黄河下游游荡段排沙比对水沙条件与断面形态的响应

doi:10.11821/dlxb202101010

Abstract

Abstract:

One of the main tasks for the river regulation in the Lower Yellow River (LYR) is to improve sediment transport capacity of the braided reach, which is influenced by incoming flow and sediment regime as well as riverbed boundary condition. Variations in the reach-scale geomorphic coefficient and incoming flow-sediment regime (incoming sediment coefficient and fluvial erosion intensity) were investigated, using the hydrological data and cross-sectional profiles surveyed in the braided reach between Huayuankou and Gaocun over the period from 1971 to 2016. Empirical relationships were then established to quantitatively demonstrate the integrated effects of flow-sediment regime and the post-flood channel geometry in the previous year on the values of sediment delivery ratio (SDR) during flood seasons and flood events respectively in the study reach. Results indicate that: (1) the values of SDR of flood seasons and flood events increased with a smaller incoming sediment coefficient or a larger fluvial erosion intensity, and the incoming sediment coefficient was equal to 0.012 kg·s/m ⁶ when the value of flood-season SDR approached 1. The correlation coefficient is 0.76 for the relationship between flood-event SDR, incoming sediment coefficient, and the ratio of the water volume at the inlet section to the one at the outlet section in the study reach. (2) The SDR of the braided reach decreased with wider and shallower channel geometry, and it was less than 1 when the geomorphic coefficient was greater than 15 /m ^0.5. (3) The determination coefficient is 0.82 for the empirical function established among flood-season SDR, incoming sediment coefficient and geomorphic coefficient, and the weight of the channel geometry is greater than the incoming sediment coefficient in the function of flood-event SDR. The established functions can reflect the sediment-transport characteristics of the braided reach, which is helpful to quantify the influence of channel geometry and flow-sediment regime on sediment transport capacity.

Key words: channel geometry, flow-sediment regime, sediment delivery ratio, flood season, flood event, braided reach, Lower Yellow River

CHENG Yifei, XIA Junqiang, ZHOU Meirong, WANG Yingzhen. Response of sediment delivery ratio to the incoming flow-sediment regime and channel geometry in the braided reach of the Lower Yellow River[J].Acta Geographica Sinica, 2021, 76(1): 127-138.

Figures/Tables 11

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Tab. 1

Fig. 8

Tab. 2

Fig. 9

References 34

[1]	Yao Wenyi, Su Yunqi, Li Yong. Influencing factors and judging indexes for the basic flood-conveying and sediment-transporting capacity in the Lower Yellow River. Journal of Sediment Research, 2009(1):1-9.
	[ 姚文艺, 苏运启, 李勇. 黄河下游排洪输沙基本功能的影响因素及判别指标. 泥沙研究, 2009(1):1-9.]
[2]	Xu Jiongxin. Influence of basin factors and human activities on sediment-transporting capacity in the lower Yellow River. Science in China Series D: Earth Sciences, 2004,34(8):775-781.
	[ 许炯心. 流域因素与人类活动对黄河下游河道输沙功能的影响. 中国科学: 地球科学, 2004,34(8):775-781.]
[3]	Yan Ming, He Li, Wang Yanjun, et al. Temporal and spatial variation of flood-conveying and sediment-transporting capacity of the lower reaches of the Yellow River during 1950-2015. Research of Soil and Water Conservation, 2019,26(4):1-6, 12.
	[ 颜明, 贺莉, 王彦君, 等. 1950—2015年黄河下游河道排洪输沙时空演变. 水土保持研究, 2019,26(4):1-6, 12.]
[4]	Shen Hongbin, Wu Baosheng, Wu Huali. A review on the effects of boundary condition on sediment transport efficiency in the Lower Yellow River. Advances in Water Science, 2019,30(3):445-456.
	[ 申红彬, 吴保生, 吴华莉. 黄河下游河道边界条件影响输沙效率研究述评. 水科学进展, 2019,30(3):445-456.]
[5]	Ta W Q, Wang H B, Jia X P. Suspended sediment transport response to upstream wash-load supply in the sand-bed reach of the Upper Yellow River, China. Journal of Hydrology, 2015,528:562-570.
[6]	Shen Hongbin, Wu Baosheng. Exponent change rule of power law for sediment transport in alluvial rivers. Advances in Water Science, 2018,29(2):179-185.
	[ 申红彬, 吴保生. 冲积河流泥沙输移幂律函数指数变化规律. 水科学进展, 2018,29(2):179-185.]
[7]	Liang Zhiyong, Liu Jixiang, Zhang Houjun. Study on critical conditions of scour-and-siltation in flood seasons in the lower Yellow River. Journal of China Institute of Water Resources and Hydropower Research, 2004,2(2):146-150.
	[ 梁志勇, 刘继祥, 张厚军. 黄河下游河道洪水冲淤临界水沙条件的研究. 中国水利水电科学研究院学报, 2004,2(2):146-150.]
[8]	Wu Baosheng, Zhang Yuanfeng. Analysis on sediment transport in the Lower Yellow River. Journal of Sediment Research, 2007(1):30-35.
	[ 吴保生, 张原锋. 黄河下游输沙量的沿程变化规律和计算方法. 泥沙研究, 2007(1):30-35.]
[9]	Fei Xiangjun, Fu Xudong. A study of sediment-transporting characteristics, sediment delivery ratio and siltation ratio in the Lower Yellow River. Yellow River, 2009,31(11):6-8, 11.
	[ 费祥俊, 傅旭东. 黄河下游河道排沙比、淤积率与输沙特性研究. 人民黄河, 2009,31(11):6-8, 11.]
[10]	Fu X D, Jiang L W, Wu B S, et al. Sediment delivery ratio and its uncertainties on flood event scale: Quantification for the Lower Yellow River. Science China: Technological Sciences, 2010,53(3):854-862.
[11]	Han Qiwei. Regulation of flow-sediment in the Yellow River. Journal of Tianjin University, 2008,41(9):1015-1026.
	[ 韩其为. 论黄河调水调沙. 天津大学学报, 2008,41(9):1015-1026.]
[12]	Xu J X. A study of sediment delivery by floods in the lower Yellow River, China. Hydrological Sciences Journal, 2003,48(4):553-566. doi: 10.1623/hysj.48.4.553.51416
[13]	Li Xiaoping, Li Yong, Qu Shaojun. Study on characteristics of flood scour and fill and high efficient sediment transport of the Lower Yellow River. Yellow River, 2010,32(12):71-73.
	[ 李小平, 李勇, 曲少军. 黄河下游洪水冲淤特性及高效输沙研究. 人民黄河, 2010,32(12):71-73.]
[14]	Zhang Yanyan, Wu Baosheng, Fu Xudong. Characteristics of sediment transport by flood events in the lower Yellow River. Journal of Hydrological Engineering, 2012,31(3):70-76.
	[ 张艳艳, 吴保生, 傅旭东. 黄河下游河道场次洪水输沙特性分析. 水力发电学报, 2012,31(3):70-76.]
[15]	Guo S L, Sun D P, Jiang E H, et al. Equilibrium sediment transport in lower Yellow River during later sediment-retaining period of Xiaolangdi Reservoir. Water Science and Engineering, 2015,8(1):78-84.
[16]	Ni J R, Liu X Y, Li T H, et al. Efficiency of sediment transport by flood and its control in the Lower Yellow River. Science in China Series E: Engineering and Materials Science, 2004,47(Suppl.1):173-185.
[17]	Han Qiwei. Some rules of sediment transportation and deposition-scouring in the lower Yellow River. Journal of Sediment Research, 2004(3):1-13.
	[ 韩其为. 黄河下游输沙及冲淤的若干规律. 泥沙研究, 2004(3):1-13.]
[18]	Huang H Q, Nanson G C. Hydraulic geometry and maximum flow efficiency as products of the principle of least action. Earth Surface Processes and Landforms, 2000,25(1):1-16.
[19]	Li Jie, Xia Junqiang, Deng Shanshan, et al. Recent bank retreat processes and characteristics in the braided reach of the Lower Yellow River. Advances in Water Science, 2015,26(4):517-525.
	[ 李洁, 夏军强, 邓珊珊, 等. 近期黄河下游游荡段滩岸崩退过程及特点. 水科学进展, 2015,26(4):517-525.]
[20]	Zhang Yuanfeng, Wang Ping. Variation characteristics of bedforms in wandering reach of the Lower Yellow River. Yellow River, 2018,40(8):8-11.
	[ 张原锋, 王平. 黄河下游游荡型河段床面形态变化特征. 人民黄河, 2018,40(8):8-11.]
[21]	Xia Junqiang, Wu Baosheng, Wan Yanping, et al. Composition and mechanical properties of soil in the bank of the braided reach of the Lower Yellow River. Science Bulletin, 2007,52(23):2806-2812.
	[ 夏军强, 吴保生, 王艳平, 等. 黄河下游游荡段滩岸土体组成及力学特性分析. 科学通报, 2007,52(23):2806-2812.]
[22]	Qi Pu, Sun Zanying, Yu Shoubing. Enlightenment on Yellow River governance from naturally developed stable channels in wandering reaches of lower Yellow River. Advances in Science and Technology of Water Resources, 2014,34(6):45-48.
	[ 齐璞, 孙赞盈, 于守兵. 黄河下游游荡河段自然形成的稳定河道对黄河治理的启示. 水利水电科技进展, 2014,34(6):45-48.]
[23]	Liu Cheng, He Yun, Liu An. Key drivers of changes in sediment loads of rivers. Advances in Science and Technology of Water Resources, 2017,37(1):1-7.
	[ 刘成, 何耘, 刘桉河流输沙量变化的主要驱动因素. 水利水电科技进展, 2017,37(1):1-7. ]
[24]	Xia J Q, Li X J, Zhang X L, et al. Recent variation in reach-scale bankfull discharge in the Lower Yellow River. Earth Surface Processes and Landforms, 2014,39(6):723-734.
[25]	Xia Junqiang, Wu Baosheng, Wang Yanping, et al. Estimating the bankfull discharge in the Lower Yellow River and analysis of its variation processes. Journal of Sediment Research, 2010(2):6-14.
	[ 夏军强, 吴保生, 王艳平, 等. 黄河下游河段平滩流量计算及变化过程分析. 泥沙研究, 2010(2):6-14.]
[26]	Li Jie, Xia Junqiang, Zhang Shiyuan. Variation in width-depth ratio of the braided reach in the Lower Yellow River undergoing hyperconcentrated flood processes. Yellow River, 2016,38(11):26-30.
	[ 李洁, 夏军强, 张诗媛. 高含沙洪水后黄河下游游荡段宽深比变化规律. 人民黄河, 2016,38(11):26-30.]
[27]	Wu Baosheng, Shen Guanqing. The physical meaning of incoming sediment coefficient. Yellow River, 2008,30(4):15-16.
	[ 吴保生, 申冠卿. 来沙系数物理意义的探讨. 人民黄河, 2008,30(4):15-16.]
[28]	Wu B S, Xia J Q, Fu X D, et al. Effect of altered flow regime on bankfull area of the Lower Yellow River, China. Earth Surface Processes and Landforms, 2008,33(10):1585-1601.
[29]	Fan Zuoying, Han Shaofa. A Compilation of Basic Data on Channel Evolution in the Lower Yellow River. Zhengzhou: Yellow River Institute of Hydraulic Research, YRCC, 1987: 459-463.
	[ 樊左英, 韩少发. 黄河下游河床演变基本资料汇编. 郑州: 黄河水利委员会水利科学研究所, 1987: 459-463.]
[30]	Shen Guanqing, Zhang Yuanfeng, Shang Hongxia. Mechanism of Response to Flood and Sediment-transporting Rule in the Lower Yellow River. Zhengzhou: The Yellow River Conservancy Press, 2008: 90-93.
	[ 申冠卿, 张原锋, 尚红霞. 黄河下游河道对洪水的响应机理与泥沙输移规律. 郑州: 黄河水利出版社, 2008: 90-93.]
[31]	Xu Jiongxin. Sediment transport efficiency of floods in the lower Yellow River in relation with water-sediment combination and channel geometry. Journal of Sediment Research, 2009,8(4):45-50.
	[ 许炯心. 黄河下游洪水的输沙效率及其与水沙组合和河床形态的关系. 泥沙研究, 2009,8(4):45-50.]
[32]	Ma Y X, Huang H Q, Nanson G C, et al. Channel adjustments in response to the operation of large dams: The upper reach of the lower Yellow River. Geomorphology, 2012,147/148:35-48.
[33]	Xu Jiongxin. Study on sediment transport in the lower Yellow River during flood period. Advances in Water Science, 2002,13(5):562-568.
	[ 许炯心. 黄河下游洪水的泥沙输移特征. 水科学进展, 2002,13(5):562-568.]
[34]	Li Guoying. Analysis on mechanism of peak discharge increasing during flood routing in lower reaches of Yellow River. Journal of Hydraulic Engineering, 2008,39(5):511-517.
	[ 李国英. 黄河洪水演进洪峰增值现象及其机理. 水利学报, 2008,39(5):511-517.]

自变量	系指数				R²
自变量	k	a	b	c	R²
来沙系数	0.097	-0.476	-0.138	0.296	0.82
水流冲刷强度	0.002	1.746	-2.245	0.834	0.71

自变量	系指数				R²
自变量	k	a	b	c	R²
来沙系数	-1.876	0.467	-0.113	1.486	0.60
冲刷强度	-0.829	-0.251	-0.072	1.447	0.48
