海河流域夏季降水关键区季内演变及其环流配置的定量化分析

doi:10.11821/dlxb202001004

Abstract

Abstract:

The precipitation distribution has obvious intraseasonal variation characteristics in the Haihe River Basin (HRB) during summer. In this paper, intraseasonal evolution of the key areas of precipitation in the HRB and its associated atmospheric circulation pattern have been investigated, and the relative contributions of different atmospheric circulation factors to precipitation in the key areas are quantitatively calculated, by using daily precipitation data of 148 meteorological stations over the HRB and NCEP/NCAR reanalysis data. The results present a prominent intraseasonal variation of the key areas of summer precipitation in the HRB. The key areas move clockwise around the lower reaches of the Luanhe River and Beisan River located in the northeastern HRB, which are the maximum contribution areas of station precipitation to the HRB total amount, from early summer (June) to midsummer (July and August). The key areas are distributed in northeast HRB, east and south HRB, east and central HRB along with the movement. During early summer, the activities of the Northeast Cold Vortex (NECV) play a dominant role (relative contribution is 69.6%) in precipitation in the key areas; in July, the anomalous precipitation in the key areas is mainly affected by the ridge line of the Western Pacific Subtropical High (WPSH), with a relative contribution of more than 60%; in August, the ridge line of the WPSH and the East Asian summer monsoon index (EASMI) has an equivalent contribution to precipitation in the key areas. In addition, the monthly significant correlation areas relating to these atmospheric circulation factors for precipitation, are found at the same location as the key areas of precipitation in the HRB, and their intraseasonal changing paths are both accordant with the position changes of the associated atmospheric circulation systems in summer.

Key words: Haihe River Basin, key areas of precipitation, intraseasonal change, Northeast Cold Vortex, ridge line index of the Western Pacific Subtropical High, East Asian Summer Monsoon

HE Liye, CHENG Shanjun, MA Ning, GUO Jun. Intraseasonal evolution of the key areas of precipitation in the Haihe River Basin and quantitative analysis of its associated atmospheric circulation during summer[J].Acta Geographica Sinica, 2020, 75(1): 41-52.

Figures/Tables 10

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Tab. 1

Fig. 5

Fig. 7

Fig. 6

Fig. 8

Tab. 2

References 35

[1]	Huang Ronghui, Xu Yuhong, Zhou Liantong . The interdecadal variation of summer precipitations in China and the drought trend in North China. Plateau Meteorology, 1999,18(4):465-476.
	[ 黄荣辉, 徐予红, 周连童 . 我国夏季降水的年代际变化及华北干旱化趋势. 高原气象, 1999,18(4):465-476.]
[2]	Li Chongyin . An analytical study on the precipitation in the flood period over Huabei area. Acta Meteorologica Sinica, 1992,50(1):41-49.
	[ 李崇银 . 华北地区汛期降水的一个分析研究. 气象学报, 1992,50(1):41-49.]
[3]	Gong Zhiqiang, Wang Xiaojuan, Zhi Rong , et al. Circulation system complex networks and teleconnections. Chinese Physics B, 2011,20(7):079201.
[4]	Yang Jie, Wang Qiguang, Zhi Rong , et al. Dynamic optimal multi-indexes configuration for estimating the prediction errors of dynamical climate model in North China. Acta Physica Sinica, 2011,60(2):029204.
	[ 杨杰, 王启光, 支蓉 , 等. 动态最优多因子组合的华北汛期降水模式误差估计及预报. 物理学报, 2011,60(2):029204.]
[5]	Yang Ping, Hou Wei, Feng Guolin . The characteristics of clusters of weather and extreme climate events in China during the past 50 years. Chinese Physics B, 2012,21(1):019201.
[6]	Liu Haiwen, Ding Yihui . Analysis of daily precipitation characteristics over North China during rainy seasons. Chinese Journal of Atmospheric Sciences, 2010,34(1):12-22.
	[ 刘海文, 丁一汇 . 华北汛期日降水特性的变化分析. 大气科学, 2010,34(1):12-22.]
[7]	Dai Xingang, Wang Ping, Chou Jifan . Multiscale characteristics of the rainy season rainfall and inter-decadal decaying of summer monsoon in North China. Chinese Science Bulletin, 2003,48(12):2730-2734.
[8]	Tan Guirong, Sun Zhaobo . Relationship of the subtropical high and summertime flood/droughts over North China. Journal of Tropical Meteorology, 2004,20(2):206-211.
	[ 谭桂容, 孙照渤 . 西太平洋副高与华北旱涝的关系. 热带气象学报, 2004,20(2):206-211.]
[9]	Yang Xiuqun, Xie Qian, Zhu Yimin , et al. Decadal-to-interdecadal variability of precipitation in north China and associated atmospheric and oceanic anomaly patterns. Chinese Journal of Geophysics, 2005,48(4):789-797.
	[ 杨修群, 谢倩, 朱益民 , 等. 华北降水年代际变化特征及相关的海气异常型. 地球物理学报, 2005,48(4):789-797.]
[10]	Zhou Xiaoxia, Ding Yihui, Wang Panxing . Features of moisture transport associated with the precipitation over North China during July-August. Chinese Journal of Atmospheric Sciences, 2008,32(2):345-357.
	[ 周晓霞, 丁一汇, 王盘兴 . 影响华北汛期降水的水汽输送过程. 大气科学, 2008,32(2):345-357.]
[11]	Zhou Liantong . Circulation anomalies pattern causing the persistent drought in north China. Climatic and Environmental Research, 2009,14(2):120-130.
	[ 周连童 . 引起华北地区夏季出现持续性干旱的环流异常型. 气候与环境研究, 2009,14(2):120-130.]
[12]	Zhu Yuxiang, Ding Yihui, Liu Haiwen . Simulation of the influence of winter snow depth over the Tibetan Plateau on summer rainfall in China. Chinese Journal of Atmospheric Sciences, 2009,33(5):903-915.
	[ 朱玉祥, 丁一汇, 刘海文 . 青藏高原冬季积雪影响我国夏季降水的模拟研究. 大气科学, 2009,33(5):903-915.]
[13]	Kalnay E, Kanamitsu M, Kistler R , et al. The NCEP/NCAR 40-year reanalysis project. Bulletin of the American Meteorological Society, 1996,77(3):437-471.
[14]	Sun Li, Zheng Xiuya, Wang Qi . The climatological characteristics of Northeast cold vortex in China. Quarterly Journal of Applied Meteorology, 1994,5(3):297-303.
	[ 孙力, 郑秀雅, 王琪 . 东北冷涡的时空分布特征及其与东亚大型环流系统之间的关系. 应用气象学报, 1994,5(3):297-303.]
[15]	He Liye, Ma Ning, Guo Jun . The impact of the Northeast Cold Vortex on early summer precipitation anomalies in the Haihe River Basin. Chinese Journal of Geophysics, 2017,60(10):3745-3752.
	[ 何丽烨, 马宁, 郭军 . 东北冷涡对海河流域初夏降水异常的影响. 地球物理学报, 2017,60(10):3745-3752.]
[16]	Liu Yunyun, Li Weijing, Ai Wanxiu , et al. Reconstruction and application of the monthly Western Pacific Subtropical High Indices. Journal of Applied Meteorological Science, 2012,23(4):414-423.
	[ 刘芸芸, 李维京, 艾孑兑秀 , 等. 月尺度西太平洋副热带高压指数的重建与应用. 应用气象学报, 2012,23(4):414-423.]
[17]	Zhang Qingyun, Tao Shiyan, Chen Lieting . The inter-annual variability of East Asian summer monsoon indices and its association with the pattern of general circulation over East Asia. Acta Meteorologica Sinica, 2003,61(4):559-568.
	[ 张庆云, 陶诗言, 陈烈庭 . 东亚夏季风指数的年际变化与东亚大气环流. 气象学报, 2003,61(4):559-568.]
[18]	Shen Qian, Zhang Shixuan, Zhao Junhu , et al. Contribution of typhoon over coastal waters to summer rainfall in eastern China. Acta Physica Sinica, 2013,62(18):189-201.
	[ 申茜, 张世轩, 赵俊虎 , 等. 近海台风对中国东部夏季降水的贡献. 物理学报, 2013,62(18):189-201.]
[19]	Huang Jianping, Yi Yuhong . Inversion of a nonlinear dynamical model from the observation. Science in China(Series B), 1991,34(10):1246-1251.
[20]	Plummer N, Salinger M J, Nicholls N , et al. Changes in climate extremes over the Australian region and New Zealand during the twentieth century. Climatic Change, 1999,42(1):183-202.
[21]	Manton M J, Della-Marta P M, Haylock M R , et al. Trend in extreme daily rainfall and temperature in Southeast Asia and the South Pacific: 1961-1998. International Journal of Climatology, 2001,21(3):269-284.
[22]	Zhai Panmao, Zhang Xuebin, Wan Hui , et al. Trends in total precipitation and frequency of daily precipitation extremes. Journal of Climate, 2005,18(7):1096-1108.
[23]	Zhang Qiang, Li Jianfeng, Chen Xiaohong , et al. Spatial variability of probability distribution of extreme precipitation in Xinjiang. Acta Geographica Sinica, 2011,66(1):3-12.
	[ 张强, 李剑锋, 陈晓宏 , 等. 基于Copula函数的新疆极端降水概率时空变化特征. 地理学报, 2011,66(1):3-12.]
[24]	Simmonds I, Bi D, Hope P . Atmospheric water vapor flux and its association with rainfall over China in summer. Journal of Climate, 1999,12(5):1353-1367.
[25]	Sun Yan, Zhu Weijun, Wang Qianqian , et al. Spatial/temporal variations of summer precipitation anomalies in North China and their relations to atmospheric circulation. Transactions of Atmospheric Sciences, 2010,33(1):67-73.
	[ 孙燕, 朱伟军, 王谦谦 , 等. 华北夏季降水异常的变化及其与大气环流的联系. 大气科学学报, 2010,33(1):67-73.]
[26]	Xu Guiyu, Yang Xiuqun, Sun Xuguang . Interdecadal and interannual variation characteristics of rainfall in North China and its relation with the northern hemisphere atmospheric circulations. Chinese Journal of Geophysics, 2005,48(3):511-518.
	[ 徐桂玉, 杨修群, 孙旭光 . 华北降水年代际、年际变化特征与北半球大气环流的联系. 地球物理学报, 2005,48(3):511-518.]
[27]	Zhai Yingjia, Li Yaohui, Shi Chunhua . Temporal and spatial characteristics of August precipitation in North China and its causes in last 50 years. Plateau Meteorology, 2013,32(3):787-797.
	[ 翟颖佳, 李耀辉, 施春华 . 近50年华北区8月降水异常的时空特征及其成因分析. 高原气象, 2013,32(3):787-797.]
[28]	Ye Min, Wu Yongping, Zhou Jie , et al. Objective quantification of the water vapor path influencing precipitation in North China in summer. Acta Physica Sinica, 2014,63(12):470-481.
	[ 叶敏, 吴永萍, 周杰 , 等. 影响华北盛夏降水的水汽路径客观定量化的研究. 物理学报, 2014,63(12):470-481.]
[29]	Hao Lisheng, Ding Yihui . Progress of precipitation research in North China. Progress in Geography, 2012,31(5):593-601.
	[ 郝立生, 丁一汇 . 华北降水变化研究进展. 地理科学进展, 2012,31(5):593-601.]
[30]	Guo Qiyun, Wang Jiqin . A comparative study on summer monsoon in China and India. Journal of Tropical Meteorology, 1988,4(1):53-60.
	[ 郭其蕴, 王继琴 . 中国与印度夏季风降水的比较研究. 热带气象学报, 1988,4(1):53-60.]
[31]	Dai Xingang, Wang Ping, Chou Jifan . Multiscale characteristics of the rainy season rainfall and interdecadal decaying of summer monsoon in North China. Chinese Science Bulletin, 2003,48(12):2730-2734.
[32]	Ding Yihui, Wang Zunya, Sun Ying . Interdecadal variation of the summer precipitation in East China and its association with decreasing Asian summer monsoon. Part I: Observed evidences. International Journal of Climatology, 2007,28(9):1139-1161.
[33]	Zhao Zhenguo. Summer Drought/flood Patterns and Environment Fields in China. Beijing: China Meteorological Press, 1999: 49-52.
	[ 赵振国 . 中国夏季旱涝及环境场. 北京: 气象出版社, 1999: 49-52.]
[34]	Fan Guangzhou, Lü Shihua . Numerical simulation study for the effect of terrain on North China summer precipitation. Plateau Meteorology, 1999,18(4):659-667.
	[ 范广洲, 吕世华 . 地形对华北地区夏季降水影响的数值模拟研究. 高原气象, 1999,18(4):659-667.]
[35]	Wei Yinghua, Chen Hong, Liu Yiwei , et al. Cause analysis of heavy rainfall over the northern Haihe River Basin under terrain influence. Meteorological and Environmental Sciences, 2018,41(3):81-88.
	[ 尉英华, 陈宏, 刘一玮 , 等. 地形影响下海河流域北系强降水成因分析. 气象与环境科学, 2018,41(3):81-88.]

月份	典型多雨年	典型少雨年
6月	1967,1971,1976,1977,1979,1980,1986,1991,2001	1963,1965,1968,1972,1974,1981,1983,1994,1997,1999,2000,2010
7月	1961,1962,1964,1969,1977,1988,1990,1994,2012,2013	1968,1980,1983,1984,1987,1997,1999,2002,2014
8月	1963,1964,1966,1967,1969,1973,1984,1987,1996,2010	1968,1989,1991,1997,2001,2002

环流指数	贡献率(%)
环流指数	6月	7月	8月
NECVI	69.59	27.70	2.74
副高脊线指数	8.56	60.64	46.01
东亚夏季风指数	21.85	11.66	51.25
