阿尔泰山喀纳斯河谷晚第四纪冰川地貌演化过程

doi:10.11821/dlxb201505006

Abstract

Abstract:

Multiple glacial advances/retreats have occurred in Kanas region of the Altay Mountains. Glacial erosive and accumulative landforms are not only very important for the analysis of the regional geomorphological process but also meaningful for the research on global change. According to the field investigation on the Quaternary geomorphology in the lower part of the Kanas Lake outlet in the main valley, this paper measured the altitude of multiple level U-shaped valley in different regions and confirmed the highest limit of glacial boulders and their spatial distribution. Using the electron spin resonance (ESR) method, we dated the glacial tills of the different moraines preserved along the main valley. Results of the glacial sequences, extent and glacial geomorphological process showed that four glacial advances occurred the lower part of the Kanas valley. Compared with the previous research results, these glaciations can be assigned as the Zhonglianggan glaciation, corresponding to the marine isotope stage 12 (MIS12), MIS8/10 glaciation, Penultimate glaciation (MIS6), and the last glacial cycle (LGC). LGC glacial advance can be further divided into three stages which correspond to MIS 4, 3, and 2. Based on the distribution of the three level U-shaped valleys, we concluded that the extent of glaciers decreased with time. The thickness of the glacier during Zhonglianggan glaciation was 50-395 m from the Glacial Station to the end of the glacier, and the length and width are also the largest at that time. The three-dimension extent showed that the glaciers were distributed in the main valley and on both sides of the ridges. The thickness was 102-199 m and 88-269 m during the MIS8/10 and the Penultimate glaciation, and the glacier reached near Tuojingwan. Well persevered multiple level U-shaped valley bottom on the eastern slope of the main valley near the region of Yazehu Lake indicated that the Quaternary glaciers have the warm glacier features such as strong activities, flowability and continuity. Clear asymmetry that occurred in the Kanas main valley showed that the development of the glacial valley was affected by regional climate and topography.

Key words: Altay Mountains, Kanas river valley, late Quaternary, glacial sequence, geomophological process

Wei ZHANG, Yanjing FU, Beibei LIU, Liang LIU, Zhijiu CUI, Yuanhuang SHI, Siwen WANG. Geomorphological process of late Quaternary glaciers in Kanas river valley of the Altay Mountains[J].Acta Geographica Sinica, 2015, 70(5): 739-750.

Figures/Tables 9

Fig. 1

Fig. 2

Tab. 1

Fig. 3

Tab. 1

Tab. 3

Fig. 4

Fig. 5

Fig. 6

References 56

[1]	Ehlers J, Gibbard P L. The extent and chronology of Cenozoic Global Glaciation. Quaternary International, 2007, 164/165: 6-20.
[2]	Shi Yafeng. Characteristics of late Quaternary monsoonal glaciation on the Tibetan Plateau andin East Asia. Quaternary International, 2002, 97/98: 79-91.
[3]	Cui Zhijiu, Chen Yixin, Zhang Wei, et al.Research history, glacial chronology and origins of Quaternary glaciations in China. Quaternary Sciences, 2011, 31(5): 749-764.
	[崔之久, 陈艺鑫, 张威, 等. 中国第四纪冰期历史、特征及成因探讨. 第四纪研究, 2011, 31(5): 749-764.]
[4]	Xu Liubing, Ou Xianjiao, Lai Zhongping, et al.Timing and style of Late Pleistocene glaciation in the Queer Shan, northern Hengduan Mountains in the eastern Tibetan Plateau. Journal of Quaternary Science, 2010, 25(6): 957-966.
[5]	Zhang Wei, Cui Zhijiu, Li Yonghua. Review of the timing and extent of glaciers during the last glacial cycle in the bordering mountains of Tibet and in East Asia. Quaternary International, 2006, 154/155: 32-43.
[6]	Wang Jie, Kassab C, Harbor J M, et al.Cosmogenic nuclide constraints on late Quaternary glacial chronology on the Dalijia Shan, northeastern Tibetan Plateau. Quaternary Research, 2013, 79: 439-451.
[7]	Liu Gengnian, Li Yingkui, Chen Yixin, et al.Glacial landform chronology and environment reconstruction of Peiku Gangri, Himalayas. Journal of Glaciology and Geocryology, 2011, 33(5): 959-970.
	[刘耕年, Li Yingkui, 陈艺鑫, 等. 喜马拉雅山佩枯岗日冰川地貌的年代学、平衡线高度和气候研究. 冰川冻土, 2011, 33(5): 959-970.]
[8]	Zhou Shangzhe, Wang Xiaoli, Wang Jie, et al. A preliminary study on timing of the oldest Pleistocene glaciation in Qinghai-Tibetan Plateau. Quaternary International, 2006, 154/155: 44-51.
[9]	Liu Gengnian, Zhang Xiaoyong, Cui Zhijiu, et al. A review of glacial sequences of the Kunlun Pass, northern Tibetan Plateau. Quaternary International, 2006, 154-155: 63-72.
[10]	Cui Zhijiu, Yang Chienfu, Liu Gengnian, et al. The Quaternary glaciation of Shesan Mountain in Taiwan and glacial classification in monsoon areas. Quaternary International, 2002, 97/98: 147-153.
[11]	Zhou Shangzhe, Li Jijun.New dating results of Quaternary glaciations in China. Journal of Glaciology and Geocryology, 2003, 25(6): 660-666.
	[周尚哲, 李吉均. 第四纪冰川测年研究新进展. 冰川冻土, 2003, 25(6): 660-666.]
[12]	Wang Jian, Raisbeck G, Xu Xiaobin, et al.In situ cosmogenic 10Be dating of the Quaternary glaciations in the southern Shaluli Mountain on the southeastern Tibetan Plateau. Science in China Series D: Earth Sciences, 2006, 49(12): 1291-1298.
[13]	Zhang Zhigang, Wang Jian, Xu Xiaobin, et al.Cosmogenic isotope 10Be dating for Kuzhaori moraine in Daocheng ice cap. Marine Geology & Quaternary Geology, 2012, 32(1): 85-91.
	[张志刚, 王建, 徐孝彬, 等. 稻城冰帽库照日冰碛垄的宇生核素10Be年代测定. 海洋地质与第四纪地质, 2012, 32(1): 85-91.]
[14]	Zhang Wei, Liu Beibei, Cui Zhijiu, et al.Division of glaciation and correlation between the Quaternary glaciation in China and the marine isotope stage. Geographical Research, 2013, 32(4): 628-637.
	[张威, 刘蓓蓓, 崔之久, 等. 中国第四纪冰川作用与深海氧同位素阶段的对比和厘定. 地理研究, 2013, 32(4): 628-637.]
[15]	Fu Ping, Stroeven A P, Harbor J M, et al.Paleoglaciation of Shaluli Shan, southeastern Tibetan Plateau. Quaternary Science Reviews, 2013, 64: 121-135.
[16]	Zhang Wei, He Mingyue, Li Yonghua, et al.Quaternary glacier development and the relationship between the climate change and tectonic uplift in the Helan Mountain. Chinese Science Bulletin, 2012, 57(34): 4491-4504.
[17]	Owen L A, Finkel R C, Caffee M W.A note on the extent of glaciation throughout the Himalaya during the global Last Glacial Maximum. Quaternary Science Reviews, 2002, 21(1-3): 147-157.
[18]	Zhang Wei, Liu Beibei.Features of the glaciation during the Last Glaciation in northwestern Yunnan Province. Journal of Glaciology and Geocryology, 2014, 36(1): 30-37.
	[张威, 刘蓓蓓. 滇西北山地末次冰期冰川发育及其基本特征. 冰川冻土, 2014, 36(1): 30-37.]
[19]	Zhao Jingdong, Wang Jie, Yin Xiufeng.Quaternary glaciations research in China: Current status and controversy. Journal of Glaciology and Geocryology, 2013, 35(1): 119-125.
	[赵井东, 王杰, 殷秀峰. 中国第四纪冰川研究的现状与争议. 冰川冻土, 2013, 35(1): 119-125.]
[20]	Zhao Jingdong, Shi Yafeng, Wang Jie.Comparison between Quaternary glaciations in China and the Marine Oxygen Isotope Stage (MIS): An improved schema. Acta Geographica Sinica, 2011, 66(7): 867-884.
	[赵井东, 施雅风, 王杰. 中国第四纪冰川演化序列与MIS对比研究的新进展. 地理学报, 2011, 66(7): 867-884.]
[21]	Yi Chaolu, Cui Zhijiu, Xiong Heigang.Numerical periods of Quaternary glaciations in China. Quaternary Sciences, 2005, 25(5): 609-619.
	[易朝路, 崔之久, 熊黑钢. 中国第四纪冰期数值年表初步划分. 第四纪研究, 2005, 25(5): 609-619.]
[22]	Zhang Wei, Liu Beibei, Li Yonghua, et al.Late Pleistocene glaciations on Qianhu Mountain, northwest Yunnan Province, China. Geografiska Annaler: Series A, Physical Geography, 2014, 96(3): 417-429.
[23]	Zhang Wei, Liu Beibei, Li Yonghua, et al.Quaternary glacier development and environmental evolution in Qianhu Mountain, northwestern Yunnan Province. Acta Geographica Sinica, 2012, 67(5): 657-670.
	[张威, 刘蓓蓓, 李永化, 等. 云南千湖山第四纪冰川发育特点与环境变化. 地理学报, 2012, 67(5): 657-670.]
[24]	Zhou Bocheng.An analysis on the relationship between streamflow and precipitation in Altay Mountains region. Journal of Glaciology and Geocryology, 1983, 5(4): 49-56.
	[周伯诚. 我国阿尔泰山的降水及河流径流分析. 冰川冻土, 1983, 5(4): 49-56.]
[25]	Bai Jinzhong, Li Zhongqin, Zhang Mingjun, et al.Glacier changes in Youyi area in the Altay Mountains of Xinjiang during 1959-2008. Arid land Geography, 2012, 35(1): 116-124.
	[白金中, 李忠勤, 张明军, 等. 1959-2008年新疆阿尔泰山友谊峰地区冰川变化特征. 干旱区地理, 2012, 35(1): 116-124.]
[26]	Wang Lilun, Liu Chaohai, Kang Xingcheng, et al.Fundamental Features of modern glaciers in the Altay Shan of China. Journal of Glaciology and Geocryology, 1983, 5(4): 27-38.
	[王立伦, 刘潮海, 康兴成, 等. 我国阿尔泰山现代冰川的基本特征: 以哈拉斯冰川为例. 冰川冻土, 1983, 5(4): 27-38.]
[27]	Wang Lilun, Liu Chaohai, Wang Ping.Modern glaciers in Altay Mountains of China. Acta Geographica Sinica, 1985, 40(2): 142-154.
	[王立伦, 刘潮海, 王平. 中国阿尔泰山的现代冰川. 地理学报, 1985, 40(2): 142-154.]
[28]	Cui Zhijiu, Yi Chaolu, Yan Jingfu.Quaternary glaciations in the Halasi River catchment and its surroundings in the Altai Mountains in Xinjiang, China. Journal of Glaciology and Geocryology, 1992, 14(4): 342-351.
	[崔之久, 易朝路, 严竞浮. 新疆阿尔泰山哈纳斯河流域及其邻域第四纪冰川作用. 冰川冻土, 1992, 14(4): 342-351.]
[29]	Liu Chaohai, Wang Lilun.Traces of ancient glaciations and their division in the Quaternary at the drainage basin of Halasi River in the Altay Shan of China. Journal of Glaciology and Geocryology, 1983, 5(4): 39-47.
	[刘潮海, 王立伦. 阿尔泰山哈拉斯河流域冰川遗迹及冰期的初步探讨. 冰川冻土, 1983, 5(4): 39-47.]
[30]	He Guoqi, Li Maosong.Significance of paleostructure and paleogeography of Ordovician-Silurian rock associations in northern Xinjiang, China. Acta Scientiarum Naturalium Universitatis Pekinensis, 2001, 37(1): 99-110.
	[何国琦, 李茂松. 中国新疆北部奥陶—志留系岩石组合的古构造、古地理意义. 北京大学学报(自然科学版), 2001, 37(1): 99-110.]
[31]	Qu Guosheng, He Guoqi.The Orogeny in the Altaides. Acta Geologica Sinica, 1992, 66(3): 193-205.
	[曲国胜, 何国琦. 阿尔泰造山带的构造运动. 地质学报, 1992, 66(3): 193-205.]
[32]	Xu Xiangke, Yang Jianqiang, Dong Guocheng, et al.OSL dating of glacier extent during the Last Glacial and the Kanas Lake basin formation in Kanas River valley, Altai Mountains, China. Geomorphology, 2009, 112: 306-317.
[33]	Zhao Jingdong, Yin Xiufeng, Harbor J M, et al.Quaternary glacial chronology of the Kanas River valley, Altai Mountains, China. Quaternary International, 2013, 311: 44-53.
[34]	Jiang Heli, Zhao Jingdong, Yin Xiufeng, et al.New OSL chronology of the Last Glaciation in Kanas River valley, Altay Mountains, China. Journal of Glaciology and Geocryology, 2012, 34(2): 304-310.
	[江合理, 赵井东, 殷秀峰, 等. 阿尔泰山喀纳斯河流域末次冰期OSL年代学新证. 冰川冻土, 2012. 34(2): 304-310.]
[35]	Liu Chunru, Yin Gongming, Zhang Huiping, et al.ESR geochronology of the Minjiang River terraces at Wenchuan, eastern margin of Tibetan Plateau, China. Geochronometria, 2013, 40(4): 360-367.
[36]	Zhao Jingdong, Liu Shiyin, He Yuanqing, et al.The glacial sediments sequences in the Ateaoyinake River valley, Tianshan Mountains. Acta Geographica Sinica, 2006, 61(5): 491-500.
	[赵井东, 刘时银, 何元庆等. 天山阿特奥依纳克河流域冰川沉积序列. 地理学报, 2006, 61(5): 491-500.]
[37]	Prescott J R, Hutton J T.Cosmic ray contributions to dose rates for luminescence and ESR dating: Large depths and long-term time variations. Radiation Measurements, 1994, 23(2/3): 497-500.
[38]	Buhay W M, Schwarcz H P, Grün R.ESR dating of fault gouge: The effect of grain size. Quaternary Science Reviews, 1988, 7(3/4): 515-522.
[39]	Ye Yuguang, Diao Shaobo, He Jie, et al.ESR dating studies of palaeo-debris-flow deposits in Dongchuan, Yunnan Province, China. Quaternary Science Reviews, 1998, 17(11): 1073-1076.
[40]	Mahaney W C, Vortisch W, Julig P J.Relative differences between glacially crushed quartz transported by mountain and continental ice; some examples from North America and East Africa. American Journal of Science, 1988, 288(8): 810-826.
[41]	Yi Chaolu.Subglacial comminution in till-evidence from microfabric studies and grain-size distributions. Journal of Glaciology, 1997, 43: 473-479.
[42]	Rink W J.Electron spin resonance (ESR) dating and ESR applications in quaternary science and archaeometry. Radiation Measurements, 1997, 27(5/6): 975-1025.
[43]	Zhao Jingdong, Song Yougui, King J W, et al.Glacial geomorphology and glacial history of the Muzart River valley, Tianshan Range, China. Quaternary Science Reviews, 2010, 29(11/12): 1453-1463.
[44]	Xu Liubing, Zhou Shangzhe.Quaternary glaciations recorded by glacial and fluvial landforms in the Shaluli Mountains, Southeastern Tibetan Plateau. Geomorphology, 2009, 103: 268-275.
[45]	Yi Chaolu, Li Xiaoze, Qu Jianjun. Quaternary glaciation of Puruogangri: The largest modern ice field in Tibet. Quaternary International, 2002, 97/98: 111-121.
[46]	Wang Jie, Zhou Shangzhe, Zhao Jingdong, et al.Quaternary glacial geomorphology and glaciations of Kongur Mountain, eastern Pamir, China. Science China Earth Sciences, 2011, 54(4): 591-602.
[47]	Wang Yongxing, Urkenbek. Formation of Hanas Lake and the environmental change around the lake in Quaternary. Arid land Geography, 1989, 12(2): 22-28.
	[王永兴, 乌尔坤别克. 哈纳斯湖的形成及湖周第四纪环境演变. 干旱区地理, 1989, 12(2): 22-28.]
[48]	Zhou Shangzhe, Yi Chaolu, Shi Yafeng, et al.Study on the ice age MIS12 in Western China. Journal of Geomechanics, 2001, 7(4): 321-327.
	[周尚哲, 易朝路, 施雅风, 等. 中国西部MIS12冰期研究. 地质力学学报, 2001, 7(4): 321-327.]
[49]	Zhao Jingdong, Wang Jie, Shangguan Donghui.Sequences of the Quaternary glacial sediments and their preparatory chronology in the Tomur River Valley, Tianshan Mountains. Journal of Glaciology and Geocryology, 2009, 31(4): 628-633.
	[赵井东, 王杰, 上官冬辉. 天山托木尔河流域第四纪冰川沉积序列及其初步年代学. 冰川冻土, 2009, 31(4): 628-633.]
[50]	Zhou Shangzhe, Li Jijun, Zhang Shiqiang, et al.Glacial geomorphology and ice ages in the Bailang River Basin, Qilian Mountains. Journal of Glaciology and Geocryology, 2001, 23(2): 131-138.
	[周尚哲, 李吉均, 张世强, 等. 祁连山摆浪河谷地的冰川地貌与冰期. 冰川冻土, 2001, 23(2): 131-138.]
[51]	Wu Yongqiu, Cui Zhijiu, Liu Gengnian, et al.Glaciation sequences in the Kunlunshan Pass Area. Journal of Glaciology and Geocryology, 1999, 21(1): 71-76.
	[伍永秋, 崔之久, 刘耕年, 等. 昆仑山垭口地区的冰期系列. 冰川冻土, 1999, 21(1): 71-76.]
[52]	Li Liping, Anwar Mohammat, Guo Zhaodi, et al.Study on plant species composition and richness of the mountain coniferous forests in Xinjiang. Arid Zone Research, 2011, 28(1): 40-46.
	[李利平, 安尼瓦尔·买买提, 郭兆迪, 等. 新疆山地针叶林植物物种组成与丰富度研究. 干旱区研究, 2011, 28(1): 40-46.]
[53]	Yang Geng, Chen Bin, Zhang Chenggong, et al.Geological meaning and geological heritages of Xingjiang Kanas National Geopark. Journal of Arid Land Resources and Environment, 2012, 26(4): 194-199.
	[杨更, 陈斌, 张成功, 等. 新疆喀纳斯国家地质公园地质遗迹资源及其地学意义. 干旱区资源与环境, 2012, 26(4): 194-199.]
[54]	Hu En, Yi Chaolu, Li Yanjun.Observation and evolution investigation of the moraine geomorphology in the Rongbuk Valley of Mount Qomolangma. Journal of Glaciology and Geocryology, 2010, 32(2): 316-324.
	[胡恩, 易朝路, 李艳军. 珠穆朗玛峰绒布河谷冰碛地貌测量与演化研究. 冰川冻土, 2010, 32(2): 316-324.]
[55]	Cui Zhijiu.Kinds and features of glacial moraine and till at the head of Urumqi River, Tianshan. Journal of Glaciology and Geocryology, 1981, 3(Suppl.): 36-48.
	[崔之久. 天山乌鲁木齐河源冰碛垄与冰碛沉积的类型和特征. 冰川冻土, 1981, 3(增刊): 36-48.]
[56]	Liu Bin, Yi Chaolu, Wang Ninglian, et al.The differential GPS surveying on the little ice age moraines in the Qilian Mountains and its geomorphology significance. Journal of Glaciology and Geocryology, 2009, 31(5): 945-952.
	[刘斌, 易朝路, 王宁练, 等. 祁连山小冰期冰碛垄差分GPS测量及其地貌意义. 冰川冻土, 2009, 31(5): 945-952.]

实验室号	野外编号	采样地点	经纬度坐标/N、E	海拔/m	物质	U	Th	K	含水量/%	年剂量/GY/Ka	古剂量/GY	年龄/Ka
14042	KE13-03	湖口滞碛	48°42'41.21"87°1'21.42"	1375	细砂	3.35	18.5	1.80	0.12	4.06	116±17	28±4
14043	KE13-04	冰水平原	48°41'21.82"87°0'42.02"	1380	细砂	5.12	45.9	1.68	0.18	6.35	518±120	81±18
14044	KE13-05	七级平台	48°41'31.54"87°3'23.75"	1615	细砂	4.24	18.9	1.66	0.10	4.18	916±184	219±44
14045	KE13-06	七级平台	48°41'31.15"87°3'0.13"	1575	细砂	3.72	15.7	2.20	0.06	4.33	332±71	76±16
14046	KE13-07	花楸谷	48°35'25.76"87°4'22.33"	1310	细砂	3.43	17.0	1.82	0.15	4.00	786±146	196±36

地区	测年地点	方法	年代/ka	MIS	来源
	白湖高侧碛垄	OSL	27.2±2.0 16.1±1.5	MIS2	[34]
	湖口第一组终碛垄	OSL ESR	28.2±3.3 28±4	MIS2 MIS4	[32] 本文
	湖口第二组终碛垄	OSL	34.3±4.2 38.1±4.5	MIS 3a	[32]
阿尔泰山		OSL	43.6±6.7 52.1±7.8	MIS 3	[33]
	湖口第三组终碛垄	OSL	49.9±5.4	MIS 3b	[32]
		OSL ESR	73.1±6.6 76±16	MIS 4	[33] 本文
	驼颈湾终碛垄花楸谷侧碛垄老图瓦村侧碛垄	ESR ESR ESR	125±12 156±15 196±36 219±44	MIS 6	[32] 本文
	蒙古阿尔泰山	TL	467±51	MIS12	[47]
天山	乌鲁木齐河河源	ESR	459.7 477.1 a	MIS12	[48]
	托木尔河	ESR	418.9±40.2	MIS12	[49]
	阿特奥依纳克河	ESR	453.0±45.3 440.6±41.7	MIS12	[36]
祁连山	摆浪河	ESR	462.9	MIS12	[50]
昆仑山	昆仑山垭口	ESR	710±228	MIS16	[51]

考察地点	编号	纬度(N)	经度(E)	高度(m)	宽度(m)	相对高度(m)	总厚度(m)
冰川站	A3	48°43' 49.79"	87°3' 24.67"	2165	5280	395	772
	A2	48°43' 44.18"	87°2' 56.89"	1770	4010	199
	A1	48°43' 32.39"	87°2' 22.80"	1571	3090	178
	A0	48°43' 17.23"	87°1' 48.89"	1393
七级台地	B3	48°42' 22.54"	87°3' 40.90"	2160		360	764
	B2	48°41' 1.37"	87°3' 44.40"	1800		135
	B1	48°41' 35.78"	87°3' 22.58"	1665		269
	B0	48°41' 35.39"	87°2' 4.12"	1396
鸭泽湖	C3	48°40' 9.77"	87°2' 42.14"	1862	4240	151	465
	C2	48°40' 14.74"	87°2' 32.86"	1711	3670	127
	C1	48°40' 15.28"	87°2' 9.02"	1584	2520	187
	C0	48°40' 11.14"	87°1' 42.28"	1397
卧龙湾	D3	48°37' 24.78"	87°3' 56.77"	1743	2560	68	373
	D2	48°37' 21.79"	87°3' 32.36"	1675	1890	115
	D1	48°37' 17.58"	87°3' 17.06"	1560	1250	190
	D0	48°37' 10.28"	87°3' 6.84"	1370
驼颈湾	E3	48°33' 24.73"	87°8' 49.85"	1450	1160	50	240
	E2	48°33' 22.68"	87°8' 45.71"	1400	945	102
	E1	48°33' 13.75"	87°8' 39.01"	1298	413	88
	E0	48°32' 58.08"	87°8' 45.85"	1210
