生态脆弱区社会—生态景观恢复力时空演变及情景模拟

doi:10.11821/dlxb201907013

Abstract

Abstract:

It is of fundamental significance to reveal the influencing mechanism of changes in human activities on ecological environment and landscape services, and to promote regional sustainable development that explores spatio-temporal variation and evolution of social-ecological resilience at the most operable landscape scale. Taking the loess hilly-gully region of Mizhi county as an example, this paper constructed an evaluation index system of social-ecological landscape resilience from the three dimensions of ecosystem, society system, and production system. The resilience of spatial-temporal evolution of the social-ecological landscape and subsystems were analyzed in this area along with their mutual relationships. The following results were obtained from this study: (1) During 2000-2015, the spatial distribution of the three subsystems resilience was prominently distinct and significantly strengthened. Among them, the resilience was significantly enhanced in the first stage of "Grain for Green Project" (2000-2009), and the resilience index of the three systems increased by 0.134, 0.048 and 0.028, respectively. (2) The spatial distribution of resilience on social-ecological landscape was also significantly distinct and the resilience index increased by 11.60%. The spatial distribution of resilience on social-ecological landscape presents a pattern of "high in center and low in eastern and western parts". (3) The positive relationships between the changes of the subsystems resilience and landscape system resilience were dominant, and the synergistic relationship between the resilience of the subsystems was obvious. The synergy rate of two or three systems is over 90%. In this study, OWA method was applied based on different weights of interference and adaptive ability indexes to set up situational preferences. Following this, simulation diagrams of social-ecological landscape resilience of the unsustainably oriented scenario, the current situation oriented scenario and sustainably oriented scenario were mapped, which provide a decision support for the adaptive management of regional landscape.

Key words: social-ecological landscape, landscape resilience, spatio-temporal evolution, scenario simulation, fragile area

ZHANG Hang,LIANG Xiaoying,LIU Di,SHI Qinqin,CHEN Hai. The resilience evolution and scenario simulation of social-ecological landscape in the fragile area[J].Acta Geographica Sinica, 2019, 74(7): 1450-1466.

Figures/Tables 16

Fig. 1

Tab. 1

Fig. 2

Tab. 2

Fig. 3

Tab. 3

Tab. 4

Tab. 5

Fig. 4

Fig. 5

Tab. 6

Tab. 7

Fig. 6

Tab. 8

Fig. 7

Tab. 9

References 47

[1]	Cumming G S, Olsson P, Chapin F S , et al. Resilience, experimentation, and scale mismatches in social-ecological landscapes. Landscape Ecology, 2013,28(6):1139-1150. doi: 10.1007/s10980-012-9725-4
[2]	Ciftcioglu G C . Assessment of the resilience of socio-ecological production landscapes and seascapes: A case study from Lefke Region of North Cyprus. Ecological Indicators, 2017,73(6):128-138. doi: 10.1016/j.ecolind.2016.09.036
[3]	Zhao Wenwu, Fang Xuening . Sustainable landscapes and landscape sustainability science. Journal of Ecology, 2014,34(10):2453-2459. doi: 10.5846/stxb201312042884
	[ 赵文武, 房学宁 . 景观可持续性与景观可持续性科学. 生态学报, 2014,34(10):2453-2459.] doi: 10.5846/stxb201312042884
[4]	Mcginlay J, Gowing D J G, Budds J . Conserving socio-ecological landscapes: An analysis of traditional and responsive management practices for floodplain meadows in England. Environmental Science & Policy, 2016,66:234-241.
[5]	Petrosillo I, Zaccarelli N, Zurlini G . Multi-scale vulnerability of natural capital in a panarchy of social-ecological landscapes. Ecological Complexity, 2010,7(3):359-367. doi: 10.1016/j.ecocom.2010.01.001
[6]	Garmestani A S, Benson M H . A framework for resilience-based governance of social-ecological systems. Ecology & Society, 2013,18(1):265-277.
[7]	Chen Jia, Yang Xinjun, Yin Sha , et al. The vulnerability evolution and simulation of the social-ecological systems in the semi-arid area based on the VSD framework. Acta Geographica Sinica, 2016,71(7):1172-1188.
	[ 陈佳, 杨新军, 尹莎 , 等. 基于VSD框架的半干旱地区社会—生态系统脆弱性演化与模拟. 地理学报, 2016,71(7):1172-1188.]
[8]	Zhang Tian, Liu Yanxu, Wang Yanglin . The rural spatial evolution and reconstruction on a resilience view. Journal of Ecology, 2017,37(7):2147-2157.
	[ 张甜, 刘焱序, 王仰麟 . 恢复力视角下的乡村空间演变与重构. 生态学报, 2017,37(7):2147-2157.]
[9]	Wu J G . Landscape sustainability science: Ecosystem services and human well-being in changing landscapes. Landscape Ecology, 2013,8(6):999-1023.
[10]	Rescia A J, Willaarts B A, Schmitz M F , et al. Changes in land uses and management in two nature reserves in Spain: Evaluating the social-ecological resilience of cultural landscapes. Landscape & Urban Planning, 2010,98(1):26-35.
[11]	Min K, You S, Chon J , et al. Sustainable land-use planning to improve the coastal resilience of the social-ecological landscape. Sustainability, 2017,9(7):1086. doi: 10.3390/su9071086
[12]	Li Y, Shi Y, Qureshi S , et al. Applying the concept of spatial resilience to socio-ecological systems in the urban wetland interface. Ecological Indicators, 2014,42(7):135-146. doi: 10.1016/j.ecolind.2013.09.032
[13]	Rescia A J, Ortega M, Rescia A J , et al. Quantitative evaluation of the spatial resilience to the B. oleae pest in olive grove socio-ecological landscapes at different scales. Ecological Indicators, 2017,84:820-827.
[14]	Yang Xinjun, Shi Yuzhong, Wang Ziqiao . Exploring the impacts of road construction on a local social-ecological system in Qinling mountainous area. Acta Geographica Sinica, 2015,70(8):1313-1326.
	[ 杨新军, 石育中, 王子侨 . 道路建设对秦岭山区社会—生态系统的影响. 地理学报, 2015,70(8):1313-1326.]
[15]	Bergamini N, Blasiak R, Eyzaguirre P , et al. Indicators of Resilience in Socio-ecological Production Landscapes. UNU-IAS Policy Report, 2010.
[16]	Plieninger T, Bieling C. Resilience and the Cultural Landscape: Understanding and Managing Change in Human Shaped Environments. Cambridge: Camridge University Press, 2012(2):264.
[17]	Oudenhoven F J, Mijatovic D, Eyzaguirre P B . Social-ecological indicators of resilience in agrarian and natural landscapes. Management of Environmental Quality: An International Journal, 2011,22(2):154-173.
[18]	Wang Qun, Lu Lin, Yang Xingzhu . Study on measurement and impact mechanism of socio-ecological system resilience in Qiandao Lake. Acta Geographica Sinica, 2015,70(5):779-795.
	[ 王群, 陆林, 杨兴柱 . 千岛湖社会—生态系统恢复力测度与影响机理. 地理学报, 2015,70(5):779-795.]
[19]	Zhou Xiaofang . Measuring methods for the resilience of social-ecological systems. Journal of Ecology, 2017,37(12):4278-4288.
	[ 周晓芳 . 社会—生态系统恢复力的测量方法综述. 生态学报, 2017,37(12):4278-4288.]
[20]	Zhang Mengjie, Guan Dongjie, Su Weici . Scenarios simulation and indices thresholds determination of ecological security in Three Gorges Reservoir based on system dynamics. Acta Ecologica Sinica, 2015,35(14):4880-4890. doi: 10.5846/stxb201311122717
	[ 张梦婕, 官冬杰, 苏维词 . 基于系统动力学的重庆三峡库区生态安全情景模拟及指标阈值确定. 生态学报, 2015,35(14):4880-4890.] doi: 10.5846/stxb201311122717
[21]	Xu Yueqing, Li Shuangcheng, Cai Yunlong . Spatial simulation using GIS and artificial neural network for regional poverty: A case study of Maotiaohe Watershed, Guizhou province. Progress in Geography, 2006,25(3):79-85. doi: 10.3969/j.issn.1007-6301.2006.03.010
	[ 许月卿, 李双成, 蔡运龙 . 基于GIS和人工神经网络的区域贫困化空间模拟分析: 以贵州省猫跳河流域为例. 地理科学进展, 2006,25(3):79-85.] doi: 10.3969/j.issn.1007-6301.2006.03.010
[22]	Li Shaoying, Li Xia, Liu Xiaoping , et al. Multi-scenario simulations on the interactions of jobs-housing based on agent-based model. Acta Geographica Sinica, 2013,68(10):1389-1400.
	[ 李少英, 黎夏, 刘小平 , 等. 基于多智能体的就业与居住空间演化多情景模拟: 快速工业化区域研究. 地理学报, 2013,68(10):1389-1400.]
[23]	Liu Yanxu, Peng Jian, Han Yinan , et al. Suitability assessment for building land consolidation on gentle hillside based on OWA operator: A case in Dali Bai Nationality Borough in Yunnan, China. Acta Ecologica Sinica, 2014,34(12):3188-3197. doi: 10.5846/stxb201312233004
	[ 刘焱序, 彭建, 韩忆楠 , 等. 基于OWA的低丘缓坡建设开发适宜性评价: 以云南大理白族自治州为例. 生态学报, 2014,34(12):3188-3197.] doi: 10.5846/stxb201312233004
[24]	Liu Yanxu, Wang Yanglin, Peng Jian , et al. Urban landscape ecological risk assessment based on the 3D framework of adaptive cycle. Acta Geographica Sinica, 2015,70(7):1052-1067.
	[ 刘焱序, 王仰麟, 彭建 , 等. 基于生态适应性循环三维框架的城市景观生态风险评价. 地理学报, 2015,70(7):1052-1067.]
[25]	Liu Yanxu, Wang Yanglin, Peng Jian , et al. Land ecological suitability assessment for forest coupled with the resilience perspective: A case study in Wangqing county, Jilin province, China. Acta Geographica Sinica, 2015,70(3):476-487.
	[ 刘焱序, 王仰麟, 彭建 , 等. 耦合恢复力的林区土地生态适宜性评价: 以吉林省汪清县为例. 地理学报, 2015,70(3):476-487.]
[26]	Feng Shu, Zhao Wenwu, Chen Liding , et al. Advances in landscape ecology in the Loess Plateau since 2010 in China. Acta Ecologica Sinica, 2017,37(12):3957-3966.
	[ 冯舒, 赵文武, 陈利顶 , 等. 2010年来黄土高原景观生态研究进展. 生态学报, 2017,37(12):3957-3966.]
[27]	Chen Hai, Liang Xiaoying, Wang Tao . Land use intensity, landscape complexity and village specialization in the fragile area of Mizhi county. Resources Science, 2014,36(10):2183-2193.
	[ 陈海, 梁小英, 王涛 . 生态脆弱区土地集约利用、景观复杂性、村落专业化的关系研究: 以陕西省米脂县为例. 资源科学, 2014,36(10):2183-2193.]
[28]	Sun Honghu, Cheng Xianfu, Dai Mengqin , et al. Study on the influence factors and evaluation index system of regional flood disaster resilience based on DEMATEL method: Taking Chaohu Basin as a case. Resources and Environment in the Yangtze Basin, 2015,24(9):1577-1583. doi: 10.11870/cjlyzyyhj201509019
	[ 孙鸿鹄, 程先富, 戴梦琴 , 等. 基于DEMATE的区域洪涝灾害恢复力影响因素及评价指标体系研究: 以巢湖流域为例. 长江流域资源与环境, 2015,24(9):1577-1583.] doi: 10.11870/cjlyzyyhj201509019
[29]	Jia Hui, Chen Hai, Mao Nanzhao , et al. Landscape sustainable development in highly sensitive ecological fragile areas. Resources Science, 2018,40(6):1277-1286.
	[ 贾慧, 陈海, 毛南赵 , 等. 高度敏感生态脆弱区景观可持续性评价. 资源科学, 2018,40(6):1277-1286.]
[30]	Peng Jian, Wu Jiansheng, Pan Yajing , et al. Evaluation for regional ecological sustainability based on PSR model: Conceptual framework. Progress in Geography, 2012,31(7):933-940. doi: 10.11820/dlkxjz.2012.07.012
	[ 彭建, 吴健生, 潘雅婧 , 等. 基于PSR模型的区域生态持续性评价概念框架. 地理科学进展, 2012,31(7):933-940.] doi: 10.11820/dlkxjz.2012.07.012
[31]	Yan Haiming, Zhan Jinyan, Zhang Tao . Review of ecosystem resilience research progress. Progress in Geography, 2012,31(3):303-314. doi: 10.11820/dlkxjz.2012.03.005
	[ 闫海明, 战金艳, 张韬 . 生态系统恢复力研究进展综述. 地理科学进展, 2012,31(3):303-314.] doi: 10.11820/dlkxjz.2012.03.005
[32]	Peng Jian, Dang Weixiong, Liu Yanxu , et al. Review on landscape ecological risk assessment. Acta Geographica Sinica, 2015,70(4):664-677.
	[ 彭建, 党威雄, 刘焱序 , 等. 景观生态风险评价研究进展与展望. 地理学报, 2015,70(4):664-677.]
[33]	Peng Jian, Wang Yanglin, Zhang Yuan , et al. Evaluating the effectiveness of landscape metrics in quantifying spatial patterns. Ecological Indicators, 2010,10(2):217-223. doi: 10.1016/j.ecolind.2009.04.017
[34]	Zurlini G, Petrosillo I, Jones K B , et al. Highlighting order and disorder in social-ecological landscapes to foster adaptive capacity and sustainability. Landscape Ecology, 2013,28(6):1161-1173. doi: 10.1007/s10980-012-9763-y
[35]	Ning Lixin, Ma Lan, Zhou Yunkai , et al. Spatiotemporal variations of ecosystem health of the coastal zone in Jiangsu Province based on the PSR model. China Environmental Science, 2016,36(2):534-543.
	[ 宁立新, 马兰, 周云凯 , 等. 基于PSR模型的江苏海岸带生态系统健康时空变化研究. 中国环境科学, 2016,36(2):534-543.]
[36]	Peng Jian, Xie Pan, Liu Yanxu , et al. Integrated ecological risk assessment and spatial development trade-offs in lowslope hilly land: A case study in Dali Bai Autonomous Prefecture, China. Acta Geographica Sinica, 2015,70(11):1747-1761.
	[ 彭建, 谢盼, 刘焱序 , 等. 低丘缓坡建设开发综合生态风险评价及发展权衡: 以大理白族自治州为例. 地理学报, 2015,70(11):1747-1761.]
[37]	Lu Changhe, Wang Qian, Ma Junfei . Effects of the ecological construction in the hlilly Loess Plateau. Journal of Arid Land Resources and Environment, 2011,25(10):28-31.
	[ 吕昌河, 王茜, 马俊飞 . 黄土丘陵区生态建设效应与农户响应. 干旱区资源与环境, 2011,25(10):28-31.]
[38]	Guo Yongrui, Zhang Jie . Research progress and themes of geography on community resilience. Progress in Geography, 2015,34(1):100-109. doi: 10.11820/dlkxjz.2015.01.012
	[ 郭永锐, 张捷 . 社区恢复力研究进展及其地理学研究议题. 地理科学进展, 2015,34(1):100-109.] doi: 10.11820/dlkxjz.2015.01.012
[39]	Speranza C I, Wiesmann U, Rist S . An indicator framework for assessing livelihood resilience in the context of social-ecological dynamics. Global Environmental Change, 2014,28(1):109-119. doi: 10.1016/j.gloenvcha.2014.06.005
[40]	Perz S G, Shenkin A, Barnes G , et al. Connectivity and resilience: A multidimensional analysis of infrastructure impacts in the southwestern Amazon. Social Indicators Research, 2012,106(2):259-285. doi: 10.1007/s11205-011-9802-0
[41]	Li Xiao, Zhou Dingyang . An overview of the resilience of agro-ecosystems. Resources Science, 2015,37(9):1747-1754.
	[ 李晓, 周丁扬 . 农业系统恢复力研究进展综述. 资源科学, 2015,37(9):1747-1754.]
[42]	Xu Yong, Sun Xiaoyi, Tang Qing . Human activity intensity of land surface: Concept, method and application in China. Acta Geographica Sinica, 2015,70(7) : 1068-1079.
	[ 徐勇, 孙晓一, 汤青 . 陆地表层人类活动强度: 概念、方法及应用. 地理学报, 2015,70(7):1068-1079.]
[43]	Song Shixiong, Liang Xiaoying, Mei Yajun , et al. Modeling and simulating land abandonment behavior of farmer households based on the CBDI. Journal of Natural Resources, 2016,31(11):1926-1937.
	[ 宋世雄, 梁小英, 梅亚军 , 等. 基于CBDI的农户耕地撂荒行为模型构建及模拟研究: 以陕西省米脂县冯阳坬村为例. 自然资源学报, 2016,31(11):1926-1937.]
[44]	Xiang Hui, Kong Xiangbin, Wu Zhaokun , et al. Spatial distribution characteristics of potential productivity of arable land in main crop production area in China. Transactions of the Chinese Society of Agricultural Engineering, 2012,28(24):235-244.
	[ 相慧, 孔祥斌, 武兆坤 , 等. 中国粮食主产区耕地生产能力空间分布特征. 农业工程学报, 2012,28(24):235-244.]
[45]	Yager R R . On ordered weighted averaging aggregation operators in multi-criteria decision making. IEEE Transactions on Systems, Man and Cybernetics, 1988,18(1):183-190. doi: 10.1109/21.87068
[46]	Yager R R . Quantifier guided aggregation using OWA operators. International Journal of Intelligent Systems, 1996,11(1):49-73. doi: 10.1002/(SICI)1098-111X(199601)11:1<>1.0.CO;2-3
[47]	Lu Dadao . The framework document of "Future Earth" and the development of Chinese geographical science: The foresight of Academician HUANG Bingwei's statement. Acta Geographica Sinica, 2014,69(8):1043-1051.
	[ 陆大道 . “未来地球”框架文件与中国地理科学的发展: 从“未来地球”框架文件看黄秉维先生论断的前瞻性. 地理学报, 2014,69(8):1043-1051.]

准则层(权重)	要素层	指标(权重)	单位	指标方向
生态系统(0.350)	景观格局	景观多样性指数(0.146)	%	+
	景观格局	景观连接性指数(0.152)	%	-
	生态系统功能	植被覆盖度(0.169)	%	-
	生态胁迫	化肥施用强度(0.179)	kg/hm²	+
	生态胁迫	农药施用强度(0.137)	kg/hm²	+
	生态保护	“三田”面积占比(0.216)	%	+
社会系统(0.293)	产业结构	产业结构多样化指数(0.207)	%	+
	人口压力	人类活动强度(0.281)	%	-
	农户生计	农业总产值(0.234)	元	+
	集体记忆	外迁人口占比(0.279)	%	-
生产系统(0.357)	地形条件	坡度(0.208)	度	-
	地形条件	高程(0.161)	m	-
	生产能力	粮食产量(0.213)	kg	+
	生产能力	耕地面积占比(0.228)	%	+
	劳动力	农业劳动力数量(0.190)	人	+

恢复力等级		2000年		2000-2009年面积变化 (km²)	2009年		2009-2015年面积变化 (km²)	2015年		2000-2015年面积变化 (km²)
恢复力等级		面积 (km²)	比例 (%)	2000-2009年面积变化 (km²)	面积 (km²)	比例 (%)	2009-2015年面积变化 (km²)	面积 (km²)	比例 (%)	2000-2015年面积变化 (km²)
生态系统	I级	378.52	31.49	-324.56	53.96	4.58	-28.59	42.90	3.64	-335.62
	II级	412.39	34.89	-61.78	350.61	29.74	-21.43	329.18	27.92	-83.21
	III级	230.07	17.94	218.66	448.73	38.06	-45.64	415.1	35.21	185.03
	IV级	135.95	11.72	111.25	247.20	20.69	51.54	298.74	25.34	162.79
	V级	22.00	3.96	55.92	77.92	6.61	44.39	93.01	7.89	71.01
社会系统	I级	72.28	6.13	-36.14	36.14	3.07	22.26	58.40	4.95	-13.88
	II级	482.73	41.03	-62.33	420.4	35.66	-225.54	194.86	16.53	-287.87
	III级	245.55	20.83	117.92	363.47	30.83	20.84	384.31	32.60	138.76
	IV级	271.72	23.05	-108.42	163.30	13.85	244.66	407.96	34.61	136.24
	V级	106.28	9.02	89.27	195.55	16.59	-62.23	133.32	11.31	27.04
生产系统	I级	138.93	11.79	-62.79	76.14	6.46	-28.53	47.61	4.04	-91.32
	II级	199.86	16.95	0.54	200.40	17.00	11.16	211.56	17.95	11.70
	III级	589.18	49.98	-25.71	563.47	47.80	-54.86	508.61	43.14	-80.57
	IV级	199.00	16.88	64.30	263.3	22.34	-0.48	302.82	25.69	103.82
	V级	51.50	4.37	24.05	75.55	6.41	32.45	108.00	9.16	56.50

恢复力等级	I级	II级	III级	IV级	V级	2000年总计
I级 (km²)	42.90	174.32	91.93	39.43	29.94	378.52
II级 (km²)		144.51	173.27	94.61		412.39
III级 (km²)		10.35	99.06	92.20	28.46	230.07
IV级 (km²)			50.84	62.87	22.24	135.95
V级 (km²)				9.63	12.37	22.00
2015年总计(km²)	42.90	329.18	415.10	298.74	93.01	1178.90
面积净变化(km²)	-335.62	-83.21	185.03	162.79	71.01

恢复力等级	I级	II级	III级	IV级	V级	2000年总计
I级 (km²)	14.62	32.50	25.16			72.28
II级 (km²)	18.23	210.79	201.48	53.23		483.73
III级 (km²)		87.53	132.08	25.94		245.55
IV级 (km²)			67.57	80.57	123.58	271.72
V级 (km²)				16.23	90.05	106.28
2015年总计(km²)	58.40	194.86	384.31	407.96	133.32	1178.85
面积净变化(km²)	-13.88	-288.87	138.76	136.24	27.04

恢复力等级	I级	II级	III级	IV级	V级	2000年总计
I级 (km²)	47.61	57.12	34.20			138.93
II级 (km²)		76.43	60.50	62.93		199.86
III级 (km²)		69.34	400.98	109.36	29.50	609.18
IV级 (km²)		8.67	12.93	111.60	65.80	199.00
V级 (km²)				18.93	32.70	51.50
2015年总计(km²)	47.61	211.56	508.61	302.82	128.00	1178.85
面积净变化(km²)	-91.32	-8.30	29.43	13.51	21.81

The resilience evolution and scenario simulation of social-ecological landscape in the fragile area

RichHTML

PDF (PC)

Like

Knowledge

Cited

Abstract

Cite this article

share this article

Figures/Tables 16

References 47

Related Articles 15

Metrics

Comments

恢复力等级	I级	II级	III级	IV级	V级	2000年总计
I级 (km²)	50.11	58.01	65.09			173.21
II级 (km²)	8.29	83.65	113.94	165.82		371.70
III级 (km²)		53.20	180.36	191.32	35.07	459.95
IV级 (km²)			24.92	45.99	43.81	114.72
V级 (km²)				4.83	54.44	59.27
2015年总计(km²)	58.40	194.86	384.31	407.96	133.32	1178.85
面积净变化(km²)	-114.81	-176.84	-75.64	293.24	74.05

次序权重	a→0(0.0001) 极悲观	a = 0.1 悲观	a = 0.5 较悲观	a = 1 无偏好	a = 2 较乐观	a = 10 乐观	a→∞(1000) 极乐观
人类活动强度	1	0.8123	0.3536	0.0667	0.0156	0.0000	0
外迁人口占比	0	0.0554	0.1380	0.0667	0.0428	0.0000	0
坡度	0	0.0327	0.1000	0.0667	0.0641	0.0000	0
化肥施用强度	0	0.0229	0.0792	0.0667	0.0800	0.0000	0
高程	0	0.0173	0.0652	0.0667	0.0909	0.0018	0
农药施用强度	0	0.0136	0.0546	0.0667	0.0972	0.0069	0
景观多样性指数	0	0.0109	0.0461	0.0667	0.0994	0.0192	0
景观连接性指数	0	0.0088	0.0389	0.0667	0.0978	0.0419	0
植被覆盖度	0	0.0072	0.0327	0.0667	0.0929	0.0759	0
产业结构多样性	0	0.0058	0.0271	0.0667	0.085	0.1170	0
农业劳动力数量	0	0.0046	0.0220	0.0667	0.0746	0.1558	0
农业总产值	0	0.0035	0.0173	0.0667	0.0622	0.1798	0
“三田”面积占比	0	0.0026	0.0127	0.0667	0.0481	0.1776	0
粮食产量	0	0.0017	0.0084	0.0667	0.0328	0.1434	0
耕地面积占比	0	0.0008	0.0042	0.0667	0.0166	0.0803	1

[1]	FAN Zemeng. Spatial identification and scenario simulation of ecotone distribution in China [J]. Acta Geographica Sinica, 2021, 76(3): 626-644.
[2]	CHAI Yuanfang, DENG Jinyun, YANG Yunping, SUN Zhaohua, LI Yitian, ZHU Lingling. Evolution characteristics and driving factors of the water level at the same discharge in the Jingjiang reach of Yangtze River [J]. Acta Geographica Sinica, 2021, 76(1): 101-113.
[3]	WANG Shaojian, GAO Shuang, HUANG Yongyuan, SHI Chenyi. Spatio-temporal evolution and trend prediction of urban carbon emission performance in China based on super-efficiency SBM model [J]. Acta Geographica Sinica, 2020, 75(6): 1316-1330.
[4]	MA Enpu, CAI Jianming, LIN Jing, GUO Hua, HAN Yan, LIAO Liuwen. Spatio-temporal evolution of global food security pattern and its influencing factors in 2000-2014 [J]. Acta Geographica Sinica, 2020, 75(2): 332-347.
[5]	YU Shuchen, WANG Lunche, XIA Weiping, YU Deqing, LI Chang'an, HE Qiuhua. Spatio-temporal evolution of riparian lakes in Dongting Lake area since the late Qing Dynasty [J]. Acta Geographica Sinica, 2020, 75(11): 2346-2361.
[6]	LI Gang, WANG Jiaobei, XU Tingting, GAO Xing, JIN Annan, YU Yue. Spatio-temporal evolution process and integrated measures for prevention and control of COVID-19 epidemic in China [J]. Acta Geographica Sinica, 2020, 75(11): 2475-2489.
[7]	Wenbo ZHU, Jingjing ZHANG, Yaoping CUI, Hui ZHENG, Lianqi ZHU. Assessment of territorial ecosystem carbon storage based on land use change scenario: A case study in Qihe River Basin [J]. Acta Geographica Sinica, 2019, 74(3): 446-459.
[8]	ZHOU Liang, CHE Lei, ZHOU Chenghu. Spatio-temporal evolution and influencing factors of urban green development efficiency in China [J]. Acta Geographica Sinica, 2019, 74(10): 2027-2044.
[9]	Hua DENG, Jing'an SHAO, Jinliang WANG, Ming GAO, Chaofu WEI. Land use driving forces and its future scenario simulation in the Three Gorges Reservoir Area using CLUE-S model [J]. Acta Geographica Sinica, 2016, 71(11): 1979-1997.
[10]	Weishan CHEN, Lin LIU, Yutian LIANG. Characterizing the spatio-temporal evolution of retail business at transfer hubs of Guangzhou Metro [J]. Acta Geographica Sinica, 2015, 70(6): 879-892.
[11]	LENG Zhiming, TANG Shan. Estimation and spatio-temporal evolution analysis of self-development capacity in Wuling Mountain Areas based on county data of 2005, 2008 and 2011 [J]. Acta Geographica Sinica, 2014, 69(6): 782-796.
[12]	QI Yuanjing, YANG Yu, JIN Fengjun. China’s economic development stage and its patio-temporal evolution：A prefectural-level analysis [J]. Acta Geographica Sinica, 2013, 68(4): 517-531.
[13]	HUANG Yi, MA Yaofeng, XUE Huaju. Spatio-temporal-situational evolution and regional influencing factors of the inbound tourism service quality in China [J]. Acta Geographica Sinica, 2013, 68(12): 1689-1701.
[14]	QIN Xianhong, DUAN Xuejun, YANG Jian. Scenario Simulation of Urban Land Use Allocation and Scheme Evaluation Based on GIS: A Case Study of Taicang City [J]. Acta Geographica Sinica, 2010, 65(9): 1121-1129.
[15]	. Epidemiological Features and Spatio-temporal Evolution in the Early Phase of the Beijing H1N1 Epidemic [J]. Acta Geographica Sinica, 2010, 65(3): 361-368.

恢复力等级	情景一		情景一、二面积变化 (km²)	情景二		情景二、三面积变化 (km²)	情景三		情景一、三面积变化 (km²)
恢复力等级	面积 (km²)	比例 (%)	情景一、二面积变化 (km²)	面积 (km²)	比例 (%)	情景二、三面积变化 (km²)	面积 (km²)	比例 (%)	情景一、三面积变化 (km²)
I级	278.10	23.59	-218.13	59.96	5.09	-46.16	13.80	1.17	-264.30
II级	464.95	39.44	-312.77	152.17	12.91	-76.48	75.69	6.42	-389.25
III级	224.54	19.05	409.79	634.34	53.81	-212.65	421.68	35.77	197.14
IV级	158.04	13.41	43.05	201.10	17.06	276.37	477.47	40.50	319.43
V级	53.22	4.51	78.06	131.28	11.14	58.92	190.21	16.14	136.98
