1986-2015年小浪底水库运行前后黄河下游主槽调整规律

doi:10.11821/dlxb201911016

Abstract

Abstract:

Previous studies indicate that the lower Yellow River experienced a continuous siltation period and a continuous scouring period during the past 30 years. However, the patterns of main-channel adjustments during these two periods are not clear. Based on measured discharge, sediment load, and cross-sectional data between 1986 and 2015, the changes in the morphological parameters (width, depth, and cross-sectional geomorphic coefficient) of the main channel were analyzed. The results showed that before the operation of the Xiaolangdi Reservoir (XLDR) from 1986-1999, the main channel shrunk continuously with decreasing width and depth. Because the decrease rate in width was greater than that in depth, the geomorphic coef?cient decreased in the reach above Gaocun. In contrast, for the reach below Gaocun, the decrease rate in width was smaller than that in depth, and the geomorphic coef?cient increased. After the XLDR began operating, the main channel eroded continuously, and the width and depth increased from 2000-2015. Because the increase rate in depth was obviously larger than that in width, the geomorphic coef?cient decreased in all sub-reaches. The cross-sectional geometry of the main channel exhibited different adjustment patterns during two periods. Before the XLDR operation, the main channel mainly narrowed in the transverse direction and silted in the vertical direction in the reach above Aishan (AS); in the reach below AS, the main channel primarily vertically silted. After the XLDR operation, the main channel adjusted by widening and deepening in the reach above AS; for the reach below AS, the main channel adjusted mainly by deepening. Compared to the decrease rates in main-channel width and depth during the siltation period, the increase rate in width during the scouring period was obviously smaller, while that in depth was larger. After continuous siltation and scouring, the main-channel cross-sectional geometry changed from relatively wide and shallow to relatively narrow and deep. The pattern of main-channel adjustment was closely related to the water and sediment conditions. For the braided reach, the geomorphic coef?cient was negatively correlated with discharge and positively correlated with suspended sediment concentration (SSC) during the siltation period. In contrast, the geomorphic coefficient was positively correlated with discharge and negatively correlated with SSC during the scouring period. For the transitional and wandering reach, the geomorphic coef?cient was negatively correlated with discharge and positively correlated with SSC.

Key words: the Lower Yellow River, changes in water and sediment conditions, Xiaolangdi Reservoir, main-channel geometry

WANG Yanjun, WU Baosheng, SHEN Guanqing. Adjustment in the main-channel geometry of the lower Yellow River before and after the operation of the Xiaolangdi Reservoir from 1986 to 2015[J].Acta Geographica Sinica, 2019, 74(11): 2411-2427.

Figures/Tables 16

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Fig. 8

Fig. 9

Tab. 1

Annual post-flood main-channel cross-sectional geometry parameters for different reaches of the lower Yellow River from 1986 to 2015

年份	主槽河宽(m)							主槽水深(m)							主槽河相系数(m^-0.5)
年份	小花	花夹	夹高	高孙	孙艾	艾泺	泺利	小花	花夹	夹高	高孙	孙艾	艾泺	泺利	小花	花夹	夹高	高孙	孙艾	艾泺	泺利
1986	1575	2489	1905	862	624	493	462	1.72	1.78	1.95	2.82	3.64	4.52	3.93	23.06	27.98	22.34	10.39	6.86	4.91	5.47
1987	1621	2393	1907	871	629	490	463	1.62	1.70	1.84	2.79	3.44	4.38	3.80	24.91	28.83	23.71	10.56	7.30	5.06	5.66
1988	1184	1684	1126	675	611	469	441	1.85	2.08	2.35	3.09	3.60	4.81	4.11	18.63	19.75	14.28	8.42	6.87	4.50	5.11
1989	1362	1940	1067	685	614	464	437	1.77	1.69	2.33	2.81	3.39	4.41	3.70	20.90	26.13	14.04	9.32	7.32	4.88	5.64
1990	1165	1604	969	712	589	463	439	1.78	1.59	2.08	2.69	3.30	4.27	3.54	19.18	25.23	14.94	9.91	7.36	5.04	5.92
1991	1310	1432	900	678	583	465	438	1.57	1.54	2.05	2.72	3.12	4.05	3.30	23.11	24.62	14.60	9.59	7.73	5.32	6.34
1992	859	1226	707	556	437	413	386	2.33	1.67	2.32	3.23	3.33	4.21	3.67	12.60	20.91	11.47	7.31	6.28	4.83	5.36
1993	978	1479	781	535	450	396	378	2.17	1.53	2.00	2.91	3.40	4.12	3.26	14.40	25.17	14.01	7.96	6.25	4.83	5.96
1994	878	1245	775	558	455	402	378	2.19	1.47	1.92	2.87	3.22	3.86	2.94	13.51	24.02	14.47	8.24	6.63	5.19	6.61
1995	840	1020	800	546	457	400	375	1.95	1.65	1.87	2.47	2.96	3.69	2.87	14.85	19.33	15.14	9.46	7.22	5.42	6.75
1996	1020	978	747	568	460	407	378	2.16	1.90	2.40	2.58	3.16	4.10	3.39	14.78	16.44	11.38	9.23	6.80	4.92	5.73
1997	850	934	559	553	457	410	378	1.95	1.67	1.82	2.10	2.76	3.44	2.97	14.95	18.29	13.01	11.18	7.75	5.88	6.55
1998	797	906	604	491	410	378	358	2.14	1.84	1.94	2.26	2.96	3.83	3.15	13.19	16.38	12.68	9.81	6.85	5.08	6.00
1999	878	778	573	498	419	374	357	1.77	1.74	1.79	2.03	2.65	3.53	2.91	16.74	16.03	13.34	11.02	7.73	5.47	6.49
2000	905	845	605	471	428	362	352	2.46	1.92	1.65	1.92	2.56	3.36	2.87	12.23	15.16	14.93	11.31	8.07	5.67	6.54
2001	981	828	636	468	422	365	347	2.67	2.06	1.76	1.82	2.64	3.36	2.82	11.74	13.96	14.32	11.86	7.79	5.69	6.59
2002	853	955	649	455	421	356	333	3.21	2.25	1.88	2.16	2.74	3.56	3.31	9.10	13.73	13.57	9.87	7.49	5.30	5.51
2003	854	841	636	467	416	358	328	3.83	2.96	2.53	2.69	3.18	4.19	3.90	7.63	9.79	9.98	8.04	6.41	4.51	4.65
2004	910	909	666	443	432	362	343	3.75	2.93	3.09	2.91	3.32	4.48	4.01	8.04	10.30	8.34	7.22	6.27	4.25	4.62
2005	951	1095	706	453	441	361	345	3.64	3.11	3.21	3.11	3.54	4.89	4.45	8.48	10.63	8.27	6.85	5.93	3.88	4.17
2006	957	1273	722	457	450	364	353	4.07	2.82	3.07	3.43	3.61	4.66	4.30	7.59	12.64	8.76	6.24	5.88	4.09	4.36
2007	1100	1137	733	472	462	366	357	4.18	3.68	3.24	3.60	3.68	4.85	4.48	7.94	9.16	8.35	6.03	5.85	3.95	4.22
2008	1201	1166	727	491	464	367	358	3.95	3.36	3.38	3.79	3.89	4.82	4.53	8.77	10.15	7.98	5.84	5.54	3.97	4.18
2009	1225	1275	764	517	472	366	360	4.00	3.40	3.43	4.02	3.94	4.91	4.62	8.75	10.52	8.07	5.66	5.52	3.90	4.11
2010	1258	1358	763	521	468	371	363	4.12	3.39	3.53	4.09	4.09	5.09	4.76	8.61	10.87	7.82	5.58	5.29	3.78	4.00
2011	1299	1443	773	523	467	374	365	4.22	3.49	3.79	4.27	4.30	5.25	4.88	8.54	10.89	7.34	5.36	5.03	3.68	3.91
2012	1224	1466	845	525	468	377	368	4.34	3.51	3.64	4.35	4.57	5.41	4.94	8.06	10.90	7.99	5.26	4.74	3.59	3.88
2013	1261	1488	870	534	462	384	372	4.36	3.53	3.56	4.46	4.62	5.57	4.93	8.14	10.93	8.29	5.18	4.66	3.52	3.92
2014	1259	1480	873	547	471	384	372	4.36	3.91	3.77	4.52	4.61	5.52	5.11	8.14	9.84	7.83	5.17	4.71	3.55	3.78
2015	1280	1522	879	569	472	387	377	4.55	4.08	3.85	4.46	4.69	5.63	4.97	7.86	9.57	7.69	5.36	4.63	3.50	3.90

Tab. 1

Tab. 2

Statistical parameters of the main-channel cross-sectional geometry before and after the operationof the Xiaolangdi Reservoir

时段	断面形态变量	小花段	花夹段	夹高段	高孙段	孙艾段	艾泺段	泺利段
1986-1999年	$y B 0.5$	0.75	0.56	0.55	0.76	0.82	0.87	0.88
	$y H$	1.03	0.98	0.92	0.72	0.73	0.78	0.74
	$y ξ$	0.73	0.57	0.60	1.06	1.13	1.12	1.19
	$y B 0.5 - 1$	-0.25^*	-0.44^*	-0.45^*	-0.24	-0.18	-0.13	-0.12
	$y H - 1$	0.03	-0.02	-0.08	-0.28^*	-0.27^*	-0.22^*	-0.26^*
2000-2015年	$y B 0.5$	1.21	1.40	1.24	1.07	1.06	1.02	1.03
	$y H$	2.57	2.34	2.15	2.20	1.77	1.59	1.71
	$y ξ$	0.47	0.60	0.58	0.49	0.60	0.64	0.60
	$y B 0.5 - 1$	0.21	0.40	0.24	0.07	0.06	0.02	0.03
	$y H - 1$	1.57^*	1.34^*	1.15^*	1.20*	0.77*	0.59^*	0.71^*

Tab. 2

Fig. 10

Fig. 11

Fig. 12

Fig. 13

Fig. 14

References 26

[1]	Cui B, Chang X, Shi W . Abrupt changes of runoff and sediment load in the lower reaches of the Yellow River, China. Water Resources, 2014,41(3):252-260.
[2]	Wang H, Yang Z, Saito Y , et al. Stepwise decreases of the Huanghe (Yellow River) sediment load (1950-2005): Impacts of climate change and human activities. Global and Planetary Change, 2007,57:331-354.
[3]	Lu Zhongchen, Chen Shaofeng, Chen Hao . The evolutionary tendency forecast of channel morphology and river state of the wandering braided rivers in the Lower Yellow River. Acta Geographica Sinica, 2000,55(6):729-736.
	[ 陆中臣, 陈劭锋, 陈浩 . 黄河下游游荡段河道平面形态与河势变化趋势预测. 地理学报, 2000,55(6):729-736.]
[4]	Wu B, Wang G, Xia J , et al. Response of bankfull discharge to discharge and sediment load in the Lower Yellow River. Geomorphology, 2008,100:366-376.
[5]	Peng Jun, Chen Shenliang, Liu Feng , et al. Erosion and siltation processes in the Lower Yellow River during different river courses into the sea. Acta Geographica Sinica, 2010,65(5):613-622.
	[ 彭俊, 陈沈良, 刘锋 , 等. 不同流路时期黄河下游河道的冲淤变化过程. 地理学报, 2010,65(5):613-622.]
[6]	Wang S, Li Y . Channel variations of the different channel pattern reaches in the Lower Yellow River from 1950 to 1999. Quaternary International, 2011,244:238-247.
[7]	Xia J, Li X, Zhang X , et al. Recent variation in reach-scale bankfull discharge in the Lower Yellow River. Earth Surface Processes and Landforms, 2014,39:723-734.
[8]	Wang H, Wu X, Bi N , et al. Impacts of the dam-orientated water-sediment regulation scheme on the lower reaches and delta of the Yellow River (Huanghe): A review. Global and Planetary Change, 2017,157:93-113.
[9]	Zhang M, Huang H, Carling P , et al. Sedimentation of overbank floods in the confined complex channel-floodplain system of the Lower Yellow River, China. Hydrological Processes, 2017,31:3472-3488.
[10]	Xia X, Dong J, Wang M , et al. Effect of water-sediment regulation of the Xiaolangdi Reservoir on the concentrations, characteristics, and fluxes of suspended sediment and organic carbon in the Yellow River. The Science of the Total Environment, 2016,571:487-497.
[11]	Kong D, Miao C, Wu J , et al. Bi-objective analysis of water-sediment regulation for channel scouring and delta maintenance: A study of the Lower Yellow River. Global and Planetary Change, 2015,133:27-34.
[12]	Wu Baosheng, Li lingyun . Characteristics of cross-section in the lower channel of the Yellow River. Yellow River, 2008,30(2):15-16, 79.
	[ 吴保生, 李凌云 . 黄河下游河道横断面的若干特点. 人民黄河, 2008,30(2):15-16, 79.]
[13]	Zheng S, Han S, Tan G , et al. Morphological adjustment of the Qingshuigou channel on the Yellow River Delta and factors controlling its avulsion. Catena, 2018,166:44-55.
[14]	Ma Y, Huang H, Nanson G , et al. Channel adjustments in response to the operation of large dams: The upper reach of the Lower Yellow River. Geomorphology, 2012, 147-148:35-48.
[15]	Tian S, Wang W, Xie B , et al. Fluvial processes of the downstream reaches of the reservoirs in the Lower Yellow River. Journal of Geographical Sciences, 2016,26(9):1321-1336.
[16]	Li J, Xia J, Zhou M , et al. Variation in reach-scale thalweg-migration intensity in a braided reach of the Lower Yellow River in 1986-2015. Earth Surface Processes and Landforms, 2017,42:1952-1962.
[17]	Xia J, Zhang X, Wang Z , et al. Modelling of hyperconcentrated flood and channel evolution in a braided reach using a dynamically coupled one-dimensional approach. Journal of Hydrology, 2018,561:622-635.
[18]	Miao C, Kong D, Wu J , et al. Functional degradation of the water-sediment regulation scheme in the Lower Yellow River: Spatial and temporal analyses. The Science of the Total Environment, 2016,551/552:16-22.
[19]	Sun Z, Wang W, Li Y , et al. Can the narrowing of the Lower Yellow River by regulation result in non-siltation and even channel scouring? Journal of Geographical Sciences, 2016,26(9):1337-1348
[20]	Zheng Shan . Study on the simulation of non-equilibrium fluvial processes[D]. Beijing: Tsinghua University, 2013.
	[ 郑珊 . 非平衡态河床演变过程模拟研究[D]. 北京: 清华大学, 2013.]
[21]	Yellow River Conservancy Commission of the Ministry of Water Resources (MWR). Yellow River Sediment Bulletin, 2015.
	[ 水利部黄河水利委员会. 黄河泥沙公报, 2015.]
[22]	Zhang Yuanfeng, Shen Guanqing . Regulation indices of hyperconcentrated floods in the Lower Yellow River. Journal of Sediment Research, 2017,42(5):25-30.
	[ 张原锋, 申冠卿 . 黄河下游高含沙洪水河床形态及调控指标. 泥沙研究, 2017,42(5):25-30.]
[23]	Wu Baosheng, Xia Junqiang, Zhang Yuanfeng . Response of bankfull discharge to variation of flow discharge and sediment load in lower reaches of Yellow River. Journal of Hydraulic Engineering, 2007,38(7):886-892. doi: 10.3321/j.issn:0559-9350.2007.07.019
	[ 吴保生, 夏军强, 张原锋 . 黄河下游平滩流量对来水来沙变化的响应. 水利学报, 2007,38(7):886-892.] doi: 10.3321/j.issn:0559-9350.2007.07.019
[24]	Yao Wenyi, Zhang Huaxing, Hou Zhijun , et al. Discussion on the reversibility of the river channel shrinking in the Lower Yellow River. Proceedings of the 2nd International Yellow River Forum on Keeping Healthy Life of the River, 2015,4:197-204.
	[ 姚文艺, 张华兴, 侯志军 , 等. 论黄河下游河道萎缩的可逆性. 第二届黄河国际论坛论文集, 2015,4:197-204.]
[25]	Xu Jiongxin, Zhang Ouyang . Complicated fill-scour behaviors of the Huanghe River and the channel forming processes. Acta Geographica Sinica, 2000,55(3):274-280.
	[ 许炯心, 张欧阳 . 黄河下游游荡段河床调整对于水沙组合的复杂响应. 地理学报, 2000,55(3):274-280.]
[26]	Zhang Ouyang, Xu Jiongxin, Zhang Hongwu . The response of the channel form adjustment at the wandering-braided reaches of the Lower Yellow River to flood events. Journal of Sediment Research, 2002(6):1-7.
	[ 张欧阳, 许炯心, 张红武 . 不同来源区洪水对黄河下游游荡河段河床横断面形态调整过程的影响. 泥沙研究, 2002(6):1-7.]
