2000-2017年河龙区间输沙量锐减归因分析

doi:10.11821/dlxb201909004

Abstract

Abstract:

Since 2000, the amount of sediment loads in the Yellow River has decreased sharply. It is of great practical significance to scientifically understand the reasons for the sediment load change in the Yellow River. This study selected the Hekou-Longmen (HL) section, which consists of main sand producing areas of the Yellow River, as the study region, analyzed the sediment discharge change trend, constructed the calculation method of the contribution rate for the sediment reduction of major soil and water conservation measures, such as terraces, check dams, and vegetation, and expounded the reasons of sediment load reduction on the HL section since 2000. The main results were as follows: (1) From 1952 to 2017, there was no significant change of annual precipitation in the HL section, and the annual runoff and annual sediment load both showed an extremely significant (p < 0.001) declining trend. (2) The two mutation years for sediment load reduction in the HL section were in 1979 and 1999, respectively. The average annual sediment loads decreased from 9.30×10 ⁸ t during 1952-1979, to 4.20×10 ⁸ t during 1980-1999, it was, and in 2000-2017, it dropped to 1.03×10 ⁸ t, a decrease of 89%. (3) Influenced by vegetation and terraces, the amount of soil erosion on the slope of the HL section decreased year by year from 2000 to 2015, changing from 1.90×10 ⁸ t to 5.13×10 ⁸ t, and the average annual sediment reduction of check dams from 2000 to 2011 was 1.38×10 ⁸ t. (4) Vegetation restoration was the main reason for the reduction of sediment loads in the HL section, with a contribution rate of 54%. Terraces and check dams, and reservoir and water diversion contributed 34%, and 12%, respectively. (5) Vegetation restoration mainly led to reduced runoff sediments, while check dam construction played a major part in reducing the sediment transport ratio of the basin. According to the changing trend of sediment load, countermeasures are put forward.

Key words: Hekou-Longmen section, sediment load, ecological construction, contribution rate of sediment reduction

GAO Haidong, LIU Han, JIA Lianlian, PANG Guowei, WANG Jie. Attribution analysis of precipitous decrease of sediment loads in the Hekou-Longmen section of Yellow River since 2000[J].Acta Geographica Sinica, 2019, 74(9): 1745-1757.

Figures/Tables 12

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Tab. 1

Fig. 5

Fig. 6

Tab. 2

Fig. 7

Tab. 3

Tab. 4

Fig. 8

References 29

[1]	Wang S, Fu B, Piao S , et al. Reduced sediment transport in the Yellow River due to anthropogenic changes. Nature Geoscience, 2016,9:38-41.
[2]	Miao C Y, Ni J R, Borthwick A G L . Recent changes of water discharge and sediment load in the Yellow River basin, China. Progress in Physical Geography, 2010,34(4):541-561.
[3]	Hu Chunhong, Zhang Zhihao . The research of mechanism of constructing riverbed and index of flow and sediment of floodwater in the Lower Yellow River. Science China Technological Sciences, 2015,45:1043-1051.
	[ 胡春宏, 张治昊 . 黄河下游漫滩洪水造床机理与水沙调控指标研究. 中国科学: 技术科学, 2015,45(10):1043-1051.]
[4]	Gao P, Deng J, Chai X , et al. Dynamic sediment discharge in the Hekou-Longmen region of Yellow River and soil and water conservation implications. Science of the Total Environment, 2017,578:56-66.
[5]	Mu Xingming, Zhang Xiuqin, Gao Peng , et al. Theory of double mass curves and its applications in hydrology and meteorology. Journal of China Hydrology, 2010,30(4):47-51.
	[ 穆兴民, 张秀勤, 高鹏 , 等. 双累积曲线方法理论及在水文气象领域应用中应注意的问题. 水文, 2010,30(4):47-51.]
[6]	Fu G, Charles S P, Chiew F H S . A two-parameter climate elasticity of streamflow index to assess climate change effects on annual streamflow. Water Resources Research, 2007,43(11):2578-2584.
[7]	Sankarasubramanian A, Vogel R M, Limbrunner J F . Climate elasticity of streamflow in the United States. Water Resources Research, 2001,37(6):1771-1781.
[8]	Shi Changxing, Guo Lipeng . Sediment yield reduction by soil conservation measure on slopes in the Wudinghe River catchment. Journal of Sediment Research, 2006(5):22-27.
	[ 师长兴, 郭立鹏 . 无定河坡面措施减沙和拦粗泥沙量分析. 泥沙研究, 2006(5):22-27.]
[9]	Wei Yanhong, Jiao Jüying, Zhang Shijie . Contribution of sediment retention by check-dams to sediment discharge reduction of typical tributaries on the Loess Plateau. Science of Soil and Water Conservation, 2017,15(5):16-22.
	[ 魏艳红, 焦菊英, 张世杰 . 黄土高原典型支流淤地坝拦沙对输沙量减少的贡献. 中国水土保持科学, 2017,15(5):16-22.]
[10]	Yao Wenyi, Ran Dachuan, Chen Jiangnan . Recent changes in runoff and sediment regimes and future projections in the Yellow River Basin. Advances in Water Science, 2013,24(5):607-616.
	[ 姚文艺, 冉大川, 陈江南 . 黄河流域近期水沙变化及其趋势预测. 水科学进展, 2013,24(5):607-616.]
[11]	Wang G S, Xia J, Chen J . Quantification of effects of climate variations and human activities on streamflow by a monthly water balance model: A case study of the Chaobai River basin in northern China. Water Resources Research, 2009,45(7):206-216.
[12]	Li D, Tian Y, Liu C . Distributed hydrological simulation of the source regions of the Yellow River under environmental changes. Acta Geographica Sinica, 2004,59(4):565-573.
	[ 李道峰, 田英, 刘昌明 . 黄河河源区变化环境下分布式水文模拟. 地理学报, 2004,59(4):565-573.]
[13]	He Xuqiang, Zhang Bo, Sun Liwei , et al. Contribution rates of climate change and human activity on the streamflow in upper and middle reaches of Heihe River basin. Chinese Journal of Ecology, 2012,31(11):2884-2890.
	[ 何旭强, 张勃, 孙力炜 , 等. 气候变化和人类活动对黑河上中游径流量变化的贡献率. 生态学杂志, 2012,31(11):2884-2890.]
[14]	Wang Suiji, Yan Yunxia, Yan Ming , et al. Contributions of precipitation and human activities to the streamflow change of the Huangfuchuan Drainage Basin: Application of comparative method of the slope changing ratio of cumulative quantity. Acta Geographica Sinica, 2012,67(3):388-397.
	[ 王随继, 闫云霞, 颜明 , 等. 皇甫川流域降水和人类活动对径流量变化的贡献率分析: 累积量斜率变化率比较方法的提出及应用. 地理学报, 2012,67(3):388-397.]
[15]	Lai Tianzeng, Zhang Qiang, Zhang Zhenghao , et al. Quantitative evaluations of fractional contribution of human activities and climate changes to the streamflow variations across the East River basin. Acta Scientiarum Naturalium Universitatis Sunyatseni, 2016,55(4):136-145.
	[ 赖天锃, 张强, 张正浩 , 等. 人类活动与气候变化对东江流域径流变化贡献率定量分析. 中山大学学报(自然科学版), 2016,55(4):136-145.]
[16]	Liu Xiaoyan. Causes of Sharp Decrease in Water and Sediment in Recent Years in the Yellow River. Beijing: Science Press, 2016.
	[ 刘晓燕 . 黄河近年水沙锐减成因. 北京: 科学出版社, 2016.]
[17]	Zhang Wenbo, Xie Yun, Liu Baoyuan . Rainfall erosivity estimation using daily rainfall amounts. Scientia Geographica Sinica, 2002,22(6):705-711.
	[ 章文波, 谢云, 刘宝元 . 利用日雨量计算降雨侵蚀力的方法研究. 地理科学, 2002,22(6):705-711.]
[18]	Jiang Zhongshan, Wang Zhiqiang, Liu Zhi . Quantitative study on spatial variation of soil erosion in a small watershed in the loess hilly region. Journal of Soil and Water Conservation, 1996,1:1-9.
	[ 江忠善, 王志强, 刘志 . 黄土丘陵区小流域土壤侵蚀空间变化定量研究. 水土保持学报, 1996,1:1-9.]
[19]	Kong D, Miao C, Wu J , et al. Impact assessment of climate change and human activities on net runoff in the Yellow River Basin from 1951 to 2012. Ecological Engineering, 2016,91:566-573.
[20]	Pettitt A N . A non-parametric approach to the change-point problem. Applied Statistics, 1979,28(2):126-135. doi: 10.2307/2346729
[21]	Qin W, Guo Q, Cao W , et al. A new RUSLE slope length factor and its application to soil erosion assessment in a Loess Plateau watershed. Soil & Tillage Research, 2018,182:10-24.
[22]	Gao Yunfei, Guo Yutao, Liu Xiaoyan , et al. Failure criteria of the warping dams on sediment interception in the Middle Yellow River in northern Shaanxi. Acta Geographica Sinica, 2014,69(1):73-79.
	[ 高云飞, 郭玉涛, 刘晓燕 , 等. 陕北黄河中游淤地坝拦沙功能失效的判断标准. 地理学报, 2014,69(1):73-79.]
[23]	Shi H L, Hu C H, Wang Y G , et al. Analyses of trends and causes for variations in runoff and sediment load of the Yellow River. International Journal of Sediment Research, 2016,32(2):171-179.
[24]	Zheng H Y, Miao C Y, Wu J W , et al. Temporal and spatial variations in water discharge and sediment load on the Loess Plateau, China: A high-density study. Science of the Total Environment, 2019,666:875-886.
[25]	Shi P, Zhang Y, Ren Z P , et al. Land-use changes and check dams reducing runoff and sediment yield on the Loess Plateau of China. Science of the Total Environment, 2019(664):984-994.
[26]	Chen Hao . Relationship between erosion and sediment yield in drainage basins of loess gully-hilly areas. Acta Geographica Sinica, 2000,55(3):354-363.
	[ 陈浩 . 黄土丘陵沟壑区流域系统侵蚀与产沙关系. 地理学报, 2000,55(3):354-363.]
[27]	Xie Wangcheng, Li Tianhong . Research comment on watershed sediment delivery ratio. Acta Scientiarum Naturalium Universitatis Pekinensis, 2012,48(4):685-694.
	[ 谢旺成, 李天宏 . 流域泥沙输移比研究进展. 北京大学学报(自然科学版), 2012,48(4):685-694.]
[28]	Xu Jiongxin, Sun Ji . Effect of erosion control measures on sediment delivery ratio. Advances in Water Science, 2004,15(1):29-34.
	[ 许炯心, 孙季 . 水土保持措施对流域泥沙输移比的影响. 水科学进展, 2004,15(1):29-34.]
[29]	Gao Haidong, Li Zhanbin, Li Peng , et al. The capacity of soil loss control in the Loess Plateau based on soil erosion control degree. Acta Geographica Sinica, 2015,70(9):1503-1515.
	[ 高海东, 李占斌, 李鹏 , 等. 基于土壤侵蚀控制度的黄土高原水土流失治理潜力研究. 地理学报, 2015,70(9):1503-1515.]

时段	年均降水量(mm)	年均径流量(亿m³)	年均输沙量(亿t)
P1(1952-1979年)	477	66.50	9.30
P2(1980-1999年)	437	39.34	4.20
P3(2000-2017年)	448	21.63	1.03

年份	植被影响下的坡面年土壤侵蚀量(亿t)	梯田比(%)	梯田减沙贡献率(%)	植被和梯田共同作用下的坡面年土壤侵蚀量(亿t)
2000	3.97	6.92	14.02	3.42
2001	5.83	6.42	11.96	5.13
2002	5.82	6.61	12.74	5.08
2003	5.38	6.80	13.51	4.65
2004	3.92	7.25	15.42	3.32
2005	3.39	7.94	18.52	2.76
2006	3.80	8.05	18.98	3.08
2007	4.06	7.43	16.22	3.40
2008	3.13	8.13	19.38	2.53
2009	3.69	8.31	20.22	2.94
2010	3.17	8.32	20.27	2.52
2011	3.09	9.02	23.54	2.36
2012	3.59	8.13	19.39	2.90
2013	4.09	8.16	19.50	3.29
2014	2.61	9.78	27.21	1.90
2015	2.90	9.53	25.99	2.15

流域(水文站)	NDVI与Q	NDVI与S	NDVI与Cs
皇甫川(皇甫)	0.116	-0.215	-0.657^*
孤山川(高石崖)	-0.015	-0.626*	-0.897^**
窟野河(温家川)	0.390	-0.645*	-0.783^**
秃尾河(高家川)	-0.537^*	-0.454	-0.439
佳芦河(申家湾)	0.402	0.161	-0.166
无定河(白家川)	0.556^*	-0.404	-0.479
清涧河(延川)	-0.045	-0.280	-0.448
延河(甘谷驿)	0.112	-0.332	-0.504

流域	项目	1965-1979年	1980-1999年	2000-2011年
皇甫川	输沙量	0.61	0.34	0.08
	拦沙量	0.03	0.05	0.09
	泥沙输移比	0.95	0.87	0.47
孤山川	输沙量	0.29	0.12	0.02
	拦沙量	0.02	0.03	0.02
	泥沙输移比	0.94	0.80	0.50
佳芦河	输沙量	0.25	0.06	0.02
	拦沙量	0.11	0.11	0.05
	泥沙输移比	0.69	0.38	0.29
大理河	输沙量	0.51	0.22	0.19
	拦沙量	0.15	0.25	0.19
	泥沙输移比	0.77	0.47	0.50
