伏牛山地区森林生态系统服务权衡/协同效应多尺度分析

doi:10.11821/dlxb202005007

Abstract

Abstract:

Forest ecosystem service trade-offs and synergies are important research topics for several disciplines. The multi-scale analysis of service trade-offs and synergies assists in the implementation of more effective forest resource management. Based on multi-source data including forest distribution, topography, NDVI, meteorology and soil conditions, key forest ecosystem services, including total forest volume, carbon storage, water yield, soil retention and habitat quality were mapped and evaluated for the Funiu Mountain Region through integrated deployment of the CASA model, the InVEST3.2 model and the ArcGIS10.2 software. The characteristics of trade-offs and synergies among different ecosystem services were then mapped and considered across multiple spatial scales (i.e., by region, north and south slopes, vertical belt) using the spatial overlay analysis method. The main results are as follows: (1) Mean forest volume is 49.26 m ³/hm ², carbon density is 156.94 t/hm ², water supply depth is 494.46 mm, the unit amount of soil retention is 955.4 t/hm ², and the habitat quality index is 0.79. (2) The area of forests with good synergy is 28.79%, and the area of forests with poor synergy is 10.15%, while about 61.06% of forests show severe trade-offs and weak trade-offs. The overall benefits of forest ecosystem services in the study area are still low. In the future, bad synergy and severe trade-off areas should be the focus of forest resource management and efficiency regulation. (3) Synergy between ecosystem services is better for forest on south slope than that on north slope. Deciduous broad-leaved forest belt at moderate elevations on south slope in the mountains (SIII) has the highest synergies, while that at low elevations on north slope (NI) exhibits the lowest synergy levels.

Key words: forest ecosystem services, trade-off/synergy, multi-scale analysis, CASA, InVEST, Funiu Mountain Region

ZHANG Jingjing, ZHU Wenbo, ZHU Lianqi, LI Yanhong. Multi-scale analysis of trade-off/synergy effects of forest ecosystem services in the Funiu Mountain Region[J].Acta Geographica Sinica, 2020, 75(5): 975-988.

Figures/Tables 11

Fig. 1

Fig. 2

Tab. 1

Tab. 2

Tab. 3

Tab. 4

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

References 50

[1]	Hou Wenjuan, Gao Jiangbo, Dai Erfu , et al. The runoff generation simulation and its spatial variation analysis in Sanchahe basin as the south source of Wujiang. Acta Geographica Sinica, 2018,73(7):1268-1282. doi: 10.11821/dlxb201807007
	[ 侯文娟, 高江波, 戴尔阜 , 等. 基于SWAT模型模拟乌江三岔河生态系统产流服务及其空间变异. 地理学报, 2018,73(7):1268-1282.] doi: 10.11821/dlxb201807007
[2]	Li Peng, Jiang Luguang, Feng Zhiming , et al. Research progress on trade-offs and synergies of ecosystem services: An overview. Acta Ecologica Sinica, 2012,32(16):5219-5229. doi: 10.5846/stxb
	[ 李鹏, 姜鲁光, 封志明 , 等. 生态系统服务竞争与协同研究进展. 生态学报, 2012,32(16):5219-5229.] doi: 10.5846/stxb
[3]	Asadolahi Z, Salmanmahiny A, Sakieh Y , et al. Dynamic trade-off analysis of multiple ecosystem services under land use change scenarios: Towards putting ecosystem services into planning in Iran. Ecological Complexity, 2018,36:250-260. doi: 10.1016/j.ecocom.2018.09.003
[4]	Qian Caiyun, Gong Jie, Zhang Jinxi , et al. Change and tradeoffs-synergies analysis on watershed ecosystem services: A case study of Bailongjiang Watershed, Gansu. Acta Geographica Sinica, 2018,73(5):868-879. doi: 10.11821/dlxb201805007
	[ 钱彩云, 巩杰, 张金茜 , 等. 甘肃白龙江流域生态系统服务变化及权衡与协同关系. 地理学报, 2018,73(5):868-879.] doi: 10.11821/dlxb201805007
[5]	MEA (Millennium Ecosystem Assessment). Ecosystems and Human Well-Being. Washington: DC: Island Press, 2005.
[6]	Dai Erfu, Wang Xiaoli, Zhu Jianjia , et al. Progress and perspective on ecosystem services trade-offs. Advances in Earth Science, 2015,30(11):1250-1259. doi: 10.11867/j.issn.1001-8166.2015.11.1250
	[ 戴尔阜, 王晓莉, 朱建佳 , 等. 生态系统服务权衡/协同研究进展与趋势展望. 地球科学进展, 2015,30(11):1250-1259.] doi: 10.11867/j.issn.1001-8166.2015.11.1250
[7]	Turner K G, Odgaard M V, Bøcher P K , et al. Bundling ecosystem services in Denmark: Trade-offs and synergies in a cultural landscape. Landscape & Urban Planning, 2014,125(10):89-104.
[8]	Xu X, Yang G, Tan Y , et al. Ecosystem services trade-offs and determinants in China's Yangtze River Economic Belt from 2000 to 2015. Science of The Total Environment, 2018,634:1601-1614. doi: 10.1016/j.scitotenv.2018.04.046
[9]	Liu Y, Bi J, Lv J , et al. Spatial multi-scale relationships of ecosystem services: A case study using a geostatistical methodology. Scientific Reports, 2017,7(1):1-12. doi: 10.1038/s41598-016-0028-x
[10]	Wang Pengtao, Zhang Liwei, Li Yingjie , et al. Spatio-temporal characteristics of the trade-off and synergy relationships among multiple ecosystem services in the upper reaches of Hanjiang River Basin. Acta Geographica Sinica, 2017,72(11):2064-2078. doi: 10.11821/dlxb201711011
	[ 王鹏涛, 张立伟, 李英杰 , 等. 汉江上游生态系统服务权衡与协同关系时空特征. 地理学报, 2017,72(11):2064-2078.] doi: 10.11821/dlxb201711011
[11]	Jopke C, Kreyling J, Maes J , et al. Interactions among ecosystem services across Europe: Bagplots and cumulative correlation coefficients reveal synergies, trade-offs, and regional patterns. Ecological Indicators, 2015,49:46-52. doi: 10.1016/j.ecolind.2014.09.037
[12]	Xue H, Li S, Chang J . Combining ecosystem service relationships and DPSIR framework to manage multiple ecosystem services. Environmental Monitoring and Assessment, 2015,187(3):1-15. doi: 10.1007/s10661-014-4167-x
[13]	Su C, Fu B . Evolution of ecosystem services in the Chinese Loess Plateau under climatic and land use changes. Global and Planetary Change, 2013,101:119-128. doi: 10.1016/j.gloplacha.2012.12.014
[14]	Sun Zexiang, Liu Zhifeng, He Chunyang , et al. Multi-scale analysis of ecosystem service trade-offs in urbanizing drylands of China: A case study in the Hohhot-Baotou-Ordos-Yulin region. Acta Ecologica Sinica, 2016,36(15):4881-4891.
	[ 孙泽祥, 刘志锋, 何春阳 , 等. 中国快速城市化干燥地区的生态系统服务权衡关系多尺度分析: 以呼包鄂榆地区为例. 生态学报, 2016,36(15):4881-4891.]
[15]	Peng Jian, Hu Xiaoxu, Zhao Mingyue , et al. Research progress on ecosystem service trade-offs: From cognition to decision-making. Acta Geographica Sinica, 2017,72(6):960-973. doi: 10.11821/dlxb201706002
	[ 彭建, 胡晓旭, 赵明月 , 等. 生态系统服务权衡研究进展: 从认知到决策. 地理学报, 2017,72(6):960-973.] doi: 10.11821/dlxb201706002
[16]	Strand J, Soares-Filho B, Costa M H , et al. Spatially explicit valuation of the Brazilian Amazon forest's ecosystem services. Nature Sustainability, 2018,1(11):657-664. doi: 10.1038/s41893-018-0175-0
[17]	Cademus R, Escobedo F J, Mclaughlin D , et al. Analyzing trade-offs, synergies, and drivers among timber production, carbon sequestration, and water yield in Pinus elliotii forests in Southeastern USA. Forests, 2014,5(6):1409-1431. doi: 10.3390/f5061409
[18]	Wang X, Dai E, Zhu J . Spatial patterns of forest ecosystem services and influencing factors in the Ganjiang River Basin. Journal of Resources and Ecology, 2016,7(6):439-452. doi: 10.5814/j.issn.1674-764x.2016.06.004
[19]	Dai E, Wang X, Zhu J , et al. Quantifying ecosystem service trade-offs for plantation forest management to benefit provisioning and regulating services. Ecology and evolution, 2017,7(19):7807-7821.
[20]	Zhu Jianjia, Dai Erfu, Zheng Du , et al. Characteristic of tradeoffs between timber production and carbon storage for plantation under harvesting impact: A case study of Huitong National Research Station of Forest Ecosystem. Acta Geographica Sinica, 2018,73(1):152-163. doi: 10.11821/dlxb201801013
	[ 朱建佳, 戴尔阜, 郑度 , 等. 采伐影响下人工林木材生产与固碳功能权衡特征: 以湖南会同森林生态实验站为例. 地理学报, 2018,73(1):152-163.] doi: 10.11821/dlxb201801013
[21]	Jonah B, Kalifi F G, Jens E , et al. Reductions in emissions from deforestation from Indonesia's moratorium on new oil palm, timber, and logging concessions. Proceedings of the National Academy of Sciences, 2015,112(5):1328-1333.
[22]	Thompson B S, Friess D A . Stakeholder preferences for payments for ecosystem services (PES) versus other environmental management approaches for mangrove forests. Journal of Environmental Management, 2019,233:636-648. doi: 10.1016/j.jenvman.2018.12.032
[23]	Chisholm R A . Trade-offs between ecosystem services: Water and carbon in a biodiversity hotspot. Ecological Economics, 2010,69(10):1973-1987. doi: 10.1016/j.ecolecon.2010.05.013
[24]	Gou Mengmeng . Trade-off and synergy analysis of ecosystem services of subtropical secondary forests in southern China[D]. Changsha: Central South University of Forestry and Technology, 2017.
	[ 勾蒙蒙 . 亚热带次生林生态系统服务权衡与协同分析[D]. 长沙: 中南林业科技大学, 2017.]
[25]	Kang H, Seely B, Wang G , et al. Evaluating management tradeoffs between economic fiber production and other ecosystem services in a Chinese-fir dominated forest plantation in Fujian Province. Science of the Total Environment, 2016, 557-558:80-90. doi: 10.1016/j.scitotenv.2016.03.061
[26]	Delphin S, Escobedo F J, Abd-Elrahman A , et al. Urbanization as a land use change driver of forest ecosystem services. Land Use Policy, 2016,54:188-199. doi: 10.1016/j.landusepol.2016.02.006
[27]	Vangansbeke P, Blondeel H, Landuyt D , et al. Spatially combining wood production and recreation with biodiversity conservation. Biodiversity and Conservation, 2017,26(13):3213-3239. doi: 10.1007/s10531-016-1135-5
[28]	Eak R, Rik T, Gary L . Trade-offs and synergies between carbon, forest diversity and forest products in Nepal community forests. Environmental Conservation, 2017,44(1):5-13. doi: 10.1017/S0376892916000448
[29]	He Y, Qin L, Li Z , et al. Carbon storage capacity of monoculture and mixed-species plantations in subtropical China. Forest Ecology & Management, 2013,295(5):193-198.
[30]	Wang H, Liu S, Wang J , et al. Effects of tree species mixture on soil organic carbon stocks and greenhouse gas fluxes in subtropical plantations in China. Forest Ecology & Management, 2013,300(4):4-13.
[31]	Liang J, Crowther T W, Picard N , et al. Positive biodiversity-productivity relationship predominant in global forests. cience, 2016, 354(6309): aaf8957. Doi: 10.1126/science.aaf8957.
[32]	Zhang Yamei, Guo Fang . Ecological carrying capacity of vegetation landscape at Baotianman Nature Reserve in Funiu Mountain. Journal of Northwest Forestry University, 2011,26(5):224-228.
	[ 张雅梅, 郭芳 . 河南伏牛山宝天曼自然保护区植被景观生态承载力分析. 西北林学院学报, 2011,26(5):224-228.]
[33]	Yang Hongxia . Study on community structure and biomass, carbon storage of Oak natural secondary forest in the Funiu mountains of Henan Province[D]. Zhengzhou: Henan Agricultural University, 2016.
	[ 杨红震 . 河南伏牛山区栎类天然次生林群落结构与生物量、碳储量研究[D]. 郑州: 河南农业大学, 2016.]
[34]	Yu Chao, Song Liyi, Li Mingyang , et al. Spatio-temporal dynamics of forest aboveground biomass in Xixia County, Henan Province, China. Journal of Nanjing Forestry University (Natural Sciences Edition), 2017,41(6):93-101.
	[ 余超, 宋立奕, 李明阳 , 等. 河南西峡县森林地上生物量时空动态分析. 南京林业大学学报(自然科学版), 2017,41(6):93-101.]
[35]	Guo Jianrong . Studies on technologies of ecosystem service monitor and regulation and control of Quercus aliena var. acuterserrata forests of Baotianman[D]. Zhengzhou: Henan Agricultural University, 2012.
	[ 郭建荣 . 宝天曼自然保护区锐齿栎森林生态系统服务功能监测与调控技术研究[D]. 郑州: 河南农业大学, 2012.]
[36]	Zhu W, Zhang X, Zhang J , et al. A comprehensive analysis of phenological changes in forest vegetation of the Funiu Mountains, China. Journal of Geographical Sciences, 2019,29(1):131-145. doi: 10.1007/s11442-019-1588-z
[37]	Song Chaoshu. Scientific Survey of the Funiu Mountain Nature Reserve. Beijing: China Forestry Publishing House, 1994.
	[ 宋朝枢 . 伏牛山自然保护区科学考察集. 北京: 中国林业出版社, 1994.]
[38]	Zhang Y, Qi W, Zhou C , et al. Spatial and temporal variability in the net primary production of alpine grassland on the Tibetan Plateau since 1982. Journal of Geographical Sciences, 2014,24(2):269-287. doi: 10.1007/s11442-014-1087-1
[39]	Fang Jingyun, Liu Guohua, Xu Songling . Biomass and net production of forest vegetation in China. Acta Ecologica Sinica, 1996,16(5):497-508.
	[ 方精云, 刘国华, 徐嵩龄 . 我国森林植被的生物量和净生产量. 生态学报, 1996,16(5):497-508.]
[40]	Guang Zengyun . Study on forest biomass and productivity in Henan. Journal of Henan Agricultural University, 2006,40(5):493-497.
	[ 光增云 . 河南森林生物量与生产力研究. 河南农业大学学报, 2006,40(5):493-497.]
[41]	Allen R G, Pereira L S, Raes D , et al. Crop evapotranspiration: Guidelines for computing crop water requirements-FAO Irrigation and Drainage Paper 56, FAO, Land and Water Development Division. Rome: Food and Agriculture Organization of the United Nations, 1998.
[42]	Sharp R, Tallis H T, Ricketts T , et al. InVEST User's Guide. Stanford: The Natural Capital Project, 2014.
[43]	Cui Gaoyang, Chen Yunming, Cao Yang , et al. Analysis on carbon stock distribution patterns of forest ecosystems in Shaanxi Province. Chinese Journal of Plant Ecology, 2015,39(4), 333-342.
	[ 崔高阳, 陈云明, 曹扬 , 等. 陕西省森林生态系统碳储量分布格局分析. 植物生态学报, 2015,39(4):333-342.]
[44]	Hu Wenjie, Wang Xiaorong, Cui Hongxia , et al. Comparison of ecosystem carbon density between Quercus aliena var. acuteserrata and Quercus variabilis forest. Journal of Forest and Environment, 2017,37(1):8-15.
	[ 胡文杰, 王晓荣, 崔鸿侠 , 等. 锐齿槲栎和栓皮栎林生态系统碳密度比较. 森林与环境学报, 2017,37(1):8-15.]
[45]	Zhou W, Liu G, Pan J , et al. Distribution of available soil water capacity in China. Journal of Geographical Sciences, 2005,15(1):3-12. doi: 10.1007/BF02873101
[46]	Wischmeier W H, Smith D D . Predicting rainfall-erosion losses from cropland east of the Rocky Mountains: Guide for selection of practices for soil and water conservation. Washington: US Department of Agriculture, 1965.
[47]	Williams J R, Arnold J G . A system of erosion: Sediment yield models. Soil Technology, 1997,11(1):43-55. doi: 10.1016/S0933-3630(96)00114-6
[48]	Jiang Zhongshan, Wang Zhiqiang, Liu Zhi . Quantitative study on spatial variation of soil erosion in a small watershed in the loess hilly region. Journal of Soil Erosion and Eoil Conservation, 1996,2(1):1-9.
	[ 江忠善, 王志强, 刘志 . 黄土丘陵区小流域土壤侵蚀空间变化定量研究. 水土保持学报, 1996,2(1):1-9.]
[49]	Yao Yunchang . Evaluation and dynamics analysis of habitat quality based on InVEST model in the Sanjiang Plain [D]. Changchun: Northeast Institute of Geography and Agroecology, Chinese Academy of Sciences, 2017.
	[ 姚云长 . 基于InVEST模型的三江平原生境质量评价与动态分析[D]. 长春: 中国科学院东北地理与农业生态研究所, 2017.]
[50]	Mao Qi, Peng Jian, Liu Yanxu , et al. An ecological function zoning approach coupling SOFM and SVM: A case study in Ordos. Acta Geographica Sinica, 2019,74(3):460-474. doi: 10.11821/dlxb201903005
	[ 毛祺, 彭建, 刘焱序 , 等. 耦合SOFM与SVM的生态功能分区方法: 以鄂尔多斯市为例. 地理学报, 2019,74(3):460-474.] doi: 10.11821/dlxb201903005

服务类型	计算模型或思路	所需主要参数及处理
蓄积量	利用CASA模型计算森林植被净初级生产力(NPP)^[38],参照文献[39,40],确定伏牛山地区不同森林类型NPP与蓄积量之间的转换公式,从而得到森林蓄积量空间数据。	植被指数采用MODIS NDVI,气温、降水量和太阳辐射均运用ANUSPLIN软件进行空间插值获得。太阳辐射是由日照时数计算所得^[41]。
固碳	InVEST模型碳储量模块^[42]	碳密度的获取主要参照文献[43,44],并根据不同树种的根茎比^[36],计算得到地上和地下碳密度。
水源供给	InVEST模型水源供给模块^[42]	潜在蒸散量,利用Penman-Monteith公式(日尺度)^[38],并经ANUSPLIN插值得到;土壤深度,由土壤数据通过栅格化所得;植被可利用含水量,采用非线性拟合土壤可用含水率估算模型计算所得^[45];流域和子流域图,基于DEM数据,运用Hydrology分析工具提取得到。
土壤保持	InVEST模型土壤保持模块^[42]	降雨侵蚀力因子,采用Wischmeier的月尺度公式计算得到^[46];土壤可蚀性因子,采用土壤可蚀性估算模型计算得到^[47];工程措施因子,均赋为1,表示均未采取水土保持措施;植被覆盖和管理因子,参考文献[48]中关于林地植被管理因子的计算方法计算得到。
生境支持	InVEST模型生境支持模块^[42]	生境威胁源包括水田、旱地、农村居民点、城镇建设用地、工矿用地及交通用地,由2015年1:10万土地覆被提取得到,并转为30 m的栅格数据;生境威胁源表和敏感性表参照文献[49],并结合研究区实际情况进行赋值;法律准入性矢量图,利用伏牛山国家级自然保护区植被图提取出保护区边界,并根据保护区程度分级,在属性表中分别赋予其可达度值。

服务类型	低(1)	中(2)	高(3)
蓄积量服务	0~0.224	0.224~0.329	0.329~1
固碳服务	0~0.293	0.293~0.619	0.619~1
水源供给服务	0~0.325	0.325~0.569	0.569~1
土壤保持服务	0~0.184	0.184~0.541	0.541~1
生境支持服务	0~0.111	0.111~0.362	0.362~1

服务关系	面积占比(%)	亚类	面积占比(%)	供给能力组合	面积占比(%)	样例
权衡	61.06	强权衡	24.56	1高4低	1.45	11311、11113
				1高1中3低	2.07	11321、12113
				1高2中2低	7.37	12312、12321
				1高3中1低	13.67	22312、32212
		弱权衡	36.5	2高3低	1.89	11133、11313
				2高1中2低	4.72	23113、31123
				2高2中1低	10.78	23213、23123
				3高2低	3.99	33113、13313
				3高1中1低	12.41	33213、23313
				4高1低	2.72	33313、33133
协同	38.94	高协同	28.79	5高	0.83	33333
				4高1中	4.52	33233、23333
				3高2中	7.82	33223、32332
				2高3中	7.83	22332、32322
				1高4中	6.54	22322、22232
				5中	1.24	22222
		低协同	10.15	1中4低	0.25	11211、12111
				2中3低	2.11	12112、12211
				3中2低	3.6	12212、22112
				4中1低	4.2	22212、22122
				5低	0	11111

森林类型	蓄积量		固碳		水源供给		土壤保持		生境质量
森林类型	总量(10⁶ m³)	比例(%)	总量(10⁶ t)	比例(%)	总量(10⁸ m³)	比例(%)	总量(10⁷t)	比例(%)	生境质量
栓皮栎	27.37	44.29	92.15	46.82	31.95	52.70	54.79	47.27	0.71954
阔杂	12.25	19.83	43.97	22.34	12.31	20.31	26.18	22.59	0.79984
短柄枹栎	10.12	16.38	29.63	15.05	7.45	12.28	16.18	13.96	0.88991
锐齿槲栎	6.00	9.71	16.67	8.47	3.56	5.88	7.29	6.29	0.97995
油松	2.33	3.78	5.15	2.62	1.82	3.00	3.63	3.13	0.81979
针阔混交林	2.41	3.90	5.63	2.86	1.69	2.78	4.31	3.72	0.99998
马尾松	0.78	1.26	2.39	1.21	1.45	2.40	2.15	1.86	0.70949
华山松	0.53	0.86	1.24	0.63	0.40	0.66	1.37	1.18	0.99798
合计/平均值	61.78	100	196.83	100	60.64	100	115.9	100	0.7934
