基于土壤侵蚀控制度的黄土高原水土流失治理潜力研究

doi:10.11821/dlxb201509012

Abstract

Abstract:

The capacity of soil and water conservation measures, defined as the maximum quantity of suitable soil and water conservation measures contained in a region, were determined for the Loess Plateau based on zones suitable for establishing terraced fields, forestland and grassland with the support of geographic information system (GIS) software. The minimum possible soil erosion modulus and actual soil erosion modulus in 2010 were calculated using the revised universal soil loss equation (RUSLE), and the rate of the minimum possible soil erosion modulus under the soil and water conservation measures to the actual soil erosion modulus was defined as the soil erosion control degree. The control potential of soil erosion and water loss in the Loess Plateau was studied using this concept. Results showed that the actual soil erosion modulus were 3355 t·km^-2·a^-1, the minimum possible soil erosion modulus was 1921 t·km^-2·a^-1, and the soil erosion control degree was 0.57 (medium level) on the Loess Plateau in 2010. In terms of zones, the control degree was relatively high in the valley plain zones, soil and rock mountainous zones, and windy sand zones, but relatively low in the soil and rock hilly forest zones, hilly gully zones and plateau gully zones. In terms of river basins, the soil erosion control degree was relatively high in the Dahei River, Huangfu River, Qingshui River, Kuye River and Pianguan River basins, but relatively low in the Qingjian River, Wuding River, Jialu River, and Yanhe River basins. The rate of erosion zones with a soil erosion modulus of less than 1000 t·km^-2·a^-1 increased from 50.48% to 57.71%, forest and grass coverage rose from 56.74% to 69.15%, ratio of terraced fields increased from 4.36% to 19.03%, and per capita grain yield rose from 418 kg·a^-1 to 459 kg·a^-1 under the soil and water conservation measures compared with actual conditions.

Key words: Loess Plateau, soil erosion control degree, control potential of soil erosion and water loss, RUSLE

Haidong GAO, Zhanbin LI, Peng LI, Lianlian JIA, Guoce XU, Zongping REN, Guowei PANG, Binhua ZHAO. The capacity of soil loss control in the Loess Plateau based on soil erosion control degree[J].Acta Geographica Sinica, 2015, 70(9): 1503-1515.

Figures/Tables 11

Fig. 1

Fig. 2

Tab. 2

Fig. 3

Tab. 2

Tab. 3

Fig. 4

Tab. 4

Tab. 5

Fig. 5

Tab. 6

References 41

[1]	The Ministry of Water Resources of the People's Republic of China, Chinese Academy of Sciences, Chinese Academy of Engineering. Water Loss and Soil Erosion and Ecological Security of China: The Loess Plateau. Beijing: Science Press, 2010: 28-59.
	[水利部, 中国科学院, 中国工程院. 中国水土流失防治与生态安全(西北黄土高原区卷). 北京: 科学出版社, 2010: 28-59.]
[2]	Fu Bojie, Liu Yu, Lu Yihe, et al.Assessing the soil erosion control service of ecosystems change in the Loess Plateau of China. Ecological Complexity, 2011, 8: 284-293.
[3]	Markus Dotterweich.The history of human-induced soil erosion: Geomorphic legacies, early descriptions and research, and the development of soil conservation: A global synopsis. Geomorphology, 2013, 201: 1-34.
[4]	Liu Xiaoyan, Wang Fugui, Yang Shengtian, et al.Sediment reduction effect of level terrace in the hilly-gully region in the Loess Plateau. Journal of Hydraulic Engineering, 2014, 45(7): 793-780.
	[刘晓燕, 王富贵, 杨胜天, 等. 黄土丘陵沟壑区水平梯田减沙作用研究. 水利学报, 2014, 45(7): 793-780.]
[5]	Sun Wenyi, Shao Quanqin, Liu Jiyuan, et al.Assessing the effects of land use and topography on soil erosion on the Loess Plateau in China. Catena, 2014, 121: 151-163.
[6]	Wang Fei, Mu Xingmin, Li Rui, et al.Co-evolution of soil and water conservation policy and human-environment linkages in the Yellow River Basin since 1949. Science of the Total Environment, 2015, 508: 166-177.
[7]	Zhu Tongxin. Gully and tunnel erosion in the hilly Loess Plateau region, China. Geomorphology, 2012, 153/154: 144-155.
[8]	Allison Bullock, Brian King.Evaluating China's slope land conversion program as sustainable management in Tianquan and Wuqi counties. Journal of Environmental Management, 2011, 92: 1916-1922.
[9]	Upper and Middle Reaches of the Yellow River Administrative Bureau. Introduction to the Soil and Water Conservation of Yellow River Basin. Zhengzhou: Yellow River Water Conservancy Press, 2011:64-96.
	[黄河上中游管理局. 黄河流域水土保持概论. 郑州: 黄河水利出版社, 2011: 64-96.]
[10]	Yellow River Conservancy Commission of the Ministry of Water Resources. Yellow River Basin Comprehensive Planning (2012-2030). Zhengzhou: Yellow River Water Conservancy Press, 2013: 1-10.
	[水利部黄河水利委员会. 黄河流域综合规划(2012-2030年). 郑州: 黄河水利出版社, 2013: 1-10.]
[11]	Yao Wenyi, Ran Dachuan, Chen Jiangnan.Recent changes in runoff and sediment regimes and future projections in the Yellow River basin. Advances in Water Science, 2013, 24(5): 607-616.
	[姚文艺, 冉大川, 陈江南. 黄河流域近期水沙变化及其趋势预. 水科学进展, 2013, 24(5): 607-616.]
[12]	Zhang Xiaoping, Zhang Lu, Wang Yong, et al.Tempo-spatially responses of the annual streamflow to LUCC in the middle reaches of Yellow River, China. Science of Soil and Water Conservation, 2009, 7(1): 19-26.
	[张晓萍, 张橹, 王勇, 等. 黄河中游地区年径流对土地利用变化时空响应分析. 中国水土保持科学, 2009, 7(1): 19-26.]
[13]	Xie Wangcheng, Li Tianhong.Research comment on watershed sediment delivery ratio. Acta Scientiarum Naturalium Universitatis Pekinensis, 2012, 48(4): 685-694.
	[谢旺成, 李天宏. 流域泥沙输移比研究进展. 北京大学学报(自然科学版), 2012, 48(4): 685-694.]
[14]	Xu Jiongxin, Sun Ji.Effect of erosion control measures on sediment delivery ratio. Advances in Water Science, 2004, 15(1): 29-34.
	[许炯心, 孙季. 水土保持措施对流域泥沙输移比的影响. 水科学进展, 2004, 15(1): 29-34.]
[15]	Su Chunli, Liang Yin, Li Decheng, et al.Concept and evaluation methodology of watershed management and recovery degree in red soil region. Soils, 2011, 43(3): 466-475.
	[苏春丽, 梁音, 李德成, 等. 红壤区小流域治理度的概念与评价方法. 土壤, 2011, 43(3): 466-475.]
[16]	Gao Haidong, Li Zhanbin, Li Peng, et al.Quantitative study on influences of terraced field construction and check-dam siltation on soil erosion. Journal of Geographical Sciences, 2012, 22(5): 946-960.
[17]	Fischer Gunther, Nachtergaele Freddy, Prieler Sylvia, et al. Global Agro-ecological Zones Assessment for Agriculture (GAEZ2008). IIASA, Laxenburg, Austria and FAO, 2008, Rome, Italy.
[18]	Liu Jiyuan, Kuang Wenhui, Zhang Zengxiang, et al.Spatiotemporal characteristics, patterns, and causes of land-use changes in China since the late 1980s. Journal of Geographical Sciences, 2014, 24(2): 195-210.
[19]	National Bureau of Statistics of the People's Republic of China. China County Statistical Yearbook 2012. Beijing: China Statistics Press, 2012: 10-426.
	[国家统计局农村社会经济调查司. 中国县(市)社会经济统计年鉴2012. 北京: 中国统计出版社, 2012: 10-426.]
[20]	Yellow River Basin Monitoring Center of Water-Soil Conservation and Eco-Environment. The Middle and Upper Reaches of the Yellow River Survey of Soil and Water Conservation Measures. Xi'an: Upper and Middle Yellow River Bureau, 2011.
	[黄河流域水土保持生态环境监测中心. 黄河上中游水土保持措施调查报告. 西安: 黄河上中游管理局, 2011.]
[21]	Ministry of Public Security Authority of the People's Republic of China. The National Counties Population Statistics Yearbook 2011. Beijing: Qunzhong Press, 2013: 121-219.
	[公安部治安管理局. 2011年中华人民共和国全国分县市人口统计资料. 北京: 群众出版社, 2013: 121-219.]
[22]	Gao Haidong, Li Zhanbin, Li Peng, et al.Concept and calculation methods of erosion control degree: A case study of the Wangmaogou watershed. Science of Soil and Water Conservation, 2013, 11(1):17-24.
	[高海东, 李占斌, 李鹏, 等. 流域侵蚀控制度的概念与计算方法: 以王茂沟流域为例. 中国水土保持科学, 2013, 11(1): 17-24.]
[23]	Jiang Dingsheng.Soil Erosion and Control Model in the Loess Plateau. Beijing: China Water & Power Press, 1997: 106-120.
	[蒋定生. 黄土高原水土流失与治理模式. 北京: 中国水利水电出版社, 1997: 106-120.]
[24]	Li Rui, Yang Wenzhi, Li Bicheng.Research Progress and Prospect of the Chinese Loess Plateau. Beijing: Science Press, 2008: 183-211.
	[李锐, 杨文治, 李壁成. 中国黄土高原研究与展望. 北京: 科学出版社, 2008: 183-211.]
[25]	Zheng Jingyun, Yin Yunhe, Li Bingyuan.A new scheme for climate regionalization in China. Acta Geographica Sinica, 2010, 65(1): 3-12.
	[郑景云, 尹云鹤, 李炳元. 中国气候区划新方案. 地理学报, 2010, 65(1): 3-12.]
[26]	Kenneth G Renard, George R Foster, Weesies Gleen, et al. Predicting soil erosion by water: A guide to conservation planning with the Revised Universal Soil Loss Equation (RUSLE)//U.S. Department of Agriculture Agricultural Handbook No.703.1997. US Department of Agriculture, Washington, DC.
[27]	Angulo-Martínez M, Beguería S.Estimating rainfall erosivity from daily precipitation records: A comparison among methods using data from the Ebro Basin (NE Spain). Journal of Hydrology, 2009, 379(1/2): 111-121.
[28]	Williams J R, Jones C A, Kiniry J R.The EPIC crop growth model. Transactions of the ASAE, 1989, 32(2): 497-511.
[29]	Don K McCool, George R. Foster, Mutchler C K, et al. Revised slope length factor for the universal soil loss equation.Transactions of the American Society of Agricultural Engineers, 1989, 32: 1571-1576.
[30]	Zhang Hhongming, Yang Qinke, Li Rui, et al.Extension of a GIS procedure for calculating the RUSLE equation LS factor. Computers &Geosciences, 2013, 52: 177-188.
[31]	Zhang Yan, Liu Baoyuan, Shi Peijun, et al.Crop cover factor estimating for soil loss prediction. Acta Ecologica Sinica, 2001, 21(7): 1050-1056.
	[张岩, 刘宝元, 史培军, 等. 黄土高原土壤侵蚀作物覆盖因子计算. 生态学报, 2001, 21(7): 1050-1056.]
[32]	Zhang Yan, Liu Baoyuan, Zhang Qingchun, et al.Effect of different vegetation types on soil erosion by water. Acta Botanica Sinica, 2003, 45(10): 1204-1209.
[33]	Jiao Juying, Zou Houyuan, Jia Yanfeng, et al.Research progress on the effects of soil erosion on vegetation. Acta Ecologica Sinica, 2009, 29: 85-91.
[34]	Ran Dachuan.Water and sediment variation and ecological protection measures in the middle reach of the Yellow River. Resources Science, 2006, 28(1): 93-100.
	[冉大川. 黄河中游水土保持措施的减水减沙作用研究. 资源科学, 2006, 28(1): 93-100.]
[35]	Zhang Yuanxing, Gao Jianen, Shao Hui.The terraced fields environmental impact assessment in data-scarce areas based on the embedded terraced module SWAT model. Nature Environment and Pollution Technology, 2014, 13(2): 283-288.
[36]	Wu Faqi, Zhang Yubin, Wang Jian.Study on the benefits of level terrace on soil and water conservation. Science of Soil and Water Conservation, 2004, 2(1): 34-37.
	[吴发启, 张玉斌, 王健. 黄土高原水平梯田的蓄水保土效益分析. 中国水土保持科学, 2004, 2(1): 34-37.]
[37]	Liu Shiliang, Wang Cong, Zhang Xilai, et al.Soil and water conservation effect of different terrace configurations in land consolidation project. Journal of Soil and Water Conservation, 2011, 25(4): 59-68.
	[刘世梁, 王聪, 张希来, 等. 土地整理中不同梯田空间配置的水土保持效应. 水土保持学报, 2011, 25(4): 59-68.]
[38]	Xie Hongxia.Study on the spatio-temporal change of soil loss and on the assessment of impacts on environment of soil and water conservation in Yanhe basin [D]. Xi'an: Shaanxi Normal University, 2008.
	[谢红霞. 延河流域土壤侵蚀时空变化及水土保持环境效应评价研究[D]. 西安: 陕西师范大学, 2008.]
[39]	Li Lan, Zhou Zhonghao, Liu Gangcai.The present situation and some thoughts of soil loss tolerance study. Advances in Earth Science, 2005, 20(10): 1127-1134.
	[李兰, 周忠浩, 刘刚才. 容许土壤流失量的研究现状及其设想. 地球科学进展, 2005, 20(10): 1127-1134.]
[40]	Zhang Shijie, Jiao Juying.Soil loss tolerance in the Loess Plateau based on the healthy function of the lower reaches of the Yellow River. Science of Soil and Water Conservation, 2011, 9(1): 9-15.
	[张世杰, 焦菊英. 基于下游河流健康的黄土高原土壤容许流失量. 中国水土保持科学, 2011, 9(1): 9-15.]
[41]	Li Zhen, Zhang Yan, Zhu Qingke, et al.Assessment of bank gully development and vegetation coverage on the Chinese Loess Plateau. Geomorphology, 2015, 228(1): 462-469.

植被覆盖度(%)	0~20	20~40	40~60	60~80	80~100
林地	0.25	0.12	0.06	0.02	0.004
草地	0.45	0.24	0.15	0.09	0.043

分区	现状土壤侵蚀模数(t·km^-2·a^-1)	最小可能土壤侵蚀模数(t·km^-2·a^-1)	降幅(%)
河谷平原区	1377	978	28.98
风沙区	465	311	33.12
黄土土石丘陵林区	3436	1863	45.78
黄土丘陵沟壑区	4997	2477	50.43
黄土高塬沟壑区	5417	2611	51.80
土石山区	3824	2650	30.70
全区	3355	1921	42.74

分区	现状条件下(%)			水土保持措施容量条件下(%)
分区	微度侵蚀区		轻度及以上侵蚀区	微度侵蚀区	轻度及以上侵蚀区
河谷平原区	72.89	27.11		75.90	24.10
风沙区	87.27	12.73		90.38	9.62
土石丘陵林区	45.16	54.84		52.77	47.23
丘陵沟壑区	31.66	68.34		43.57	56.43
高塬沟壑区	37.38	62.62		46.58	53.42
土石山区	40.81	59.19		46.94	53.06
全区	50.48	49.52		57.71	42.29

河流	现状土壤侵蚀模数(t·km^-2·a^-1)	最小可能土壤侵蚀模数(t·km^-2·a^-1)	土壤侵蚀控制度
祖厉河	5050	3134	0.62
清水河	2718	1849	0.68
大黑河	1802	1536	0.85
偏关河	5358	3496	0.65
岚漪河	5132	3209	0.63
蔚汾河	5452	2834	0.52
皇甫川	2287	1710	0.75
孤山川	3175	1916	0.60
窟野河	1911	1300	0.68
秃尾河	2192	1079	0.49
佳芦河	4356	1767	0.41
无定河	2597	1011	0.39
清涧河	8230	3128	0.38
延河	9531	3871	0.41
北洛河	5292	2877	0.54
泾河	6345	3189	0.50
渭河	4603	2161	0.47
汾河	3486	1808	0.52

土地利用类型	现状条件下			水土保持措施容量条件下
土地利用类型	面积(万hm²)		比例(%)	面积(万hm²)	比例(%)
水田	58.75	0.91		58.74	0.91
水浇地	288.72	4.47		288.72	4.47
坝地	28.63	0.44		28.63	0.44
梯田	281.85	4.36		1229.31	19.03
坡耕地	1443.91	22.35		0.00	0.00
林地	968.28	14.99		1248.72	19.33
草地	2697.69	41.75		3219.16	49.82
其它	693.63	10.73		388.18	6.01
