中国区域创新的时空动态分析

doi:10.11821/dlxb201412004

Abstract

Abstract:

Through an integration of exploratory spatial data analysis (ESDA) and confirmatory spatial data analysis (CSDA), this study examines the space-time dynamics of regional innovation at the provincial scale in China from 2000 to 2011. The results show that: firstly, since the implementation of national innovation strategy, the annual growth ratio of innovation outputs of the provinces in China has experienced a drastic process of acceleration, which suggests the overall improvement of regional innovation capabilities. However, an overwhelming status in growth rate still belongs to eastern region, leading to the rise of the coastal-interior division and the divergence among regions, and regional innovation in China may fall into the “Matthew Effect” that the strong will become stronger and the weak will be constantly weaker. Secondly, regional innovation outputs and inputs in China experience an increasing change of spatial clustering over time. Various types of hot spots are identified over time, revealing that innovation hot spots overlay well with other variables. Finally, the selected explanatory variables, such as GDP, RDE, RDP and PCH, have significant direct impacts on provincial innovation in China. There exist obvious spatial spillover effects in provincial innovation activities, and the geographic region of which has crossed the provincial border. The spatial dependence of innovation activities gives rise to the feedback among the provinces, and the acknowledge spillover of adjacent province have material influence on a specific province.

Key words: regional innovation, exploratory spatial data analysis, confirmatory spatial data analysis, hot spot, spatial panel Dubin mode, acknowledge spillover, China

Yeqing CHENG, Zheye WANG, Jing MA. Analyzing the space-time dynamics of innovation in China[J].Acta Geographica Sinica, 2014, 69(12): 1779-1789.

Figures/Tables 11

Tab. 1

Tab. 2

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Tab. 3

Tab. 4

References 54

[1]	Lin G C S, Wang C. Technological innovation in China's high-tech sector: Insights from a 2008 survey of the integrated circuit design industry in Shanghai. Eurasian Geography and Economics, 2009, 50(4): 402-424.
[2]	Romer P M.Endogenous technological change. The Journal of Political Economy, 1990, 98(5): 71-102.
[3]	Bottazzi L, Peri G.Innovation and spillovers in regions: Evidence from European patent data. European Economic Review, 2003, 47(4): 687-710.
[4]	Pavitt K.The globalizing learning economy. Academy of Management Review, 2002, 27(1): 125-127.
[5]	Feldman M P.The Geography of Innovation. Boston: Kluwer Academic Publishers. 1994.
[6]	Moreno R, Paci R, Usai S.Spatial spillovers and innovation activity in European regions. Environment and Planning A, 2005, 37(10): 1793-1812.
[7]	LeSage J P, Fischer M M, Scherngell T. Knowledge spillovers across Europe: Evidence from a Poisson spatial interaction model with spatial effects. Papers in Regional Science, 2007, 86(3): 393-421.
[8]	Fischer M M, Scherngell T, Reismann M.Knowledge spillovers and total factor productivity: Evidence using a spatial panel data model. Geographical Analysis, 2009, 41(2): 204-220.
[9]	Asheim B T, Gertler M S.The geography of innovation: regional innovation systems//Fagerberg J et al. The Oxford Handbook of Innovation. New York: Oxford University Press, 2006.
[10]	Krugman P.Geography and Trade. Cambridge, MA: The MIT Press, 1991.
[11]	Jaffe A, Trajtenberg M, Henderson R.Geographic localization of knowledge spillovers as evidenced by patent citations. Quarterly Journal of Economics, 1993, 108(3): 577-598.
[12]	Autant-Bernard C.Spatial econometrics of innovation: Recent contributions and research perspectives. Spatial Economic Analysis, 2012, 7(4): 403-419.
[13]	Griliches Z.Issues in assessing the contribution of R&D to productivity growth. Bell Journal of Economics, 1979, 10(1): 92-116.
[14]	Jaffe A B.Technological opportunity and spillovers of R&D: Evidence from firm's patents, profits and market value. American Economic Review, 1986, 76(5): 984-1001.
[15]	Anselin L, Varga A, Acs Z J.Geographical spillovers and university research: A spatial econometric perspective. Growth and Change, 2000, 31(4): 501-515.
[16]	Fischer M M, Slavtchev V.Universities and innovation in space. Industry and Innovation, 2007, 14(2): 201-218.
[17]	Gu Baoguo, Qiao Yanqing, Gu Weiyu.Research on the regional difference of spillover effect from technology transfer by MNCs. China Soft Science Magazine, 2005, 20(10): 100-105.
	[顾保国, 乔延清, 顾炜宇. 跨国公司技术转移溢出效应区域差异分析. 中国软科学, 2005, 20(10): 100-105.]
[18]	Liu Hedong.Empirical research on spillover effects of regional innovation: Analysis based on dynamic panel model of beyond knowledge production function. Studies in Science of Science, 2011, 19(7): 1087-1093.
	[刘和东. 区域创新溢出效应的实证研究: 基于超越知识生产函数的动态面板模型分析. 科学学研究, 2011, 19(7): 1087-1093.]
[19]	Wu Yuming, He Jiankun.Spatial econometric analysis of R&D spillovers and regional innovation cluster. Journal of Management Sciences in China, 2008, 11(4): 59-66.
	[吴玉鸣, 何建坤. 研发溢出、区域创新集群的空间计量经济分析. 管理科学学报, 2008, 11(4): 59-66.]
[20]	Zhang Yuming, Nie Yanhua, Li Kai.An empirical analysis on the impact of knowledge spillovers on regional innovative output: A case of high technology industry. Soft Science, 2009, 23(7): 99-102.
	[张玉明, 聂艳华, 李凯. 知识溢出对区域创新产出影响的实证分析: 以高技术产业为例. 软科学, 2009, 23(7): 99-102.]
[21]	Liu Manfeng, Tang Houxing.Empirical study on effect of knowledge spillovers based on spatial Durbin model. Science & Technology Progress and Policy, 2010, 27(18): 28-33.
	[刘满凤, 唐厚兴. 基于空间Durbin模型的区域知识溢出效应实证研究. 科技进步与对策, 2010, 27(18): 28-33.]
[22]	Bai Shaojun, Zhao Liyu.Innovation production and spillover effects in R&D activities based on a spatial panel model. Science & Technology Progress and Policy, 2010, 27(21): 1-4.
	[白少君, 赵立雨. 基于空间面板数据模型的R&D活动中知识生产与溢出效应研究. 科技进步与对策, 2010, 27( 21): 1-4.]
[23]	Martin S.Spillovers, appropriability, and R&D. Journal of Economics, 2002, 75(1): 1-32.
[24]	Cheng Yeqing, Deng Jixiang.Spatio-temporal pattern changes and its driving factors of urban-rural integrated development level in the major grain-producing areas of central Jilin Province. Acta Geographica Sinica, 2010, 65(12): 1591-1601.
	[程叶青, 邓吉祥. 吉林中部粮食主产区城乡综合发展水平格局特征. 地理学报, 2010, 65(12): 1591-1601.]
[25]	Cheng Yeqing, Wang Yanfei, Wang Zheye et al. Changing rural development inequality in Jilin Province, Northeast China. Chinese Geographical Science, 2013, 23(5): 620-633.
[26]	Li Guoping, Wang Chunyang.Spatial characteristics and dynamic changes of provincial innovation output in China: An investigation using the ESDA. Geographical Research, 2012, 31(1): 95-106.
	[李国平, 王春杨. 我国省域创新产出的空间特征和时空演化: 基于探索性空间数据分析的实证. 地理研究, 2012, 31(1): 95-106.]
[27]	Lim U.The spatial distribution of innovative activity in US metropolitan areas: Evidence from patent data. Journal of Regional Analysis and Policy, 2003, 33(2): 97-126.
[28]	Jaffe A B.Real effects of academic research. The American Economic Review, 1989, 79(5): 957-970.
[29]	Anselin L, Varga A, Acs Z J.Local geographic spillovers between university research and high technology innovations. Journal of urban economics, 1997, 42(3): 422-448.
[30]	Bode. The spatial pattern of localized R&D spillovers: An empirical investigation for Germany. Journal of Economic Geography, 2004, 4(1): 43-64.
[31]	Griliches Z.Patent statistics as economic indicators: A survey. Journal of Economic Literature, 1990, 28(4): 1661-1707.
[32]	Archibugi D.In search of a useful measure of technological innovation (To make economists happy without discontenting technologists). Technological Forecasting and Social Change, 1988, 35(3): 253-277.
[33]	Basberg B L.Technological change in the Norwegian whaling industry: A case-study in the use of patent-statistics as a technology indicator. Research Policy, 1982, 11(3): 163-171.
[34]	Polanyi M. Knowing and being.Mind, 1961, LXX(280): 458-470.
[35]	Cohen W M, Klepper S.The tradeoff between firm size and diversity in the pursuit of technological progress, Small Business Economics, 1992, 4(1): 1-14.
[36]	Furman J L, Porter M E, Stern S.The determinants of national innovative capacity. Research Policy, 2002, 31(6): 899-933.
[37]	Liu Shunzhong, Guan Jiancheng.The evaluation on the innovating performance of regional innovation systems. Studies in Science of Science, 2002, 20(1): 75-78.
	[刘顺忠, 官建成.区域创新系统创新绩效的评价. 科学学研究, 2002, 20(1): 75-78.]
[38]	Fang Yuanping, Xie Man.The effect of innovation elements agglomeration on regional innovation output: Based on Chinese provinces and cities' ESDA-GWR Analysis. Economic Geography, 2012, 32(9): 8-14.
	[方远平, 谢蔓. 创新要素的空间分布及其对区域创新产出的影响: 基于中国省域的ESDA-GWR分析. 经济地理, 2012, 32(9): 8-14.]
[39]	China State Statistics Bureau. China Statistical Yearbook (2000-2012). Beijing: China Statistics Press, 2000-2012.
	[国家统计局. 中国统计年鉴 (2000-2012). 北京: 中国统计出版社, 2000-2012.]
[40]	Statistics Bureau of China, Ministry of Science and Technology of China. China Statistical Yearbook on Science and Technology, 2000-2012. Beijing: China Statistics Press, 2000-2012.
	[国家统计局, 中华人民共和国科学与技术部. 中国科技统计年鉴 (2000-2012). 北京: 中国统计出版社, 2000-2012.]
[41]	Anselin L.Exploring spatial data with GeoDa: A workbook. Center for Spatially Integrated Social Science, 2005.
[42]	Anselin L.GIS research infrastructure for spatial analysis of real estate markets. Journal of Housing Research, 1998, 9(1): 113-133.
[43]	Anselin L.Local indicators of spatial association: LISA. Geographical analysis, 1995, 27(2): 93-115.
[44]	Ord J K, Getis A.Testing for local spatial autocorrelation in the presence of global autocorrelation. Journal of Regional Science, 2001, 41(3): 411-432.
[45]	Ye X Y, Wu L.Analyzing the dynamics of homicide patterns in Chicago: ESDA and spatial panel approaches. Applied Geography, 2011, 31(2): 800-807.
[46]	Anselin L, Le Gallo J, Jayet H.Spatial panel econometrics//Matyas L, Sevestre P. The Econometrics of Panel Data: Fundamentals and Recent Developments in Theory and Practice. Berlin, German: Springer-Verlag, 2008.
[47]	LeSage J P, Pace R K. Introduction to Spatial Econometrics. New York: Taylor & Francis-CRC Press. 2009.
[48]	Lee L F, Yu J.Some recent developments in spatial panel data models. Regional Science and Urban Economics, 2010, 40(5): 255-271.
[49]	LeSage J P, Pace R K. Spatial econometric modeling of origin-destination flows. Journal of Regional Science, 2008, 48(5): 941-967.
[50]	Sun Y F.China's national innovation system in transition. Eurasian Geography and Economics. 2002, 43(6): 476-492.
[51]	Rey S, Ye X Y.Comparative spatial dynamics of regional systems//Páez J et al. Progress in Spatial Analysis: Theory, Computation, and Thematic Applications. Berlin: Springer, 2010.
[52]	Ye X Y, Rey S.A framework for exploratory space-time analysis of economic data. The Annals of Regional Science, 2013, 50(1): 315-339.
[53]	Elhorst J P..
[54]	Elhorst J P.Spatial panel data models//Fischer M M, Getis A. Handbook of Applied Spatial Analysis. Berlin: Springer, 2010: 377-407.

省/区域	代码	专利申请数 (项)			年均增长率 (%)
省/区域	代码	2000	2006	2011	2000-2006	2006-2011
沿海 (东部) 地区		91613	349258	1124594	24.99	33.96
辽宁	LN	7151	17052	37102	15.58	21.45
河北	HeB	3848	7220	17595	11.06	24.94
北京	BJ	10344	26555	77955	17.02	30.90
天津	TJ	2789	13299	38489	29.74	30.43
山东	SD	10019	38284	109599	25.04	30.08
江苏	JS	8211	53267	348381	36.57	59.92
上海	SH	11337	36042	80215	21.26	22.14
浙江	ZJ	10316	52980	177066	31.35	35.21
福建	FJ	4211	10351	32325	16.17	32.93
广东	GD	21123	90886	196272	27.53	21.22
海南	HaN	502	538	1489	1.16	28.98
广西	GX	1762	2784	8106	7.92	30.63
中部地区		23080	60096	212569	17.29	37.14
黑龙江	HLJ	3106	6535	23432	13.20	37.61
吉林	JL	2501	4578	8196	10.60	15.67
内蒙古	NMG	1138	1946	3841	9.35	18.53
山西	SX	1475	2824	12769	11.43	45.82
河南	HeN	3823	11538	34076	20.21	31.09
湖北	HuB	3486	14576	42510	26.93	30.68
安徽	AH	1877	4679	48556	16.44	79.48
湖南	HuN	4117	10249	29516	16.42	30.27
江西	JX	1557	3171	9673	12.59	32.16
西部地区		13481	35857	141598	17.71	40.97
重庆	CQ	1780	6471	32039	24.00	49.17
四川	SC	4496	13109	49734	19.52	39.56
贵州	GZ	986	2674	8351	18.09	32.94
云南	YN	1710	3085	7150	10.33	23.39
西藏	XZ	28	89	263	21.26	31.11
陕西	SSX	2080	5717	32227	18.35	54.09
甘肃	GS	798	1460	5287	10.59	37.95
青海	QH	174	325	732	10.97	22.51
宁夏	NX	341	671	1079	11.94	12.61
新疆	XJ	1088	1187	4736	12.92	20.37

变量	1999 (2000)	2005 (2006)	2010 (2011)
PAT	0.1112**	0.2077**	0.3247***
PCH	0.2591**	0.1392**	0.1570**
GDP	0.3062***	0.4011***	0.5099***
RDP	0.0824*	0.1386**	0.2028**
RDE	-0.0381	0.0647	0.1067**

变量	弹性系数	t-统计量	概率
RDP	0.197554***	2.968552	0.002992
RDE	0.073244	1.061109	0.288640
PCH	0.186669***	3.029316	0.002451
GDP	1.390521***	8.467188	0.000001
W*RDP	0.109720	0.718619	0.472376
W*RDE	0.498953***	3.723155	0.000197
W*PCH	0.137290	0.982938	0.325638
W*GDP	-0.570832**	-2.228075	0.025876
W*PAT	0.193968***	2.911511	0.003597

变量	直接效应	t-统计量	间接效应	t-统计量
RDP	0.2047***	3.0237	0.1766	1.0078
RDE	0.0964*	1.4214	0.6146***	3.7809
PCH	0.1972***	3.0709	0.2115	1.2431
GDP	1.3711***	8.4905	-0.3523	-1.3039
