基于能量的鄱阳湖—长江相互作用表征指标研究

doi:10.11821/dlxb201709009

Abstract

Abstract:

The complicated relationship between the Yangtze River and Poyang Lake is the factor determining the exchange of water and sediment between them and has great influence on the water resources, flood control, navigation, and ecological environment of the entire region. Based on the theory of energy, this paper explains the principle of the river-lake relationship from a new perspective. By constructing a new index F_e, the authors were able to analyze the evolution of the relationship between the Yangtze River and Poyang Lake since the 1950s. The results indicate that the value of F_e shows an increasing trend, which means the river effect is weakening while the lake effect is strengthening. Operation of the Three Gorges Dam has an important impact on the river-lake relationship, which further weakens the river effect. The river effect increases slightly in the dry season but decreases significantly at the end of the flood period. In addition, the relationship between the Yangtze River and Poyang Lake may induce drought and flood disasters to some degree. Flooding is more likely to occur when flow from the five tributaries of the Poyang Lake is large and the Yangtze River blocking effect is strong. In contrast, drought is more likely to occur when flow from the five tributaries of the Poyang Lake is small, while the lake effect is strong. Meanwhile, the probability of drought in the Poyang Lake from September to October increases due to the impounding of the Three Gorges Reservoir.

Key words: Poyang Lake, Yangtze River, river-lake relationship, Three Gorges Dam, characterization index

Jinyun DENG, Shaoying FAN. Characterization index for expressing the relationship between the Yangtze River and Poyang Lake based on the theory of energy[J].Acta Geographica Sinica, 2017, 72(9): 1645-1654.

Figures/Tables 10

Fig. 1

Tab. 1

Fig. 2

Tab. 2

Fig. 3

Fig. 4

Tab. 3

Fig. 5

Tab. 4

Tab. 5

Reasonableness analysis of Fe using 2011 hydrological data

月份	$I FJ$	$I FW$	F_e	$I QJ$	$I QW$	月份	$I FJ$	$I FW$	F_e	$I QJ$	$I QW$
1月	0.32	0.39	0.066	0.10^*	0.08^*	7月	0.29	0.09	-0.049	0.73	0.28
2月	0.31	0.43	0.077	0.04	0.06	8月	0.52	0.14	-0.065	0.63	0.10
3月	0.30	0.46	0.091	0.06	0.09	9月	0.54	0.24	-0.020	0.41	0.07
4月	0.35	0.44	0.066	0.10^*	0.08^*	10月	0.30	0.31	0.026	0.23	0.10
5月	0.29	0.46	0.084	0.10	0.12	11月	0.48^*	0.32^*	0.019	0.26^*	0.07^*
6月	0.33	0.34	0.023	0.60^*	0.37^*	12月	0.34	0.41	0.069	0.05^*	0.05^*

Tab. 5

References 20

[1]	Liu Zhigang, Ni Zhaokui.The rules and the effects of varing river-lake relationships on the evolution of Poyang Lake. Acta Scientiae Circumstantiae, 2015, 35(5): 1265-1273.
	[刘志刚, 倪兆奎. 鄱阳湖发展演变及江湖关系变化影响. 环境科学学报, 2015, 35(5): 1265-1273.]
[2]	Wan Rongrong, Yang Guishan, Wang Xiaolong, et al.Progress of research on the relationship between the Yangtze River and its connected lakes in the middle reaches. Journal of Lake Science, 2014, 26(1): 1-8. doi: 10.18307/2014.0101
	[万荣荣, 杨桂山, 王晓龙, 等. 长江中游通江湖泊江湖关系研究进展. 湖泊科学, 2014, 26(1): 1-8.] doi: 10.18307/2014.0101
[3]	Zhao Junkai, Li Jiufa, Dai Zhijun, etal. Analysis of water exchange between river and lakes in the middle and lower Yangtze River in low flow years. Journal of Natural Resources, 2011, 26(9): 1613-1624. doi: 10.11849/zrzyxb.2011.09.017
	[赵军凯. 枯水年长江中下游江湖水交换作用分析. 自然资源学报, 2011, 26(9): 1613-1624.] doi: 10.11849/zrzyxb.2011.09.017
[4]	Wang Dong, Li Yitian, Deng Jinyun, et al.Preliminary analysis of changes in hydraulic elements of Dongting Lake instorage period of Three Gorges Reservoir. Journal of Hydroelectric Engineering, 2014, 33(2): 26-32. doi: 10.3724/SP.J.1105.2011.10334
	[王冬, 李义天, 邓金运, 等. 三峡水库蓄水期洞庭湖水力要素变化初步分析. 水力发电学报, 2014, 33(2): 26-32.] doi: 10.3724/SP.J.1105.2011.10334
[5]	Lai Xijun, Huang Qun, Zhang Yinghao, et al.Discharge capacity analysis on Poyang Lake. Journal of Lake Science, 2014, 26(4): 529-534.
	[赖锡军, 黄群, 张英豪, 等. 鄱阳湖泄流能力分析. 湖泊科学, 2014, 26(4): 529-534.]
[6]	Eddy C C, Colin B I G, Christopher H P, et al. Importance of lake-river interaction on seasonal patterns in the general circulation of Kamloops Lake, British Columbia. Limnol. Oceanogr., 1979, 24(4): 634-644. doi: 10.4319/lo.1979.24.4.0634
[7]	Kneis D, Knoesche R, Bronstert A, et al.Analysis and simulation of nutrient retention and management for a lowland river-lake system. Hydrology & Earth System Sciences, 2006, 26(1): 121-124. doi: 10.5194/hess-10-575-2006
[8]	Elisa M, Gara J I, Wolanski E.A review of the water crisis in Tanzania's protected areas, with emphasis on the Katuma river-Lake Rukwa ecosystem. Ecohydrology & Hydrobiology, 2010, 10(2-4): 153-165. doi: 10.2478/v10104-011-0001-z
[9]	Guo Hua, Hu Qi, Zhang Qi.Changes in hydrological interactions of the Yangtze River and the Poyang Lake in China during 1957-2008. Acta Geographica Sinica, 2011, 66(5): 609-618. doi: 10.11821/xb201105004
	[郭华, Hu Qi, 张奇. 近50年来长江与鄱阳湖水文相互作用的变化. 地理学报, 2011, 66(5): 609-618.] doi: 10.11821/xb201105004
[10]	Fang Chunming, Cao Wenhong, Mao Jixin, et al.Relationship between Poyang Lake and Yangtze River and the influence of Three Gorges Reservoir. Journal of Hydraulic Engineering, 2012, 43(2): 175-181.
	[方春明, 曹文洪, 毛继新, 等. 鄱阳湖与长江关系及三峡蓄水的影响. 水利学报, 2012, 43(2): 175-181.]
[11]	Hu Q, Feng S, Guo H, et al.Interactions of the Yangtze River flow and hydrologic process of the Poyang Lake, China. Journal of Hydrology, 2007, 347: 90-100. doi: 10.1016/j.jhydrol.2007.09.005
[12]	Dai X, Wan R R, Yang G S.Non-stationary water level fluctuation in China's Poyang Lake and its interactions with Yangtze River. Journal of Geographical Sciences, 2015, 25(3): 274-288. doi: 10.1007/s11442-015-1167-x
[13]	Du Yanliang, Zhou Huaidong, Peng Wenqi, et al.Modeling the impacts of the change of river-lake relationship on the hydrodynamic and water quality revolution in Poyang Lake. Acta Scientiae Circumstantiae, 2015, 35(5): 1274-1284. doi: 10.13671/j.hjkxxb.2014.1047
	[杜彦良, 周怀东, 彭文启, 等. 近10年流域江湖关系变化作用下鄱阳湖水动力及水质特征模拟. 环境科学学报, 2015, 35(5): 1274-1284.] doi: 10.13671/j.hjkxxb.2014.1047
[14]	Ye Xuchun, Li Xianghu, Zhang Qi.Temporal variation of backflow frequency from the Yangtze River to Poyang Lake and its influencing factors. Journal of Southwest University (Natural Science Edition), 2012, 34(11): 69-75.
	[叶许春, 李相虎, 张奇. 长江倒灌鄱阳湖的时序变化特征及其影响因素. 西南大学学报(自然科学版), 2012, 34(11): 69-75.]
[15]	Guo Hua, Hu Qi, Zhang Qi, et al.Annual variations in climatic and hydrological processes and related flood and drought occurrences in the Poyang Lake basin. Acta Geographica Sinica, 2012, 67(5): 699-709. doi: 10.1007/s11783-011-0280-z
	[郭华, Hu Qi, 张奇, 等. 鄱阳湖流域水文变化特征成因及旱涝规律. 地理学报, 2012, 67(5): 699-709.] doi: 10.1007/s11783-011-0280-z
[16]	Zhang Z X, Chen X, Xu C Y, et al.Examining the influence of river-lake interaction on the drought and water resources in the Poyang Lake basin. Journal of Hydrology, 2015, 522: 510-521. doi: 10.1016/j.jhydrol.2015.01.008
[17]	Guo H, Hu Q, Zhang Q, et al. Effects of the Three Gorges Dam on Yangtze River flow and river interaction with Poyang Lake, China:2003-2008. Journal of Hydrology, 2012, 416/417: 19-27.
[18]	Hu Chunhong, Wang Yangui.Sediment problems and relationship between river and lakes since the operation of Three Gorges Project. Journal of Yangtze River Scientific Research Institute, 2014, 31(5): 107-116. doi: 10.3969/j.issn.1001-5485.2014.05.022
	[胡春宏, 王延贵. 三峡工程运行后泥沙问题与江湖关系变化. 长江科学院院报, 2014, 31(5): 107-116.] doi: 10.3969/j.issn.1001-5485.2014.05.022
[19]	Zhang Q, Ye X C, Werner A, et al.An investigation of enhanced recessions in Poyang Lake: Comparison of Yangtze River and local catchment. Journal of Hydrology, 2014, 517: 425-434. doi: 10.1016/j.jhydrol.2014.05.051
[20]	Zhang ZX, Huang Y H, Xu C Y, et al.Analysis of Poyang Lake water balance and its indication of river-lake interaction. SpringerPlus, 2016, 5(1): 1555. doi: 10.1186/s40064-016-3239-5 pmid: 5021641

作用	整体主要表现	原理	湖口处的主要表现
长江作用	顶托作用	长江来流能量增加	势能增加不利于出流
鄱阳湖作用	补水作用	五河来流能量增加	动能增加利于出流

年份	F_e	年份	F_e	年份	F_e	年份	F_e	年份	F_e
1953年	0.009	1967年	-0.011	1980年	-0.022	1993年	-0.012	2006年	0.062
1954年	-0.025	1968年	-0.024	1981年	-0.009	1994年	0.014	2007年	0.009
1955年	-0.009	1969年	0.006	1982年	-0.027	1995年	0.013	2008年	0.010
1956年	0.002	1970年	0.005	1983年	-0.030	1996年	-0.017	2009年	0.010
1957年	0.004	1971年	-0.004	1984年	-0.010	1997年	0.026	2010年	0.025
1958年	0.005	1972年	0.019	1985年	-0.015	1998年	-0.006	2011年	0.030
1959年	0.025	1973年	0.005	1986年	0.005	1999年	0.009	2012年	0.020
1960年	0.018	1974年	-0.018	1987年	-0.009	2000年	-0.010	2013年	0.029
1961年	0.016	1975年	0.000	1988年	0.010	2001年	0.015	2014年	0.009
1962年	0.012	1976年	0.010	1989年	-0.029	2002年	0.006
1963年	-0.028	1977年	-0.002	1990年	-0.029	2003年	-0.014
1964年	-0.049	1978年	0.014	1991年	-0.032	2004年	-0.008
1965年	-0.025	1979年	0.002	1992年	0.024	2005年	-0.005

月份	1953-2002年	2004-2014年	变化率(%)	月份	1953-2002年	2004-2014年	变化率(%)
1月	8307	10252	23	7月	43330	36982	-15
2月	8387	10401	24	8月	38188	33843	-11
3月	10820	13199	22	9月	35332	30016	-15
4月	16362	16279	-1	10月	27701	19601	-29
5月	24730	23159	-6	11月	17950	16045	-11
6月	30052	30713	2	12月	11085	11524	4
