SWH双源蒸散模型模拟效果验证及不确定性分析

doi:10.11821/dlxb201611002

Abstract

Abstract:

Evapotranspiration (ET) is one of the core processes of water cycle in ecosystem and ET modeling is a hotspot and frontier in the field of the global climate changes. It is therefore important to provide spatiotemporal information of ET across diverse ecosystems in order to predict the response of ecosystem carbon and water cycles to changes in global climate and land use. The SWH model incorporates the Ball-Berry stomatal conductance model and a light use efficiency-based gross primary productivity (GPP) model into the Shuttleworth-Wallace model, which can simulate both ET and GPP. The newly developed SWH model presents a satisfactory prediction ability of simulating ET in a forest and a grassland ecosystem, respectively. However, the SWH model still lacks comprehensive evaluation and uncertainty analysis at regional scale. In this study, we (1) tested the model's performances on estimating ET and GPP at seasonal and annual time scales; (2) quantified the uncertainties of the model parameters and driving variables, including Normalized Difference Vegetation Index, NDVI and meteorological data; (3) quantified the sensitivity of model outputs to the parameters and driving variables; (4) quantified and separated the uncertainties of ET simulation from the parameters and driving variables. Results showed that the SWH model performed well for ET simulation at regional scale as indicated by high coefficient of determination (R² = 0.75) of linear regression of modeled against measured ET. Among the key parameters in the SWH model, two parameters related to estimating canopy stomatal conductance (g₀and a₁) make great contribution to the model uncertainty. Among the forcing variables, NDVI is most critical in estimating GPP, which contributes much to uncertainty in ET simulation. In comparison, the climatic forcing variables contributes less to uncertainty in ET simulation owing to the high accuracy of the climate data (such as radiation and air temperature) or model’s low sensitivities to some variables (such as precipitation).

Key words: SWH model, Shuttleworth-Wallace model, evapotranspiration, uncertainty analysis

Genan WU, Zhongmin HU, Shenggong LI, Han ZHENG, Xianjin ZHU, Xiaomin SUN, Guirui YU, Jingbao LI. Evaluation and uncertainty analysis of a two-source evapotranspiration model[J].Acta Geographica Sinica, 2016, 71(11): 1886-1897.

Figures/Tables 11

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Tab. 1

Tab. 2

Tab. 3

Tab. 4

Tab. 5

Tab. 6

References 19

[1]	Yang Y, Long D, Shang S.Remote estimation of terrestrial evapotranspiration without using meteorological data. Geophysical Research Letters, 2013, 40(12): 3026-3030. doi: 10.1002/grl.50450
[2]	Oki T,Kanae S.Global hydrological cycles and world water resources. Science, 2006, 313(5790): 1068-1072. doi: 10.1126/science.1128845 pmid: 16931749
[3]	Stannard D I.Comparison of Penman-Monteith, Shuttleworth-Wallace, and modified Priestley-Taylor evapotranspiration models for wildland vegetation in semiarid rangeland. Water Resources Research, 1993, 29(5): 1379-1392. doi: 10.1029/93WR00333
[4]	Zhang B, Kang S, Li F, et al.Comparison of three evapotranspiration models to Bowen ratio-energy balance method for a vineyard in an and desert region of Northwest China. Agricultural and Forest Meteorology, 2008, 148(10): 1629-1640. doi: 10.1016/j.agrformet.2008.05.016
[5]	Ortega-Farias S, Poblete-Echeverría C, Brisson N.Parameterization of a two-layer model for estimating vineyard evapotranspiration using meteorological measurements. Agricultural and Forest Meteorology, 2010, 150(2): 276-286. doi: 10.1016/j.agrformet.2009.11.012
[6]	Bing Longfei, Su Hongbo, Shao Quanqin, et al.Changing characteristic of land surface evapotranspiration and soil moisture in China during the past 30 years. Journal of Geo-Information Science, 2012, 14(1): 1-13. doi: 10.3724/SP.J.1047.2012.00001
	[邴龙飞, 苏红波, 邵全琴, 等. 近30年来中国陆地蒸散量和土壤水分变化特征分析. 地球信息科学学报, 2012, 14(1): 1-13.] doi: 10.3724/SP.J.1047.2012.00001
[7]	Kato Tomomichi, Reiji Kimura, et al.Estimation of evapotranspiration, transpiration ratio and water-use efficiency from a sparse canopy using a compartment model. Agricultural Water Management, 2004, 65: 173-191. doi: 10.1016/j.agwat.2003.10.001
[8]	Brisson N, Itier B, L'Hotel J C, et al. Parameterization of the Shuttleworth-Wallace model to estimate daily maximum transpiration for use in crop model. Ecology Modeling, 1998, 107: 159-169. doi: 10.1016/S0304-3800(97)00215-9
[9]	Zhang L, Zhou D, Fan J, et al.Comparison of four light use efficiency models for estimating terrestrial gross primary production. Ecological Modeling, 2015, 300: 30-39. doi: 10.1016/j.ecolmodel.2015.01.001
[10]	Hu Z, Li S, Yu G, et al.Modeling evapotranspiration by combining a two-source model, a leaf stomatal model, and a light-use efficiency model. Journal of Hydrology, 2013, 501(25): 186-192. doi: 10.1016/j.jhydrol.2013.08.006
[11]	Hu Z, Yu G, Zhou Y, et al.Partitioning of evapotranspiration and its controls in four grassland ecosystems: Application of a two-source model. Agricultural and Forest Meteorology, 2009, 149: 1410-1420. doi: 10.1016/j.agrformet.2009.03.014
[12]	Zhang L, Hu Z, Fan J, et al.A meta-analysis of the canopy light extinction coefficient in terrestrial ecosystems. Frontiers of Earth Science, 2014, 8(4): 599-609. doi: 10.1007/s11707-014-0446-7
[13]	Shuttleworth W J, Wallace J S.Evaporation from sparse crops: An energy combination theory. Quarterly Journal of the Royal Meteorological Society, 1985, 111: 839-855. doi: 10.1002/qj.49711146910
[14]	Yu G, Wen X, Sun X, et al.Overview of ChinaFLUX and evaluation of its eddy covariance measurement. Agricultural and Forest Meteorology, 2006, 137(3): 125-137. doi: 10.1016/j.agrformet.2006.02.011
[15]	Yu G, Zhu X, Fu Y, et al.Spatial patterns and climate drivers of carbon fluxes in terrestrial ecosystems of China. Global Change Biology, 2013, 19(3): 798-810. doi: 10.1111/gcb.12079
[16]	Zhang L, Yu G, Gu F, et al.Uncertainty analysis of modeled carbon fluxes for a broad-leaved Korean pine mixed forest using a process-based ecosystem model. Journal of Forest Research, 2012, 17: 286-282. doi: 10.1007/s10310-011-0305-2
[17]	Lunetta R S, Ediriwickrema J, Johnson D M, et al.Impacts of vegetation dynamics on the identification of land-cover change in a biologically complex community in North Carolina, USA. Remote Sensing of Environment, 2002, 82(2): 258-270. doi: 10.1016/S0034-4257(02)00042-1
[18]	Cleugh H A, Leuning R, Mu Q Z, et al.Regional evaporation estimates from flux tower and MODIS satellite data. Remote Sensing of Environment, 2007, 106(3): 285-304. doi: 10.1016/j.rse.2006.07.007
[19]	Mu Q, Heinsch F A, Zhao M, et al.Development of a global evapotranspiration algorithm based on MODIS and global meteorology data. Remote Sensing of Environment, 2007, 111(4): 519-536. doi: 10.1016/j.rse.2007.04.015

	b₂	b₃	a₁	g₀	d	ε_max	平均值
农田	0.9	1.5	4	1.6	0.2	1.2	2.0
草地	2.6	0.8	3.4	1.9	0.3	1.6	2.1
森林	0.4	1.5	3.7	1.2	0.1	1	1.7
平均值	1.3	1.3	3.7	1.6	0.2	1.3

	b₂	b₃	a₁	g₀	ε_max	D
农田	18.4	36.4	50.7	89.3	13.6	31.4
草地	26.5	54.9	40.8	123.5	41.7	50.5
森林	22.9	29.7	60.0	80.0	27.3	45.1
平均值	22.6	40.3	50.5	97.6	27.5	42.3

	b₂	b₃	a₁	g₀	ε_max	D
农田	0.16	0.55	2.04	1.46	0.16	0.06
草地	0.69	0.42	1.39	2.32	0.67	0.13
森林	0.10	0.44	2.20	0.94	0.27	0.05
平均值	0.31	0.47	1.87	1.57	0.37	0.08

	大气相对湿度	降水	光合有效辐射	气温	NDVI	平均值
长白山	4.5	0.0	4.5	2.9	4.9	2.7
鼎湖山	4.5	0.0	4.5	3.1	5.8	3.1
当雄	2.9	0.9	2.9	1.4	7.2	2.7
海北灌丛	4.1	2.4	4.1	2.0	5.7	3.0
内蒙	5.6	0.4	5.6	4.4	7.6	3.9
千烟洲	4.1	1.4	4.1	0.8	6.1	2.6
海北湿地	4.3	0.3	4.3	3.5	5.8	2.8
禹城	2.2	0.1	2.2	2.9	4.3	2.1
平均值	4.0	0.7	4.0	2.6	5.9

	降水	光合有效辐射	大气相对湿度	气温
长白山	110.8	10.9	11.0	26.9
鼎湖山	99.4	37.1	7.3	9.8
当雄	62.7	6.7	25.6	61.5
海北灌丛	45.8	6.2	10.1	72.3
内蒙	49.1	13.8	12.6	12.6
千烟洲	20.0	23.9	5.6	6.5
海北湿地	51.6	16.5	13.2	64.4
禹城	62.6	19.0	9.0	13.4
平均值	62.8	16.8	11.8	33.4

Evaluation and uncertainty analysis of a two-source evapotranspiration model

RichHTML

PDF (PC)

Like

Knowledge

Cited

Abstract

Cite this article

share this article

Figures/Tables 11

References 19

Related Articles 15

Metrics

Comments

	降水	光合有效辐射	大气相对湿度	气温	NDVI
长白山	0.00	0.49	0.50	0.78	0.71
鼎湖山	0.00	1.67	0.33	0.30	0.84
当雄	0.56	0.19	0.74	0.86	1.04
海北灌丛	1.10	0.25	0.41	1.45	0.83
内蒙	0.20	0.77	0.71	0.55	1.10
千烟洲	0.28	0.98	0.23	0.05	0.88
海北湿地	0.15	0.71	0.57	2.25	0.84
禹城	0.06	0.42	0.20	0.39	0.62
平均值	0.29	0.69	0.46	0.83	0.86
