流域土壤有效厚度水平衡验证及其对陆面水碳通量模拟的影响

doi:10.11821/dlxb201605009

Abstract

Abstract:

The soil effective depths are different due to regional features of various types of soils and vegetation, which impacts spatial and temporal distribution of soil moisture storage capacity and land surface water-carbon flux. In this study, the soil effective depth was calibrated using LPJ dynamic vegetation model on the target of remaining watershed water balance in three climate regions (Dongjiang River watershed in humid areas, Huaihe River watershed in humid, semi-humid areas and Jinghe River watershed in semi-humid and semi-arid areas). On this basis, we examined soil moisture storage capacity and land surface water-carbon flux (runoff R, actual evapotranspiration ET and net primary productivity NPP) resulting from variation of the soil effective depth. The results indicated that the estimated soil effective depth is 70 cm in the Dongjiang watershed, 90 cm in the Huaihe watershed and 140 cm in the Jinghe watershed. The soil effective depth and soil moisture storage capacity increase with the increase of drought degree. The correction of the soil effective depth in terms of water balance effectively reduces the simulation error, and affects the simulated results of the land surface water-carbon flux. However, the large or small effect is related to climatic conditions. The annual mean runoff and actual evapotranspiration change significantly in the humid areas, while the NPP changes significantly in the humid and semi-humid areas. The results provide a reference for improving the reliability of application of the LPJ model in different climate regions.

Key words: soil effective depth, soil moisture storage capacity, actual evapotranspiration, net primary productivity, dynamic vegetation model

Richao HUANG, Xi CHEN, Yimeng SUN, Man GAO, Qinbo CHENG, Yongsheng ZHANG. Validation of watershed soil effective depth based on water balance and its effect on simulation of land surface water-carbon flux[J].Acta Geographica Sinica, 2016, 71(5): 807-816.

Figures/Tables 9

Fig. 1

Fig. 2

Tab. 1

Fig. 3

Tab. 2

Tab. 3

Fig. 4

Fig. 5

Fig. 6

References 26

[1]	Yang Dawen, Lei Huimin, Cong Zhentao.Overview of the research status in interaction between hydrological processes and vegetation in catchment. Journal of Hydraulic Engineering, 2010(10): 1142-1149.
	[杨大文, 雷慧闽, 丛振涛. 流域水文过程与植被相互作用研究现状评述. 水利学报, 2010(10): 1142-1149.]
[2]	Sun Guodong. Simulation of potential vegetation distribution and estimation of carbon flux in China from1981 to 1998 with LPJ Dynamic Global Vegetation Model. Climatic and Environmental Research, 2009(4): 341-351.
	[孙国栋. LPJ模型对1981-1998年中国区域潜在植被分布和碳通量的模拟. 气候与环境研究, 2009(4): 341-351.]
[3]	Yin Yunhe, Wu Shaohong, Zhao Dongsheng, et al.Impact of climate change on actual evapotranspiration on the Tibetan Plateau during 1981-2010. Acta Geographica Sinica, 2012, 67(11): 1471-1481.
	[尹云鹤, 吴绍洪, 赵东升, 等. 1981-2010年气候变化对青藏高原实际蒸散的影响. 地理学报, 2012, 67(11): 1471-1481.]
[4]	Wang Xufeng, Ma Mingguo.Carbon and water fluxes of cornfield simulated with LPJ mode. Advances in Earth Science, 2009, 24(7): 734-740.
	[王旭峰, 马明国. 基于LPJ模型的制种玉米碳水通量模拟研究. 地球科学进展, 2009, 24(7): 734-740.]
[5]	Gerten D, Schaphoff S, Haberlandt U, et al.Terrestrial vegetation and water balance: Hydrological evaluation of a dynamic global vegetation model. Journal of Hydrology, 2004, 286(1-4): 249-270. doi: 10.1016/j.jhydrol.2003.09.029
[6]	Bloh W V, Rost S, Gerten D, et al Efficient parallelization of a dynamic global vegetation model with river routing. Environmental Modelling & Software, 2010, 25(6): 685-690. doi: 10.1016/j.envsoft.2009.11.012
[7]	Ukkola A M, Murray S J.Hydrological evaluation of the LPX dynamic global vegetation model for small river catchments in the UK. Hydrological Processes, 2014, 28(4): 1939-1950. doi: 10.1002/hyp.9735
[8]	Sitch S, Smith B,Prentice I C, et.al. Evaluation of ecosystem dynamics, plant geography and terrestrial carbon cycling in the LPJ dynamic global vegetation model. Global Change Biology, 2003, 9(2): 161-185. doi: 10.1046/j.1365-2486.2003.00569.x pmid: 1703012
[9]	Ni Jian.BIOME models: Main principles and applications. Acta Phytoecologica Sinica, 2002(4): 481-488.
	[倪健.BIOME系列模型: 主要原理与应用. 植物生态学报, 2002(4): 481-488.]
[10]	Pan Y, McGuire A D, Melillo J M, et al. A biogeochemistry - based dynamic vegetation model and its application along a moisture gradient in the continental United States. Journal of Vegetation Science, 2002, 13(3): 369-382.
[11]	Joos F, Prentice I C, Sitch S, et.al. Global warming feedbacks on terrestrial carbon uptake under the Intergovernmental Panel on Climate Change (IPCC) emission scenarios. Global Biogeochemical Cycles, 2001, 15(4): 891-907.
[12]	Wania R, Ross I, Prentice I C.Implementation and evaluation of a new methane model within a dynamic global vegetation model: LPJ-WHyMe v1.3.1. Geoscientific Model Development, 2010, 3(2): 565-584. doi: 10.5194/gmd-3-565-2010
[13]	Reager J T, Famiglietti J S.Characteristic mega-basin water storage behavior using GRACE. Water Resources Research, 2013, 49(6): 3314-3329. doi: 10.1002/wrcr.20264 pmid: 24563556
[14]	Ladson T, Lander J, Western A, et al.Estimating extractable soil moisture content for Australian soils. Cooperative Research Centre for Catchment Hydrology, 2004.
[15]	FAO UNESCO.Soil Map of The World Legend and Volumes. UNESCO P.
[16]	Dunne K A, Willmott C J.Global distribution of plant-extractable water capacity of soil. International Journal of Climatology, 1996, 16(8): 841-859. doi: 10.1002/(SICI)1097-0088(199608)16:8<841::AID-JOC60>3.0.CO;2-8
[17]	Zhao Renjun.Watershed Hydrological Modeling: Xinanjiang Model and Northern Shaanxi Model. Beijing: China Water Power Press, 1984: 117.
	[赵人俊. 流域水文模拟: 新安江模型与陕北模型. 北京: 水利电力出版社, 1984: 117.]
[18]	Milly P C D, Dunne K A. Sensitivity of the global water cycle to the water-holding capacity of land. Journal of Climate, 1994, 7(4): 506-526. doi: 10.1175/1520-0442(1994)007<0506:SOTGWC>2.0.CO;2
[19]	Feddema J J.Estimated impacts of soil degradation on the African water balance and climate. Climate Research, 1998, 10(2): 127-141. doi: 10.3354/cr010127
[20]	Goward S N, Xue Y, Czajkowski K P.Evaluating land surface moisture conditions from the remotely sensed temperature/vegetation index measurements: An exploration with the simplified simple biosphere model. Remote Sensing of Environment, 2002, 79(2/3): 225-242.
[21]	Chen Caocao, Xie Gaodi, Zhen Lin, et al.Analysis of Jinghe watershed vegetation dynamic sand evaluation of its relation to precipitation. Acta Ecologica Sinica, 2008, 28(3): 925-938. doi: 10.3321/j.issn:1000-0933.2008.03.004
	[陈操操, 谢高地, 甄霖, 等. 泾河流域植被覆盖动态变化特征及其与降雨的关系. 生态学报, 2008, 28(3): 925-938.] doi: 10.3321/j.issn:1000-0933.2008.03.004
[22]	Wang Zhaoli.Effects of climatic change and LUCC on hydrological system in the East River Basin, South China [D]. Guangzhou: Sun Yat-senUniversity, 2007.
	[王兆礼. 气候与土地利用变化的流域水文系统响应: 以东江流域为例[D]. 广州: 中山大学, 2007.]
[23]	Pan Meihui, Wu Yongqiu.The spatial variation of geology, topography and soil characteristics in the Dongjiang watershed//Proceedings of the 2011 Annual Meeting of the Geographical Society of China, 2011: 1.
	[潘美慧, 伍永秋.东江流域地质、地貌和土壤特征及空间异质性分析//中国地理学会2011年学术年会论文摘要集, 2011: 1.]
[24]	Zobler L.A world soil ﬁle for global climate modeling. NASA Tech. Memo. 87802, NASA, New York, 1986: 33.
[25]	McGuire A D, Sitch S, Clein J S, etal. Carbon balance of the terrestrial biosphere in the twentieth century: Analyses of CO2, climate and land use effects with four process-based ecosystem models. Global Biogeochemical Cycles, 2001, 15(1): 183-206.
[26]	Lü Leting, Peng Qiuzhi, Guo Yuanyuan, et al.Runoff simulation of Dongjiang River Basin based on the soil and water assessment tool. Journal of Natural Resources, 2014, 29(10): 1746-1757. doi: 10.11849/zrzyxb.2014.10.010
	[吕乐婷, 彭秋志, 郭媛媛, 等. 基于SWAT模型的东江流域径流模拟. 自然资源学报, 2014, 29(10): 1746-1757.] doi: 10.11849/zrzyxb.2014.10.010

水系	测站	流域面积 (km²)	年均降水量 (mm)	年均径流量 (mm)	年径流系数	干旱系数	气候
泾河	张家山	43216	454	40	0.09	1.86	半湿润、半干旱
淮河	蚌埠	121330	863	256	0.30	1.17	半湿润、湿润
东江	博罗	25325	1827	947	0.52	0.59	湿润

流域		泾河			淮河			东江
流域		修正前		修正后		修正前	修正后	修正前	修正后
d₁/d₂(cm)		50/100	60/80		50/100	60/30		50/100	40/30
WM (cm)	流域均值	22.1	20.6		22.1	13.2		20.4	9.5
WM (cm)	变化范围	19.1~22.5	17.8~21.0		16.5~22.5	9.9~13.5		18.0~22.5	8.4~10.5
E_R(%)		10.0	0.1		3.0	0.1		4.8	0.6
E_NS(%)		45.9	47.3		53.8	54.6		60.9	58.0

	泾河								淮河
通量	实测 (mm)	未修正			修正后				实测 (mm)	未修正				修正后
通量	实测 (mm)	模拟 (mm)		E_R (%)	Cv (%)		模拟 (mm)		E_R (%)	Cv (%)	模拟 (mm)	E_R (%)	Cv (%)	模拟 (mm)	E_R (%)	Cv (%)
R	40	44	10.0	69.0		40	0.1		73.0	256	247	3.0	38.3		256	0.1	39.5
ET	414	406	0.98	11.5	410	0.97		11.6	608	611	0.5	6.8		603	0.82	7.3
NPP		502		17.4	513			17.4		538		12.0		555		12.1
	东江
通量	实测 (mm)								未修正					修正后
通量	实测 (mm)	模拟 (mm)	E_R (%)								Cv (%)	模拟 (mm)	E_R (%)	Cv (%)
R	947								891	5.9	29.5			941	0.1	31.0
ET	880								931	5.56	4.0			882	0.23	4.7
NPP									622		8.7			621		13.7
