):101-112.]
[19]	Roth M . Review of atmospheric turbulence over cities. Quarterly Journal of the Royal Meteorological Society, 2000,126:941-990.
[20]	Miao S, Chen F, Lemone M A , et al. An observational and modeling study of characteristics of urban heat island and boundary layer structures in Beijing. Journal of Applied Meteorology and Climatology, 2009,48(3):484-501.
[21]	Zhao L, Lee X, Smith R B , et al. Strong contributions of local background climate to urban heat islands. Nature, 2014,511:216-219.
[22]	Zhou D, Zhao S, Zhang L , et al. The footprint of urban heat island effect in China. Scientific Reports, 2015,5:11160.
[23]	Li D, Bou-Zeid E . 2013: Synergistic interactions between urban heat islands and heat waves: The impact in cities is larger than the sum of its parts. Journal of Applied Meteorology and Climatology, 2013,52:2051-2064.
[24]	Li D, Sun T, Liu M , et al. Contrasting responses of urban and rural surface energy budgets to heat waves explain synergies between urban heat islands and heat waves. Environmental Research Letters, 2015,10:054009.
[25]	Li D, Sun T, Liu M , et al. Changes in wind speed under heat waves enhance urban heat Islands in the Beijing metropolitan area. Journal of Applied Meteorology and Climatology, 2016,55:2369-2375.
[26]	Founda D, Santamouris M . Synergies between urban heat island and heat waves in Athens (Greece), during an extremely hot summer (2012). Scientific Reports, 2017,7(1):10973.
[27]	Sun T, Kotthaus S, Li D , et al. Attribution and mitigation of heat wave-induced urban heat storage change. Environmental Research Letters, 2017,12:114007.
[28]	Scott A A, Waugh D W, Zaitchik B F . Reduced urban heat island intensity under warmer conditions. Environmental Research Letters, 2018,13:064003.
[29]	Yue Wenze, Xu Jianhua . Impact of human activities on urban thermal environment in Shanghai. Acta Geographica Sinica, 2008,63(3):247-256.
	[ 岳文泽, 徐建华 . 上海市人类活动对热环境的影响. 地理学报, 2008,63(3):247-256.]
[30]	Miao Junfeng . An overview of numerical studies of interactions of urban heat island and sea breeze circulations. Transactions of Atmospheric Sciences, 2014,37(4):521-528.
	[ 苗峻峰 . 城市热岛和海风环流相互作用的数值模拟研究进展. 大气科学学报, 2014,37(4):521-528.]
[31]	Gu Wen, Zhang Jing, Tan Jianguo , et al. Characteristics and circulation background of Shanghai summer sea breeze front and its induced convection. Journal of Tropical Meteorology, 2017,33(5):644-653.
	[ 顾问, 张晶, 谈建国 , 等. 上海夏季海风锋及其触发对流的时空分布和环流背景分析. 热带气象学报, 2017,33(5):644-653.]
[32]	Tan J G, Zheng Y, Tang X , et al. The urban heat island and its impact on heat waves and human health in Shanghai. International Journal of Biometeorology, 2010,54:75-84.
[33]	Kormann R, Meixner F X . An analytical footprint model for non-neutral stratification. Boundary-Layer Meteorology. 2001,99:207-224.
[34]	Zhu Mingjia, Zhao Qianyi, Liu Shaomin , et al. Analysis of the characteristics of turbulent flux and its footprint climatology at an agricultural site. Advances in Earth Science, 2013,28(12):1313-1325.
	[ 朱明佳, 赵谦益, 刘绍民 , 等. 农田下垫面观测通量的变化特征及其气候学足迹分析. 地球科学进展, 2013,28(12):1313-1325.]
[35]	Kotthaus S, Grimmond C S B . Energy exchange in a dense urban environment (Part II): Impact of spatial heterogeneity of the surface. Urban Climate, 2014,10:281-307.
[36]	Zou J, Liu G, Sun J , et al. The momentum flux gradient relations derived from field measurements in the urban roughness sublayer in three cities in China. Journal of Geophysical Research Atmospheres, 2016,120:10797-10809.
[37]	Ao X Y, Grimmond C S B, Liu D W , et al. Radiation fluxes in a business district of Shanghai, China. Journal of Applied Meteorology and Climatology, 2016,55(11):2451-2468.
[38]	Ao X Y, Grimmond C S B, Chang Y Y , et al. Heat, water and carbon exchanges in the tall megacity of Shanghai: Challenges and results. International Journal of Climatology, 2016,36(14):4608-4624.
[39]	Ramamurthy P, Bou-Zeid E . Heatwaves and urban heat islands: A comparative analysis of multiple cities. Journal of Geophysical Research Atmospheres, 2017,122:168-178.
[40]	Zhao L, Oppenheimer M, Zhu Q , et al. Interactions between urban heat islands and heat waves. Environmental Reserach Letters, 2018,13:034003.

编号	日期	持续天数(d)
1	2016年7月20日-2016年7月30日	11
2	2016年8月13日-2016年8月21日	9
3	2017年7月5日-2017年7月8日	4
4	2017年7月11日-2017年7月28日	18

Synergistic interaction between urban heat island and heat waves and its impact factors in Shanghai

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 13

References 40

Related Articles 11

Metrics

Comments

[1]	JIANG Song, PENG Jian, DONG Jianquan, CHENG Xueyan, DAN Yuzhuo. Conceptual connotation and quantitative characterization of surface urban heat island effect [J]. Acta Geographica Sinica, 2022, 77(9): 2249-2265.
[2]	LIU Yonghong, XU Yongming, ZHANG Fangmin, SHU Wenjun. Influence of Beijing spatial morphology on the distribution of urban heat island [J]. Acta Geographica Sinica, 2021, 76(7): 1662-1679.
[3]	FENG Zhangxian,WANG Shijun,JIN Shanhe,YANG Jun. Effects of urban morphology and wind conditions on land surface temperature in Changchun [J]. Acta Geographica Sinica, 2019, 74(5): 902-911.
[4]	GAO Hong-yan,CAI Xin-ling,HE Hao,WANG Li-hua,KOU Xiao-lan,ZHANG Hong. The Impact of Urbanization on the Surface Temperature in Xi'an [J]. Acta Geographica Sinica, 2009, 64(9): 1093-1102.
[5]	XIE Zhiqing, DU Yin, ZENG Yan, SHI Yafeng, WU Jingang. Impact of Urbanization on Regional Temper atur e Change in the Yangtze River Delta [J]. Acta Geographica Sinica, 2007, 62(7): 717-727.
[6]	ZHANG Yongqiang, SHEN Yanjun, LIU Changming,Yu Qiang, SUN Hongyong, JIA Jinsheng, TANG Changyuan, AKIHIKO Kondoh. Measurement and Analysis of Water, Heat and CO₂ Flux from a Farmland in the North China Plain [J]. Acta Geographica Sinica, 2002, 57(3): 335-344.
[7]	Chen Shenbin, Pan Liqing. EFFECTS OF URBANIZATION ON THE ANNUAL MEAN TEMPERATURE OF BEIJING [J]. Acta Geographica Sinica, 1997, 52(1): 27-36.
[8]	Zhao Shipeng. AN INTEGRATION OF GIS AND ANALYTICAL MODELS FOR EVALUATION OF DISASTERS CAUSED BY MOUNTAIN TORRENTS [J]. Acta Geographica Sinica, 1996, 51(5): 471-479.
[9]	Zhang Mingjin, Zhang Ping. STUDY ON DESIGN OF CORE GEOGRAPHICAL INFORMATION SYSTEM [J]. Acta Geographica Sinica, 1995, 50(s1): 44-53.
[10]	Li Zihua, Tang Bin, Ren Qifu. A STUDY ON THE EFFECTS OF THE HEAT AND WET ISLAND IN THE CITY OF CHONGQING DURING WINTERTIME [J]. Acta Geographica Sinica, 1993, 48(4): 358-366.
[11]	Bian Hai, Tie Xuexi. NUMERICAL SIMULATION OF THE NOCTURNAL URBAN HEAT ISLAND OVER TIANJIN [J]. Acta Geographica Sinica, 1988, 43(2): 150-158.

通量站	建筑高度(m)	不透水面(%)	建筑(%)	树木(%)	草地(%)	裸土(%)	水体(%)
XJH	36	62	23	4	10	0	1
FX	6	20	14	10	53	2	1
