西安市城市景观的正负生态系统服务测算及空间格局

doi:10.11821/dlxb201607010

Abstract

Abstract:

Comprehensive assessment of the positive ecosystem services and disservices provided by urban landscape and evaluation of its contribution of different urban landscapes to total value of ecosystem services, are crucial to optimizing and regulating the urban landscape configuration and the eco-environment construction in rapid urbanization. Based on the knowledge of landscape ecology and ecosystem service and the Landsat images (OLI-TIRS) data, we valued the ecosystem services of urban landscape including its disservices and analyzed their spatial pattern of Xi'an urbanized area by building the models and employing software of ERDAS, ArcGIS10.1 in 2013. The results showed that: (1) The disservice value of urban landscape is remarkably higher than the positive ecological service value, and the net value is approximately -12.71×10⁸ yuan in Xi'an city. In the process of rapid urbanization, the positive service value of urban landscape dramatically decreased and the negative service took up a large proportion of total values resulting from the transformation from natural landscape to semi-artificial landscape and artificial landscape, 87.81% of the urbanized area provided for negative net value of ecosystem services, and only 12.19% of the area provided positive net services. The expansion of urban landscape dominated by large built-up area will inevitably lead to the decline in ecosystem service value. (2) The value of positive ecosystem services provided by urban landscape in Xi'an city varied from urban core area to urban fringe obviously, which is lower in central area than in fringe area; And the high value area close to the road and in the parks shows the mixed patterns with plaque and grid. The total value of negative ecosystem services in the inner area is higher than that in the urban fringe, and high value area is more concentrated in space. Natural landscape and semi-artificial landscape are the main providers of the positive ecosystem services in city. (3) The spatial distribution of the urban landscape fundamentally determines the spatial pattern of the comprehensive ecosystem services, and the mosaic of different urban landscape types reflects the spatial pattern of the positive and negative ecosystem services shaped by the patches and the chessboard structure. The nearer to the area of urban fringe, the higher the comprehensive ecosystem services value is. There are the high value areas where the forest, grassland and water were distributed or scattered in the park or along road side in the city.

Key words: urban landscape, comprehensive ecosystem service, positive and negative ecosystem services, Xi'an City

Mengtao LI, Zhongxue ZHOU. Positive and negative ecosystem services evaluation and its spatial pattern analysis on urban landscape: A case study of Xi'an City[J].Acta Geographica Sinica, 2016, 71(7): 1215-1230.

Figures/Tables 13

Fig. 1

Fig. 2

Tab. 1

Tab. 2

Tab. 3

Tab. 4

Tab. 5

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Fig. 8

References 42

[1]	Costanza R, D'Arge R, Groot R D, et al. The value of the world's ecosystem services and natural capital. Nature, 1996, 387: 253-260.
[2]	Shapiro J, Báldi A.Accurate accounting: How to balance ecosystem services and disservices. Ecosystem Services, 2014, 7: 201-202. doi: 10.1016/j.ecoser.2014.01.002
[3]	Moro P A, Assisi F, Cassetti F, et al.Toxicological hazards of natural environments: Clinical reports from Poison Control Centre of Milan. Urban Forestry & Urban Greening, 2009, 8(3): 179-186. doi: 10.1016/j.ufug.2009.02.007
[4]	LyytimakiJ, SipilaM. Hopping on one leg: The challenge of ecosystem disservices for urbangreen management. Urban Forestry & Urban Greening, 2009, 8: 309-315. doi: 10.1016/j.ufug.2009.09.003
[5]	Döhren P A, Haase D.Ecosystem disservices research: A review of the state of the art with afocus on cities. Ecological Indicators, 2015, 51: 490-497. doi: 10.1016/j.ecolind.2014.12.027
[6]	Yang Wenrui.Spatiotemporal changeand driving forces of urban landscape pattern in Beijing. Acta Ecologica Sinica, 2015, 35(13): 1-14. doi: 10.5846/stxb201409231882
	[阳文锐. 北京城市景观格局时空变化及驱动力. 生态学报, 2015, 35(13): 1-14.] doi: 10.5846/stxb201409231882
[7]	Xu Jianhua, Yue Wenze, Tan Wenqi.A statistical study on spatial scaling effects of urban landscape pattern: A case study of the central area of external circle highway in Shanghai. Acta Ecologica Sinica, 2004, 59(6): 1058-1067. doi: 10.3321/j.issn:0375-5444.2004.06.030
	[徐建华, 岳文泽, 谈文琦. 城市景观格局尺度效应的空间统计规律: 以上海中心城区为例. 地理学报, 2004, 59(6): 1058-1067.] doi: 10.3321/j.issn:0375-5444.2004.06.030
[8]	Dobbs C, Kendal D, Nitschke C R.Multiple ecosystem services and disservices of the urban forest establishing their connections with landscape structure and sociodemographics. Ecological Indicators, 2014, 43: 44-55.
[9]	Shi Longyu, Cui Shenghui, Yin Kai, et al.The impact of land use/cover change on ecosystem service in Xiamen. Acta Geographica Sinica, 2010, 65(6): 708-714. doi: 10.11821/xb201006008
	[石龙宇, 崔胜辉, 尹锴, 等. 厦门市土地利用/覆被变化对生态系统服务的影响. 地理学报, 2010, 65(6): 708-714.] doi: 10.11821/xb201006008
[10]	PengJ, LiuY, Wu J, et al. Linking ecosystem services and landscape patterns to assess urban ecosystem health: A case study in Shenzhen City, China. Landscape and Urban Planning, 2015: 56-68. doi: 10.1016/j.landurbplan.2015.06.007
[11]	Peng Jian, Wang An, Liu Yanxu, et al.Research progress and prospect on measuring urbanecological land demand.Acta Geographica Sinica, 2015, (70(2): 333-346. doi: 10.11821/dlxb201502013
	[彭建, 汪安, 刘焱序, 等. 城市生态用地需求测算研究进展与展望. 地理学报, 2015, 70(2): 333-346.] doi: 10.11821/dlxb201502013
[12]	Shackleton S, Chinyimba A, Hebinck P, et al.Multiple benefits and values of trees in urban landscapes in two towns in northern South Africa. Landscape & Urban Planning, 2015, 136: 76-86. doi: 10.1016/j.landurbplan.2014.12.004
[13]	Li Feng, Ye Yaping, Song Bowen, et al.Spatial structure of urban ecological land and its dynamic development of ecosystem services: A case study in Changzhou City, China. Acta Ecologica Sinica, 2011, 31(19): 5623-5631.
	[李锋, 叶亚平, 宋博文, 等. 城市生态用地的空间结构及其生态系统服务动态演变: 以常州市为例. 生态学报, 2011, 31(19): 5623-5631.]
[14]	Chen Liding, Sun Ranhao, Liu Hailian, et al.Eco-environmental effects of urban landscape pattern changes: Progresses, problems, and perspectives. Acta Ecologica Sinica, 2013, 33(4): 1042-1050. doi: 10.5846/stxb201205070659
	[陈利顶, 孙然好, 刘海莲, 等. 城市景观格局演变的生态环境效应研究进展. 生态学报, 2013, 33(4): 1042-1050.] doi: 10.5846/stxb201205070659
[15]	Zhang Xiaochen, Zhu Zhiling, Wang Caijuan, et al.Analysis variation of city ecosystem service function value in Yinchuan. Arid Environmental Monitoring, 2009, 23(1): 41-45. doi: 10.3969/j.issn.1007-1504.2009.01.009
	[张晓晨, 朱志玲, 王彩娟, 等. 银川市城市生态系统服务功能价值的变化分析. 干旱环境监测, 2009, 23(1): 41-45.] doi: 10.3969/j.issn.1007-1504.2009.01.009
[16]	. 2014-03-05.
	[2013年西安227个污染天PM2. 2014-03-05.]
[17]	Li Boyan, Ren Zhiyuan, Li Ruizong, et al.Urban heat island intensity quantitative inversion and city land surface temperatures in Xi'an. Resources Science, 2014, 36(12): 2631-2636.
	[李柏延, 任志远, 李瑞宗, 等. 西安市地表温度反演及城市热岛强度定量化研究. 资源科学, 2014, 36(12): 2631-2636.]
[18]	Yang Wenrui, Li Feng, Wang Rusong, et al.Eco-service efficiency assessment method of urban land use: A case study of Changzhou City, China. Acta Ecologica Sinica, 2013, 33(14): 4486-4494. doi: 10.5846/stxb201204190568
	[阳文锐, 李锋, 王如松, 等. 城市土地利用的生态系统服务功效评价方法: 以常州市为例. 生态学报, 2013, 33(14): 4486-4494.] doi: 10.5846/stxb201204190568
[19]	Han Ye, Zhou Zhongxue.Evaluation on ecosystem services in haze absorption by urban green land and its spatial pattern analysis in Xi'an. Geographical Research, 2015, 34(7): 1247-1258. doi: 10.11821/dlyj201507005
	[韩晔, 周忠学. 西安市绿地景观吸收雾霾生态系统服务测算及空间格局. 地理研究, 2015, 34(7): 1247-1258.] doi: 10.11821/dlyj201507005
[20]	Yu Xinxiao, Lu Shaowei, Jin Fang, et al.The assessment of the forest ecosystem services evaluation in China. Acta Ecologica Sinica, 2005, 25(8): 2098-2101. doi: 10.3321/j.issn:1000-0933.2005.08.038
	[余新晓, 鲁绍伟, 靳芳, 等. 中国森林生态系统服务功能价值评估. 生态学报, 2005, 25(8): 2098-2101.] doi: 10.3321/j.issn:1000-0933.2005.08.038
[21]	Zhou Zixiang, Li Jing, Feng Xueming.The value of fixing carbon and releasing oxygen in the Guanzhong-Tianshui economic region using GIS. Acta Ecologica Sinica, 2013, 33(9): 2907-2918. doi: 10.5846/stxb201202130187
	[周自翔, 李晶, 冯雪铭. 基于GIS的关中—天水经济区土地生态系统固碳释氧价值评价. 生态学报, 2013, 33(9): 2907-2918.] doi: 10.5846/stxb201202130187
[22]	Fan Jianzhong, Li Dengke, Zhou Hui.Valuation on carbon fixation and oxygen release in reforested croplands of Shaanxi Province of China. Chinese Journal of Ecology, 2013, 32(4): 874-881.
	[范建忠, 李登科, 周辉. 陕西省退耕还林固碳释氧价值分析. 生态学杂志, 2013, 32(4): 874-881.]
[23]	Liu Hua, Song Tao, Li Peipei.Microclimatic modification of urban green in Hefei City. Urban Environment & Urban Ecology, 2009, 22(6): 39-42.
	[刘华, 宋涛, 李培培. 合肥城市主要绿地类型小气候调节作用初析. 城市环境与城市生态, 2009, 22(6): 39-42.]
[24]	Xie Gaodi, Zhen Lin, Lu Chunxia, et al.Expert knowledge based valuation method of ecosystem services in China. Journal of Natural Resources, 2008, 23(5): 911-919. doi: 10.11849/zrzyxb.2008.05.019
	[谢高地, 甄霖, 鲁春霞, 等. 一个基于专家知识的生态系统服务价值化方法. 自然资源学报, 2008, 23(5): 911-919.] doi: 10.11849/zrzyxb.2008.05.019
[25]	Xie Gaodi, Lu Chunxia, LengYunfa, et al. Ecological assets valuation of the Tibetan Plateau. Journal of Natural Resources, 2003, 18(2): 189-196. doi: 10.3321/j.issn:1000-3037.2003.02.010
	[谢高地, 鲁春霞, 冷允法, 等. 青藏高原生态资产的价值评估. 自然资源学报, 2003, 18(2): 189-195.] doi: 10.3321/j.issn:1000-3037.2003.02.010
[26]	Hu Zhongxiu, Zhou Zhongxue.Ecosystem service evaluation and its spatial pattern analysis of urban greenland in Xi'an City. Arid Land Geography, 2013, 36(3): 553-561.
	[胡忠秀, 周忠学. 西安市绿地生态系统服务系统服务功能测算及其空间格局研究. 干旱区地理, 2013, 36(3): 553-561.]
[27]	Yao Yao. Zhou Zhongxue.Influence of land use change on service function of ecosystem and their relationship: Taking example for Guanzhong Area. Acta Agriculturae Jiangxi, 2012, 24(4): 163-167. doi: 10.3969/j.issn.1001-8581.2012.04.048
	[姚瑶, 周忠学. 土地利用变化对生态系统服务功能的影响及其两者关系研究: 以关中地区为例. 江西农业学报, 2012, 24(4): 163-167.] doi: 10.3969/j.issn.1001-8581.2012.04.048
[28]	Wang Zhenbo, Fang Chuanglin, Xu Guang, et al.Spatial-temporal characteristics of the PM2.5 in China in 2014. Acta Geographica Sinica, 2015, 70(11): 1720-1734. doi: 10.11821/dlxb201511003
	[王振波, 方创琳, 许光, 等. 2014年中国城市PM2.5浓度的时空变化规律. 地理学报, 2015, 70(11): 1720-1734.] doi: 10.11821/dlxb201511003
[29]	Zhang Yinjun, Chen Xi, Xie Gaodi, et al.Pollution status and spatial distribution of PM2.5 in China. Resources Science, 2015, 37(7): 1339-1346.
	[张殷俊, 陈曦, 谢高地, 等. 中国细颗粒物(PM2.5)污染状况和空间分布. 资源科学, 2015, 37(7): 1339-1346.]
[30]	Miguel Cárdenas Rodríguez, Laura Dupont-Courtade, Walid Oueslati.Air pollution and urban structure linkages: Evidence from European cities. Renewable and Sustainable Energy Reviews, 2016, 53: 1-9. doi: 10.1016/j.rser.2015.07.190
[31]	Yang Long, He Kebin, Zhang Qiang, et al.Vertical distributive characters of PM2.5 at the ground layer in autumn and winter in Beijing. Research of a Environmental Sciences, 2005, 18(2): 23-28. doi: 10.3321/j.issn:1001-6929.2005.02.005
	[杨龙, 贺克斌, 张强, 等. 北京秋冬季近地层PM2.5质量浓度垂直分布特征. 环境科学研究, 2005, 18(2): 23-28.] doi: 10.3321/j.issn:1001-6929.2005.02.005
[32]	Yang Qiongliang, Ouyang Ting, Yan Hong, et al.Research progress of pollen allergy. Chinese Agricultural Science Bulletin. 2015, 31(24): 163-167.
	[杨琼梁, 欧阳婷, 颜红, 等. 花粉过敏的研究进展. 中国农学通报, 2015, 31(24): 163-167.]
[33]	Ding Wei, Pang Ruiming, Xu Qinghai, et al. Surface pollen assemblages as indicators of human impact in the warm temperate hilly areas of eastern China. Chinese Science Bulletin, 2011, 56,(11): 839-847. doi: 10.7666/d.y1868925
	[丁伟, 庞瑞洺, 许清海, 等. 中国东部暖温带低山丘陵区表土花粉对人类活动的指示意义. 科学通报, 2011, 56(11): 839-847.] doi: 10.7666/d.y1868925
[34]	Bai Yang, Wang Xiaoyun, Jiang Haimei, et al.Progress of urban heat island. Journal of Meteorology and Environment, 2013, 29(2): 101-106. doi: 10.3969/j.issn.1673-503X.2013.02.016
	[白杨, 王晓云, 姜海梅. 等. 城市热岛效应研究进展. 气象与环境学报, 2013, 29(2): 101-106.] doi: 10.3969/j.issn.1673-503X.2013.02.016
[35]	Li Zhaojiang, Jiang Yi.Analysis on cooling energy consumption of residential buildings in China,s urban areas. Heating Ventilating and Air Conditioning, 2009, 39(5): 82-88.
	[李兆坚, 江亿. 我国城镇住宅夏季能耗状况分析. 暖通空调, 2009, 39(5): 82-88.]
[36]	O’FarrellPJ, Donaldson J S, Hoffman M T. The influence of ecosystem goods and services on livestock management practices on the Bokkeveld plateau, South Africa. Agriculture Ecosystems & Environment, 2007, 122: 312-324. doi: 10.1016/j.agee.2007.01.025
[37]	Weslawski J M, Andrulewicz E, Kotwicki L, et al.Basis for a valuation of the polish exclusive economic zone of the Baltic Sea: Rationale and quest for tools. Oceanologia, 48: 145-167. doi: 10.1111/j.1471-4159.1961.tb13470.x
[38]	Lyytimaki J, Petersen L K, Normander B, et al.Nature as a nuisance? Ecosystem services anddisservices to urban lifestyle. Environmental Sciences, 2008, 58: 161-172. doi: 10.1080/15693430802055524
[39]	Wang H F, Qureshi S, Knapp S, et al.A basic assessment of residential plant diversity and its ecosystemservices and disservices in Beijing, China. Applied Geography, 2015, 64: 121-131. doi: 10.1016/j.apgeog.2015.08.006
[40]	Lyytimaki J.Bad nature: Newspaper representations of ecosystem disservices. Urban Forestry & Urban Greening, 2014, 13: 418-424. doi: 10.1016/j.ufug.2014.04.005
[41]	Hanski I, Hertzen L V, Fyhrquist N, et al.Environmental biodiversity, human microbiota, and allergy are interrelated. Proceedings of the National Academy of Sciences, 2012, 109(21): 8334-8339. doi: 10.1073/pnas.1205624109 pmid: 22566627
[42]	Villa F, Bagstad K J, Voigt B, et al.The misconception of ecosystem disservices: How a catchy term may yield the wrong messages for science and society. Ecosystem Services, 2014, 10: 52-53. doi: 10.1016/j.ecoser.2014.09.003

		生态系统服务	指标含义
复合生态系统服务	正向生态系统服务	环境净化	城市中绿地景观吸收大气中SO₂、氮氧化物和滞尘
		气体调节	城市中绿地景观维持大气化学组分平衡,如固碳释氧等
		气候调节	城市中绿地景观对区域气候的调节,如降低温度、增加降水
		旅游休闲	公园绿地、园地等满足都市居民休闲观光、亲近自然的需求
	负向生态系统服务	花粉过敏	花粉通过风的传播,人遇花粉而造成过敏的现象
		大气污染	空气中污染物达到足够浓度和时间,危害人类健康和生活
		夏季热岛效应	城市下垫面具有更大的吸热率和更小的比热容,造成同一时间城区气温高于郊区气温,居民需要更长时间的空调降温

城市景观类型	吸收污染物类型
城市景观类型	吸收二氧化硫	吸收氮氧化物	粉尘
林地	291.03	215.36	44300.00
草地	21.70	16.06	120.00
耕地	45.00	33.30	940.00
园地	90.00	66.60	9000.00
水域	0	0	0
建设用地	0	0	0

生态服务功能	林地	园地	草地	耕地	水域	建设用地
气候调节	0.409	0.273	0.136	0.135	0.350	0
旅游休闲	0.194	0.100	0.006	0.002	0.658	0

	环境净化	气体调节	气候调节	旅游休闲	合计	百分比(%)
水域	0	0	0.86	0.30	1.16	0.71
林地	51.50	27.38	26.86	3.93	109.68	67.35
园地	1.45	3.26	2.44	0.08	7.22	4.44
草地	0.08	4.62	2.46	0.01	7.17	4.40
耕地	1.67	25.10	10.83	0.01	37.61	23.10
建设用地	0	0	0	0	0	0
合计	54.70	60.36	43.45	4.39	162.84	100.0
百分比(%)	33.59	37.06	26.69	2.66	100.0

	空气污染	花粉过敏	热岛效应	合计	百分比(%)
水域	0.10	0.15	0	0.25	0.0002
林地	2.77	10.67	0	13.44	0.009
园地	0.37	0.47	0.87	1.71	0.001
草地	0.75	1.08	21.37	23.19	0.01
耕地	3.31	2.74	166.72	172.78	0.12
建设用地	19.32	30.35	1172.99	1222.67	0.85
合计	26.62	45.46	1361.95	1434.04	100
百分比(%)	0.02	0.03	0.95	100
