全球航运服务业的空间分布差异研究

doi:10.11821/dlxb202304009

Abstract

Abstract:

The shipping service industry is a major driving force in the economic growth and reorganization of port cities' spatial structure, as well as a core element in raising hub port cities' competitiveness. Recently, the global distribution and network connections of the shipping service industry have attracted significant attention, but few studies have analyzed the distribution differences and influencing factors of different shipping service industries. In this study, we divided the shipping service industry into upstream shipping auxiliary industries (ship owners, ship management, ship repair and construction) and downstream shipping derivative service industries (shipping finance, shipping insurance, maritime law). And based on Lloyd's Maritime Directory in 2019, we built a database about the world's shipping service industry. The spatial connection network of the global shipping service industry was then examined at the global, regional and city levels, using the correlation network model and the negative binomial regression model, which revealed the differences in distribution between the upstream and downstream shipping services. The affecting elements on upstream and downstream shipping services are explored in the last section. The results are as follows: (1) Europe and Asia are the primary distribution region of the upstream and downstream shipping service industries, a pyramid structure is shown under the variation in countries' distribution. The spatial distribution of the upstream industry is wider in range, closer in connections and stronger in agglomeration, compared to the downstream industry. (2) The global shipping service network presents a dual-center structure. Europe centers on London and builds a trans-continental radiation network of downstream shipping derivative services connecting to neighboring capital cities. Asia forms an upstream service network that connects Hong Kong, Shanghai and other cities with Singapore as the center. (3) The upstream shipping auxiliary industry is mainly distributed in non-capital seaport cities, while the downstream shipping derivative service industry is chiefly distributed in the capitals and other administrative centers. (4) The e-commerce index and the logistics performance index are positively related to the upstream and downstream industries. Otherwise, the upstream shipping auxiliary industry is also affected by the degree of economic freedom, the number of tourist arrivals, and the liner transport index, while the downstream shipping derivative service industry is mainly influenced by international trade and political culture. This study provides a theoretical reference for China to construct an international shipping center, reaches the linkage development between upstream and downstream shipping services, and improves the overall strength of China's shipping industry.

Key words: upstream and downstream shipping service industry, spatial pattern, influencing factors, chain network

WANG Liehui, CHEN Ping, ZHANG Nanyi. Spatial pattern and influencing factors of shipping service industry[J].Acta Geographica Sinica, 2023, 78(4): 913-929.

Figures/Tables 14

Tab. 1

Tab. 2

Influencing factors of global shipping service industries

类别	具体指标	指标解释
地方经济	国内生产总值(美元)	一个国家或地区的经济中年生产出的全部最终产品和劳务的价值
	人均国内生产总值(美元)	国内生产总值与人口总数的比值
	经济自由度指数	反映政府对经济的干涉水平，分值越高，干涉程度越小
	国际贸易额(美元)	一个国家或地区商品和服务的进出口总额
服务水平	B2C电子商务指数数据	一个国家或地区与在线购物相关服务的水平
	服务贸易额(美元)	一个国家或地区服务进口和出口的总额
	国际旅游入境人数(人)	常居住地不在该国或地区，居住时间不超过12个月，且不以从事获取报酬的活动为旅行目的的游客数量
	服务业就业人员占比(%)	服务业就业人员占就业人口总数的百分比
	航空客运量(人)	在所在国或地区注册的航空承运人的国内和国际航班乘客数
物流绩效	班轮运输联通指数	一个国家或地区在全球班轮运输网络中的连通程度
	出口清关效率(d)	货物通过海关清关直接出口的平均时间
	物流绩效指数	一个国家或地区物流水平的总体表现，分数越高表现越好
	货柜码头吞吐量(TEU)	通过陆运到海运或者海运到陆路方式运输的集装箱流量
政治环境	发言权和问责制	国家公民在多大程度上能够参与选择他们的政府，以及言论自由、结社自由和媒体自由
	政府效能	对公共服务质量、公职人员队伍素质、公职队伍独立于政治压力的程度、政策制订和执行的质量，以及政府对这些政策的承诺的可信度
	监管质量	政府为允许和提升私人部门发展而形成和执行良好政策监管的能力
	法律原则	社会成员对社会规则的信心和遵守规则程度
	控制腐败	公民把公共权力用于谋取私利的程度
劳动力	人口总数(人)	一个国家或地区所有公民的总人口数
	人口增长(%)	一个国家或地区当年的人口数量与前一年的人口数量的比值
	中等教育年限(a)	一个国家或地区中学受教育的年限
	Top100高校数量(所)	一个国家或地区所拥有的Top100名校的数量

Tab. 2

Tab. 3

The assignment correspondence of the cities where the headquarters of shipping enterprises and the branches are located

企业机构总数量(个)	总部所在城市赋值	分支所在城市赋值
> 15	5	3
8~14	4	2
2~7	3	1
$≤$ 1	0	0

Tab. 3

Tab. 4

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Tab. 5

Fig. 6

Fig. 7

Fig. 8

Tab. 6

References 39

[1]	Wang Liehui, Ning Yuemin. International maritime services trends and the study of high-end maritime services development in Ningbo. Economic Geography, 2010, 30(2): 268-272.
	[王列辉, 宁越敏. 国际高端航运服务业发展趋势与宁波的策略. 经济地理, 2010, 30(2): 268-272.]
[2]	Ye Shilin, Cao Youhui. Research on port and shipping service industry from the perspective of geography. Economic Geography, 2018, 38(11): 150-157.
	[叶士琳, 曹有挥. 地理学视角下的港航服务业研究进展. 经济地理, 2018, 38(11): 150-157.]
[3]	Parag Connor. Super Territory: Global Supply Chain, Super City and the Rise of New Business Civilization. Cui Chuangang, Zhou Daxin, trans. Beijing: Citic Publishing House, 2016: 19-29.
	[帕拉格·康纳. 超级版图: 全球供应链、超级城市与新商业文明的崛起. 崔传刚, 周大昕, 译. 北京: 中信出版社, 2016: 19-29.]
[4]	Shao Wanqing. Coordination and Optimization of Port Service Supply Chain. Zhejiang: Zhejiang Gongshang University Press, 2014: 31-47.
	[邵万清. 港口服务供应链的协调与优化. 浙江: 浙江工商大学出版社, 2014: 31-47.]
[5]	Kalchschmidt M, Birolini S, Cattaneo M, et al. The geography of suppliers and retailers. Journal of Purchasing and Supply Management, 2020, 26(4): 100626. DOI: 10.1016/j.pursup.2020.100626. doi: 10.1016/j.pursup.2020.100626
[6]	Jacobs W, Koster H, Hall P. The location and global network structure of maritime advanced producer services. Urban Studies, 2011, 48(13): 2749-2769. doi: 10.1177/0042098010391294
[7]	Beaverstock J V. Subcontracting the accountant! Professional labour markets, migration, and organisational networks in the global accountancy industry. Environment and Planning A, 1996, 28(2): 303-326. doi: 10.1068/a280303
[8]	Taylor P J, Derudder B, Faulconbridge J, et al. Advanced producer service firms as strategic networks, global cities as strategic places. Economic Geography, 2014, 90(3): 267-291. doi: 10.1111/ecge.2014.90.issue-3
[9]	Wang Liehui, Lin Yushan, Ducruet C. Changes of ports' connection across the Taiwan Straits in the global maritime network (1895-2016). Acta Geographica Sinica, 2018, 73(12): 2282-2296. doi: 10.11821/dlxb201812002
	[王列辉, 林羽珊, Cesar Ducruet. 1895—2016年全球海运网络中的海峡两岸港口运输联系变化. 地理学报, 2018, 73(12): 2282-2296.] doi: 10.11821/dlxb201812002
[10]	Chang Y T, Talley W K. Port competitiveness, efficiency, and supply chains: A literature review. Transportation Journal, 2019, 58(1): 1-20. DOI: 10.5325/transportationj.58.1.0001. doi: 10.5325/transportationj.58.1.0001
[11]	Ruan X, Feng X H, Pang K. Development of port service network in OBOR via capacity sharing: An idea from Zhejiang province in China. Maritime Policy & Management, 2018, 45(1): 105-124.
[12]	Hall P V, Jacobs W. Shifting proximities: The maritime ports sector in an era of global supply chains. Regional Studies, 2010, 44(9): 1103-1115. doi: 10.1080/00343400903365110
[13]	Slack B. The port service industry in an environment of change. Geoforum, 1989, 20(4): 447-457. doi: 10.1016/0016-7185(89)90028-6
[14]	Chen Zaiqi, Yan Xiaopei, Cao Xiaoshu. The spatial characters and associated mechanism of port service industries in Guangzhou. Scientia Geographica Sinica, 2010, 30(1): 30-38. doi: 10.13249/j.cnki.sgs.2010.01.30
	[陈再齐, 闫小培, 曹小曙. 广州市港口服务业空间特征及其形成机制研究. 地理科学, 2010, 30(1): 30-38.]
[15]	Qiu Zhiping, Liu Zhen. Research on the structure features evolution and driving factors of global liner shipping network: Based on the social network analysis of UN LSBCI data. Economic Geography, 2021, 41(1): 39-48, 146. doi: 10.2307/141855
	[邱志萍, 刘镇. 全球班轮航运网络结构特征演变及驱动因素: 基于联合国LSBCI数据的社会网络分析. 经济地理, 2021, 41(1): 39-48, 146.]
[16]	Gao Zhijun, Liu Wei. Connotation and formation mechanism of shipping service industry chain. Navigation of China, 2013, 36(3): 120-125.
	[高志军, 刘伟. 航运服务产业链的内涵与生成机理. 中国航海, 2013, 36(3): 120-125.]
[17]	Associates F. The Future of London's Maritime Services Cluster: A Call for Action. London: Corporation of London, 2004.
[18]	Chen Jihong, Zhen Hong, Zong Beihua. Countermeasures for the development of modern shipping service industry in Shanghai. Shipping Management, 2008, 30(12): 26-27, 34.
	[陈继红, 真虹, 宗蓓华. 上海市现代航运服务业发展对策. 水运管理, 2008, 30(12): 26-27, 34.]
[19]	Wang Liehui, Zhang Nanyi, Lin Yushan. Spatial evolution and factors of global advanced maritime service industry. Geographical Research, 2021, 40(3): 708-724. doi: 10.11821/dlyj020191031
	[王列辉, 张楠翌, 林羽珊. 全球高端航运服务业的时空演化及影响因素分析. 地理研究, 2021, 40(3): 708-724.] doi: 10.11821/dlyj020191031
[20]	Beaverstock J. Global city regions: Their emerging forms. Urban Studies, 2002, 39(4): 822-823.
[21]	Taylor P J. Specification of the world city network. Geographical Analysis, 2001, 33(2): 181-194. doi: 10.1111/gean.2001.33.issue-2
[22]	Derudder B, Taylor P. The cliquishness of world cities. Global Networks, 2005, 5(1): 71-91. doi: 10.1111/glob.2005.5.issue-1
[23]	Wang Liehui, Zhang Nanyi, Zhu Yan. Network structure of maritime producer services of the 21st Century Maritime Silk Road. Scientia Geographica Sinica, 2020, 40(10): 1663-1670. doi: 10.13249/j.cnki.sgs.2020.10.010
	[王列辉, 张楠翌, 朱艳. “21世纪海上丝绸之路”航运服务业网络格局研究. 地理科学, 2020, 40(10): 1663-1670.] doi: 10.13249/j.cnki.sgs.2020.10.010
[24]	Tran N. Market structure and horizontal growth strategies: A case study of the container shipping industry. German Economic Review, 2022, 23(3): 423-461. doi: 10.1515/ger-2021-0075
[25]	Alahmadi D H, Abdulrahman B F, Alrajhi Mona M, et al. Comparative analysis of blockchain technology to support digital transformation in ports and shipping. Journal of Intelligent Systems, 2021, 31(1): 55-69. doi: 10.1515/jisys-2021-0131
[26]	Guo Jianke, Wu Lulu, Li Bo, et al. Rank-size structure and coupling type of coastal port city system based on multifunctional perspective. Scientia Geographica Sinica, 2020, 40(7): 1050-1061. doi: 10.13249/j.cnki.sgs.2020.07.002
	[郭建科, 吴陆陆, 李博, 等. 多功能视角的沿海港口城市体系位序规模结构及耦合类型. 地理科学, 2020, 40(7): 1050-1061.] doi: 10.13249/j.cnki.sgs.2020.07.002
[27]	Li J, Jiang Y L, Guan W, et al. Agglomeration effects or port-related benefits? (Re)Location patterns of basic maritime industries: The case of Dalian city, China. Maritime Policy & Management, 2022, 49(5): 685-701.
[28]	Chen Zaiqi, Yan Xiaopei, Cao Xiaoshu. The spatial characters and associated mechanism of port service industries in Guangzhou. Scientia Geographica Sinica, 2010, 30(1): 30-38. doi: 10.13249/j.cnki.sgs.2010.01.30
	[陈再齐, 闫小培, 曹小曙. 广州市港口服务业空间特征及其形成机制研究. 地理科学, 2010, 30(1): 30-38.]
[29]	Zhang W, Lam J S L. An empirical analysis of maritime cluster evolution from the port development perspective: Cases of London and Hong Kong. Transportation Research Part A: Policy and Practice, 2017, 105: 219-232. doi: 10.1016/j.tra.2017.05.015
[30]	Wang Luo. Singapore increases tax support for shipping industry. Pearl River Water Transport, 2012(7): 40-41.
	[王洛. 新加坡再增航运业税务支持. 珠江水运, 2012(7): 40-41.]
[31]	Jiang Shuhua, Jiao Huafu, Guan Jing. Spatial distribution and functional evolution of shipping service industry in Shanghai. Scientia Geographica Sinica, 2021, 41(10): 1783-1791. doi: 10.13249/j.cnki.sgs.2021.10.010
	[蒋淑华, 焦华富, 管晶. 上海市航运服务业空间分布及功能演变. 地理科学, 2021, 41(10): 1783-1791.] doi: 10.13249/j.cnki.sgs.2021.10.010
[32]	Wang Yafei, Mu Xiaonan. An empirical analysis of the relationship between economic freedom and economic growth. Inner Mongolia Social Sciences, 2006, 27(1): 77-81.
	[王亚飞, 穆晓楠. 经济自由度与经济增长关系的实证分析. 内蒙古社会科学(汉文版), 2006, 27(1): 77-81.]
[33]	Wang Wei, Jin Fengjun. Route network pattern and its influencing factors of container shipping enterprises. Geographical Research, 2020, 39(5): 1088-1103. doi: 10.11821/dlyj020190414
	[王伟, 金凤君. 全球集装箱航运企业的航线网络格局及影响因素. 地理研究, 2020, 39(5): 1088-1103.] doi: 10.11821/dlyj020190414
[34]	Cheng Lulu. An analysis of the competitiveness of urban logistics in Guangdong province based on principal component analysis. Logistics Sci-Tech, 2018, 41(6): 109-111.
	[程露露. 主成分分析法下对广东省城市物流竞争力的分析. 物流科技, 2018, 41(6): 109-111.]
[35]	Feng Jiapei, Liu Yang. "The Belt and Road" Initiative and the New Impetus of Hongkong Shipping Service Industry Development. Maritime China, 2015(12): 48-49.
	[冯佳培, 刘洋. “一带一路”倡议与香港航运服务业发展新动力. 中国远洋航务, 2015(12): 48-49.]
[36]	Zhang Xihuan. Hong Kong ship registration system and successful experience. Scientific Development, 2009(6): 59-66.
	[张锡桓. 香港船舶注册登记制度及成功经验. 科学发展, 2009(6): 59-66.]
[37]	Liu Changjun. The study on the countermeasures of inland waterway ships control in Tianjin sea area[D]. Dalian: Dalian Maritime University, 2020.
	[刘长军. 天津海域内河船舶治理对策研究[D]. 大连: 大连海事大学, 2020.]
[38]	Xi Ying. Research on cross-border logistics cooperation in China from the perspective of logistics performance index. Journal of Commercial Economics, 2017(22): 102-104.
	[席颖. 物流绩效指数视角下中国跨境物流协作研究. 商业经济研究, 2017(22): 102-104.]
[39]	Wang Liehui, Zhang Sheng, Chen Rui. Network vulnerability of ports around the South China Sea and the impact on Chinese maritime transport. World Regional Studies, 2022, 31(4): 700-712. doi: 10.3969/j.issn.1004-9479.2022.04.20220069
	[王列辉, 张圣, 陈锐. 南海周边航运网络脆弱性及对中国集装箱运输的影响. 世界地理研究, 2022, 31(4): 700-712.] doi: 10.3969/j.issn.1004-9479.2022.04.20220069

	船东	船舶管理	船舶修造	海事金融	海事保险	海事法律	合计
企业分布城市(个)	1253	436	365	81	248	255	1706
企业联系城市(个)	57371	1176	1014	449	840	1992	62842

变量	平均值	标准差	最小值	最大值
人均GDP(美元)	15695	23352	126.9	181403
经济自由度	60.38	11.54	5.9	89.4
国际贸易额(美元)	2.81×10¹¹	7.09×10¹¹	1.89×10⁸	5.25×10¹²
电子商务指数	56.97	25.39	5.4	96.4
国际旅游入境人数(人)	1.24×10⁷	2.95×10⁷	6100	2.12×10⁸
服务业就业人员占比(%)	57.58	17.01	17.31	88.51
出口清关效率(d)	7.638	5.191	1.1	39.3
物流绩效指数	2.871	0.559	1.71	4.2
班轮运输联通指数	28.19	26.51	0.658	151.9
货柜码头吞吐量(TEU)	4.37×10⁶	1.95×10⁷	2366	2.42×10⁸
发言权和问责制	0.058	0.948	-2.193	1.687
控制腐败	-0.000716	0.967	-1.723	2.17
人口总数(人)	4.20×10⁷	1.54×10⁸	11646	1.40×10⁹
人口增长率(%)	1.251	1.12	-1.805	4.469
Top100高校数量(所)	0.581	3.347	0	40

上游航运辅助业		下游航运衍生服务业
首都	非首都海港城市	首都	非首都海港城市	非首都内陆城市
新加坡	伊斯坦布尔	伦敦	纽约	法兰克福
伦敦	巴塞罗那	新加坡	香港	米兰
东京	孟买	巴黎	比雷埃夫斯	约翰内斯堡
首尔	迪拜	阿姆斯特丹	鹿特丹
马德里	香港	奥斯陆	悉尼
曼谷	瓦伦西亚	东京	迪拜
开普敦	上海	雅典	上海
	哥德堡	布鲁塞尔	汉堡
	比雷埃夫斯	马德里	墨尔本
	台北	阿布扎比	布里斯班
	休斯敦	北京	奥克兰
	毕尔巴鄂	曼谷	多伦多
	汉堡	莫斯科	巴塞罗那
	伊兹密尔	华盛顿
	萨福克
	吉达
	釜山
	胡志明市
	德班
	比戈
	加的斯
	金奈
	艾塞克斯

	上游航运辅助业		下游航运衍生服务业
影响因素指标	系数	p > z	系数	p > z
人均GDP	-0.361	0.118	0.017	0.874
经济自由度	0.370	0.047^**	-0.358	0.509
国际贸易额	0.031	0.840	0.261	0.022^**
电子商务指数	0.673	0.002^**	0.642	0.041^**
国际旅游入境人数	0.174	0.075^*	-0.084	0.623
服务业就业人员占比	0.105	0.430	-0.303	0.192
出口清关效率	0.063	0.355	0.245	0.085*
物流绩效指数	0.511	0.006^**	0.527	0.026^**
班轮运输联通指数	0.536	0^***	-0.041	0.840
货柜码头吞吐量	-0.441	0.224	0.422	0.457
发言权和问责制	0.066	0.023^*	-0.355	0.234
控制腐败	0.046	0.840	0.347	0.013^**
人口总数	0.413	0.346	-0.097	0.300
人口增长率	-0.175	0.227	0.081	0.594
Top100高校数量	-0.044	0.605	0.255	0.075^*
