基于GIS与地理探测器的岩溶槽谷石漠化空间分布及驱动因素分析

doi:10.11821/dlxb201905014

Abstract

Abstract:

：The rocky desertification in the karst area is becoming the third largest ecological problem in western China following desertification, as well as soil and water loss. In recent years, rocky desertification in the karst trough valley is increasing seriously, and puts more and more pressure on the environment. Therefore, by GIS spatial analysis functions and geodetector models, this paper aims to explore the spatial distribution of rocky desertification in different gradients and its driving factors based on rock desertification, lithology, slope, elevation, rainfall, land use, population density and the total output value of primary industry in the valley. The results are as follows: (1) The total rocky desertification area in the karst trough area is 21, 323.7 km ², accounting for 8.3% of the land area in the study area; of which the light, moderate and severe rocky desertification areas are 11, 894.8 km ², 8615.8 km ² and 813.1 km ², respectively, accounting for 55.8%, 40.4% and 3.8% of the desertified area. (2) From the spatial distribution, rocky desertification mainly occurs in the continuous limestone, and the light, moderate and severe rocky desertification areas respectively account for 22.1%, 22.4% and 1.9% of the corresponding rocky desertification types in the trough area; Rocky desertification in the trough area mainly occurs in the gradient range of 15° to 25°, and the light, moderate, and severe rocky desertification areas account for 27.1%, 18.2% and 2.3% of the corresponding rocky desertification in the trough area, respectively; From the elevation, it is mainly distributed in the range of 400-800 m, and the areas of rocky desertification with light, moderate, and severe erosion grades account for 24.9%, 18.4% and 0.2% of the corresponding rocky desertification area in the trough area, respectively; From the land use type, it mainly occurs in upland mountains; From the population density, it concentrates in areas with 100-200 persons/km ²; From the total output value of primary industry, it concentrates in areas with 2.5-50 billion. (3) The factor detectors of geographical detectors revealed that the lithology, land use, and slope are the main driving factors for the formation of rocky desertification in the trough region. Interactive detectors further revealed that the lithology and land use types (q = 0.85) together with slopes and land use types (q = 0.75) drive the formation of rocky desertification in the trough area.

Key words: karst trough valley, rocky desertification, spatial analysis, driving factors, geographic detector

WANG Zhengxiong,JIANG Yongjun,ZHANG Yuanzhu,DUAN Shihui,LIU Jiuchan,ZENG Ze,ZENG Sibo. Spatial distribution and driving factors of karst rocky desertification based on GIS and geodetectors[J].Acta Geographica Sinica, 2019, 74(5): 1025-1039.

Figures/Tables 14

Fig. 1

Fig. 2

Fig. 3

Tab. 1

Tab. 2

Tab. 3

Tab. 4

Tab. 5

Tab. 6

Tab. 7

Tab. 9

Tab. 1

References 41

[1]	Yuan, D X . Rock desertiﬁcation in the subtropical karst of south China. Zeitschrift fur Geomorphologie, 1997,108:81-90.
[2]	Wang S J, Li R L, Sun C X , et al. How types of carbonate rock assemblages constrain the distribution of karst rocky desertiﬁed land in Guizhou Province, PR China: Phenomena and mechanisms, Land Degradation & Development, 2004,15(2):123-131.
[3]	Jiang Z C, Lian Y Q, Qin X Q . Rocky desertification in Southwest China: Impacts, causes, and restoration. Earth-Science Reviews, 2014,132:1-12. doi: 10.1016/j.earscirev.2014.01.005
[4]	Planning Outline for Comprehensive Management of Rocky Desertification in Karst Area(2006-2015). National Development and Reform Commission and State Forestry Administration, Ministry of Agriculture, Ministry of Water Resources.
	[ 岩溶地区石漠化综合治理规划大纲(2006-2015年). 国家发展改革委会同林业局、农业部、水利部.]
[5]	Yuan D X. Major Environmental Geological Problems and Strategies in Southwest Karst Rocky Mountains. Beijing: Science Press, 2014.
	[ 袁道先 . 西南岩溶石山地区重大环境地质问题及对策研究. 北京: 科学出版社, 2014.]
[6]	Wang Shijie, Li Yangbing, Li Ruiling . Formation background, evolution and treatment of Karst Rocky Desertification. Quaternary Sciences, 2003,23(6):657-666. doi: 10.3321/j.issn:1001-7410.2003.06.009
	[ 王世杰, 李阳兵, 李瑞玲 . 喀斯特石漠化的形成背景、演化与治理. 第四纪研究, 2003,23(6):657-666.] doi: 10.3321/j.issn:1001-7410.2003.06.009
[7]	Jiang Zhongcheng, Luo Weiqun, Tong Liqiang , et al. Evolution characteristics and influencing factors of Karst Rocky Desertification in Southwest China in the 21st Century. Chinese Journal of Karst, 2016,35(5):461-468. doi: 10.11932/karst20160504
	[ 蒋忠诚, 罗为群, 童立强 , 等. 21世纪西南岩溶石漠化演变特点及影响因素. 中国岩溶, 2016,35(5):461-468.] doi: 10.11932/karst20160504
[8]	Zhang Xinbao, Wang Shijie, Bai Xiaoyong , et al. The relationship between spatial distribution of rocky desertification and karst landform, lithology, annual average precipitation and population density density in Guizhou. Earth and Environment, 2013,41(1):1-6.
	[ 张信宝, 王世杰, 白晓永 , 等. 贵州石漠化空间分布与喀斯特地貌、岩性、年均降水和人口密度密度的关系. 地球与环境, 2013,41(1):1-6.]
[9]	Li Ruiling . Natural background and spatial regional differentiation of rocky desertification in karst areas of Guizhou [D]. Guiyang: Institute of Geochemistry, Chinese Academy of Sciences, 2004.
	[ 李瑞玲 . 贵州岩溶地区土地石漠化形成的自然背景及其空间地域分异[D]. 贵阳: 中国科学院地球化学研究所, 2004.]
[10]	Jiang Y, Li L, Groves C , et al. Relationships between rocky desertification and spatial pattern of land use in typical karst area, Southwest China. Environmental Earth Sciences, 2009,59(4):881-890. doi: 10.1007/s12665-009-0083-8
[11]	Bai Xiaoyong, Xiong Kangning, Li Yangbing , et al. Quantitative study on spatial difference of rocky desertification and population factors in different karst mountain areas. Journal of Mountain Science, 2006,24(2):242-248. doi: 10.3969/j.issn.1008-2786.2006.02.019
	[ 白晓永, 熊康宁, 李阳兵 , 等. 喀斯特山区不同强度石漠化与人口因素空间差异性的定量研究. 山地学报, 2006,24(2):242-248.] doi: 10.3969/j.issn.1008-2786.2006.02.019
[12]	Wang Jinfeng, Xu Chengdong . Geographical detectors: Principles and prospects. Acta Geographica Sinica, 2017,72(1):116-134. doi: 10.11821/dlxb201701010
	[ 王劲峰, 徐成东 . 地理探测器:原理与展望. 地理学报, 2017,72(1):116-134.] doi: 10.11821/dlxb201701010
[13]	Wang J F, Hu Y . Environmental health risk detection with GeogDetector. Environmental Modelling & Software, 2005,20(10):114-115. doi: 10.1016/j.envsoft.2012.01.015
[14]	Dong Yuxiang, Xu Wei, Yang Ren , et al. Discussion on the northern boundary of China's terrestrial tropics based on geographical detectors. Acta Geographica Sinica, 2017,72(1):135-147. doi: 10.11821/dlxb201701011
	[ 董玉祥, 徐茜, 杨忍 , 等. 基于地理探测器的中国陆地热带北界探讨. 地理学报, 2017,72(1):135-147.] doi: 10.11821/dlxb201701011
[15]	Wang J F, Li X H, Christakos G , et al. Geographical detectors-based health risk assessment and its application in the neural tube defects study of the Heshun Region, China. International Journal of Geographical Information Science, 2010,24(1):107-127. doi: 10.1080/13658810802443457
[16]	Wang J F, Zhang T L, Fu B J . A measure of spatial stratified heterogeneity. Ecological Indicators, 2016,67:250-256. doi: 10.1016/j.ecolind.2016.02.052
[17]	Wang Jinfeng, Ge Yong, Li Lianfa , et al. Geographic spatiotemporal data analysis methods. Acta Geographica Sinica, 2014,69(9):1326-1345. doi: 10.11821/dlxb201409007
	[ 王劲峰, 葛咏, 李连发 , 等. 地理学时空数据分析方法. 地理学报, 2014,69(9):1326-1345.] doi: 10.11821/dlxb201409007
[18]	Pu Junbing, Yuan Daoxian, Pei Zhengjiao , et al. Water environment problems in karst areas in Southwest China. Science: Shanghai, 2010,62(2):32-36. doi: 10.3969/j.issn.0368-6396.2010.02.010
	[ 蒲俊兵, 袁道先, 覃政教 , 等. 我国西南岩溶区水环境问题. 科学, 2010,62(2):32-36.] doi: 10.3969/j.issn.0368-6396.2010.02.010
[19]	Liu Zaihua, Dreybrodt W, Li Huaju . Comparison of dissolution rate control mechanisms of limestone and dolomite. Earth Science, 2006,31(3):411-416. doi: 10.3321/j.issn:1000-2383.2006.03.021
	[ 刘再华, Dreybrodt W , 李华举. 灰岩和白云岩溶解速率控制机理的比较. 地球科学, 2006,31(3):411-416.] doi: 10.3321/j.issn:1000-2383.2006.03.021
[20]	Jiang Yongjun, Zhang Cheng, Li Linli , et al. Analysis of the current situation and genesis of rocky desertification in Hanjiang District of Chongqing based on RS and GIS. Hydrogeology and Engineering Geology, 2007,34(1):81-85. doi: 10.3969/j.issn.1000-3665.2007.01.018
	[ 蒋勇军, 章程, 李林立, 袁道先 , 等. 基于RS、GIS的重庆黔江区石漠化现状与成因分析. 水文地质工程地质, 2007,34(1):81-85.] doi: 10.3969/j.issn.1000-3665.2007.01.018
[21]	Li Yangbing, Bai Xiaoyong, Zhou Guofu , et al. Relationship between land use and rocky desertification in typical rocky desertification areas of China. Acta Geographica Sinica, 2006,61(6):624-632. doi: 10.3321/j.issn:0375-5444.2006.06.007
	[ 李阳兵, 白晓永, 周国富 , 等. 中国典型石漠化地区土地利用与石漠化的关系. 地理学报, 2006,61(6):624-632.] doi: 10.3321/j.issn:0375-5444.2006.06.007
[22]	Li Yangbing, Bai Xiaoyong, Qiu Xingchun , et al. Correlation between Karst Rocky desertification and land use. Journal of Resource Science, 2006,28(2):67-73. doi: 10.3321/j.issn:1007-7588.2006.02.011
	[ 李阳兵, 白晓永, 邱兴春 , 等. 喀斯特石漠化与土地利用相关性研究. 资源科学, 2006,28(2):67-73.] doi: 10.3321/j.issn:1007-7588.2006.02.011
[23]	Zhang Xinbao, Wang Shijie, Meng Tianyou , et al. Mechanism of farming driving rocky land in karst areas of Southwest China. Earth and Environment, 2010,38(2):123-128.
	[ 张信宝, 王世杰, 孟天友 , 等. 农耕驱动西南喀斯特地区坡地石质化的机制. 地球与环境, 2010,38(2):123-128.]
[24]	Peng T, Wang S J . Effects of land use, land cover and rainfall regimes on the surface runoff and soil loss on karst slopes in southwest China. Catena, 2012,90(1):53-62. doi: 10.1016/j.catena.2011.11.001
[25]	Wang S J, Liu Q M, Zhang D F . Karst rocky desertification in southwestern China: Geomorphology, landuse, impact and rehabilitation. Land Degradation & Development, 2004,15(2):115-121. doi: 10.1002/ldr.592
[26]	Xiong Kangning, Li Jin, Long Mingzhong . Characteristics and key issues of soil erosion in typical karst rocky desertification control areas. Acta Geographica Sinica, 2012,67(7):878-888. doi: 10.11821/xb201207002
	[ 熊康宁, 李晋, 龙明忠 . 典型喀斯特石漠化治理区水土流失特征与关键问题. 地理学报, 2012,67(7):878-888.] doi: 10.11821/xb201207002
[27]	Li Ruiling, Wang Shijie, Xiong Kangning , et al. Spatial correlation analysis between slope and rocky desertification in karst areas of Guizhou Province. Bulletin of Soil and Water Conservation, 2006,26(4):82-86. doi: 10.3969/j.issn.1000-288X.2006.04.021
	[ 李瑞玲, 王世杰, 熊康宁 , 等. 贵州省岩溶地区坡度与土地石漠化空间相关分析. 水土保持通报, 2006,26(4):82-86.] doi: 10.3969/j.issn.1000-288X.2006.04.021
[28]	Li Yangbing, Wang Shijie, Zhou Mengwei , et al. Relationship between karst rocky desertification and slope at different spatial scales. Soil and Water Conservation Research, 2009,16(5):70-72.
	[ 李阳兵, 王世杰, 周梦维 , 等. 不同空间尺度下喀斯特石漠化与坡度的关系. 水土保持研究, 2009,16(5):70-72.]
[29]	Zhang Yongrong, Zhou Zhongfa, Ma Shibin . Analysis of rocky desertification and climate change in karst mountainous area of Guizhou in recent 20 years. Environmental Science and Technology, 2014,37(9):192-197.
	[ 张勇荣, 周忠发, 马士彬 . 近20年贵州喀斯特山区石漠化与气候变化特征分析. 环境科学与技术, 2014,37(9):192-197.]
[30]	Wu Lianglin, Huang Qiuyan, Zhou Yongzhang , et al. Spatial correlation of karst rocky desertification and human activities based on GIS/RS: A case study of Du'an Yao Autonomous County in Guangxi. Soil and Water Conservation Research, 2007,14(4):121-125.
	[ 吴良林, 黄秋燕, 周永章 , 等. 基于GIS/RS的喀斯特石漠化与人文活动空间相关性研究: 以广西都安瑶族自治县为例. 水土保持研究, 2007,14(4):121-125.]
[31]	Xiong Y J, Qiu G Y, Mo D K , et al. Rocky desertification and its causes in karst areas: A case study in Yongshun County, Hunan Province, China. Environmental Geology, 2009,57(7):1481-1488. doi: 10.1007/s00254-008-1425-7
[32]	Xiao Rongbo, Ouyang Zhiyun, Wang Xiaoke , et al. Sensitivity evaluation and spatial analysis of rocky desertification in Southwest China. Chinese Journal of Ecology, 2005,1(5):551-554.
	[ 肖荣波, 欧阳志云, 王效科 , 等. 中国西南地区石漠化敏感性评价及其空间分析. 生态学杂志, 2005,1(5):551-554.]
[33]	Yin H, Jiang Z, Luo W . Study on dynamic evaluation of soil erosion and rocky desertification in karst area of Southwest China. Water and Soil Conservation Research, 2011,18(1):66-70.
[34]	Zhang H, Zhao X . Human drive mechanism of land use change in karst mountain areas: A case study of Guizhou Province. Geographical Research, 1999,18(2):136-142.
[35]	Lai C, Qin Z, Zhang W . Rocky desertification sensitivity assessment and spatial distribution characteristics of Sichuan Province. Research of Soil and Water Conservation, 2013,20(4):99-104.
[36]	LI D, Wu X, Yu D . Evaluation on eco-environmental sensitivity of Yunnan Province. Chinese Journal of Ecology, 2008,28(11):5270-5271.
[37]	Sachs E, Sarah P . Effect of raindrop temperatures on soil runoff and erosion in dry and wet soils. A laboratory experiment. Land Degradation & Development, 2017,28(12):106-112. doi: 10.1002/ldr.2682
[38]	Huang Xiaoya, Chen Xi, Zhang Zhicai , et al. Analysis of rainfall concentration and its variation characteristics in karst areas of Southwest China: A case study of the upper reaches of the Wujiang River Basin. Earth and Environment, 2013,41(3):203-208.
	[ 黄晓亚, 陈喜, 张志才 , 等. 西南喀斯特地区降雨集中度及其变化特征分析: 以乌江流域中上游为例. 地球与环境, 2013,41(3):203-208.]
[39]	Hang X, Chen X, Zhang Z . Analysis of rainfall concentration and its change characteristics in karst region of Southwest China: A case study of the middle and upper reaches of Wujiang River Basin. Earth and Environment, 2013,41(3):203-208.
[40]	Mohamadi M A, Kavian A . Effects of rainfall patterns on runoff and soil erosion in field plots. International Soil & Water Conservation Research, 2015,3(4):273-281. doi: 10.1016/j.iswcr.2015.10.001
[41]	Gonzálezpelayo O, Andreu V, Gimenogarcía E , et al. Rainfall influence on plot-scale runoff and soil loss from repeated burning Mediterranean-shrub ecosystem, Valencia, Spain. Geomorphology, 2010,118(3/4):444-452. doi: 10.1016/j.geomorph.2010.02.014

岩性类型 (面积/km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠 (km²)	石漠化总面积(km²)	发生率 (%)
连续性灰岩(39995.2)	4722.9(39.7%)	4771(55.4%)	412.9(50.8%)	9906.8	24.8
连续性白云岩(19153.2)	1383.3(11.6%)	986.5(11.4%)	228.5(28.1%)	2598.3	16.1
灰岩与白云岩互层(23568.7)	1860.8(15.6%)	1250.5(14.5%)	82.1(10.1%)	3193.4	12.0
碳酸盐岩夹碎屑岩(49402.8)	3927.8(33.1%)	1607.8(18.7%)	89.6(11.0%)	5625.2	11.4
总计(132119.9)	11894.8(100%)	8615.8(100%)	813.1(100%)	21323.7	16.1

坡度(°) (面积/km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠 (km²)	石漠化总面积 (km²)	发生率 (%)
0~8(21096.1)	1048.5(8.8%)	765.1(8.9%)	47.8(5.9%)	1861.4	8.8
8~15(36956.2)	3520.4(29.6%)	2584.2(30.0%)	230.9(28.4%)	6335.5	17.1
15~25(44495.3)	5780(48.6%)	3899.9(45.2%)	495(60.9%)	10174.9	22.9
> 25(29572.3)	1545.9(13.0%)	1366.6(15.9%)	39.4(4.8%)	2951.9	10.0
总计(132119.9)	11894.8(100%)	8615.8(100%)	813.1(100%)	21323.7	16.1

海拔(m) (面积/km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠 (km²)	石漠化总面积 (km²)	发生率 (%)
0~400(51526.7)	2048.6(17.2%)	865.1(10.0%)	47.8(5.9%)	2961.5	5.7
400~800(27745.2)	5299.6(44.6%)	3922.9(45.5%)	563.8(63.3%)	9786.3	35.3
800~1200(35672.4)	3520.5(29.6%)	2642.2(30.7%)	165.6(20.4%)	7586.0	21.3
> 1200(17175.6)	1026.1(8.6%)	1185.6(13.8%)	35.9(4.4%)	2247.6	13.1
总计(132119.9)	11894.8(100%)	8615.8(100%)	813.1(100%)	21323.7	16.1

降雨量(mm)(面积/km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠化 (km²)	石漠化总面积 (km²)	发生率 (%)
800~1000(31708.4)	1605.8(13.5%)	1852.4(21.5%)	158.6(19.5%)	3616.8	11.4
1000~1200(47564.1)	2533.6(21.3%)	3325.6(38.6%)	289.5(35.6%)	6148.7	12.9
1200~1400(32011.4)	5780.9(48.6%)	2007.5(23.3%)	221.9(27.3%)	8010.3	25.0
> 1400(20835.9)	1974.5(16.6%)	1430.2(16.6%)	143.1(17.6%)	3547.8	17.0
总计(132119.9)	11894.8(100%)	8615.8(100%)	813.1(100%)	21323.7	16.1

土地利用方式 (面积/km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠化 (km²)	石漠化总面积 km²	发生率 (%)
耕地(28515.8)	5900.4(49.6%)	4795.6(55.7%)	164.2(20.1%)	10165.6	38.1
林地(61669.1)	1881(15.8%)	683.3(7.9%)	469.6(57.8%)	2728.5	1.9
草地(29009.1)	2080.2(17.5%)	996.7(11.6%)	85.3(10.5%)	3162.2	4.9
未利用地(12925.9)	2033.2(17.1%)	2140.2(24.8%)	94.1(11.6%)	5267.4	33.0
总计(132119.9)	11894.8(100%)	8615.8(100%)	813.1(100%)	22141.7	16.8

Spatial distribution and driving factors of karst rocky desertification based on GIS and geodetectors

RichHTML

PDF (PC)

Like

Knowledge

Cited

Abstract

Cite this article

share this article

Figures/Tables 14

References 41

Related Articles 15

Metrics

Comments

人口密度(人/km²) (面积/km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠化 (km²)	石漠化总面积	发生率 (%)
0~100(36993.6)	2789.3(23.5%)	2869.2(33.3%)	141.5(17.4%)	5800.1	15.7
100~200(38314.8)	5654.8(47.5%)	3868.4(44.9%)	341.3(42.0%)	9864.5	25.7
200~300(39636.0)	1905.4(16.0%)	1758.1(20.4%)	102.8(12.6%)	3766.3	9.5
> 300(17175.6)	1545.3(13.0%)	120.0(1.4%)	227.5(28.0%)	1892.8	11.0
总计(132119.9)	11894.8(100%)	8615.8(100%)	813.1(100%)	21323.7	16.1

第一产业总值(亿元) (面积/km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠化 (km²)	石漠化总面积	发生率 (%)
0~10(47260.2)	2080.2(17.5%)	996.7(11.6%)	84.3(10.3%)	3161.2	6.7
10~25(45223.8)	2921.6(24.6%)	1683.3(19.5%)	269.6(33.2%)	4874.5	10.8
25~50(20294.3)	3033.2(25.5%)	2288.6(26.6%)	95(11.7%)	5416.8	24.7
> 50(19341.6)	3859.8(32.4%)	3647.2(42.3%)	364.2(44.8%)	7871.2	28.0
总计(132119.9)	11894.8(100%)	8615.8(100%)	813.1(100%)	20323.7	16.10

	岩性	坡度	海拔高度	年均降量	人口密度	土地利用	第一产业总值
坡度	0.21	0
海拔高度	0.47	0.27	0
年均降雨	0.15	0.14	0.32	0
人口密度	0.35	0.34	0.27	0.15	0
土地利用	0.85	0.75	0.26	0.34	0.32	0
第一产业总值	0.14	0.19	0.15	0.18	0.34	0.28	0

岩性	土地利用 (km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠化 (km²)	总计 (km²)	石漠化发生率(%)
连续性灰岩	耕地(12024.1)	1216.3(16.4%)	1629.2(13.5%)	196.9(1.6%)	3042.4	31.6
	林地(10288.7)	23.1(0.2%)	5.9(0.1%)	0.1(0%)	29	0.3
	草地(12232.1)	1977.8(9.9%)	960.5(7.9%)	39.0(0.3%)	2977.2	18.1
	未利用地(5450.4)	1121.3(20.6%)	258.9(4.8%)	16.6(0.3%)	1396.8	25.6
小计	39995.2	4338.4(36.5%)	2854.4(33.1%)	252.6(31.1%)	7445.4	15.7
连续性白云岩	耕地(4133.9)	1548.3(37.5%)	960.5(23.2%)	98.5(2.4%)	2607.3	17.0
	林地(8940.1)	75.5(0.6%)	5.8(0.1%)	1.7(0.2%)	83	0.3
	草地(4205.3)	441.8(10.5%)	213.0(5.1%)	29.0(3.6%)	683.7	4.4
	未利用地(1873.9)	870.1(7.3%)	750.4(8.7%)	59.4(7.3%)	1679.9	24.2
小计	19153.2	2935.8(15.3%)	1929.7(10.1%)	188.5(1.0%)	5054	10.7
灰岩与白云岩互层	耕地(5086.9)	1396.7(11.7%)	1015.9(11.8)	120.3(14.8%)	2533	18.1
	林地(11001.1)	0.8(0%)	5.1(0.1%)	1.9(0.2%)	7.8	0.0
	草地(5174.9)	524.2(4.4%)	203.8(2.4%)	13.4(1.6%)	741.4	5.8
	未利用地(2305.9)	757.7(6.4%)	338.5(3.4%)	84.7(10.4%)	1181	20.7
小计	23568.7	2679.4(22.5%)	1563.3(18.1%)	220.4(27.1%)	4463.1	9.3
碳酸盐岩夹碎屑岩	耕地(10662.8)	1054.9(9.9%)	923.3(8.7%)	82.9(0.8%)	2061.2	19.3
	林地(23059.5)	18.1(0.2%)	12.1(0.1%)	0.0(0%)	30.2	0.1
	草地(10847.2)	397.9(3.3%)	419.5(4.9%)	28.4(3.5%)	845.8	6.1
	未利用地(4833.3)	470.3(9.7%)	913.5(18.9%)	40.2(0.8%)	1424	22.9
小计	49402.8	1941.2(3.9%)	2268.4(4.6%)	151.6(0.3%)	4361.2	8.8

坡度	土地利用 (km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠化 (km²)	总计 (km²)	石漠化发生率(%)
0~8°	耕地(4591.7)	334.1(7.3%)	82.5(1.8%)	17.0(2.1%)	758.3	9.4
	林地(9602.7)	151.6(1.6%)	156.5(1.8%)	4.9(0.6%)	547.7	0.3
	草地(4666.3)	167.9(2.2%)	101.1(1.2%)	7.2(0.9%)	583.1	5.9
	未利用地(2235.3)	265.4(2.2%)	175.1(2.0%)	39.8(1.3%)	789.4	17.6
小计	21096.1	919.1(7.7%)	515.2(6.0%)	100.7(12.4%)	2678.5	7.0
8°~15o	耕地(7752.5)	580.5(7.5%)	327.1(4.2%)	38.4(0.5%)	1653.5	12.2
	林地(18670.2)	212.6(1.1%)	181.3(1%)	16.6(0.1%)	717.1	1.9
	草地(7914.9)	539.6(4.7%)	342.3(4.0%)	72.0(8.9%)	1663.5	10.5
	未利用地(2618.5)	411.3(3.5%)	219.4(2.5%)	26.2(3.2%)	1148.3	21.8
小计	36956.2	1744.0(14.7%)	1070.2(12.4%)	153.3(18.9)	5182.4	7.0
15°~25o	耕地(10786.7)	981.2(9.1%)	667.3(6.2%)	31.0(0.3%)	2938.9	15.6
	林地(17952.9)	411.5(3.5%)	556.8(6.5%)	19.1(2.3%)	1726.4	4.1
	草地(10976.8)	496.5(4.2%)	294.7(3.4%)	15.4(1.9%)	1411.5	7.2
	未利用地(4778.9)	564.5(4.7%)	581.0(6.7%)	59.7(7.3%)	2104.1	24.7
小计	44495.3	2453.8(20.6%)	2099.8(24.4%)	125.1(15.4%)	8180.9	9.2
坡度	土地利用 (km²)	轻度石漠化 (km²)	中度石漠化 (km²)	重度石漠化 (km²)	总计 (km²)	石漠化发生率(%)
> 25°	耕地(1525.0)	679.7(6.1%)	430.0(5.2%)	30.5(0.2%)	1994.3	15.5
	林地(17185.3)	307.0(1.8%)	209.4(1.2%)	10.2(0.1%)	921.4	3.1
	草地(6154.0)	424.6(3.6%)	299.8(3.5%)	20.9(2.6%)	1303.2	10.0
	未利用地(3707.3)	249.9(2.1%)	306.3(3.6%)	54.2(6.7%)	1062.9	17.9
小计	28571.6	1661.2(14.0%)	1245.5(9.5%)	115.8(14.2%)	5281.9	8.9

[1]	WEI Shimei, PAN Jinghu. Network structure resilience of cities at the prefecture level and above in China [J]. Acta Geographica Sinica, 2021, 76(6): 1394-1407.
[2]	ZHOU Kan, LI Hui, SHEN Yuming. Spatiotemporal patterns and driving factors of environmental stress in Beijing-Tianjin-Hebei region: A county-level analysis [J]. Acta Geographica Sinica, 2020, 75(9): 1934-1947.
[3]	GUO Zecheng, WEI Wei, SHI Peiji, ZHOU Liang, WANG Xufeng, LI Zhenya, PANG Sufei, XIE Binbin. Spatiotemporal changes of land desertification sensitivity in the arid region of Northwest China [J]. Acta Geographica Sinica, 2020, 75(9): 1948-1965.
[4]	MA Chunyue, Mamat Sawut, YAO Jie, Gulnur Isak. Spatio-temporal changes of cotton production in China from 1950 to 2015 [J]. Acta Geographica Sinica, 2020, 75(8): 1699-1710.
[5]	LIU Yujie, GE Quansheng, DAI Junhu. Research progress in crop phenology under global climate change [J]. Acta Geographica Sinica, 2020, 75(1): 14-24.
[6]	Yafei WANG, Jie FAN. The core-periphery structure of Major Function Zones in China [J]. Acta Geographica Sinica, 2019, 74(4): 710-722.
[7]	WANG Yang,WANG Lili,QI Pengwei,LIU Zhihai. Revealing the dominant factors and spatial stability restrictive mechanism for Major Function-Oriented Zoning in Chongqing municipality [J]. Acta Geographica Sinica, 2019, 74(1): 44-62.
[8]	CAO Xiaoshu, XU Jianbin. Spatial heterogeneity analysis of regional economic development and driving factors in China's provincial border counties [J]. Acta Geographica Sinica, 2018, 73(6): 1065-1075.
[9]	Tao LI, Jiaming LIU, Lei WANG, He ZHU, Ling YU. Spatial differences in international investment in hotels and its driving factors in China [J]. Acta Geographica Sinica, 2017, 72(10): 1904-1919.
[10]	Peng LU, Yan TIAN, Panpan CHEN, Duowen MO. Spatial and temporal modes of prehistoric settlement distribution around Songshan Mountain [J]. Acta Geographica Sinica, 2016, 71(9): 1629-1639.
[11]	Jun YANG, Yuting GE, Jianchao XI, Quansheng GE, Xueming LI. Spatial-temporal island tourismification effects differentiation of Changhai county [J]. Acta Geographica Sinica, 2016, 71(6): 1074-1094.
[12]	Zhaoqing HAN, Youhua RAN, Junxiu LIU, Jun LI. The changing distribution of rocky desertification in the Guangxi Region, 1930s to 2000 [J]. Acta Geographica Sinica, 2016, 71(3): 390-399.
[13]	Shanju BAO, Lin LU. Impact of planning-guided spatial evolvement on temporal-spatial evolution of land price: Taking Hefei as an example [J]. Acta Geographica Sinica, 2015, 70(6): 906-918.
[14]	YANG Xingzhu, WANG Qun. Evaluation of rural human settlement quality difference and its driving factors in tourism area of southern Anhui Province [J]. Acta Geographica Sinica, 2013, 68(6): 851-867.
[15]	WANG Jiao'e, HU Hao. Competition and cooperation of high-speed rail and air transport in China: A perspective from spatial service market view [J]. Acta Geographica Sinica, 2013, 68(2): 175-185.
