重庆市乡村生产空间系统脆弱性时空分异与差异化调控

doi:10.11821/dlxb202008009

Abstract

Abstract:

Vulnerability, one of the major properties of rural production space system (RPSS), is an effective measure in how system will be susceptible to negative effects or damage, as well as the way to achieving sustainable development of the system. This study establishes an evaluation index system and model of the vulnerability of RPSS and quantitatively measures the RPSS vulnerability of Chongqing from 2007 to 2017 to reveal its spatio-temporal differentiation. Accordingly it identifies vulnerability types and proposes targeted regulation strategies. The results are shown as follows. (1) The vulnerability of the RPSS is a comprehensive measure of the operating state of the system consisting of exposure, sensitivity and adaptability. It embodies the balance relationship of mutual influence and interaction that lies between rural diversified subjects centered on "human" and the rural production space centered on "land". (2) On the whole, the exposure of the RPSS shows an upward trend and a spatial pattern of "partly prominent, high in the north and low in the south"; the sensitivity shows a downward trend of fluctuation and a spatial pattern of "high in the east and low in the west"; the adaptability shows a rapidly increasing trend and a spatial pattern of "high in the west and low in the east". The overall vulnerability of RPSS presents a downward trend and the spatial pattern of "high in the east and low in the west". (3) After dividing the vulnerability of the RPSS into four types, namely, including adaptability type, exposure-sensitivity type, sensitivity-adaptation type, and strong comprehensive type, and based on the principle of "ecological priority - classified regulation - highlight emphasis - local adaptation", this study proposes differentiated "vulnerability reduction" strategies for different types, so as to guide the sustainable development of RPSS.

Key words: rural production space system, vulnerability, spatio-temporal differentiation, differentiated regulation, Chongqing

WANG Cheng, HE Yanzhou. Spatio-temporal differentiation and differentiated regulation of the vulnerability of rural production space system in Chongqing[J].Acta Geographica Sinica, 2020, 75(8): 1680-1698.

Figures/Tables 8

Fig. 1

Tab. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

References 40

[1]	Long Hualou. Land consolidation and rural spatial restructuring. Acta Geographica Sinica, 2013,68(8):1019-1028.
	[ 龙花楼. 论土地整治与乡村空间重构. 地理学报, 2013,68(8):1019-1028.]
[2]	Tian Yaping, Xiang Qingcheng, Wang Peng. Regional coupled human-natural systems vulnerability and its evaluation indexes. Geographical Research, 2013,32(1):55-63.
	[ 田亚平, 向清成, 王鹏. 区域人地耦合系统脆弱性及其评价指标体系. 地理研究, 2013,32(1):55-63.]
[3]	Lu Daming, Shi Yuzhong, Li Wenlong, et al. Spatiotemporal change of vulnerability in counties of northwest China. Progress in Geography, 2017,36(4):404-415.
	[ 鲁大铭, 石育中, 李文龙, 等. 西北地区县域脆弱性时空格局演变. 地理科学进展, 2017,36(4):404-415.]
[4]	Wang Cheng, Li Haoying. Conceptual and research frameworks of rural production space system. Progress in Geography, 2017,36(8):913-923.
	[ 王成, 李颢颖. 乡村生产空间系统的概念性认知及其研究框架. 地理科学进展, 2017,36(8):913-923.]
[5]	Wang Cheng, Ma Xiaosu, Tang Ning, et al. Operational mechanism and restructuring of rural production space system from the perspective of farming household behavior. Progress in Geography, 2018,37(5):636-646.
	[ 王成, 马小苏, 唐宁, 等. 农户行为视角下的乡村生产空间系统运行机制及重构启示. 地理科学进展, 2018,37(5):636-646.]
[6]	He Yanzhou, Wang Cheng, Tang Ning, et al. Quantitative research on the state of rural production space system of Chongqing in the perspective of entropy. Journal of Southwest University (Natural Science Edition), 2018,40(10):112-119.
	[ 何焱洲, 王成, 唐宁, 等. 熵视角下的重庆市乡村生产空间系统状态量化研究. 西南大学学报(自然科学版), 2018,40(10):112-119.]
[7]	Wang Cheng, Zhou Mingming, Li Haoying, et al. Research on the order of rural production space system based on a system entropy model in the dissipative structure. Geographical Research, 2019,38(3):619-631.
	[ 王成, 周明茗, 李颢颖, 等. 基于耗散结构系统熵模型的乡村生产空间系统有序性研究. 地理研究, 2019,38(3):619-631.]
[8]	He Yanzhou, Wang Cheng. The evolution and sustainable development capacity of rural production space system based on information entropy. Journal of Natural Resources, 2019,34(4):815-828.
	[ 何焱洲, 王成. 基于信息熵的乡村生产空间系统演化及其可持续发展能力. 自然资源学报, 2019,34(4):815-828.]
[9]	He Yanzhou, Wang Cheng. Evaluation and pattern optimization of rural production space system function: A case study of Banan District, Chongqing Municipality. Economic Geography, 2019,39(3):162-171.
	[ 何焱洲, 王成. 乡村生产空间系统功能评价与格局优化: 以重庆市巴南区为例. 经济地理, 2019,39(3):162-171.]
[10]	Song Yongyong, Mi Wenbao, Zhong Juntao, et al. Spatial differentiation and its factors for coupled human-environment interaction systems vulnerability in limited developing ecological zone in Ningxia. Journal of Arid Land Resources and Environment, 2016,30(11):85-91.
	[ 宋永永, 米文宝, 仲俊涛, 等. 宁夏限制开发生态区人地耦合系统脆弱性空间分异及影响因素. 干旱区资源与环境, 2016,30(11):85-91.]
[11]	Shi Yuzhong, Li Wenlong, Lu Daming, et al. Spatio-temporal analysis of drought vulnerability on the Loess Plateau of China at town level. Resources Science, 2017,39(11):2130-2140.
	[ 石育中, 李文龙, 鲁大铭, 等. 基于乡镇尺度的黄土高原干旱脆弱性时空演变分析: 以榆中县为例. 资源科学, 2017,39(11):2130-2140.]
[12]	He Yanbing, Huang Xiaojun, Zhai Lingxin, et al. Assessment and influencing factors of social vulnerability to rapid urbanization in urban fringe: A case study of Xi'an. Acta Geographica Sinica, 2016,71(8):1315-1328.
	[ 何艳冰, 黄晓军, 翟令鑫, 等. 西安快速城市化边缘区社会脆弱性评价与影响因素. 地理学报, 2016,71(8):1315-1328.]
[13]	Chen Jia, Yang Xinjun, Yin Sha, et al. The vulnerability evolution and simulation of the social-ecological systems in the semi-arid area based on the VSD framework. Acta Geographica Sinica, 2016,71(1):1172-1188.
	[ 陈佳, 杨新军, 尹莎, 等. 基于VSD框架的半干旱地区社会—生态系统脆弱性演化与模拟. 地理学报, 2016,71(1):1172-1188.]
[14]	Zhou Su'e, Zhang Mingjun, Wang Shengjie, et al. Assessment of vulnerability in natural-social system in Hexi, Gansu. Resources Science, 2018,40(2):452-462.
	[ 周苏娥, 张明军, 王圣杰, 等. 甘肃省河西地区自然—社会系统脆弱性评价. 资源科学, 2018,40(2):452-462.]
[15]	Cheng Yu, Ren Jianlan, Xu Chenglong. The vulnerability assessment and obstacles about man-land system of resources-recession city: A case study of Zaozhuang City in Shandong Province. Economic Geography, 2015,35(3):87-93.
	[ 程钰, 任建兰, 徐成龙. 资源衰退型城市人地系统脆弱性评估: 以山东枣庄市为例. 经济地理, 2015,35(3):87-93.]
[16]	Li Bo, Su Fei, Yang Zhi, et al. Vulnerability-based analysis of the spatial-temporal dynamic patterns of the human-sea territorial system of the Bohai-Rim region, China. Acta Ecologica Sinica, 2018,38(4):1436-1445.
	[ 李博, 苏飞, 杨智, 等. 基于脆弱性视角的环渤海地区人海关系地域系统时空特征及演化分析. 生态学报, 2018,38(4):1436-1445.]
[17]	Fang Chuanglin, Wang Yan. A comprehensive assessment of urban vulnerability and its spatial differentiation in China. Acta Geographica Sinica, 2015,70(2):234-247.
	[ 方创琳, 王岩. 中国城市脆弱性的综合测度与空间分异特征. 地理学报, 2015,70(2):234-247.]
[18]	Bohle H G. Vulnerability and criticality: Perspectives from social geography. IHDP Update, 2001,2:3-5.
[19]	Metzger M J, Rounsevell M D A, Acosta L, et al. The vulnerability of ecosystem services to land use change. Agriculture Ecosystems & Environment, 2006,114(1):69-85.
[20]	Polsky C, Neff R, Yamal B. Building comparable global change vulnerability assessments: The vulnerability scoping diagram. Global Environmental Change, 2007,17(3):472-485.
[21]	White G F. Natural Hazards. Oxford: Oxford University Press, 1974.
[22]	Burton I, Kates R, White G. The Environment as Hazard. New York: The Guilford Press, 1993: 66-78.
[23]	Timmerman P. Vulnerability, resilience and the collapse of society. Environmental Monograph, 1981,21(3):164-173.
[24]	Kasperson J X, Kasperson R E. International Workshop on Vulnerability and Global Environmental Change. Stockholm: Stockholm Environment Institute, 2001.
[25]	Kates R W, Clark W C, Corell R, et al. Environment and development: Sustainability science. Science, 2001,292(5517):641-642. doi: 10.1126/science.1059386 pmid: 11330321
[26]	Zhang Wanping. A study on vulnerability of social system of cities: A case study of Gansu Province[D]. Lanzhou: Northwest Normal University, 2014.
	[ 张万萍. 城市社会系统脆弱性研究[D]. 兰州: 西北师范大学, 2014.]
[27]	Adger W N. Vulnerability. Global Environmental Change, 2006,16(3):268-281.
[28]	Turner II B L, Kasperson R E, Matson P A, et al. A framework for vulnerability analysis in sustainability science. Proceedings of the National Academy of Sciences of the United States of America, 2003,100(14):8074-8079.
[29]	UNISDR. Living with risk: A global review of disaster reduction initiatives. United Nations, 2004.
[30]	IPCC. Climate change: Impacts, Adaptation and Vulnerability. Cambridge: Cambridge University Press, 2001.
[31]	Li He, Zhang Pingyu, Cheng Yeqing. Concepts and assessment methods of vulnerability. Progress in Geography, 2009,27(2):18-25.
	[ 李鹤, 张平宇, 程叶青. 脆弱性的概念及其评价方法. 地理科学进展, 2009,27(2):18-25.]
[32]	Liu Xiaoqian, Wang Yanglin, Peng Jian. Progress in vulnerability analysis of coupled human-environment system. Advances in Earth Science, 2009,24(8):61-68.
	[ 刘小茜, 王仰麟, 彭建. 人地耦合系统脆弱性研究进展. 地球科学进展, 2009,24(8):61-68.]
[33]	Chen Ping, Chen Xiaoling. Summary on research of coupled human-environment system vulnerability under global environmental change. Progress in Geography, 2010,29(4):454-462.
	[ 陈萍, 陈晓玲. 全球化变化下人—环境耦合系统的脆弱性研究综述. 地理科学进展, 2010,29(4):454-462.]
[34]	Huang Xiaojun, Huang Xin, Cui Cailan, et al. The concept, analytical framework and assessment method of social vulnerability. Progress in Geography, 2014,33(11):1512-1525.
	[ 黄晓军, 黄馨, 崔彩兰, 等. 社会脆弱性概念、分析框架与评价方法. 地理科学进展, 2014,33(11):1512-1525.]
[35]	Costanza R, Groot R, Sutton P, et al. Changes in the global value of ecosystem services. Global Environmental Change, 2014,26:152-158.
[36]	Xie Gaodi, Zhang Caixia, Zhang Leiming, et al. Improvement of the evaluation method for ecosystem service value based on per unit area. Journal of Natural Resources, 2015,30(8):1243-1254.
	[ 谢高地, 张彩霞, 张雷明, 等. 基于单位面积价值当量因子的生态系统服务价值化方法改进. 自然资源学报, 2015,30(8):1243-1254.]
[37]	Wang Fuxi, Mao Aihua, Li Helong, et al. Quality measurement and regional difference of urbanization in Shandong province based on the entropy method. Scientia Geographica Sinica, 2013,33(11):1323-1329.
	[ 王富喜, 毛爱华, 李赫龙, 等. 基于熵值法的山东省城镇化质量测度及空间差异分析. 地理科学, 2013,33(11):1323-1329.]
[38]	Zhu Lijuan. County functional division in important eco-function areas: A case study in Guanze, Fujian Province[D]. Fuzhou: Fujian Normal University, 2016.
	[ 朱丽娟. 重点生态功能区县域功能区划分方法探讨: 以福建省光泽县为例[D]. 福州: 福建师范大学, 2016.]
[39]	Li Pingxing, Chen Wen, Sun Wei. Spatial differentiation and influencing factors of rural territorial multifunctions in developed regions: A case study of Jiangsu Province. Acta Geographica Sinica, 2014,69(6):797-807.
	[ 李平星, 陈雯, 孙伟. 经济发达地区乡村地域多功能空间分异及影响因素: 以江苏省为例. 地理学报, 2014,69(6):797-807.]
[40]	Wang Yiqiang, Zhao Yuan. Dominant factors analysis of the formation mechanism of provincial coal resource flow in China. Resources Science, 2015,37(4):723-732.
	[ 王宜强, 赵媛. 中国省域煤炭资源空间流动形成机制的主导要素解析. 资源科学, 2015,37(4):723-732.]

要素层	指标层	内涵	单位	性质	权重
要素层	指标层	内涵	单位	性质	2007年	2012年	2017年	平均值
暴露度(E)	农药使用强度	农药使用量/耕地面积	t/hm²	+	0.078	0.107	0.131	0.105
	化肥施用强度	化肥施用量/耕地面积	t/hm²	+	0.130	0.164	0.078	0.124
	复种指数	农作物播种面积/耕地面积	-	+	0.045	0.030	0.032	0.036
	地质灾害发生强度	地质灾害点体积/研究单元面积	m³/hm2	+	0.291	0.282	0.309	0.294
	水土流失率	水土流失面积/研究单元面积	%	+	0.079	0.079	0.091	0.083
	城镇用地占比	城镇用地面积/研究单元面积	%	+	0.377	0.338	0.359	0.358
敏感性(S)	平均耕地质量等别	反映耕地的耕作质量情况^①	等	+	0.103	0.097	0.099	0.100
	≥ 25°耕地占比	≥ 25°耕地面积/耕地面积	%	+	0.346	0.327	0.330	0.334
	地形起伏度	最大高程值-最小高程值	m	+	0.231	0.217	0.220	0.223
	人均水资源量	水资源总量/乡村总人口	亿m³/万人	-	0.040	0.040	0.050	0.043
	森林覆盖率	林地面积/研究单元面积	%	-	0.176	0.118	0.122	0.139
	地均生态服务价值	区域生态服务价值总和^②/研究单元面积	元/hm²	-	0.104	0.201	0.179	0.161
适应能力(A)	人均农林牧渔业总产值	农林牧渔业总产值/乡村总人口	元/人	+	0.040	0.099	0.049	0.063
	单位面积粮食产量	粮食总产量/耕地面积	t/hm²	+	0.035	0.032	0.045	0.038
	单位面积蔬菜产量	蔬菜总产量/耕地面积	t/hm²	+	0.274	0.213	0.192	0.226
	农林水事务财政支持强度	农林水事务支出/耕地面积	万元/hm²	+	0.278	0.318	0.272	0.289
	农业机械化水平	农业机械总动力/耕地面积	kW/hm²	+	0.199	0.142	0.182	0.174
	灌排设施覆盖率	农田水利用地面积/耕地面积	%	+	0.174	0.196	0.260	0.210
