黄河头道拐—潼关区间植被恢复及其对水沙过程影响

doi:10.11821/dlxb202105012

Abstract

Abstract:

The Toudaoguai-Tongguan section is the main source area of sediments in the Yellow River and has the largest vegetation restoration rate in China. Subsequently, the rapid restoration of vegetation has had significant effects on the runoff and sediment transport processes. In this paper, the vegetation restoration characteristics, and the influencing factors and their effects on runoff and sediment processes in different landform units in the Toudaoguai-Tongguan section were analyzed based on the MOD13Q1 Normalized Difference Vegetation Index (NDVI) data using the statistical and trend analysis techniques. And then, the future vegetation development trend in this area was predicted. The results suggest that the vegetation exhibits a significant increasing trend (p < 0.05) in 82.87% of the study area, and the semi-humid loess hilly and gully zones have the largest vegetation restoration rate. Slope gradient and precipitation have different effects on the vegetation restoration in different landform units. With the increase of precipitation, the correlation between NDVI and annual precipitation in the Toudaoguai-Tongguan section is lessened. In the context of vegetation restoration, precipitation is still the major factor influencing the main river runoffs in the middle reaches of the Yellow River, whereas the sediment load is affected by both precipitation and NDVI, and the sediment concentration exhibits a relatively strong negative correlation with NDVI. With the increase of vegetation coverage, the amount of soil erosion in the watershed decreases, and the river sediment load exhibits a decreasing trend. The contribution rate of the amount of soil erosion to the sediment load varies between 39%-88%. Based on the vegetation restoration potential and vegetation restoration rate, it was predicted that the mean values of NDVI in the Toudaoguai-Tongguan section in 2020, 2030, 2040, and 2050 would be 0.68, 0.75, 0.79, and 0.80, respectively.

Key words: vegetation restoration, trend analysis, middle reaches of the Yellow River, runoff and sediment process

GAO Haidong, WU Zhao. Vegetation restoration and its effect on runoff and sediment processes in the Toudaoguai-Tongguan section of the Yellow River[J].Acta Geographica Sinica, 2021, 76(5): 1206-1217.

Figures/Tables 12

Fig. 1

Fig. 2

Fig. 3

Tab. 1

Tab. 2

Fig. 4

Fig. 5

Tab. 3

Tab. 4

Partial correlation coefficients between hydrological factors and NDVI and precipitation

流域/站点	水文因子	NDVI	年降水量	流域/站点	水文因子	NDVI	年降水量
皇甫川/ 皇甫	径流量	-0.35	0.73^**	清涧河/ 延川	径流量	-0.30	0.35
	输沙量	-0.55^*	0.62^*		输沙量	-0.31	0.07
	含沙量	-0.68^**	-0.02		含沙量	-0.48	0.12
县川河/ 旧县	径流量	-0.41	0.36	昕水河/ 大宁	径流量	-0.13	0.77^**
	输沙量	-0.33	0.24		输沙量	-0.82^**	0.50
	含沙量	-0.39	0.16		含沙量	-0.86^**	0.05
孤山川/ 高石崖	径流量	-0.58^*	0.86^**	延河/ 甘谷驿	径流量	-0.29	0.73^**
	输沙量	-0.80^**	0.66^**		输沙量	-0.46	0.27
	含沙量	-0.88^**	0.36		含沙量	-0.54^*	0.07
朱家川/ 桥头	径流量	-0.30	0.63^*	仕望川/ 大村	径流量	0.65^*	0.81^**
	输沙量	-0.43	0.53^*		输沙量	0.19	0.26
	含沙量	-0.36	0.25		含沙量	-0.06	0.15
窟野河/ 温家川	径流量	-0.15	0.72^**	洛河/ 刘家河	径流量	-0.60^*	0.90^**
	输沙量	-0.90^**	0.80^**		输沙量	-0.52^*	0.85^**
	含沙量	-0.88^**	0.61^*		含沙量	-0.40	0.75^**
秃尾河/ 高家川	径流量	-0.56^*	0.34	葫芦河/ 张村驿	径流量	0.70^*	0.56^*
	输沙量	-0.53^*	0.17		输沙量	0.64^*	0.84^**
	含沙量	-0.51^*	0.15		含沙量	-0.39	0.48
汾河/ 静乐	径流量	0.86^**	0.12	马莲河/ 雨落坪	径流量	-0.42	0.75^**
	输沙量	-0.73^**	0.60^*		输沙量	-0.59^*	0.67^**
	含沙量	-0.77^**	0.51		含沙量	-0.43	0.27
佳芦河/ 申家湾	径流量	-0.06	0.74^**	泾河/ 杨家坪	径流量	-0.09	0.59^*
	输沙量	-0.50^*	0.79^**		输沙量	-0.72^**	0.62^*
	含沙量	-0.72^**	0.79^**		含沙量	-0.61^*	0.18
湫水河/ 林家坪	径流量	-0.11	0.54^*	渭河/ 秦安	径流量	0.50^**	0.91^**
	输沙量	-0.20	0.27		输沙量	-0.76^**	0.73^**
	含沙量	-0.33	0.23		含沙量	-0.68^**	0.06
大理河/ 绥德	径流量	-0.44	0.68^**	渭河/ 武山	径流量	0.66^**	0.92^**
	输沙量	-0.59^*	0.61^*		输沙量	-0.25	0.45
	含沙量	-0.62^*	0.56^*		含沙量	-0.50	0.07

Tab. 4

Fig. 6

Tab. 5

Fig. 7

References 33

[1]	Fu B J, Wang S, Liu Y, et al. Hydrogeomorphic ecosystem responses to natural and anthropogenic changes in the Loess Plateau of China. Annual Review of Earth and Planetary Sciences, 2017,45(1):223-243. doi: 10.1146/annurev-earth-063016-020552
[2]	Smith T M, Shugart H H, Bonan G B, et al. Modeling the potential response of vegetation to global climate change. Advances in Ecological Research, 1992,22:93-116.
[3]	Beerling D J. Long-term responses of boreal vegetation to global change: An experimental and modelling investigation. Global Change Biology, 1999,5(1):55-74. doi: 10.1046/j.1365-2486.1998.00209.x
[4]	Gonsamo A, Chen J M. Circumpolar vegetation dynamics product for global change study. Remote Sensing of Environment, 2016,182:13-26. doi: 10.1016/j.rse.2016.04.022
[5]	Zeppel M J B, Wilks J V, Lewis J D. Impacts of extreme precipitation and seasonal changes in precipitation on plants. Biogeosciences, 2014,11(11):3083-3093. doi: 10.5194/bg-11-3083-2014
[6]	Seddon A, Macias-Fauria M, Long P, et al. Sensitivity of global terrestrial ecosystems to climate variability. Nature, 2016,531(7593):229-232. doi: 10.1038/nature16986
[7]	Chen C, Park T, Wang X H, et al. China and India lead in greening of the world through land-use management. Nature Sustainability, 2019,2:122-129. doi: 10.1038/s41893-019-0220-7 pmid: 30778399
[8]	Murray S J, Foster P N, Prentice I C . Future global water resources with respect to climate change and water withdrawals as estimated by a dynamic global vegetation model. Journal of Hydrology, 2012,448/449:14-29. doi: 10.1016/j.jhydrol.2012.02.044
[9]	Xin Z B, Yu X X. Impact of vegetation restoration on hydrological processes in the middle reaches of the Yellow River, China. Forestry Studies in China, 2009,11(4):209-218. doi: 10.1007/s11632-009-0037-y
[10]	Ouyang W, Hao F H, Skidmore A K, et al. Soil erosion and sediment yield and their relationships with vegetation cover in upper stream of the Yellow River. Science of the Total Environment, 2010,409(2):396-403. doi: 10.1016/j.scitotenv.2010.10.020
[11]	Wang S, Fu B J, Piao S L, et al. Reduced sediment transport in the Yellow River due to anthropogenic changes. Nature Geoscience, 2016,9(1):38-41. doi: 10.1038/ngeo2602
[12]	Hao Z X, Zheng J Y, Ge Q S. Precipitation cycles in the middle and lower reaches of the Yellow River (1736-2000). Journal of Geographical Sciences, 2008,18(1):17-25. doi: 10.1007/s11442-008-0017-5
[13]	Wang Jianbang, Zhao Jun, Li Chuanhua, et al. The spatial-temporal patterns of the impact of human activities on vegetation coverage in China from 2001 to 2015. Acta Geographica Sinica, 2019,74(3):504-519.
	[ 王建邦, 赵军, 李传华, 等. 2001—2015年中国植被覆盖人为影响的时空格局. 地理学报, 2019,74(3):504-519.]
[14]	Zheng Jingyun, Yin Yunhe, Li Bingyuan. A new scheme for climate regionalization in China. Acta Geographica Sinica, 2010,65(1):3-12.
	[ 郑景云, 尹云鹤, 李炳元. 中国气候区划新方案. 地理学报, 2010,65(1):3-12.]
[15]	Didan K. MOD13Q1 MODIS/Terra Vegetation Indices 16-Day L3 Global 250 m SIN Grid V006 [Dataset]. NASA EOSDIS LP DAAC. 2015. DOI: 10.5067/MODIS/MOD13Q1.006.
[16]	Liu J Y, Kuang W H, Zhang Z X, et al. Spatiotemporal characteristics, patterns, and causes of land-use changes in China since the late 1980s. Journal of Geographical Sciences, 2014,24(2):195-210. doi: 10.1007/s11442-014-1082-6
[17]	Hensel D, Frans L. Regional Kendall test for trend. Environmental Science and Technology, 2006,40(13):4066-4073. doi: 10.1021/es051650b
[18]	Sen P K. Estimates of regression coefficient based on Kendall's tau. Journal of the American Statistical Association. 1968,63(324):1379-1389. doi: 10.1080/01621459.1968.10480934
[19]	Zhang Wenbo, Xie Yun, Liu Baoyuan. Rainfall erosivity estimation using daily rainfall amounts. Scientia Geographica Sinica, 2002,22(6):705-711.
	[ 章文波, 谢云, 刘宝元. 利用日雨量计算降雨侵蚀力的方法研究. 地理科学, 2002,22(6):705-711.]
[20]	Liu Baoyuan, Liang Yin, Cao Longxi, et al. Grid data on soil erodibility in China. National Earth System Science Data Center,National Science & Technology Infrastructure of China, 2018.
	[ 刘宝元, 梁音, 曹龙熹, 等. 中国土壤可蚀性因子K栅格数据集. 国家科技基础条件平台: 国家地球系统科学数据中心, 2018.]
[21]	Zhang H M, Yang Q K, Li R, et al. Extension of a GIS procedure for calculating the RUSLE equation LS factor. Computers & Geosciences, 2013,52:177-188. doi: 10.1016/j.cageo.2012.09.027
[22]	Jiang Zhongshan, Wang Zhiqiang, Liu Zhi. Quantitative study on spatial variation of soil erosion in a small watershed in the loess hilly region. Journal of Soil and Water Conservation, 1996,1:1-9.
	[ 江忠善, 王志强, 刘志. 黄土丘陵区小流域土壤侵蚀空间变化定量研究. 土壤侵蚀与水土保持学报, 1996,1:1-9.]
[23]	Miao C Y, Ni J R, Borthwick A G L, et al. A preliminary estimate of human and natural contributions to the changes in water discharge and sediment load in the Yellow River. Global and Planetary Change, 2011,76(3/4):196-205. doi: 10.1016/j.gloplacha.2011.01.008
[24]	Wang S, Fu B J, Liang W, et al. Driving forces of changes in the water and sediment relationship in the Yellow River. Science of the Total Environment, 2017,576:453-461. doi: 10.1016/j.scitotenv.2016.10.124
[25]	Wei Y H, Jiao J Y, Zhao G J, et al. Spatial-temporal variation and periodic change in streamflow and suspended sediment discharge along the mainstream of the Yellow River during 1950-2013. Catena, 2016,140:105-115. doi: 10.1016/j.catena.2016.01.016
[26]	Xu G C, Zhang J X, Li P, et al. Vegetation restoration projects and their influence on runoff and sediment in China. Ecological Indicators, 2018,95(1):233-241. doi: 10.1016/j.ecolind.2018.07.047
[27]	Sun G, Zhou G Y, Zhang Z Q, et al. Potential water yield reduction due to forestation across China. Journal of Hydrology, 2006,328(3/4):548-558. doi: 10.1016/j.jhydrol.2005.12.013
[28]	Chen L D, Wang J P, Wei W, et al. Effects of landscape restoration on soil water storage and water use in the Loess Plateau region, China. Forest Ecology and Management, 2010,259(7):1291-1298. doi: 10.1016/j.foreco.2009.10.025
[29]	Gao G Y, Zhang J J, Liu Y, et al. Spatio-temporal patterns of the effects of precipitation variability and land use/cover changes on long-term changes in sediment yield in the Loess Plateau, China. Hydrology and Earth System Sciences, 2017,21(9):4363-4378. doi: 10.5194/hess-21-4363-2017
[30]	Zhang J J, Gao G Y, Fu B J, et al. Formulating an elasticity approach to quantify the effects of climate variability and ecological restoration on sediment discharge change in the Loess Plateau, China. Water Resources Research, 2019,55(11):9604-9622. doi: 10.1029/2019WR025840
[31]	Zhang G H, Tang K M, Ren Z P, et al. Impact of grass root mass density on soil detachment capacity by concentrated flow on steep slopes. American Society of Agricultural and Biological Engineer, 2013,56(3):927-934.
[32]	Gao H, Xu X Z, Zhang H W, et al. How effective is vegetation in reducing gravity erosion on loess gully sidewall under intense rainfalls? Land Degradation & Development, 2020: 31(17):2605-2619. doi: 10.1002/ldr.v31.17
[33]	Gao Haidong, Pang Guowei, Li Zhanbin, et al. Evaluating the potential of vegetation restoration in the Loess Plateau. Acta Geographica Sinica, 2017,72(5):863-874.
	[ 高海东, 庞国伟, 李占斌, 等. 黄土高原植被恢复潜力研究. 地理学报, 2017,72(5):863-874.]

景观单元	气候带	Theil Sen斜率值	趋势	占比(%)
黄土丘陵沟壑区	半干旱	0.0115	降低	0.06
			增加	90.72
			不显著	9.22
	半湿润	0.0124	降低	0.13
			增加	95.55
			不显著	4.32
土石山区	半干旱	0.0078	降低	0.06
			增加	85.72
			不显著	14.22
	半湿润	0.0056	降低	0.19
			增加	89.28
			不显著	10.53
黄土高塬沟壑区	半干旱	0.0085	降低	0.20
			增加	74.52
			不显著	25.28
	半湿润	0.0088	降低	2.20
			增加	73.62
			不显著	24.18
平原区		0.0021	降低	13.93
			增加	34.37
			不显著	51.70
风沙区		0.0086	降低	0.22
			增加	88.29
			不显著	11.49
头道拐—潼关区间		0.0086	降低	1.66
			增加	82.87
			不显著	15.47

景观单元	坡度(°)	占比(%)	Theil Sen斜率值
黄土丘陵沟壑区	0~15	55	0.0119
黄土丘陵沟壑区	> 15	45	0.0120
黄土高塬沟壑区	0~15	74	0.0080
黄土高塬沟壑区	>15	26	0.0108
土石山区	0~15	40	0.0070
土石山区	> 15	60	0.0055

景观单元	土地利用变化	占比(%)	Theil Sen斜率值
风沙区	草地→草地	46.10	0.0086
	沙地→沙地	26.81	0.0086
	耕地→耕地	9.51	0.0092
平原区	耕地→耕地	67.99	0.0024
	建筑用地→建筑用地	10.54	0.0011
	耕地→建筑用地	6.81	-0.0031
黄土高塬沟壑区	耕地→耕地	54.96	0.0081
黄土高塬沟壑区	草地→草地	24.36	0.0109
土石山区	林地→林地	47.68	0.0046
	草地→草地	23.57	0.0081
	耕地→耕地	12.90	0.0091
	草地→林地	9.38	0.0042
黄土丘陵沟壑区	草地→草地	40.69	0.0121
	耕地→耕地	36.22	0.0123
	林地→林地	7.83	0.0103
	耕地→草地	5.38	0.0135

Vegetation restoration and its effect on runoff and sediment processes in the Toudaoguai-Tongguan section of the Yellow River

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 12

References 33

Related Articles 13

Metrics

Comments

因素	窟野河	无定河	延河	汾河	北洛河	泾河	渭河
土壤侵蚀模数	0.39	0.71	0.51	0.71	0.88	0.47	0.69
淤地坝数量	-0.61	-0.29	-0.49	-0.29	-0.12	-0.53	-0.31
