2001-2013年华北地区植被覆盖度与干旱条件的相关分析

doi:10.11821/dlxb201505004

Abstract

Abstract:

Based on previous studies, the climate drought index can be used to assess the evolution trend of ecological environment under various arid climatic conditions. It is necessary for us to further explore the relationship between vegetation coverage (index) and climate drought conditions. Therefore, in this study, based on MODIS-NDVI products and meteorological observation data, the Palmer Drought Severity Index (PDSI) and vegetation coverage in North China were first calculated. Then the interannual variation of PDSI and vegetation coverage over 2001-2013 was analyzed by using a Theil-Sen slope estimator. Finally in an ecoregion perspective the correlation between them was discussed. The experimental results demonstrated that PDSI index and vegetation coverage value varied over different ecoregions. During the period 2001-2013, vegetation coverage increased in southern and northern mountains in North China, while it showed a decreasing trend in Beijing-Tianjin-Tangshan City Circle area and suburban agricultural zone. During the 13 years, the climate of the northeastern part of North China became more humid, while in the southern part of North China, it tended to be dry. According to the correlation analysis results, 73.37% of North China had a positive correlation between the vegetation coverage and climate drought index. A negative correlation was observed mainly in urban and periurban areas of Beijing, Tianjin, Hebei Province and Henan Province. In most parts of North China, drought conditions in summer and autumn had more influence on vegetation coverage.

Key words: North China, vegetation coverage, PDSI, ecoregion, correlation analysis

ZHAO Shuyi, GONG Zhaoning, LIU Xuying. Correlation analysis between vegetation coverage and climate drought conditions in North China during 2001-2013[J].Acta Geographica Sinica, 2015, 70(5): 717-729.

Figures/Tables 10

Fig. 1

Tab. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Fig. 8

Fig. 9

References 31

[1]	Gan Chunying, Wang Xizhi, Li Baosheng, et al.Changes of vegetation coverage during recent 18 years in Lianjiang River Watershed. Scientia Geographica Sinica, 2011, 31(8): 1019-1024.
	[甘春英, 王兮之, 李保生, 等. 连江流域近18年来植被覆盖度变化分析. 地理科学, 2011, 31(8): 1019-1024.]
[2]	Mu Shaojie, Li Jianlong, Chen Yizhao, et al.Spatial differences of variations of vegetation coverage in Inner Mongolia during 2001-2010. Acta Geographica Sinica, 2012, 67(9): 1255-1268.
	[穆少杰, 李建龙, 陈奕兆, 等. 2001-2010年内蒙古植被覆盖度时空变化特征. 地理学报, 2012, 67(9): 1255-1268.]
[3]	Pettorelli N, Vik J O, Mysterud A, et al.Using the satellite derived NDVI to assess ecological responses to environmental change. Trends in Ecology and Evolution, 2005, 20(9): 503-510.
[4]	Fu G, Shen Z X, Zhang X Z, et al.Modeling gross primary productivity of alpine meadow in the northern Tibet Plateau by using MODIS images and climate data. Acta Ecologica Sinica, 2010, 30(5): 264-269.
[5]	Verbesselt J, Hyndman R, Newnham G, et al.Detecting trend and seasonal changes in satellite image time series. Remote Sensing of Environment, 2010, 114(1): 106-115.
[6]	Hou X Y, Wu T, Yu L G et al. Characteristics of multi-temporal scale variation of vegetation coverage in the Circum Bohai Bay Region, 1999-2009. Acta Ecologica Sinica, 2012, 32(6): 297-304.
[7]	Sun Yanling, Guo Peng.Spatiotemporal variation of vegetation coverage index in North China during the Period from 1982 to 2006. Arid Zone Research, 2012, 29(2): 187-193.
	[孙艳玲, 郭鹏. 1982-2006年华北植被指数时空变化特征. 干旱区研究, 2012, 29(2): 187-193.]
[8]	Li Dengke, Fan Jianzhong, Wang Juan.Change characteristics and their causes of fractional vegetation coverage (FVC) in Shanxi Province. Chinese Journal of Applied Ecology, 2010, 21(11): 2896-2903.
	[李登科, 范建忠, 王娟. 陕西省植被覆盖度变化特征及其成因. 应用生态学报, 2010, 21(11): 2896-2903.]
[9]	Chen Xiaoguang, Li Jianping, Han Yingjuan, et al.Vegetation coverage and its relationships with temperature and precipitation in Ningxia in 1981-2004. Chinese Journal of Ecology, 2007, 26(9): 1375-1383.
	[陈晓光, 李剑萍, 韩颖娟, 等. 宁夏近20年来植被覆盖度及其与气温降水的关系. 生态学杂志, 2007, 26(9): 1375-1383.]
[10]	Omuto C T, Vargas R R, Alim M S, et al.Mixed-effects modelling of time series NDVI-rainfall relationship for detecting human-induced loss of vegetation cover in drylands. Journal of Arid Environments, 2010, (11): 1552-1563.
[11]	Gu Tingmin, Zhu Ruizhao, Lin Zhiguang, et al.Climate of North China Plain. Beijing: China Meteorological Press, 1991: 1-2.
	[顾庭敏, 朱瑞兆, 林之光, 等. 华北平原气候. 北京: 气象出版社, 1991: 1-2.]
[12]	Zhang Yichi, Wu Kai, Yu Jingjie, et al.Characteristics of precipitation and air temperature variation during 1951-2009 in North China. Journal of Natural Resources, 2011, 26(11): 1930-1941.
	[张一驰, 吴凯, 于静洁, 等. 华北地区1951-2009年气温、降水变化特征. 自然资源学报, 2011, 26(11): 1930-1941.]
[13]	Liu Yuan, Wang Ying, Yang Xiaoguang.Trends in reference crop evapotranspiration and possible climatic factors in the North China Plain. Acta Ecologica Sinica. 2010, 30(4): 923-932.
	[刘园, 王颖, 杨晓光. 华北平原参考作物蒸散量变化特征及气候影响因素. 生态学报, 2010, 30(4): 923-932.]
[14]	Zheng Jingyun, Ying Yunhe, Li Bingyuan, et al.A new scheme for climate regionalization in China. Acta Geographica Sinica, 2010, 65(1): 3-12.
	[郑景云, 尹云鹤, 李炳元, 等. 中国气候区划新方案. 地理学报, 2010, 65(1): 3-12.]
[15]	Sun Shizhou.Concerning the Vegetation Chinese Regionalization Map as a part of in the Natural Geographical Atlas of the Peoples Republic of China. Chinese Journal of Plant Ecology, 1998, 22(6): 523-537.
	[孙世洲. 关于中国国家自然地图集中的中国植被区划图. 植物生态学报, 1998, 22(6): 523-537.]
[16]	Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences.
	[中国科学院生态环境研究中心. 中国生态系统评估与生态安全数据库..]
[17]	Holben B N.Characteristics of maximum-value composite images from temporal AVHRR data. International Journal of Remote Sensing, 1986, 7(11): 1471-1434.
[18]	Piao S L, Fang J Y.Dynamic vegetation cover change over the last 18 years in China. Quaternary Sciences, 2001, 21(4): 294-302.
[19]	Meteorological Reference Room, .
	[国家气象信息中心气象资料室.]
[20]	Wei Jie, Tao Shiyan, Zhang Qingyun.Analysis of drought in northern China based on the Palmer Severity Drought Index. Acta Geographica Sinica, 2003, 58(Suppl.1): 91-99.
	[卫捷, 陶诗言, 张庆云. Palmer干旱指数在华北干旱分析中的应用. 地理学报, 2003, 58(增刊1): 91-99.
[21]	Wei Jie, Ma Zhuguo.Comparison of Palmer Drought Severity Index, percentage of precipitation anomaly and surface humid index. Acta Geographica Sinica, 2003, 58(Suppl.1): 117-124.
	[卫捷, 马柱国. Palmer干旱指数、地表湿润指数与降水距平的比较. 地理学报, 2003, 58(增刊1): 117-124.]
[22]	Han Haitao, Hu Wenchao, Chen Xuejun, et al.Application and comparison of three meteorological drought indices. Agricultural Research in the Arid Areas, 2009, 27(1): 237-241, 247.
	[韩海涛, 胡文超, 陈学君, 等. 三种气象干旱指标的应用比较研究. 干旱地区农业研究, 2009, 27(1): 237-241, 247.]
[23]	Liu Weiwei, An Shunqing, Liu Gengshan, et al.The Farther Modification of Palmer Drought Severity Model. Journal of Applied Meteorological Science, 2004, 15(2): 207-216.
	[刘巍巍, 安顺清, 刘庚山, 等. 帕默尔旱度模式的进一步修正. 应用气象学报, 2004, 15(2): 207-216.]
[24]	Palmer W C. Meteorological Drought. Research Paper No.45. Washington DC: U.S. Department of Commerce Weather Bureau, 1965.
[25]	An Shunqing, Xing Jiuxing.A modified Palmer's Drought Index. Journal of Applied Meteorological Science, 1986(1): 75-82.
	[安顺清, 邢久星. 帕默尔旱度模式的修正. 应用气象学报, 1986(1): 75-82.]
[26]	Ma Zongjin, Fang Weiqing, Gao Qinghua, et al.Major Natural Disasters and Countermeasures of Disaster Release in China (Theory). Beijing: Science Press, 1993.
	[马宗晋, 方蔚青, 高庆华, 等. 中国重大自然灾害及减灾对策(分论). 北京: 科学出版社, 1993.]
[27]	Liu Yu, Cai Lingen.Update definition and computation of reference evapotranspiration comparison with former method. Journal of Hydraulic Engineering, 1997(6): 28-34.
	[刘钰, 蔡林根. 参照腾发量的新定义及计算方法对比. 水利学报, 1997(6): 28-34.]
[28]	Wu Zhengyi, Wang Xianpu, Liu Fangxun, et al.Vegetation in China. Beijing: Science Press, 1980.
	[吴征镒, 王献溥, 刘昉勋, 等. 中国植被. 北京:科学出版社, 1980.]
[29]	Liu Lian, Zhang Yumin, Wang Shouyi, et al.Vegetation in Hebei. Beijing: Science Press, 1996.
	[刘濂, 张裕民, 王守一, 等. 河北植被. 北京:科学出版社, 1996.]
[30]	Kuang Shengshun.The horizontal zonation distribution of vegetation in Henan. Journal of Wuhan Botanical Research, 1991(2): 153-160.
	[邝生舜. 河南植被水平地带性的分布规律. 武汉植物学研究, 1991(2): 153-160.]
[31]	Yang J, Huang C, Zhang Z, et al.The temporal trend of urban green coverage in major Chinese cities between 1990 and 2010. Urban Forestry & Urban Greening, 2014, 13(1): 19-27.

干旱指数值	等级	干旱指数值	等级
≥ 4.00	极端湿润	-1.99~-1.00	轻微干旱
3.00~3.99	严重湿润	-2.99~-2.00	中等
2.00~2.99	中等湿润	-3.99~-3.00	严重干旱
1.00~1.99	轻微湿润	≤-4.00	极端干旱
-0.99~0.99	正常
