伊河龙门峡段全新世古洪水和历史洪水水文学重建

doi:10.11821/dlxb201507012

Abstract

Abstract:

In this study, palaeoflood hydrological and sedimentary investigations were carried out in the Yiluohe River basin. Typical loess-soil stratigraphy of the Holocene period was identified at the Longmenxia (LMX) site in the Yihe River basin. Based on the analysis of sedimentary characteristics, magnetic susceptibility and particle-size distribution, the five flood slackwater deposits were identified and interbedded into the loess-soil stratigraphy. By the stratigraphic correlation and the optically stimulated luminescence method (OSL), the four episodes of flooding events occurred at 3100-3000 a BP, 1800-1700 a BP, 770-610 a BP and 420-340 a BP, respectively, namely at the end of the mid-Holocene Climatic Optimum and the beginning of the late Holocene, the dynasties of Eastern Han to Western Jin, Song-Yuan and the Ming-Qing, respectively. These flooding events might include the AD223 and 1761 flooding events and they well corresponded to the phase of the Holocene monsoonal shift, climatic abrupt change and climatic decline. The flooding peak stages were estimated with the elevations and the depositional depths of the SWD. According to the flood peak stages and hydraulic parameters, the peak discharges were reconstructed at 14100-15800 m³/s with the slope-area method. The reconstructed peak discharges of the flooding events are much more than those of the gauged modern floods at the Longmenxia gauge station in the middle reach of the Yihe River.

Key words: palaeoflood, slackwater deposits, Yiluohe River, Holocene

Guiming HU, Chunchang HUANG, Yali ZHOU, Jiangli PANG, Xiaochun ZHA, Yongqiang GUO, Yuzhu ZHANG, Xueru ZHAO. Hydrological reconstruction of Holocene palaeofloods and historical floods in the Longmen Gorge of the Yihe River[J].Acta Geographica Sinica, 2015, 70(7): 1165-1176.

Figures/Tables 12

Fig. 1

Fig. 2

Tab. 1

Fig. 3

Tab. 2

Fig. 4

Fig. 5

Tab. 3

Tab. 4

Tab. 5

Fig. 6

Fig. 7

References 35

[1]	Guo Jianmin, Zheng Jinliang.Document on Yiluohe River. Beijing: China Science and Technology Press, 1995.
	[郭建民, 郑金亮. 伊洛河志. 北京:中国科学技术出版社, 1995.]
[2]	Wang Wenkai, Mao Jizhou, Chen Daiguang, et al.Geography of Henan Province. Zhengzhou: Henan People's Publishing House, 1990.
	[王文楷, 毛继周, 陈代光, 等. 河南地理志. 郑州: 河南人民出版社, 1990.]
[3]	Shi Ziming.Natural Conditions and Natural Resources. Zhengzhou: Henan Science and Technology Press, 1983.
	[时子明. 河南自然条件与自然资源. 郑州: 河南科学技术出版社, 1983.]
[4]	Shi Fucheng, Yi Yuanjun.The earliest historical flood carved into the stone wall in the Yihe River reach at AD223. Hydrology, 1983, 3(6): 47-50.
	[史辅成, 易元俊. 我国最早的一次历史洪水石刻-伊河公元223年洪水. 水文, 1983, 3(6): 47-50.]
[5]	Zhang Yuzhu, Huang Chunchang, Pang Jiangli, et al.OSL dating of the massive landslide-damming event in the Jishixia Gorge, on the upper Yellow River, NE Tibetan Plateau. The Holocene, 2015, 25(5): 745-757.
[6]	Local Chronicles Compilation Committee of Luoyang City. Geography of Luoyang City. Henan: Hongqi Press, 1992.
	[洛阳市地方志编纂委员会. 洛阳市地理志. 河南: 红旗出版社, 1992.]
[7]	School of Water Resource and Hydropower. Hydraulics. Beijing: Higher Education Press, 1986.
	[武汉水利水电学院水利学研究室. 水力学. 北京: 高等教育出版社, 1986.]
[8]	Chew V.T. Open-Channel Hydraulic. New York: McGraw-Hill Book Company Inc., 1959.
[9]	Yang Dayuan, Ge Yu, Xie Yuebo, et al.Sedimentary records of large Holocene floods from the middle reaches of the Yellow River, China. Geomorphology, 2000, 33(1/2): 73-88.
[10]	Shi Fucheng, Yi Yuanjun, Mu Ping.Investigation, Research and Study on the Yellow River Historical Flood. Zhengzhou: Yellow River Water Conservancy Press, 2002.
	[史辅成, 易元俊, 慕平. 黄河历史洪水调查、考证和研究. 郑州: 黄河水利出版社, 2002.]
[11]	Huang Chunchang, Pang Jiangli, Zha Xiaochun.Holocene environmental change inferred from the loess-palaeosol sequences adjacent to the floodplain of the Yellow River, China. Quaternary Science Reviews, 2009, 28(25): 2633-2646.
[12]	Arie S Issar.Climatic Changes during the Holocene and Their Impact on Hydrological Systems. Cambrige University Press, 2013.
[13]	Thorndycraft V R, Benito G.The Holocene fluvial chronology of Spain: Evidence from a newly compiled radiocarbon database. Quaternary Science Reviews, 2006, 25: 223-234
[14]	Li Xiaogang, Huang Chunchang, Pang Jiangli, et al.Hydrological studies of the Holocene palaeoflood in the Hukou reach of the Yellow River. Acta Geographica Sinica, 2010, 65(11): 1371-1380.
	[李小刚, 黄春长, 庞奖励, 等. 黄河壶口段全新世古洪水事件及其水文学研究. 地理学报, 2010, 65(11): 1371-1380.]
[15]	Huang Chunchang, Li Xiaogang, Pang Jiangli, et al.Palaeoflood sedimentological and hydrological studies on the Yongheguan reach in the middle Yellow River. Acta Geographica Sinica, 2012, 67(11): 1493-1504.
	[黄春长, 李晓刚, 庞奖励, 等. 黄河永和关段全新世古洪水研究. 地理学报, 2012, 67(11): 1493-1504.]
[16]	Huang Chunchang, Pang Jiangli, Zha Xiaochun, et al.Prehistorical floods in the Guanzhong Basin in the Yellow River drainage area: A case study along the Qishuihe River Valley over the Zhouyuan Loess Tableland. Science China Earth Sciences, 2011, 41(11): 1685-1669.
	[黄春长, 庞奖励, 周亚利, 等.黄河流域关中盆地史前大洪水研究: 以周原漆水河谷为例. 中国科学: 地球科学. 2011, 41(11): 1658-1669.]
[17]	Yao Ping, Huang Chunchang, Pang Jiangli, et al.Palaeoflood hydrological study in the Luochuan, Huangling reach in the middle reach of Beiluo River. Acta Geographica Sinica, 2008, 63(11): 1198-1200.
	[姚平, 黄春长, 庞奖励, 等. 北洛河中游黄陵洛川段全新世古洪水研究. 地理学报, 2008, 63(11): 1198-1206.]
[18]	Hou Yongjian, Zhu Yizhi.Important climatic events showed by historical records from middle and lower reach plain of the Yellow River during 5-2.7 ka and their environmental significance. Marine Geology and Quaternary Geology, 2000, 20(4): 23-29.
	[侯甬坚, 祝一志. 历史记录提取的近5-2.7ka黄河中下游平原重要气候事件及其环境意义. 海洋地质与第四纪地质, 2000, 20(4): 23-29.]
[19]	Patterson W P, Dietrich K A, Holmden C, et al.Two millennia of North Atlantic seasonality and implications for Norse colonies. Proceedings of the National Academy of Sciences of the United States of America, 2010, 107(12): 5306-5310.
[20]	Loehle C, McCulloch H. Correction to: A 2000-year global temperature reconstruction based on non-tree ring proxies. Energy and Environment, 2008, 19(1): 93-100.
[21]	Kaufman D S, Schneider D P.Recent warming reverses long-term Arctic cooling. Science, 2009, 325: 1236-1239.
[22]	Zhang Xian, Shao Xiaohua, Wang Tao.Regional climate characteristics in China during the Little Ice Age. Journal of Nanjing University of Information Science and Technology: Natural Science Edition, 2013, 5(4): 317-325.
	[张娴, 邵晓华, 王涛. 中国小冰期气候研究综述. 南京信息工程大学学报: 自然科学版, 2013, 5(4): 317-325.]
[23]	Ge Quansheng, Zheng Jingyun, Hao Zhixin, et al.The characteristics of climatic change in China during the past 2000-year. Science China Earth Sciences, 2012, 42(6): 934-942.
	[葛全胜, 郑景云, 郝志新, 等. 过去2000年中国气候变化的若干重要特征. 中国科学: 地球科学, 2012, 42(6): 934-942.]
[24]	Ge Quansheng, Liu Jian, Fang Xiuqi, et al.General characteristics of temperature change and centennial warm periods during the past 2000 years. Acta Geographica Sinica, 2013, 68(5): 579-592.
	[葛全胜, 刘健, 方修琦, 等. 过去2000年冷暖变化的基本特征与主要暖期. 地理学报, 2013, 68(5): 579-592.]
[25]	Kreutz K J.Bipolar changes in atmospheric regulation during the Little Ice Age. Science, 1997, 277: 1294-1296.
[26]	Soon W, Baliunas S, Idso C, et al.Reconstructing climate and environmental changes of the past l000 years: A reappraisal. Energy and Environment, 2003, 14(2/3): 233-296.
[27]	LI Mingqi, Jin Heling, Zhang Hong.Advances of climate research in the Little Ice Age. Journal of Desert Research, 2005, 25(5): 731-737.
	[李明启, 靳鹤龄, 张洪. 小冰期气候的研究进展. 中国沙漠, 2005, 25(5): 731-737.]
[28]	Zhang De'er, Liu Chuanzhi, Jiang Jianmin. Reconstruction of six regional dry/wet series and their abrupt changes during the last 1000 years in East China. Quaternary Sciences, 1997, 17(1): 1-11.
	[张德二, 刘传志, 江剑民. 中国东部6区域近1000年干湿序列的重建和气候跃变分析. 第四纪研究, 1997, 17(1): 1-11.]
[29]	Zhang Xian.The summarization of the Little Ice Age research in China. Journal of Nanjing Information Engineering University, 2013, 5(4): 317-325.
	[张娴. 中国小冰期气候研究综述. 南京信息工程大学学报, 2013, 5(4): 317-325.]
[30]	Gao Jianhui, Liu Jian, Wang Sumin.Overview on studies of Medieval Warm Period in China. Scientia Geographica Sinica, 2006, 26(6): 376-383.
	[高健慧, 刘健, 王苏民. 中国中世纪暖期气候研究综述. 地理科学, 2006, 26(6): 376-383.]
[31]	Zhou Xiuji, Zhao Ping, Liu Ge, et al.Characteristics of decadal-centennial-scale changes in East Asian summer monsoon circulation and precipitation during the Medieval Warm Period and Little Ice Age and in the present day. Chinese Science Bulletin, 2011, 56(25): 2060-2067.
	[周秀骥, 赵平, 刘舸, 等. 中世纪暖期、小冰期与现代东亚夏季风环流和降水年代-百年尺度变化特征分析. 科学通报, 2011, 56(25): 2060-2067.]
[32]	Ge Quansheng, Zheng Jingyun, Man Zhimin, et al.Reconstruction and analysis on the series of winter-half-year temperature changes over the past 2000 years in Eastern China. Earth Science Frontiers, 2002, 9(1): 169-181.
	[葛全胜, 郑景云, 满志敏, 等. 过去2000a中国东部冬半年温度变化序列重建及初步分析. 地学前缘, 2002, 9(1): 169-181.]
[33]	Wang Shaowu.Enhancement of the warming trend in China. Geophysical Research Letters, 2000, 27(16): 2581-2584.
[34]	Zhu Kezhen.A preliminary study of climate change over the last 5 000 years in China. Science China, 1973, 3(3): 168-189.
	[竺可桢. 中国近五千年来气候变迁的初步研究. 中国科学, 1973, 3(3): 168-189.]
[35]	Shi Yafeng, Kong Zhaochen, Wang Sumin, et al.The climatic abrupt and events during Holocene Climatic Optimum in China. Science China Chemistry Vitae Terrae, 1992, 22(12): 1300-1308.
	[施雅风, 孔昭宸, 王苏民, 等. 中国全新世大暖期的气候波动与重要事件. 中国科学(B辑化学生命科学地学), 1992, 22(12): 1300-1308.]

样品	深度(cm)	U(ppm)	Th(ppm)	K(%)	含水量(%)	等效剂量(Gy)	环境剂量(Gy.ka^-1)	Age(a)
YH-MS_-1	77.5	2.31±0.09	10.1±0.29	1.86±0.06	15	1.11±0.11	2.92± 0.06	380± 40
YH-SWD3	122.5	2.96±0.11	12.8±0.36	2.02±0.06	15	2.30±0.25	3.36±0.06	690±80
YH-Lo	147.5	2.46±0.10	11.60±0.32	1.94±0.06	15	5.58±0.13	3.10±0.06	1800±60
YH-So	197.5	2.30±0.09	11.8±0.33	2.07±0.06	18	9.79±0.62	3.17±0.06	3180±200

地层层位	磁化率Magnetic susceptibility	粒级比例(%) Particle size					Md	Mz
Stratigraphy	(×10^-8 m³/kg)	<2 μm	2~16 μm	16~63 μm	63~125 μm	>125 μm	μm	μm
表土底界MS_-1	128.10	8.79	34.51	45.20	5.70	5.80	20.05	24.59
历史洪水SWD5	174.90	4.85	16.95	32.40	19.10	26.70	53.65	77.55
历史洪水SWD4	127.60	6.08	22.52	52.80	13.60	5.00	30.67	35.80
历史洪水SWD3	126.50	7.86	28.24	50.50	9.90	3.50	25.76	29.18
历史洪水SWD2	44.30	5.68	24.62	58.60	9.50	1.60	26.38	29.63
风成黄土L₀	168.90	9.52	26.98	51.00	9.50	3.00	25.42	28.56
古洪水SWD1	138.80	8.81	38.29	48.70	2.80	1.40	17.18	18.86
古土壤S₀	154.40	14.80	40.60	39.50	3.60	1.50	12.82	17.53

古洪水期次	洪峰水位高程(m)	水面宽(m)	总水深H(m)	水面比降\|S	糙率系数n	过水断面面积A(m²)	湿周L(m)	水力半径R(m)	洪峰流量Q(m³/s)
SWD5	158.55	235	10.55	0.004	0.035	2044.12	242.57	8.43	15300
SWD4	157.90	234	9.90	0.004	0.035	1897.37	240.67	7.88	13600
SWD3	157.80	234	9.80	0.004	0.035	1873.95	240.29	7.80	13300
SWD2	157.85	234	9.85	0.004	0.035	1885.66	240.51	7.84	13400
SWD1	157.40	233	9.40	0.004	0.035	1780.44	238.79	7.46	12300

古洪水期次	洪峰水位高程(m)	水面宽(m)	总水深H(m)	水面比降S	糙率系数n	过水断面面积A(m²)	湿周L(m)	水力半径R(m)	洪峰流量Q(m³/s)
SWD5	158.65	236	10.65	0.004	0.035	2067.68	243.35	8.50	15500
SWD4	158.60	235	10.60	0.004	0.035	2055.89	242.84	8.47	15400
SWD3	158.50	235	10.50	0.004	0.035	2014.73	242.19	8.32	15000
SWD2	158.30	235	10.30	0.004	0.035	1944.23	241.76	8.04	14100
SWD1	158.80	238	10.80	0.004	0.035	2091.30	245.21	8.53	15800
