三峡大坝下游水位变化与河道形态调整关系研究

doi:10.11821/dlxb201705002

Abstract

Abstract:

In this study, data measured from 1955-2016 was analyzed to study the relationship between the water level and river channel geometry adjustment in the downstream of the Three Gorges Dam (TGD) after the impoundment of the dam. The results highlighted the following facts: (1) for the same flow, the drought water level decreased, however, flood water level changed little. The lowest water level increased, while the highest water level decreased at the hydrologic stations in the downstream of the dam; (2) the distribution of erosion and deposition along the river channel changed from "erosion at channels and deposition at bankfulls" to "erosion at both channels and bankfulls"; the ratio of low water channel erosion to bankfull channel erosion was 95.5% from October 2002 to October 2015, with variations in different impoundment stages; (3) the drought water level decrease slowed down during the channel erosion in the Upper Jingjiang River and the reaches ahead but sped up in the Lower Jingjiang River and the reaches behind; concrete measures should be taken to prevent the decrease in the channel water level; (4) erosion was the basis for channel dimension upscaling in the middle reaches of the Yangtze River; the drought water level decrease was smaller than the thalweg decline; both channel water depth and width increased under the combined effects of the channel and waterway regulations; and (5) the geometry of the channels above the bankfulls did not change much; however, the comprehensive channel resistance increased under the combined effects of the river bed coarsening, bench vegetation, and human activities; as a result, the flood water level increased markedly and moderate flood to high water level phenomena occurred, which should be considered. The Three Gorges Reservoir effectively enhances the flood defense capacity of the middle and lower reaches of the Yangtze River; however, the superposition effect of tributary floods cannot be ruled out.

Key words: low water level, flood level, riverbed adjustment, cause analysis, Three Gorges Dam, middle and lower reaches of the Yangtze River

Yunping YANG, Mingjin ZHANG, Zhaohua SUN, Jianqiao HAN, Huaguo LI, Xingying YOU. The relationship between water level change and river channel geometry adjustment in the downstream of the Three Gorges Dam (TGD)[J].Acta Geographica Sinica, 2017, 72(5): 776-789.

Figures/Tables 14

Fig. 1

Tab. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Tab. 2

Fig. 6

Fig. 7

Fig. 8

Fig. 9

Tab. 3

Fig. 10

Fig. 11

References 37

[1]	Zheng Shouren.Reflections on the Three Gorges Project since its operation. Engineering, 2016(2): 389-397.
[2]	Chen Zhongyuan, Wang Zhanghua, Finlayson Brian, et al.Implications of flow control by the Three Gorges Dam on sediment and channel dynamics of the Middle Yangtze (Changjiang) River, China. Geology, 2010, 38(11): 1043-1046. doi: 10.1130/G31271.1
[3]	Yuan Weihao, Yin Daowei, Finlayson Brian, et al. Assessing the potential for change in the middle Yangtze River channel following impoundment of the Three Gorges Dam. Geomorphology, 2012, 147/148(8): 27-34.
[4]	Dai Zhijun, Liu James T.Impacts of large dams on downstream fluvial sedimentation: An example of the Three Gorges Dam (TGD) on the Changjiang (Yangtze River). Journal of Hydrology, 2013, 480(4): 10-18. doi: 10.1016/j.jhydrol.2012.12.003
[5]	Dai S B, Lu X X.Sediment load change in the Yangtze River (Changjiang): A review. Geomorphology, 2014, 215(12): 60-73. doi: 10.1016/j.geomorph.2013.05.027
[6]	Xu Quanxi, Yuan Jing, Wu Wenjun, et al.Fluvial processes in middle Yangtze River after impoundment of Three Gorges Project. Journal of Sediment Research, 2011(2): 38-46.
	[许全喜, 袁晶, 伍文俊, 等. 三峡工程蓄水运用后长江中游河道演变初步研究. 泥沙研究, 2011(2): 38-46.]
[7]	Xu Quanxi.Research on reservoir sedimentation and downstream channel erosion of dam after impoundment of Three Gorges Reservoir. Yangtze River, 2012, 43(7): 1-6. doi: 10.3969/j.issn.1001-4179.2012.07.001
	[许全喜. 三峡水库蓄水以来水库淤积和坝下游冲刷研究. 人民长江, 2012, 43(7): 1-6.] doi: 10.3969/j.issn.1001-4179.2012.07.001
[8]	Han Jianqiao, Sun Zhaohua, Huang Ying, et al.Features and causes of sediment deposition and erosion in Jingjiang reach after impoundment of the Three Gorges Project. Journal of Hydraulic Engineering, 2014, 45(3): 277-285, 286. doi: 10.13243/j.cnki.slxb.2014.03.004
	[韩剑桥, 孙昭华, 黄颖, 等. 三峡水库蓄水后荆江沙质河段冲淤分布特征及成因. 水利学报, 2014, 45(3): 277-285, 286.] doi: 10.13243/j.cnki.slxb.2014.03.004
[9]	Xu Quanxi, Zhu Lingling, Yuan Jing.Research on water-sediment variation and deposition-erosion in middle and lower Yangtze River. Yangtze River, 2013, 44(23): 16-21. doi: 10.3969/j.issn.1001-4179.2013.23.004
	[许全喜, 朱玲玲, 袁晶. 长江中下游水沙与河床冲淤变化特征研究. 人民长江, 2013, 44(23): 16-21.] doi: 10.3969/j.issn.1001-4179.2013.23.004
[10]	Sun Zhaohua, Huang Ying, Cao Qixin, et al.Spatial and temporal variations of the low flow stage in the immediate downstream reach of the Three Georges Dam. Journal of Basic Science and Engineering, 2015, 23(4): 694-704.
	[孙昭华, 黄颖, 曹绮欣, 等. 三峡近坝段枯水位降幅的时空分异性及成因. 应用基础与工程科学学报, 2015, 23(4): 694-704.]
[11]	Lu Yongjun, Chen Zhicong, Zhai Lianbai, et al.Impact of the Three Gorges Project on the water level and navigation channel in the near-dam reach downstream the Gezhouba Project. Engineering Science 2002, 4(10): 67-72.
	[陆永军, 陈稚聪, 赵连白, 等. 三峡工程对葛洲坝枢纽下游近坝段水位与航道影响研究. 中国工程科学, 2002, 4(10): 67-72.]
[12]	Fang Hongwei, Han Dong, He Guojian, et al. Flood management selections for the Yangtze River midstream after the Three Gorges Project operation. Journal of Hydrology, 2012, 432/433(8): 1-11.
[13]	Bormann Helge, Pinter Nicholas, Elfert Simon.Hydrological signatures of flood trends on German rivers: Flood frequencies, flood heights and specific stages. Journal of Hydrology, 2011, 404(1/2): 50-66. doi: 10.1016/j.jhydrol.2011.04.019
[14]	Jiang Jiahu, Huang Qun.Sub-element method for seepage analysis with free surface. Journal of Hydraulic Engineering, 1997(8): 40-44.
	[姜加虎, 黄群. 三峡工程对其下游长江水位影响研究. 水利学报, 1997(8): 40-44.]
[15]	Li Yitian, Sun Zhaohua, Liu Yun, et al.Channel degradation downstream from the Three Gorges Project and its impacts on flood level. Journal of Hydraulic Engineering, 2009, 135(9): 718-728. doi: 10.1061/(ASCE)0733-9429(2009)135:9(718)
[16]	Zhang Man, Zhou Jianjun, Huang Guoxian.Flood control problems in middle reaches of Yangtze River and countermeasures. Water Resources Protection, 2016, 32(4): 1-10. doi: 10.3880/j.issn.1004-6933.2016.04.001
	[张曼, 周建军, 黄国鲜. 长江中游防洪问题与对策. 水资源保护, 2016, 32(4): 1-10.] doi: 10.3880/j.issn.1004-6933.2016.04.001
[17]	Mei Xuefei, Dai Zhijun, Gelder P H A J M, et al. Linking Three Gorges Dam and downstream hydrological regimes along the Yangtze River, China. Earth and Space Science, 2015, 2(4): 94-106. doi: 10.1002/2014EA000052
[18]	Moshe L B, Haviv I, Enzel Y, et al.Incision of alluvial channels in response to a continuous base level fall: Field characterization, modeling, and validation along the Dead Sea. Geomorphology, 2008, 93(3/4): 524-536. doi: 10.1016/j.geomorph.2007.03.014
[19]	Greene S L, Knox J C.Coupling legacy geomorphic surface facies to riparian vegetation: Assessing red cedar invasion along the Missouri River downstream of Gavins Point dam, South Dakota. Geomorphology, 2014, 204(1): 277-286. doi: 10.1016/j.geomorph.2013.08.012
[20]	Yang S L, Xu K H, Milliman J D, et al.Decline of Yangtze River water and sediment discharge: Impact from natural and anthropogenic changes. Scientific Reports, 2015, (5): 12581. doi: 10.1038/srep12581 pmid: 26206169
[21]	Maren D S V, Yang Shilun, He Qing. The impact of silt trapping in large reservoirs on downstream morphology: The Yangtze River. Ocean Dynamics, 2013, 63(6): 691-707. doi: 10.1007/s10236-013-0622-4
[22]	Cao Fengshuai, Xiao Xin, Wu Peng, et al.Yangtze River: China's golden waterway. Civil Engineering, 2010, 163(5): 15-18. doi: 10.1680/cien.2010.163.5.15
[23]	Zhu Lingling, Chen Jianchi, Yuan Jing, et al.Sediment erosion and deposition in two lakes connected with middle Yangtze River and the impact of Three Gorges Reservoir. Advances in Water Science, 2015, 25(3): 348-357.
	[朱玲玲, 陈剑池, 袁晶, 等. 洞庭湖和鄱阳湖泥沙冲淤特征及三峡水库对其影响. 水科学进展, 2015, 25(3): 348-357.]
[24]	Zhang Qiang, Shi Yafeng, Xiong Ming, et al.Geometric properties of river cross sections and associated hydrodynamic implications in Wuhan-Jiujiang river reach, the Yangtze River. Journal of Geographical Sciences, 2009, 19(1): 58-66. doi: 10.1007/s11442-009-0058-4
[25]	Shi Yafeng, Zhang Qiang, Chen Zhongyuan, et al.Channel morphology and its impact on flood passage, the Tianjiazhen reach of the middle Yangtze River. Geomorphology, 2007, 85(3): 176-184. doi: 10.1016/j.geomorph.2006.03.019
[26]	Yu Minghui, Duan Wenzhong, Yu Weiqing.Analysis of river bed change of Yangtze River and flood level variation. Engineering Journal of Wuhan University, 2005, 38(3): 1-5, 18. doi: 10.3969/j.issn.1671-8844.2005.03.001
	[余明辉, 段文忠, 余蔚卿. 长江中下游河床冲淤与洪水位变化. 武汉大学学报(工学版), 2005, 38(3): 1-5, 18.] doi: 10.3969/j.issn.1671-8844.2005.03.001
[27]	Tang Jinwu, Li Yitian, Sun Zhaohua, et al.Preliminary study on the changes of water level at Chenglingji Station after the impoundment of the Three Gorges Project (TGP). Journal of Basic Science and Engineering, 2010, 18(2): 273-280. doi: 10.3969/j.issn.1005-0930.2010.02.0010
	[唐金武, 李义天, 孙昭华, 等. 三峡蓄水后城陵矶水位变化初步研究. 应用基础与工程科学学报, 2010, 18(2): 273-280.] doi: 10.3969/j.issn.1005-0930.2010.02.0010
[28]	Zheng Shouren.Risk analysis of implementing middle-small flood dispatch by Three Gorges Project and countermeasures. Yangtze River, 2015, 46(5): 7-12.
	[郑守仁. 三峡水库实施中小洪水调度风险分析及对策探讨. 人民长江, 2015, 46(5): 7-12.]
[29]	Yang Yunping, Zhang Mingjin, Li Yitian, et al.Suspended sediment recovery and bedsand compensation mechanism affected by the Three Gorges Project. Acta Geographica Sinica, 2016, 71(7): 1241-1254.
	[杨云平, 张明进, 李义天, 等. 长江三峡水坝下游河道悬沙恢复和床沙补给机制. 地理学报, 2016, 71(7): 1241-1254.]
[30]	Zhang Wei, Yang Yunping, Zhang Mingjin, et al.Mechanisms of suspended sediment restoration and bed level compensation in downstream reaches of the Three Gorges Projects (TGP). Journal of Geographical Sciences, 2017, 27(4): 463-480. doi: 10.1007/s11442-017-1387-3
[31]	Han Jianqiao.The interaction mechanism between longitudinal water and sediment transport and channel morphology in the downstream of Three Gorges Reservoir [D]. Wuhan: Wuhan University, 2015.
	[韩剑桥. 三峡水库下游纵向水沙输移与河道形态相互作用机制研究[D]. 武汉: 武汉大学, 2015.]
[32]	Chen S C, Chan H C, Li Y H.Observations on flow and local scour around submerged flexible vegetation. Advances in Water Resources, 2012, 43(6): 28-37. doi: 10.1016/j.advwatres.2012.03.017
[33]	Heidi M Nepf.Hydrodynamics of vegetated channels. Journal of Hydraulic Research, 2012, 50(50): 262-279.
[34]	Day J, Cable J, Lane R, et al.Sediment deposition at the Caernarvon Crevasse during the Great Mississippi Flood of 1927: Implications for coastal restoration. Water, 2016, 8(2): 38. doi: 10.3390/w8020038
[35]	Carle M V, Sasser C E, Roberts H H.Accretion and vegetation community change in the Wax Lake Delta following the historic 2011 Mississippi River Flood. Journal of Coastal Research, 2015, 313(3): 569-587. doi: 10.2112/JCOASTRES-D-13-00109.1
[36]	Zhang Xibing, Lu Jinyou, Li Qiusheng.Preliminary study on accumulated influence of the bankline use on flood control in the middle and lower reaches of the Yangtze River. Resources and Environment in the Yangtze Basin, 2011, 20(9): 1138-1142.
	[张细兵, 卢金友, 蔺秋生. 长江中下游岸线利用对防洪累积影响初步研究. 长江流域资源与环境, 2011, 20(9): 1138-1142.]
[37]	Changjiang River Scientific Research Institute of Changjiang River Water Resources Commission. Yichang to Anqing improving waterway standard effects on flood control and river regime control report in Yangtze River [R]. 2015: 299-308.
	[长江水利委员会长江科学院. 长江宜昌至安庆段提高航道标准对河势控制与防洪影响报告 [R].2015: 299-308.]

序号	水文站及河段	资料内容	资料长度	数据来源
1	宜昌、枝城、沙市、监利、螺山、汉口、大通	水量、输沙量、流量、水位	1955-2016年	长江泥沙公报长江水利委员会水文局
2	洞庭湖三口、城陵矶鄱阳湖湖口	水量、沙量、流量	1955-2016年	长江泥沙公报长江水利委员会水文局
3	宜昌—湖口河段	冲淤量	1987-2015年	长江水利委员会水文局
4	宜昌—汉口水尺	水位	1981-2014年	长江航道规划设计研究院

时间段	河段名称	宜昌—枝城	上荆江	下荆江	城陵矶—汉口	汉口—湖口
时间段	河长(km)	60.8	171.7	175.5	251.0	295.4
三峡水库蓄水前（1981-2002年）	枯水河槽(%)	102.0	100.6	9.2	17.5	69.6
	低滩(%)	-2.0	-0.6	-109.2	-117.5	-169.6
	高滩(%)	-2.0	-0.6	-109.2	-117.5	-169.6
2003-2008年 (2002年10月-2008年10月)	枯水河槽(%)	88.6	89.6	73.2	301.8	60.4
	低滩(%)	1.7	2.2	11.6	-30.7	48.3
	高滩(%)	9.6	8.2	15.2	-171.1	-8.7
2009-2014年 (2008年10月-2015年11月)	枯水河槽(%)	96.4	94.0	95.4	95.3	115.0
	低滩(%)	4.8	3.1	-0.4	5.8	-11.4
	高滩(%)	-1.1	2.9	5.0	-1.1	-3.6

河床组成类型	砂卵石河段	砂卵石~沙质过渡段	沙质河段
河段	宜昌—枝城(61 km)	枝城—大埠街(50 km)	荆江沙质段(208 km)	城陵矶—湖口(546 km)
增加倍数	1.91	1.65	1.03	1.02
