基于MCR模型和DO指数的九江滨水城市生态安全网络构建

doi:10.11821/dlxb202011014

Abstract

Abstract:

It is of vital importance to construct an ecological security network that considers both the ecological protection and the economic growth to ensure the sustainable development in waterfront cities. Based on the ecological and industrial data of Jiujiang city, we develop a comprehensive ecological security evaluation framework using the minimum cumulative resistance (MCR) model and the Duranton and Overman (DO) index. Specifically, the MCR is applied to examine the ecological landscape pattern while the DO index is introduced to analyze the degree of industrial agglomeration in continuous large areas and economic production zones. Subsequently, the eco-economic strategic nodes and green infrastructure belts are identified based on spatial conflicts between the ecological landscape patterns and economic production zones. The results demonstrate that: (1) Jiujiang city contains 29 important ecological sources with a total area of 7323 km². The areas with high-value of ecological security resistance account for 39.69%, which are distributed in the contiguous areas in the central and eastern parts of the city. In contrast, the low-value areas are on the city's periphery where there were fewer connected transition areas, which exhibit a spatially polarized "center-periphery" ecological landscape pattern. (2) The economic production zone is close to water sources, which presents spatial patterns of small-scale agglomeration and large-scale dispersion. The average length and number of agglomeration intervals are decreasing in heavily polluted, lightly polluted, and moderately polluted industries. (3) By analyzing the ecological sources, the resistance surface as well as the economic production zone, we determined ecological corridors with a length of 685.57 km and 25 eco-economic strategic nodes. As such, 18 important green infrastructure belts with a total length of 424.53 km and 26 regular green infrastructure belts with a total length of 662.46 km are designed to increase connectivity and maintain ecological processes. All of these elements constitute a "honeycomb" pattern of the ecological security network in Jiujiang city. This study expands the agglomeration economy perspective of the traditional ecological security network construction framework, and explores the data fusion of different scales. The study could contribute to scientific references for environmental management and regional sustainable development.

Key words: ecological security network, minimum cumulative resistance model, Duranton and Overman index, Jiujiang city

DAI Lu, LIU Yaobin, HUANG Kaizhong. Construction of an ecological security network for waterfront cities based on MCR model and DO index: A case study of Jiujiang city[J].Acta Geographica Sinica, 2020, 75(11): 2459-2474.

Figures/Tables 8

Fig. 1

Fig. 2

Tab. 1

Fig. 3

Tab. 2

The global agglomeration information of major manufacturing industries in Jiujiang city

行业代码及名称	全局集聚双边距离区间(km)	数量占比 (%)	平均长度($\overline{Δd}$)	$集聚度$ ( $Γ A$ )	污染分级
Code 30非金属矿物制品业	[16.19, 22.81], [23.81, 39.25]	9.90	11.03	0.26	重度
Code 17纺织业	[0, 9.83], [58.40, 63.00]	7.65	7.21	0.18	重度
Code 26化学原料和化学制品制造业	[0, 4.73]	3.16	4.73	0.21	重度
Code 18纺织服装、服饰业	[0, 5.42], [7.43, 13.80], [21.67,24.51], [38.99, 44.35], [50.65, 51.28]	22.20	4.12	1.08	中度
Code 33金属制品业	[0, 3.02], [27.34, 29.48], [44.23, 49.27]	5.24	3.40	0.11	中度
Code 19皮革、毛皮、羽毛及其制品和制鞋业	[0, 1.64], [42.78, 43.34]	3.42	1.10	0.09	中度
Code 38电气机械和器材制造业	[0, 7.81], [58.72, 61.93]	4.38	5.51	1.55	轻度
Code 37铁路、船舶、航空航天和其他运输设备制造业	[0, 3.59], [5.17, 14.93], [17.01, 23.37],[34.90, 36.86]	3.28	5.42	1.36	轻度
Code 34通用设备制造业	[0,15.94], [30.05, 31.50], [40.38, 41.20],[42.27, 46.56]	3.04	5.62	0.66	轻度

Tab. 2

Fig. 4

Fig. 5

Tab. 3

References 63

[1]	Cunha N S, Magalhaes M R. Methodology for mapping the national ecological network to mainland Portugal: A planning tool towards a green infrastructure. Ecological Indicators, 2019,104:802-818.
[2]	Hefting M M, Clement J C, Bienkowski P, et al. The role of vegetation and litter in the nitrogen dynamics of riparian buffer zones in Europe. Ecological Engineering, 2005,24(5):465-482.
[3]	Yan Changzhou, Jin Xiangcan, Zhao Jingzhu, et al. The functions of lakeside zone and its management. Ecology and Environment, 2005,14(2):294-298.
	[ 颜昌宙, 金相灿, 赵景柱, 等. 湖滨带的功能及其管理. 生态环境, 2005,14(2):294-298.]
[4]	Verhoef E T, Nijkamp P. Externalities in urban sustainability: Environmental versus localization-type agglomeration externalities in a general spatial equilibrium model of a single-sector monocentric industrial city. Ecological Economics, 2002,40(2):157-179. doi: 10.1016/S0921-8009(01)00253-1
[5]	Arnaiz-Schmitz C, Schmitz M F, Herrero-Jáuregui C, et al. Identifying socio-ecological networks in rural-urban gradients: Diagnosis of a changing cultural landscape. Science of the Total Environment, 2018,612:625-635.
[6]	Kavzoglu T. Determination of environmental degradation due to urbanization and industrialization in Gebze, Turkey. Environmental Engineering Science, 2008,25(3):429-438.
[7]	Hu Zhiqiang, Miao Changhong, Yuan Feng. Impact of industrial spatial and organizational agglomeration patterns on industrial SO₂ emissions of prefecture-level cities in China. Acta Geographica Sinica, 2019,74(10):2045-2061.
	[ 胡志强, 苗长虹, 袁丰. 集聚空间组织型式对中国地理尺度工业SO₂排放的影响. 地理学报, 2019,74(10):2045-2061.]
[8]	Jongman R H G, Külvik M, Kristiansen I. European ecological networks and greenways. Landscape and Urban Planning, 2004,68(2-3):305-319.
[9]	Zhang L Q, Peng J, Liu Y X, et al. Coupling ecosystem services supply and human ecological demand to identify landscape ecological security pattern: A case study in Beijing-Tianjin-Hebei region, China. Urban Ecosystems, 2017,20(3):701-714.
[10]	Santos J S, Leite C C C, Viana J C C, et al. Delimitation of ecological corridors in the Brazilian Atlantic Forest. Ecological Indicators, 2018,88:414-424.
[11]	Sutton-Grier A E, Wowk K, Bamford H. Future of our coasts: The potential for natural and hybrid infrastructure to enhance the resilience of our coastal communities, economies and ecosystems. Environmental Science & Policy, 2015,51:137-148.
[12]	Esbah H, Cook E A, Ewan J. Effects of increasing urbanization on the ecological integrity of open space preserves. Environmental Management, 2009,43(5):846-862. doi: 10.1007/s00267-009-9274-z pmid: 19242751
[13]	Zheng Qian, Zeng Juxin, Luo Jing, et al. Spatial structure and space governance of ecological network in Wuhan City. Economic Geography, 2018,38(9):191-199.
	[ 郑茜, 曾菊新, 罗静, 等. 武汉市生态网络空间结构及其空间管治研究. 经济地理, 2018,38(9):191-199.]
[14]	Zhao Xiaoqing, Li Sinan, Tan Kun, et al. Land use optimization of plateau lake basin based on town-agriculture-ecological spatial coordination. Transactions of the Chinese Society of Agricultural Engineering, 2019,35(8):296-307, 336.
	[ 赵筱青, 李思楠, 谭琨, 等. 城镇—农业—生态协调的高原湖泊流域土地利用优化. 农业工程学报, 2019,35(8):296-307, 336.]
[15]	Wei Wei, Jie Yaowen, Wei Xiaoxu, et al. Land use optimization based on CLUE-S model and ecological security scenario in Shiyang River Basin. Geomatics and Information Science of Wuhan University, 2017,42(9):1306-1315.
	[ 魏伟, 颉耀文, 魏晓旭, 等. 基于CLUE-S模型和生态安全格局的石羊河流域土地利用优化配置. 武汉大学学报(信息科学版), 2017,42(9):1306-1315.]
[16]	Ma L B, Bo J, Li X Y, et al. Identifying key landscape pattern indices influencing the ecological security of inland river basin: The middle and lower reaches of Shule River Basin as an example. Science of the Total Environment, 2019,674:424-438.
[17]	Li Qingpu, Zhang Zhengdong, Wan Luwen, et al. Landscape pattern optimization in Ningjiang River Basin based on landscape ecological risk assessment. Acta Geographica Sinica, 2019,74(7):1420-1437.
	[ 李青圃, 张正栋, 万露文, 等. 基于景观生态风险评价的宁江流域景观格局优化. 地理学报, 2019,74(7):1420-1437.]
[18]	Wang Y, Pan J H. Building ecological security patterns based on ecosystem services value reconstruction in an arid inland basin: A case study in Ganzhou District, NW China. Journal of Cleaner Production, 2019,241:1-12.
[19]	Yang Yuanqin, Ren Ping, Hong Buting. The study of land use conflict based on ecological security of the Chongqing section of Three Gorges Reservoir area. Resources and Environment in the Yangtze Basin, 2019,28(2):322-332.
	[ 杨远琴, 任平, 洪步庭. 基于生态安全的三峡库区重庆段土地利用冲突识别. 长江流域资源与环境, 2019,28(2):322-332.]
[20]	Wang Jianying, Li Jiangfeng, Zou Lilin, et al. Land layout for lake tourism based on ecological restraint. Chinese Journal of Applied Ecology, 2012,23(10):2871-2877. pmid: 23359952
	[ 王建英, 李江风, 邹利林, 等. 生态约束下的湖泊旅游用地布局. 应用生态学报, 2012,23(10):2871-2877.] pmid: 23359952
[21]	Liu Z F, Xie H L, Hu J. Evaluation of land ecological security for Poyang Lake Eco-Economic Zone based on emergy. Advanced Materials Research, 2013, 864-867:787-792.
[22]	Zhu Jun, Li Yimin, Yu Yanhong. Study of construction and optimization of ecological security pattern of lake basin in plateau based on GIS: A case study of Xingyun Lake Basin. Resources and Environment in the Yangtze Basin, 2017,26(8):1237-1250.
	[ 朱军, 李益敏, 余艳红. 基于GIS的高原湖泊流域生态安全格局构建及优化研究: 以星云湖流域为例. 长江流域资源与环境, 2017,26(8):1237-1250.]
[23]	Chen Kunlun, Qi Man, Wang Xu, et al. Study of urban lake landscape ecological security pattern evolution in Wuhan, 1995-2015. Acta Ecologica Sinica, 2019,39(5):1725-1734.
	[ 陈昆仑, 齐漫, 王旭, 等. 1995—2015年武汉城市湖泊景观生态安全格局演化. 生态学报, 2019,39(5):1725-1734.]
[24]	Liu D, Chang Q. Ecological security research progress in China. Acta Ecologica Sinica, 2015,35(5):111-121. doi: 10.1016/j.chnaes.2015.07.001
[25]	Peng J, Yang Y, Liu Y X, et al. Linking ecosystem services and circuit theory to identify ecological security patterns. Science of the Total Environment, 2018,644:781-790.
[26]	Sun J, Li Y P, Gao P P, et al. A Mamdani fuzzy inference approach for assessing ecological security in the Pearl River Delta urban agglomeration, China. Ecological Indicators, 2018,94:386-396.
[27]	Krugman P. Geography and Trade. Cambridge: MIT Press, 1991.
[28]	Duranton G, Overman H G. Testing for localization using micro-geographic data. The Review of Economic Studies, 2005,72(4):1077-1106.
[29]	Qiao Bin, Li Guoping, Yang Nini. The evolution and new development of the industry agglomeration measurement. The Journal of Quantitative & Technical Economics, 2007(4):124-133, 161.
	[ 乔彬, 李国平, 杨妮妮. 产业聚集测度方法的演变和新发展. 数量经济技术经济研究, 2007(4):124-133, 161.]
[30]	Nakajima K, Saito Y U, Uesugi I. Measuring economic localization: Evidence from Japanese firm-level data. Journal of the Japanese & International Economies, 2012,26(2):201-220.
[31]	Yang Qiyong, Tao Chunyuan, Yin Ke. Empirical study on the relationship between the development along the Yangtze River and its environmental pollution in Jiujiang city. Ecological Economy, 2015,31(4):156-160.
	[ 杨期勇, 陶春元, 尹科. 九江沿江开放开发与环境污染关系的实证分析. 生态经济, 2015,31(4):156-160.]
[32]	Hu Zhenpeng, Fu Jing. Quantitative study on hydrology relationship between the Yangtze River and Poyang Lake and its changes. Journal of Hydraulic Engineering, 2018,49(5):570-579.
	[ 胡振鹏, 傅静. 长江与鄱阳湖水文关系及其演变的定量分析. 水利学报, 2018,49(5):570-579.]
[33]	Wu Na, Fu Zeqiang, Xie Yuanyuan, et al. Review on the research progress of industrial layout optimization based on ecological carrying capacity. Ecological Economy, 2015,31(5):21-25.
	[ 邬娜, 傅泽强, 谢园园, 等. 基于生态承载力的产业布局优化研究进展述评. 生态经济, 2015,31(5):21-25.]
[34]	Vogt P, Ferrari J R, Lookingbill T R, et al. Mapping functional connectivity. Ecological Indicators, 2009,9(1):64-71.
[35]	Sun J, Southworth J. Indicating structural connectivity in Amazonian rainforests from 1986 to 2010 using morphological image processing analysis. International Journal of Remote Sensing, 2013,34(14):5187-5200.
[36]	Saura S, Vogt P, Velázquez J, et al. Key structural forest connectors can be identified by combining landscape spatial pattern and network analyses. Forest Ecology and Management, 2011,262(2):150-160.
[37]	Wickham J D, Riitters K H, Wade T G, et al. A national assessment of green infrastructure and change for the conterminous United States using morphological image processing. Landscape and Urban Planning, 2010,94(3/4):186-195.
[38]	Chen Zhu'an, Kuang Da, Wei Xiaojian, et al. Developing ecological networks based on MSPA and MCR: A case study in Yujiang county. Resources and Environment in the Yangtze Basin, 2017,26(8):1199-1207.
	[ 陈竹安, 况达, 危小建, 等. 基于MSPA与MCR模型的余江县生态网络构建. 长江流域资源与环境, 2017,26(8):1199-1207.]
[39]	Costanza R, d'Arge R, de Groot R, et al. The value of the world's ecosystem services and natural capital. Nature, 1997,387:253-260. doi: 10.1038/387253a0
[40]	Xie Gaodi, Lu Chunxia, Leng Yunfa, et al. Ecological assets valuation of the Tibetan Plateau. Journal of Natural Resources, 2003,18(2):189-196. doi: 10.11849/zrzyxb.2003.02.010
	[ 谢高地, 鲁春霞, 冷允法, 等. 青藏高原生态资产的价值评估. 自然资源学报, 2003,18(2):189-196.]
[41]	Bai Yu, Peng Lihong. Research and practice of ecosystem service function value of urban. Straits Science, 2011(6):16-18, 31.
	[ 白瑜, 彭荔红. 城市生态系统服务功能价值的研究与实践. 海峡科学, 2011(6):16-18, 31.]
[42]	Yu G M, Li M X, Tu Z F, et al. Conjugated evolution of regional social-ecological system driven by land use and land cover change. Ecological Indicators, 2018,89:213-226. doi: 10.1016/j.ecolind.2018.01.065
[43]	Tang Guoan, Song Jia. Comparison of slope classification methods in slope mapping from DEMs. Journal of Soil and Water Conservation, 2006,20(2):157-160, 192.
	[ 汤国安, 宋佳. 基于DEM坡度图制图中坡度分级方法的比较研究. 水土保持学报, 2006,20(2):157-160, 192.]
[44]	Wu Jiansheng, Ma Hongkun, Peng Jian. Improving urban ecological security pattern based on functional nodes-key corridors: A case study of Shenzhen City. Progress in Geography, 2018,37(12):1663-1671. doi: 10.18306/dlkxjz.2018.12.008
	[ 吴健生, 马洪坤, 彭建. 基于“功能节点—关键廊道”的城市生态安全格局构建: 以深圳市为例. 地理科学进展, 2018,37(12):1663-1671.]
[45]	Liu Y B, Dai L, Xiong H H. Simulation of urban expansion patterns by integrating auto-logistic regression, Markov chain and cellular automata models. Journal of Environmental Planning and Management, 2015,58(6):1113-1136. doi: 10.1080/09640568.2014.916612
[46]	Liu Lina, Ma Chunzi, Zhang Jingtian, et al. Ecological security assessment of typical watershed in Northeast China. Research of Environmental Sciences, 2019,32(7):1108-1116.
	[ 刘丽娜, 马春子, 张靖天, 等. 东北湖区典型流域生态安全评估. 环境科学研究, 2019,32(7):1108-1116.]
[47]	Jiang W G, Yuan L H, Wang W J, et al. Spatio-temporal analysis of vegetation variation in the Yellow River Basin. Ecological Indicators, 2015,51:117-126.
[48]	Knaapen J P, Scheffer M, Harms B. Estimating habitat isolation in landscape planning. Landscape and Urban Planning, 1992,23(1):1-16.
[49]	Cook E A. Urban landscape networks: An ecological planning framework. Landscape Research, 1991,16(3):7-15.
[50]	Li F, Ye Y P, Song B W, et al. Evaluation of urban suitable ecological land based on the minimum cumulative resistance model: A case study from Changzhou, China. Ecological Modelling, 2015,318(1):194-203.
[51]	Liang Fachao, Liu Haoran, Liu Shiyuan, et al. Spatial restructuring countermeasures of landscape ecological security network in southern Fujian: A case study of Jimei District in Xiamen. Economic Geography, 2018,38(9):231-239.
	[ 梁发超, 刘浩然, 刘诗苑, 等. 闽南沿海景观生态安全网络空间重构策略: 以厦门市集美区为例. 经济地理, 2018,38(9):231-239.]
[52]	Combes P P, Overman H G. The spatial distribution of economic activities in the European Union//Thisse J F, Henderson J V. Handbook of Regional and Urban Economics. Amsterdam: North Holland Press, 2004: 2845-2909.
[53]	Yuan Haihong, Zhang Hua, Zeng Hongyong. Measuring localization of manufacturing industries and its dynamics: Using Beijing firm-level data. China Industrial Economics, 2014(9):38-50.
	[ 袁海红, 张华, 曾洪勇. 产业集聚的测度及其动态变化: 基于北京企业微观数据的研究. 中国工业经济, 2014(9):38-50.]
[54]	Zhou Kan, Wang Qiang, Fan Jie. Impact of economic agglomeration on regional water pollutant emissions and its spillover effects. Journal of Natural Resources, 2019,34(7):1483-1495.
	[ 周侃, 王强, 樊杰. 经济集聚对区域水污染物排放的影响及溢出效应. 自然资源学报, 2019,34(7):1483-1495.]
[55]	Xia Youfu. The status quo, consequences and countermeasures of foreign investment in China's pollution-intensive industries. Management World, 1999(3):109-123.
	[ 夏友富. 外商投资中国污染密集产业现状、后果及其对策研究. 管理世界, 1999(3):109-123.]
[56]	Zhang Shanshan, Liu Cunli, Zhang Luocheng. The research of spatial evolution of pollution industrial and the future development of industries in southern Jiangsu of Taihu Lake Basin. Economic Geography, 2018,38(2):162-171. doi: 10.2307/142275
	[ 张姗姗, 刘存丽, 张落成. 苏南太湖流域污染企业空间布局演化及未来产业发展方向研究. 经济地理, 2018,38(2):162-171.]
[57]	Li Ling, Tao Feng. Selection of optimal environmental regulation intensity for Chinese manufacturing industry: Based on the green TFP perspective. China Industrial Economics, 2012(5):70-82.
	[ 李玲, 陶锋. 中国制造业最优环境规制强度的选择: 基于绿色全要素生产率的视角. 中国工业经济, 2012(5):70-82.]
[58]	Aars J, Ims R A. The effect of habitat corridors on rates of transfer and interbreeding between Vole Demes. Ecology, 1999,80(5):1648-1655.
[59]	Singh N P, Gokhale S. A method to estimate spatiotemporal air quality in an urban traffic corridor. Science of the Total Environment, 2015,538:458-467. doi: 10.1016/j.scitotenv.2015.08.065
[60]	Liang J, He X Y, Zeng G M, et al. Integrating priority areas and ecological corridors into national network for conservation planning in China. Science of the Total Environment, 2018,626:22-29.
[61]	He Canfei, Hu Xuqian. Evolution of Chinese industrial geography since reform and opening-up. Acta Geographica Sinica, 2019,74(10):1962-1979.
	[ 贺灿飞, 胡绪千. 1978年改革开放以来中国工业地理格局演变. 地理学报, 2019,74(10):1962-1979.]
[62]	Pan Jinghu, Liu Xiao. Assessment of landscape ecological security and optimization of landscape pattern based on spatial principal component analysis and resistance model in arid inland area: A case study of Ganzhou District, Zhangye City, Northwest China. Chinese Journal of Applied Ecology, 2015,26(10):3126-3136. pmid: 26995922
	[ 潘竟虎, 刘晓. 基于空间主成分和最小累积阻力模型的内陆河景观生态安全评价与格局优化: 以张掖市甘州区为例. 应用生态学报, 2015,26(10):3126-3136.] pmid: 26995922
[63]	Marshall A. Principles of Economics. London: Macmillan Press, 1920.

驱动力	阻力因子
驱动力	自然禀赋		人类开发		环境响应
阻力值	坡度(°)	土地利用类型	景观破碎度	与公路距离(m)	水质分级	NDVI
1	0~4.55	林地	0.30~0.52	> 12563	Ⅰ	0.83~0.92
2	4.55~11.12	耕地	0.52~0.96	7336~12563	Ⅱ	0.71~0.83
3	11.12~18.45	草地和未利用地	0.96~1.38	4126~7336	Ⅲ	0.53~0.71
4	18.45~26.78	水域	1.38~1.99	1650~4126	Ⅳ	0.28~0.53
5	26.78~64.43	建设用地	1.99~2.44	< 1650	Ⅴ	0.00~0.28
权重	0.07	0.20	0.29	0.19	0.14	0.11
参考文献	[43]	[44]	[45]	[38]	[46]	[47]

网络指数	网络闭合度α	网络连接度β	网络连通率γ
布局前	0.09	2.28	0.41
布局后	0.23	2.85	0.49
变化率(%)	147.08	25.31	21.16
